MNJ94054TLow power UHF transmitter

PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE BABY LOONEY TUNES NURSERY MONITOR & CRIB LIGHT KEEP THESE INSTRUCTIONS FOR YOUR FUTURE REFERENCE IF YOU HAVE ANY QUESTIONS, CALL OUR TOLL FREE CONSUMER RELATIONS NUMBER: (800) 723-3065 CAUTION: THE NURSERY MONITOR IS NOT INTENDED TO REPLACE PROPER ADULT SUPERVISION. YOU SHOULD CHECK YOUR CHILD’S ACTIVITY AT REGULAR INTERVALS AS THIS MONITOR WILL NOT ALERT PARENTS TO THE SILENT ACTIVITIES OF A CHILD. Baby Looney Tu n e s N u r s e ry Monitor & Crib Light O w n e r’s Guide Thank you for purchasing the Safety 1 s t Baby Looney Tunes Nursery Monitor & Crib Light. This is a state-of-the-art system that combines some of the most unique feature s that any baby monitor offers. We are confident that you will appreciate its many highlights. As you will soon learn there are many more feature s . . . The Baby’s Unit (Transmitter) has continuous transmission that clearly sends your b a b y ’s sounds to the Pare n t ’s Unit. This gives you the ability to continue with your daily activities throughout the house or yard and at the same time monitor your baby. The Pare n t ’s Unit (Receiver) remains with you wherever you go to pick up the sounds that are transmitted from the Baby’s Unit. It conveniently clips to your belt or easily stands on a table. Both units are completely portable or AC powered. The AC Adapter allows the receiver and transmitter to be plugged into any standard electrical outlet for use with your household electricity. For convenient use without an outlet, use a 9 volt battery for the Pare n t ’s unit and 4 “D” cell alkaline batteries for the Baby’s unit (Batteries not i n c l u d e d ) . We are sure that you will find the Safety 1st Baby Looney Tunes Nursery Monitor & Crib Light convenient and easy to use. To insure that you will benefit from all of the g reat features that our monitor offers, and to make sure that it is used pro p e r l y, we u rge you to: 1 C o n t e n t sB a t t e ry Require m e n t s Safety Instru c t i o n s P a re n t ’s Unit (Receiver) B a b y ’s Unit (Tr a n s m i t t e r ) Crib Clamp Assembly (2) A/C Adapters (4) "D" size alkaline batteries (1) 9-volt battery (Batteries Not Included) C A U T I O N RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER OR BACK. NO SERVICEABLE PA RTS INSIDE. REFER SERVICING TO SAFETY 1 S T CONSUMER RELATIONS DEPA RTMENT (800)-723-3065 DO NOT EXPOSE THIS PRODUCT TO WATER OR MOISTURE. l a u n d ry tub in a wet basement, or near a swimming pool, etc. nV E N T I L AT I O N :The Nursery Monitor should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings, or placed in an enclosed installation, such as a book case or cabinet that may impede the flow of air through the ventilation o p e n i n g s . nH E AT: The Nursery Monitor should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances that produce heat. nPOWER SOURCE:The Nursery Monitor should be connected to a power supply only of the type described in these operating i n s t ru c t i o n s . nPOWER CORD PROTECTION:The power supply cord should be routed so that it is not likely to be walked on or pinched by items placed upon or against it. Pay particular attention to the cord at the plug, convenience receptacle, and at the point it exits from the N u r s e ry Monitor. nC L E A N I N G :Use a dry cotton cloth to keep the Nursery Monitor free of dust. Do Not Use Wa t e r. nNON-USE PERIODS: The power cord of the Nursery Monitor should be unplugged from the outlet when unused for a long period of time. Batteries should be removed from both units. nOBJECT AND LIQUID ENTRY: Care should be taken so that objects do not fall onto, and liquids are not spilled into the enclosure t h rough the openings. nDAMAGE REQUIRING SERV I C E :The Nursery Monitor should be serviced by qualified service personnel when: A. The Power supply cord has been damaged; or B. Objects have fallen or liquid has been spilled into the product; or C. The Monitor has been exposed to rain; or D. The Monitor does not appear to operate normally or exhibits a marked change in its perf o rmance; or E. The Monitor has been dropped or the enclosure damaged. THE USER SHOULD NOT ATTEMPT TO SERVICE OR REPAIR THE MONITOR. ALL SERVICING SHOULD BE REFERRED TO SAFETY 1 S T CONSUMER RELATIONS DEPA RT M E N T: (800) 723-3065 WALL MOUNTING: THE PARENT’S UNIT MAY BE MOUNTED ON THE WALL ONLY AS DESCRIBED IN THESE INSTRUCTIONS. WHEN USED WITH ADAPTERS, KEEP ALL PA RTS OF THIS MONITOR OUT OF REACH OF CHILDREN! CAUTION: THIS MONITOR IS NOT INTENDED TO REPLACE PROPER ADULT SUPERVISION. YOU SHOULD CHECK YOUR CHILD’S ACTIVITY AT REGULAR INTERVALS AS THIS MONITOR WILL NOT ALERT PARENTS TO THE SILENT ACTIVITIES OF A CHILD. F e a t u res and Components PARENT'S UNIT (RECEIVER) 1Power/Channel Switch 2Volume Dial 3 AC Adapter Jack 4B a t t e ry Compartment (9-volt) 5Plastic Belt Clip 6S p e a k e r 7 Key Hole Slot for Wall Mounting 8Flexible Antenna 9 Low Battery Indicator (Red) 1 0Power On Indicator (Gre e n ) 1 1B a t t e ry Cover 1 2(9-volt) Battery (not included) 1 3B a t t e ry Contacts F ront view of Pare n t ’s Unit (Receiver)Rear view of Pare n t ’s Unit (Receiver) F e a t u res and Components (continued) BABY'S UNIT (TRANSMITTER) 1Power On Indicator 2 Low Battery Indicator 3Power/Channel Switch 4M i c ro p h o n e 5B a t t e ry Compartment (4 “D” Cell Alkaline) 6 AC Adapter Jack 7 Crib Light Button 8 Voice Activation Sensitivity Switch 9 Crib Clamp Assembly 1 0Four “D” alkaline batteries, positive (+) to top (not included) 1 1B a t t e ry Cover 12 A CAdapter Jack 12 A/C ADAPTER The A/C Adapter is a low voltage power source that allows you to use your household electricity to run the Baby and Pare n t ’s Unit when you want to conserve battery life. It connects to the A/C Adapter Jack in the Pare n t ’s Unit and in the Baby’s Unit (when not in use on cri…

Text truncated - open the document above for the full version.

Fleetwood Group Inc. FCC ID: FBR-5FKRSPBX-2 Confidentiality Request Page 1 of 1 File Name: STDREQA.DOC Date: 07/10/01 November 30, 1998 Federal Communications Commission 7435 Oakland Mills Rd. Columbia, MD 21046 Dear Sir or Madam: On the advice of our patent attorney, we would like to have the following exhibits of our application FCC ID: FBR-5FKRSPBX-2 held confidential pursuant to Section .457(d) of the Rules: Schematics Block diagrams If you have any questions, please call me at 616-820-8237 or fax to 616-820-8300. We look forward to your prompt action on this application. Sincerely, Harry Derks Manager of Electronics Engineering Fleetwood Group Inc. FLEETWOOD

Norcross, GA 30071 A Home Wireless Networks 00-0005-003 Thursday, November 19, 1998 1 4 D 3145 Avalon Ridge Place RF SCHEMATIC {Cage Code} SizeScale CAGE Code DWG NO Rev Sheet of SYN_2.8V SYN_2.8V SYN_2.8V SYN_2.8V REG_4.3V SYN_2.8V SYN_2.8V SYN_2.8V DRIVER_VCC SYN_2.8V SYN_2.8V /TR_SWITCHTR_SWITCH SYNTH_ON SYN_LE SYN_DATASYN_CLK AFC_WARP SYS_CLKTXON_B/TX_IQTX_IQAGC_ENAAGC_SDATAAGC_SCLKRXON_ARX_IDATA/RX_IDATA/RX_QDATARX_QDATARXON_BOCE VPA DRIVER_VCC VATT -1 dBm System 1 WAU Confidential Proprietary SYN_CLK PRE_AFC_PWM RX_IDATA AGC_ENA RX_IDATA/RX_QDATA/RX_QDATA AGC_SCLK AGC_SCLK SYN_LESYN_DATA AGC_ENA TXON_B AGC_SDATA AGC_SDATA RXON_B TR_SWITCH SYNTH_ON RXON_A LO2GND VATT Y1 1 2 R1 10K 1 2 C4 .01uF 1 2 R4 120 1 2 R6 10K 12 C633pF 1 2 L11 8.2nH 1 2 R9 0 1 2 R3 100 1 2 C12 33pF 1 2 R1012K 12 R5 DNS 12 R25 1.8k 1 2 R30 390 1 2 R20 DNS 12 R26 1.8k 1 2 C60 15p 12 L12 39uH 12 R37 680 1 2 L14 12nH 1 2 R24 680 1 2 R32 1.8K 1 2 R31 680 1 2 R23 390 1 2 C64 15p 12 C65120p 12 L17 22nH 1 2 L13 12nH 1 2 R403k 12 C55 15p 12 C66 15p 12 R34 1.8k 1 2 L1847 nH 12 R3922K 1 2 R28 680 1 2 R27 3k 12 R38 390 1 2 C26 33pF 1 2 C33 1000pF 1 2 C31 1pF 1 2 C35 1000pF 1 2 L9 10nH 12 C3233pF 1 2 L16390nH 12 R29 390 1 2 C59 120p 12 L1 1uH 12 R3375 1 2 C4447pF 12 C563.0pF 12 C53 3.0pF 12 L1912nH 12 L216.8nH 1 2 C43 47pF 12 C36150pF 12 C7333pF 1 2 C74 22pF 12 C69 4.7pF 1 2 C70 6.8pF 1 2 C714.7pF 1 2 C47 2.4pF 12 C48 2.4pF 12 C58 5.6pF 1 2 L15390nH 12 C54 2pF 12 C7833pF 1 2 ANT1 ANTENNA 1 1 C34 1000pF 1 2 L23 39nH 12 R431M 1 2 C79.01uF 1 2 R15 2K 1 2 L722nH 12 L10270nH 12 C933pF 12 C1533pF 12 C452.7pF 12 C13 1000pF 12 D1 12 C41 33pF 1 2 C52 0.01uF 12 R7 DNS 1 2 R22 1k 12 C7 DNS 12 C63 0.01uF 12 C62 0.01uF 12 U8 VS2 1 DIV1/3 2 GND1 3 CSH1 4 CSH2 5 GND2 6 OCE 7 IFI 8 IFIX 9 SYGCDT 10 SYGCCL 11 PGCSTR 12 SIX 13 SI 14 RXON1 15 GND3 16 LO1 18 VS1 19 MO 20 IRX 45 INI 44 SOIX 43 SOQ 42 INQX 41 QR 40 QRX 39 INQ 38 SDQX 37 RXON2 36 LO2 35 LO2E 34 LO2EX 33 LO2X 32 PUPLO2 31 GND6 30 IR 46 LO2OX 23 LO2O 24 AI 29 AREF 28 LO1X 17 VS3 27 AO 26 MOX 21 GND4 22 INIX 47 SOI 48 GND5 25 GND IN OUT FL1 1 3 2 C29100pF 12 C37 1000pF 1 2 R41 22K 12 C14 DNS 12 + C3 4.7uF,6.3V 1 2 C462.7pF 12 C20 DNS 12 U1 CNTRL 1 GND1 2 NC 3 Vout 4 GND2 5 Vin 6 C5 15pF 1 2 C49 1000pF 12 U2 CNTRL 1 GND1 2 NC 3 Vout 4 GND2 5 Vin 6 R21 1k 12 R36 560 12 C57 33pF 1 2 R35 560 12 C50 1000pF 12 + C2 4.7uF,6.3V 12 + C1 4.7uF 1 2 C22 1000pF 12 C61 0.01uF 12 C21 100pF 12 C42 33pF 1 2 C76 1200pf 12 R19 1.5K 12 IN OUT VCC GND NC U9 4 2 5 3 1 C77 6800pF 12 C6733pF 12 C38 1000pF 12 C72 1000pF 12 FL2 IN 1 IN-GND 10 GND1 2 OUT-GND 5 OUT 6 GND4 9 GND3 7 GND2 4 C51 33pF 12 GND IN OUT FL4 1 3 2 C10 DNS 12 C27 .01uF 12 C6833pF 12 U4 FoLD 1 OSCin 2 OSCout 3 GND1 4 fin_Aux 5 Vcc1 6 Do_Aux 7 EN_Aux 8 EN_Main 9 Do_Main 10 Vcc2 11 fin_Main 12 GND2 13 LE 14 Data 15 Clock 16 R49 2K 1 2 C25 100pF 1 2 L24 82nH 12 C18 150pF 12 C17 .01uF 12 L25 12nH 12 L6 10nH 1 2 U10 Vd 1 GND1 2 INPUT 3 GND2 4 GND3 5 OUTPUT 6 C16 150pF 1 2 R13 1.5K 12 C23 4pF 12 C19150pF 12 L5 22nH 1 2 U6 RF-OUT 1 GND1 2 LO2 3 GND2 4 XIF 5 IF 6 LO1 7 XLO1 8 GND 9 VCC1 10 VCC2 11 GND3 12 I 13 XI 14 QMOD 15 XQMOD 16 XQ 17 Q 18 GND4 19 PS 20 C39 .1uF 12 C40 .1uF 12 R48 68 1 2 L20 47nH 1 2 C75 27pF 12 U7 RF2 1 GND 2 RF1 3 VC1 4 RFIN 5 VC2 6 U3 CNTRL 1 GND1 2 Vt 3 OUT 4 GND2 5 GND5 8 GND3 6 GND4 7 JMP1 1 2 C858.2pF 1 2 Q1 2 13 Q2 2 13 D3 1 2 C11 .1uF 12 C8 .1uF 12 R14 68 1 2 C28 100pF 1 2 C82 1000pF 1 2 C80 .01uF 1 2 C81DNS 12 U5 GND1 1 GND2 2 J1 3 VS 4 VC 5 GND3 6 J2 7 BYPASS 8 C24 5.6pF 12 GND IN OUT FL3 32 1 4 5 6 7 L27 3.3nH 12 L26 1.8nH 1 2 R50 18 1 2 C83 1pF 12 C84 1pF 12 R2 51 1 2 R8 51 1 2

Low Power UHF Transmitter Radiometrics Midwest Corporation Test Document RP-3903 Issue Date: November 16, 1998 This report concerns: Original grant Equipment type: Low Power Transmitter Transition Rules per 15.37 are not requested. Tests Performed ForTest Facility Safety 1st, Inc. 210 Boylston St. Chestnut Hill, Massachusetts 02167 Radiometrics Midwest Corporation 12 East Devonwood Romeoville, IL 60446 Phone: (815) 293-0772 FAX: (815) 293-0820 [email protected] Test Report Written ByTest Report Approved By Joseph Strzelecki Senior EMC Engineer NARTE EMC-000877-NE Chris W. Carlson Director of Engineering NARTE EMC-000921-NE MEASUREMENT/TECHNICAL REPORT Safety 1st, Inc. Model 94054 FCC ID: MNJ94054T APPLICATION FOR CERTIFICATION RF Emission Measurements Performed For Determination of Compliance with the US Code of Federal Regulations Title 47, Chapter I, FCC Part 15 Subpart B As Required for Certification for Unintentional Radiators Tests Performed ForFCC IDRadiometrics Test DocumentPage Safety 1st, Inc. MNJ94054TRP-39032 of 11 Table of Contents 1.0 General Information ..................................................................................................................3 1.1 Product Description ...............................................................................................................3 1.2 Related Submittals ................................................................................................................3 1.3 Tested System Details...........................................................................................................3 1.4 Test Methodology ..................................................................................................................3 1.5 Test Facility............................................................................................................................3 1.6 Test Equipment .....................................................................................................................4 2.0 System Test Configuration........................................................................................................4 2.1 Test System and Justification ................................................................................................4 2.2 EUT Test Configuration ............................................................................................................4 2.3 Special Accessories...............................................................................................................4 2.4 Equipment Modifications........................................................................................................4 Figure 2.1 Configuration of Tested System .................................................................................5 3.0 Occupied Bandwidth Data ........................................................................................................6 Figure 3.1 Occupied Bandwidth Plot ...........................................................................................7 Figure 3.2 Occupied Bandwidth Plot ...........................................................................................8 4.0 Radiated Emissions Data..........................................................................................................9 4.1 Field Strength Calculation....................................................................................................10 5.0 Conducted Emission Data ......................................................................................................11 Notice: This report must not be reproduced (except in full) without the written approval of Radiometrics Midwest Corporation. Tests Performed ForFCC IDRadiometrics Test DocumentPage Safety 1st, Inc. MNJ94054TRP-39033 of 11 1.0 General Information 1.1 Product Description The Model 94054T (referred to as the EUT in this report) is a Low Power VHF Transmitter. The EUT is manufactured by Safety 1st, Inc. 1.2 Related Submittals Safety 1st, Inc. is not submitting any other submittals related to the EUT. The associated receiver is operated under part 15. It is subject to the FCC requirements pursuant to the Certification equipment authorization under Part 15 Subpart B, and will be submitted as FCC ID: MNJ49230R. 1.3 Tested System Details The FCC ID's for all equipment, plus descriptions of all cables used in the tested system which have grants, are: Model Number Serial NumberFCC ID Manufacturer & Description Cable Descriptions M/N: 94054 (EUT)MNJ94054TSafety 1st, Inc. Low Power VHF Transmitter Power (1.8m, US) from transformer to EUT Note: SH = Shielded; US = Unshielded; m = Cable Length in Meters, 1.4 Test Methodology The test procedures used are in accordance with the ANSI document C63.4-1992, (July 17, 1992) "Methods of Measurement of Radio Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". The specific procedures are described herein. Radiated testing was performed at an antenna to EUT distance of 3 meters. The antenna was raised and lowered from 1 to 4 meters. 1.5 Test Facility The open area test site used to collect the radiated data is located on 8625 Helmar Road in Newark, Illinois. The open field test site has a metal ground screen. Details of the site characteristics are on file with the FCC. Conducted emission measurements and preliminary radiated emission scans were performed in shielded enclosure “A” at Radiometrics' Romeoville, Illinois EMI test lab. These sites have been fully described in a report and accepted by the FCC in a letter dated October 1, 1996 (31040/SIT 1300F2). Conducted emission measurements were performed using a Line Impedance Stabilization Network (LISN) as the pick-up device. This device is constructed in accordance with the circuit diagram provided in Figure 3 of ANSI document C63.4-1992. Tests Performed ForFCC IDRadiometrics Test DocumentPage Safety 1st, Inc.…

Text truncated - open the document above for the full version.

FCC ID: MNJ94054T FCC Label FCC ID Label 2.2” x 1.2” Permanently Engraved on Rear of EUT Location of Label on EUT FCC ID: MNJ94054T © 1998 Safety 1st All Rights Reserved Made in China THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPER- ATIONIS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. CANADA: 210 © 1998 Safety 1st Tous les droits sont réservés. Fabriqué en Chine. CET APPAREIL EST CONFORME À LA PARTIE 15 DU RÈGLEMENT DE LA FCC. LE FONCTIONNEMENT EST SUJET AUX DEUX CON- DITIONS SUIVANTES: (1) CET APPAREIL NE PEUT CAUSER D'INTERFÉRENCES NUISIBLES ET (2) CET APPAREIL REÇOIT TOUTE INTERFÉRENCEMÊME LES INTERFÉRENCES QUI PEU- VENT OCCASIONER UN MAUVAISFONCTIONNEMENT. FCC Label

Internal Photos FCC ID: MNJ94054T Page 1 of4 Internal Assembled Internal Photos FCC ID: MNJ94054T Page 2 of4 PCB Component side Internal Photos FCC ID: MNJ94054T Page 3 of4 PCB Foil side Internal Photos FCC ID: MNJ94054T Page 4 of4 Power Supply Component Power Supply Foil

Low Power UHF Transmitter Radiometrics Midwest Corporation Test Document RP-3903 Issue Date: November 16, 1998 This report concerns: Original grant Equipment type: Low Power Transmitter Transition Rules per 15.37 are not requested. Tests Performed ForTest Facility Safety 1st, Inc. 210 Boylston St. Chestnut Hill, Massachusetts 02167 Radiometrics Midwest Corporation 12 East Devonwood Romeoville, IL 60446 Phone: (815) 293-0772 FAX: (815) 293-0820 [email protected] Test Report Written ByTest Report Approved By Joseph Strzelecki Senior EMC Engineer NARTE EMC-000877-NE Chris W. Carlson Director of Engineering NARTE EMC-000921-NE MEASUREMENT/TECHNICAL REPORT Safety 1st, Inc. Model 94054 FCC ID: MNJ94054T APPLICATION FOR CERTIFICATION RF Emission Measurements Performed For Determination of Compliance with the US Code of Federal Regulations Title 47, Chapter I, FCC Part 15 Subpart B As Required for Certification for Unintentional Radiators Tests Performed ForFCC IDRadiometrics Test DocumentPage Safety 1st, Inc. MNJ94054TRP-39032 of 11 Table of Contents 1.0 General Information ..................................................................................................................3 1.1 Product Description ...............................................................................................................3 1.2 Related Submittals ................................................................................................................3 1.3 Tested System Details...........................................................................................................3 1.4 Test Methodology ..................................................................................................................3 1.5 Test Facility............................................................................................................................3 1.6 Test Equipment .....................................................................................................................4 2.0 System Test Configuration........................................................................................................4 2.1 Test System and Justification ................................................................................................4 2.2 EUT Test Configuration ............................................................................................................4 2.3 Special Accessories...............................................................................................................4 2.4 Equipment Modifications........................................................................................................4 Figure 2.1 Configuration of Tested System .................................................................................5 3.0 Occupied Bandwidth Data ........................................................................................................6 Figure 3.1 Occupied Bandwidth Plot ...........................................................................................7 Figure 3.2 Occupied Bandwidth Plot ...........................................................................................8 4.0 Radiated Emissions Data..........................................................................................................9 4.1 Field Strength Calculation....................................................................................................10 5.0 Conducted Emission Data ......................................................................................................11 Notice: This report must not be reproduced (except in full) without the written approval of Radiometrics Midwest Corporation. Tests Performed ForFCC IDRadiometrics Test DocumentPage Safety 1st, Inc. MNJ94054TRP-39033 of 11 1.0 General Information 1.1 Product Description The Model 94054T (referred to as the EUT in this report) is a Low Power VHF Transmitter. The EUT is manufactured by Safety 1st, Inc. 1.2 Related Submittals Safety 1st, Inc. is not submitting any other submittals related to the EUT. The associated receiver is operated under part 15. It is subject to the FCC requirements pursuant to the Certification equipment authorization under Part 15 Subpart B, and will be submitted as FCC ID: MNJ49230R. 1.3 Tested System Details The FCC ID's for all equipment, plus descriptions of all cables used in the tested system which have grants, are: Model Number Serial NumberFCC ID Manufacturer & Description Cable Descriptions M/N: 94054 (EUT)MNJ94054TSafety 1st, Inc. Low Power VHF Transmitter Power (1.8m, US) from transformer to EUT Note: SH = Shielded; US = Unshielded; m = Cable Length in Meters, 1.4 Test Methodology The test procedures used are in accordance with the ANSI document C63.4-1992, (July 17, 1992) "Methods of Measurement of Radio Noise Emissions from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz". The specific procedures are described herein. Radiated testing was performed at an antenna to EUT distance of 3 meters. The antenna was raised and lowered from 1 to 4 meters. 1.5 Test Facility The open area test site used to collect the radiated data is located on 8625 Helmar Road in Newark, Illinois. The open field test site has a metal ground screen. Details of the site characteristics are on file with the FCC. Conducted emission measurements and preliminary radiated emission scans were performed in shielded enclosure “A” at Radiometrics' Romeoville, Illinois EMI test lab. These sites have been fully described in a report and accepted by the FCC in a letter dated October 1, 1996 (31040/SIT 1300F2). Conducted emission measurements were performed using a Line Impedance Stabilization Network (LISN) as the pick-up device. This device is constructed in accordance with the circuit diagram provided in Figure 3 of ANSI document C63.4-1992. Tests Performed ForFCC IDRadiometrics Test DocumentPage Safety 1st, Inc.…

Text truncated - open the document above for the full version.

SETUP PHOTOS FCC ID: MNJ94054T Page 1 of 2 Emissions Test Setup SETUP PHOTOS FCC ID: MNJ94054T Page 2 of 2 Emission Test Setup

Setup Photos FCC ID: MNJ94054T Page 1 of 1 Conducted Emissions
