MNJ48020T900 MHz Color Baby Monitor

Table of Contents Important Safety Messages & Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 FCC Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 Camera Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 Monitor Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Child Monitor Operation and Channel Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Reception . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Camera Location and Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6 Wall Mount Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Table Top Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Monitor Location and Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Installing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Monitor Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 System Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Television Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Problems and Solutions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Important Safety Messages TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOTEXPOSE THIS PRODUCT TO WATER OR MOISTURE. NEVERATTEMPT TO OPEN THE CASE OF EITHER THE CAMERA OR MONITOR. THIS IS DANGEROUS AND WILL VOID THE WARRANTY.NO SERVICEABLE PARTS INSIDE. REFER SERVICING TO SAFETY1ST CONSUMER RELATIONS (800) 723-3065.IN CANADA CALL (800) 721-3389. WARNING 3. ALWAYS KEEP THE CAMERA, TV/MONITOR AND AC ADAPTERS OUT OF REACH OF CHILDREN. 4. This product is not intended to be used as a medical monitor and its use should not replace adult supervision. It is important that an adult stay within the viewing range of the 900 MHz Hand-Held Monitor and Television at all times during use. 5. It is essential to check reception regularly. Please see the Reception section for complete instructions.6. The Camera and Monitor are intended for indoor use only.7. NEVER use the Camera or Monitor near water. For example, do not use near a bathtub, bathroom sink, laundry tub, kitchen sink, in a wet basement, etc. 8. Always unplug the AC adapters from wall outlets during long periods of non-use.9. Position the Camera, Monitor and AC adapters to allow adequate ventilation and prevent these components from overheating. 10. To prevent overheating, keep the Camera, Monitor and AC adapters away from heat sources such as radiators, heat registers, stoves or other appliances (including amplifiers) which produce heat. Also keep these components out ofdirect sunlight. 11. Use only the AC adapters provided. Use of any other adapters may damage the Camera and/or Monitor. Plug the AC adapters into standard household current only (120V AC outlet)! To prevent entanglement and overheating,DO NOT use extension cords. 12. The AC adapters may become slightly warm to the touch during operation. This is normal.13. Position the AC adapter cords so that they are not walked on or pinched by items placed upon or against them, paying particular attention to cords at AC adapter plugs, wall plugs, and the point at which the cords attach to the Cameraand Monitor. 14. This product should be serviced only by qualified service personnel at Safety 1st when: • An AC adapter or its plug is damaged,• The Camera or Monitor have fallen,• Liquid has spilled into the Camera or Monitor, or• The Camera or Monitor do not appear to operate normally or exhibit a marked change in performance 15. DO NOT attempt to service this product beyond that described in the Problems and Solutions Guide at the end of these instructions. All other servicing should be referred to qualified personnel at Safety 1st. 16. Retain these instructions for future reference.NOTE: The LED's on the Camera emit IR (Infra Red) light that is not harmful. FCC NoteNOTE: This equipment has been tested and found to…

Text truncated - open the document above for the full version.

Wireless Video Monitor Transmitter AGC Amplifier Image Sensor Light Sensor and control IR Light Source Video Audio Microphone RF Transmitter Power Supply and Regulators Room Light IR Light Image Projected on the Sensor 9 volts (unregulated) 5v Channel A/B/C Switch 4MHz 14.31818MHz Wireless Video Receiver VHF/UHF 900MHz TV Tuner NTSC Video/Audio demodulator TV Antenna Video Processing and LCD Driver 2” Color LCD Display Video Audio IF Microcontroller Chan. A/B/C Switch TV/CAM/AUD Switch Power Supply and Regulators 12 volts DC Phase Lock Loop Channel Up/Down Switches Microcontroller For OSD and LCD control 4 MHz 14.31818 MHz 3.579545 MHz Brightness Switch Channel Carrier Frequencies –Channel A 909.0 MHz –Channel B915.5 MHz –Channel C 922.0 MHz

Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Exterior Product Photograph

FCC ID: MNJ48020T  2000 Safety 1 st Inc. Made i n CHINA THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIREDOPERATION. CANADA:XXXXXXXXXXX+ all FCC label information in French.

Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Interior Circuit Board Photographs (Top & Bottom) Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Interior Circuit Board #2 Photograph

Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Interior Circuit Board Photographs (Top & Bottom) Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Interior Circuit Board #2 Photograph

1 Memorandum Date: 05/01/00 Re: Model 48020 Circuit Description The 900 MHz “Hand-Held Monitor and Television" model 48020 will be referred to as the equipment under test (EUT) in this report. The EUT is a nursery monitoring system designed to be a high quality audio, color video monitor for home use. This monitor will transmit audible sounds and color video to the Parent Unit. The frequency band chosen for this product is the 902-928 MHz band. This product is part of an ongoing family of nursery monitors provided by Safety 1 st . The Child unit operates on one of three RF channels. An external switch controls the channel selection. Device Operation When in transmit mode the microphone picks up the room sounds and amplifies the signal through an audio amplifier the color ccd camera picks up video in color under normal light conditions and in night mode uses infra red to see images. The audio signal is controlled by an automatic gain control (AGC) circuit to limit the FM modulation. The amplified audio signal is coupled directly into the audio input of the Motorola MC44355 chipset. The video signal is picked up by an image sensor. A light sensor and control determines whether there is enough light in the room and activates the LED's for night mode if necessary. The image sensor then couples the information into the Video input of the Motorola MC44355 chipset. The video and audio is then combined in the Motorola MC44355 chipset and transmitted (RF Out) through an impedance matching network, attenuator, and tank circuits to the antenna. An AC/DC wall adapter powers the unit.

Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 FEDERAL COMMUNICATIONS COMMISSION PART 15.249 CERTIFICATION TESTING 902 - 928 MHz Subpart C - Intentional Radiators for Safety 1ST, Inc. 45 Dan Road Canton, MA 02021 (800) 962 7233 of 900 MHz In Sight Hand-Held TV-Video Monitor 48020T FCCID#: MNJ48020T on April 18, 2000 by Larry K. Stillings _____________________________________ Larry K. Stillings Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T TABLE OF CONTENTS • Test Description • Test Results and Conclusions • Test Procedures • Part 15 Subpart C Test Limits • Measurement Uncertainty Budget and Calculations • Test Facility Description • Test Setup and Connection Information • Test Measurements and Results Radiated Measurements Radiated Output Power & Occupied Bandwidth Conducted Measurements • Notes and Comments Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T TEST DESCRIPTION 1. TEST OBJECTIVE To test the 900 MHz In Sight Hand-Held TV-Video Monitor 48020T to FCC Part 15.249, Subpart C limits and write a report. 2. E.U.T. DESCRIPTION GENERAL The 900 MHz In Sight Hand-Held TV-Video Monitor 48020T is a 3 channel color transmitter operating in the 902 to 928 MHz band. The 3 channels transmit at 908.9, 915.4 and 921.9 MHz. SERIAL NUMBERS: Pre production unit Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T TEST RESULTS AND CONCLUSIONS PRODUCT TESTED - 900 MHz In Sight Hand-Held TV-Video Monitor MODEL NUMBER - 48020T RADIATED TEST RESULTS The test results show that the emissions radiated from this equipment are in compliance with FCC Rules, Part 15, Subpart C, Section 15.209. OCCUPIED BANDWIDTH & OUTPUT POWER The test results show that the occupied bandwidth and output power of this equipment are in compliance with FCC Rules, Part 15, Subpart C, Section 15.239. CONDUCTED TEST RESULTS The test results show that the emissions conducted through the power line from this equipment are in compliance with FCC Rules, Part 15, Subpart C, Section 15.207. ANALYSIS AND CONCLUSIONS Based upon the radiated and conducted measurements we find that this equipment is within the limits of the FCC Rules, Part 15, Subpart C. NOTES (Special conditions unique to this test) None Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T TEST PROCEDURES 1. TEST EQUIPMENT A. HP 8546A (9 kHz - 6.5 GHz) EMI Receiver w/ RF Filter Section, S/N 3704A00323 / 3650A00360. Calibration Date 3-28-2000, calibrated annually. B. HP 8593E (9 kHz - 26.5 GHz) Spectrum Analyzer, S/N 3829A03887. Calibration Date 9-3-1999, calibrated annually. C. Electro-Metrics BiConical Antenna, Model EM6912A, S/N 149. Calibration Date 2-22-2000, calibrated annually. D. Electro-Metrics Log Periodic Antenna, Model EM-6950, S/N 1017. Calibration Date: 2-22-2000, calibrated annually. E. Electro-Metrics Double Ridged Guide Antenna, Model EM-6961, S/N 6337. Calibration Date: 7-14-1999, calibrated annually. F. HP 1 - 26.5 GHz Preamplifier, Model 08449B, S/N 3008A01323. Calibration Date: 9-29-1999, calibrated annually. G. LISN, Compliance Worldwide, Model 50 μ H / 50 ohm, S/N 100. Calibration Date 2-22-2000, calibrated annually. 2. FREQUENCY RANGE TO BE SCANNED. A. Radiated Test from 30 MHz to 40 GHz (or the 10 th harmonic of the highest frequency whichever is lower). B. Conducted Test from 450 kHz to 30 MHz. Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T 3. TEST PROCEDURES. Radiated test procedure The EUT, associated cables and peripheral devices are placed on the supporting table and any support equipment is placed off the site. The EUT is turned on and any necessary operating or test software installed and allowed to warm up. The frequency band from 30 MHz to 40 GHz is scanned. When an emission is found the emission is maximized by varying the bundle position of the connecting cables, the antenna height, the antenna polarization (vertical and horizontal) and the table orientation (360 degrees). The maximum reading is recorded and the next signal is searched for. Conducted test procedure The power line of the EUT is connected to the LISN (Line Impedance Stabilization Network). A measurement of the emissions are made from the power line for both phase and neutral on the analyzer in the frequency range from 450 kHz to 30 MHz. The maximum readings are recorded for each phase. All measurements are made according to the procedures defined in: "ANSI C63.4-1992 Standard Methods of Measurement of Radio Noise Emissions from Low-Voltage Electrical and Electronics Equipment in the Range of 9 kHz to 40 GHz, American National Standard for (ISBN 1-55937- 215-5). Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PART 15 SUBPART C TEST LIMITS 1. 15.209, 15.235 & 15.249 Radiation Limits (Quasi-Peak): Frequency MHz Distance meters Limit dB μ V/m Limit μ V/m 1.705 - 30 30 29.5* 30* 30 - 88 3 40.0 100 49.82 - 49.90 3 80.0* 10,000* 88 - 216 3 43.5 150 216 - 960 3 46.0 200 902 - 928 3 94.0* 50,000* 960 - 1000 3 54.0 500 1000 - 40000 3 54.0* 500* *NOTE: Aver…

Text truncated - open the document above for the full version.

Temp________ °C Humidity________ % Compliance Worldwide, Inc. - 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www. cw-inc. co m TEST NUMBER – 206-00 Safety 1ST, Inc. 48020T - 48020 FCC Part 15 Subpart C Transmit Fundamental Results @ 3 Meters ChannelFrequencyPolarizationHeightTableAmplitudeLimitMargin MHzH/VcmdegreesdBμVdBμVdB 1908.9V158992.4941.6 2915.4V158992.7941.3 3921.9V158992.9941.1

Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Radiated Test Setup (Front & Rear) Compliance Worldwide, Inc. – 357 Main Street - Sandown, NH 03873 (603) 887 3903 Fax 887 6445 http://www.cw-inc.com TEST NUMBER - 206-00 Safety 1ST, Inc. 900 MHz In Sight Hand-Held TV-Video Monitor - 48020T PHOTOGRAPHS Conducted Test Setup (Front & Rear)
