MQ4WR5208802.11b/g/n Portable 3G Router (Dual USB Function)

Abocom Systems Inc
802.11b/g/n Portable 3G Router (Dual USB Function) - FCC ID MQ4WR5208 - Abocom Systems Inc
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Oct 11, 2010
Application Purpose
Original Equipment
Date of Application
Oct 11, 2010
Equipment Note
802.11b/g/n Portable 3G Router (Dual USB Function)
Frequency Range
2412.00000000 - 2462.00000000
Company
Abocom Systems Inc
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗
↗
↗
↗

Test Report

↗
↗

Test Setup Photos

↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

802.11b/g/n Compact Wireless Router with USB2.0 Port User’s Manual Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: o Reorient or relocate the receiving antenna. o Increase the separation between the equipment and receiver. o Connect the equipment into an outlet on a circuit different from that to which the receiver is needed. o Consult the dealer or an experienced radio/TV technician for help. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The user’s manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. IEEE 802.11b or 802.11g operation of this product in the U.S.A. is firmware-limited to channels 1 through 11 CAUTION: The product comply with the US/Canada portable RF exposure limit and are safe for intended operation as described in the manual. The further RF exposure reduction can be achieved if the product can be kept as far as possible from the user body or reduce output power if it doesn't affect the transmission/receiving quality. Table of Content CHAPTER 1: INTRODUCTION...........................................................................1 Features..................................................................................................................................1 Physical Details...................................................................................4 CHAPTER 2: ABOUT OPERATION MODES.....................................................2 Access Point Mode................................................................................................................2 Gateway Mode.......................................................................................................................3 CHAPTER 3: CONFIGURATION..................................... 4 Hardware Connection....................................................................... 4 Login........................................................................................................................................4 Wizard.....................................................................................................................................7 Operation Mode..................................................................................................................12 Internet Settings................................................................................................................13 Wireless Settings................................................................................................................21 Firewall..................................................................................................................................37 Administrator.......................................................................................................................44 CHAPTER 4: PC CONFIGURATION...............................................................48 Overview...............................................................................................................................48 Windows Clients.................................................................................................................48 Macintosh Clients...............................................................................................................55 Linux Clients........................................................................................................................56 Other Unix Systems...........................................................................................................56 Wireless Station Configuration.......................................................................................56 APPENDIX A: TROUBLESHOOTING..............................................................58 Overview...............................................................................................................................58 General Problems...............................................................................................................58 Internet Access...................................................................................................................58 Wireless Access...................................................................................................................59 APPENDIX B: ABOUT WIRELESS LANS........................................................61 BSS.........................................................................................................................................61 Channels.....................................................................................................…

Text truncated - open the document above for the full version.

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4

ID Label/Location Info

FCC ID: MQ4WR5208 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. LABEL

Internal Photos

Page 5 Page 6 Page 7 Page 8 Page 9

RF Exposure Info

FCC ID : MQ4WR5208 No simultaneous SAR justification Per “648474 D01 SAR Handsets Multi Xmiter and Ant, v01r05”, Test mode of SAR is as below Test mode Test channel Max sar value ( W/kg ) Remark 11b Highest power 0.15 less than 0.8W/kg , other channels is unnecessary USB Dongle NA 1.6W/kg This condition is defined by FCC in tracking No.948528 Max SAR value ( W/ kg ) of each mode : Test mode BODY 11b 0.15 USB Dongle 1.6 Distance between 2 Peak SAR location For Router Peak SAR location is measured. For USB dongle Peak SAR location is defined by FCC in tracking no.:948528 “Assume the dongle has 1.6 W/kg SAR and apply the SAR to peak location ratio in KDB 648474 30 to determine simultaneous transmission SAR test exclusion or evaluation requirements. Assume the peak SAR location on the dongle is at 2 cm from the USB connector end of the dongle (measurement without including the connector) “ FCC ID : MQ4WR5208 Lxy = Distance between 2 peak sar location =√( (6.7+2) 2 + (3 - 1.8) 2 ) =8.78 cm Conclusion: Sum of SAR = 0.15 + 1.6 = 1.75 W/kg Distance between 2 Peak SAR location = 8.78cm SPLSR = 1.75 / 8.78 =0.199 < 0.3 Accordingly, simultaneous Transmission SAR is not required for this EUT

RF Exposure Info

Report No.: SA990601E11 1 Report Format Version 3.0.1 SAR TEST REPORT REPORT NO.: SA990601E11 MODEL NO.: WR5208 FCC ID: MQ4WR5208 RECEIVED: Jun. 01, 2010 TESTED: Sep. 03, 2010 ISSUED: Sep. 07, 2010 APPLICANT: AboCom Systems, Inc. ADDRESS: No. 77, Yu-Yih Rd., Chu-Nan Chen, Miao-Lih Hsuan 350, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 26 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: SA990601E11 2 Report Format Version 3.0.1 TABLE OF CONTENTS 1. CERTIFICATION .............................................................................................................. 3 2. GENERAL INFORMATION .............................................................................................. 4 2.1 GENERAL DESCRIPTION OF EUT................................................................................. 4 2.2 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................. 5 2.3 GENERAL INOFRMATION OF THE SAR SYSTEM ........................................................ 6 2.4 TEST EQUIPMENT .......................................................................................................... 9 2.5 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................... 10 2.6 DESCRIPTION OF SUPPORT UNITS........................................................................... 13 3. DESCRIPTION OF ANTENNA LOCATION .................................................................... 14 4. RECIPES FOR TISSUE SIMULATING LIQUIDS ........................................................... 15 5. SYSTEM VALIDATION................................................................................................... 18 5.1 TEST PROCEDURE ...................................................................................................... 18 5.2 VALIDATION RESULTS ................................................................................................. 19 5.3 SYSTEM VALIDATION UNCERTAINTIES ..................................................................... 20 6. TEST RESULTS ............................................................................................................. 21 6.1 TEST PROCEDURES .................................................................................................... 21 6.2 CONDUCTED POWER.................................................................................................. 23 6.3 DESCRIPTION OF TEST CONDITION.......................................................................... 23 6.4 MEASURED SAR RESULT............................................................................................ 24 6.5 POWER DRIFT TABLE .................................................................................................. 24 6.6 SAR LIMITS ................................................................................................................... 25 7. INFORMATION ON THE TESTING LABORATORIES................................................... 26 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION Report No.: SA990601E11 3 Report Format Version 3.0.1 1. CERTIFICATION PRODUCT: 802.11b/g/n Portable 3G Router (Dual USB Function) MODEL: WR5208 BRAND: AboCom APPLICANT: AboCom Systems, Inc. TESTED: Sep. 03, 2010 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Part 2 (Section 2.1093) FCC OET Bulletin 65, Supplement C (01-01) RSS-102 The above equipment (model: WR5208) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE :Sep. 07, 2010 Andrea Hsia / Specialist TECHNICAL ACCEPTANCE : , DATE :Sep. 07, 2010 Responsible for RF Mason Chang / Engineer APPROVED BY : , DATE :Sep. 07, 2010 Gary Chang / Assistant Manager Report No.: SA990601E11 4 Report Format Version 3.0.1 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT EUT 802.11b/g/n Portable 3G Router (Dual USB Function) MODEL NO. WR5208 FCC ID MQ4WR5208 POWER SUPPLY 3.7Vdc (Battery) 5.0Vdc (AC Adapter & Car Charger) MODULATION TYPE CCK, DQPSK, DBPSK for DSSS 64QAM, 16QAM, QPSK, BPSK for OFDM MODULATION TECHNOLOGY DSSS, OFDM TRANSFER RATE 802.11b:11.0/ 5.5/ 2.0/ 1.0Mbps 802.11g: 54.0/ 48.0/ 36.0/ 24.0/ 18.0/ 12.0/ 9.0/ 6.0Mbps 802.11n: up to 150.0Mbps OPERATING FREQUENCY 2412 ~ 2462MHz NUMBER OF CHANNEL 11 for 802.11b, 802.11g, 802.11n (20MHz) 7 for 802.11n (40MHz) MAXIMUM SAR (1g) 0.150W/kg ANTENNA TYPE PIFA antenna with 0.81dBi gain DATA CABLE NA I/O PORTS USB, RJ45 ACCESSORY DEVICES Adapter, Car Charger, Battery NOTE: 1. The EUT provides one completed transmitter and one receiver. MODULATION MODE TX FUNCTION 802.11b 1TX 802.11g 1TX 802.11n (20MHz) 1TX 802.11n (40MHz) 1TX 2. The EUT were powered by the following adapter, battery & Car Charger: Adapter BRAND: DVE MODEL: DSA-12PFA-05 FUS 050200 INPUT: 100-240Vac, 50/60Hz, 0.5A OUTPUT: 5Vdc, 2A POWER LINE: 1.8m non-shielded cable without core Report No.: SA990601E11 5 Report Format Version 3.0.1 Car Charger BRAND: SEMDITECH MODEL: IC-DC5…

Text truncated - open the document above for the full version.

RF Exposure Info

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: PHANTOM D2: DOSIMETRIC E-FIELD PROBE D3: DAE

RF Exposure Info

D4: SYSTEM VALIDATION DIPOLE

Test Report

Report No.: RF990601E11 1 Report Format Version 3.0.1 FCC TEST REPORT REPORT NO.: RF990601E11 MODEL NO.: WR5208 FCC ID: MQ4WR5208 RECEIVED: June 01, 2010 TESTED: June 10 to 29, 2010 ISSUED: Sep. 28, 2010 APPLICANT: AboCom Systems, Inc. ADDRESS: 1F, No. 21, R&D Rd. II, SBIP, Hsin-Chu, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 78 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990601E11 2 Report Format Version 3.0.1 Table of Contents 1. CERTIFICATION...........................................................................................5 2. SUMMARY OF TEST RESULTS...................................................................6 2.1 MEASUREMENT UNCERTAINTY................................................................7 3. GENERAL INFORMATION...........................................................................8 3.1 GENERAL DESCRIPTION OF EUT..............................................................8 3.2 DESCRIPTION OF TEST MODES..............................................................11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL..............12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................14 3.4 DESCRIPTION OF SUPPORT UNITS........................................................15 3.5 CONFIGURATION OF SYSTEM UNDER TEST.........................................16 4. TEST TYPES AND RESULTS.....................................................................18 4.1 CONDUCTED EMISSION MEASUREMENT..............................................18 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................18 4.1.2 TEST INSTRUMENTS................................................................................18 4.1.3 TEST PROCEDURES.................................................................................19 4.1.4 DEVIATION FROM TEST STANDARD.......................................................19 4.1.5 TEST SETUP..............................................................................................20 4.1.6 EUT OPERATING CONDITIONS................................................................20 4.1.7 TEST RESULTS..........................................................................................21 4.2 RADIATED EMISSION MEASUREMENT...................................................23 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................23 4.2.2 TEST INSTRUMENTS................................................................................24 4.2.3 TEST PROCEDURES.................................................................................25 4.2.4 DEVIATION FROM TEST STANDARD.......................................................25 4.2.5 TEST SETUP..............................................................................................26 Report No.: RF990601E11 3 Report Format Version 3.0.1 4.2.6 EUT OPERATING CONDITIONS................................................................26 4.2.7 TEST RESULTS..........................................................................................27 4.3 6dB BANDWIDTH MEASUREMENT..........................................................56 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT........................................56 4.3.2 TEST INSTRUMENTS................................................................................56 4.3.3 TEST PROCEDURE...................................................................................56 4.3.4 DEVIATION FROM TEST STANDARD.......................................................56 4.3.5 TEST SETUP..............................................................................................56 4.3.6 EUT OPERATING CONDITIONS................................................................56 4.3.7 TEST RESULTS..........................................................................................57 4.4 MAXIMUM PEAK OUTPUT POWER..........................................................61 4.4.1 LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT...........61 4.4.2 INSTRUMENTS..........................................................................................61 4.4.3 TEST PROCEDURES.................................................................................61 4.4.4 DEVIATION FROM TEST STANDARD.......................................................61 4.4.5 TEST SETUP..............................................................................................61 4.4.6 EUT OPERATING CONDITIONS................................................................61 4.4.7 TEST RESULTS..........................................................................................62 4.5 POWER SPECTRAL DENSITY MEASUREMENT......................................63 4.5.1 LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT...................63 4.5.2 TEST INSTRUMENTS................................................................................63 4.5.3 TEST PROCEDURE...................................................................................63 4.5.4 DEVIATION FROM TEST STANDARD.......................................................63 4.5.5 TEST SETUP..............................................................................................63 4.5.6 EUT OP…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF990601E11-1 1 Report Format Version 3.0.1 Supplemental “Transmit Simultaneously” Test Report REPORT NO.: RF990601E11-1 MODEL NO.: WR5208 FCC ID: MQ4WR5208 RECEIVED: June 01, 2010 TESTED: June 18 to 29, 2010 ISSUED: Sep. 28, 2010 APPLICANT: AboCom Systems, Inc. ADDRESS: 1F, No.21, R&D Rd. II, SBIP, Hsin-Chu, Taiwan, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Hsin Chu Laboratory LAB ADDRESS: No. 81-1, Lu Liao Keng, 9th Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (1): No. 81-1, Lu Liao Keng, 9th Ling,Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan TEST LOCATION (2): No. 49, Ln. 206, Wende Rd., Shangshan Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien 307, Taiwan This test report consists of 26 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF990601E11-1 2 Report Format Version 3.0.1 Table of Contents 1 CERTIFICATION...........................................................................................3 2 SUMMARY OF TEST RESULTS...................................................................4 2.1 MEASUREMENT UNCERTAINTY...........................................................................4 3 GENERAL INFORMATION............................................................................5 3.1 GENERAL DESCRIPTION OF EUT........................................................................5 3.2 DESCRIPTION OF TEST MODES..........................................................................8 3.3 TEST MODE APPLICABLITY AND TESTED CHANNEL DETAIL:...........................9 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS........................................10 3.5 DESCRIPTION OF SUPPORT UNITS...................................................................11 3.6 CONFIGURATION OF SYSTEM UNDER TEST....................................................12 4 TEST TYPES AND RESULTS.....................................................................14 4.1 CONDUCTED EMISSION MEASUREMENT.........................................................14 4.1.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT............................14 4.1.2 TEST INSTRUMENTS.................................................................................14 4.1.3 TEST PROCEDURES.................................................................................15 4.1.4 DEVIATION FROM TEST STANDARD........................................................15 4.1.5 TEST SETUP..............................................................................................15 4.1.6 EUT OPERATING CONDITIONS................................................................16 4.1.7 TEST RESULTS..........................................................................................17 4.2 RADIATED EMISSION MEASUREMENT..............................................................19 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT.................................19 4.2.2 TEST INSTRUMENTS.................................................................................20 4.2.3 TEST PROCEDURES.................................................................................21 4.2.4 TEST SETUP..............................................................................................22 4.2.5 EUT OPERATING CONDITIONS................................................................22 4.2.6 TEST RESULTS..........................................................................................23 5 INFORMATION ON THE TESTING LABORATORIES................................25 6 APPENDIX A - MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB......................................................26 Report No.: RF990601E11-1 3 Report Format Version 3.0.1 1 CERTIFICATION PRODUCT : 802.11b/g/n Portable 3G Router (Dual USB Function) BRAND : AboCom MODEL NO. : WR5208 TESTED : June 18 to 29, 2010 TEST SAMPLE : ENGINEERING SAMPLE APPLICANT : AboCom Systems, Inc. STANDARDS : FCC Part 15, Subpart C (Section 15.247) ANSI C63.4-2003 The above equipment (Model: WR5208) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: Sep. 28, 2010 ( Sunny Wen, Specialist ) TECHNICAL ACCEPTANCE : , DATE: Sep. 28, 2010 ( Hank Chung, Deputy Manager ) APPROVED BY : , DATE: Sep. 28, 2010 ( May Chen, Deputy Manager ) Report No.: RF990601E11-1 4 Report Format Version 3.0.1 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C Standard Section Test Type and Limit Result REMARK 15.207 AC Power Conducted Emission PASS Meet the requirement of limit. Minimum passing margin is -11.62dB at 4.371MHz 15.247(d) Transmitter Radiated Emissions Limit: Table 15.209 PASS Meet the requirement of limit Minimum passing margin is -2.4 dB at 320.00 MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Value Conducted emissions 2.44 dB Radiated emissions (30MHz-1GHz) 3.30 dB Radiated emissions (1GHz -18GHz) 2.19 dB Radiated emissions (18GHz -40GHz) 2.56 dB Report No.: RF9…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST 2 RADIATED EMISSION TEST

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION (SAR Test Set Up Photos) BOTTOM TOP EDGE-LEFT EDGE-RIGHT FRONT BACK 2 DESCRIPTION OF ANTENNA LOCATION

Contact Information

Applicant

Harry Huang(Manager)
[email protected]886-3-758-0777Fax: 886-3-758-0099

Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchHank Chung
[email protected]886-3-593-5343

81-1, Lu Laio Keng, 9th Ling, Wu Lung Tsuen, Chiun · Hsinchu Hsien · Taiwan

Non-Technical Contact

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchWendy Liao
[email protected]886-3-3183232

Test Firm

Bureau Veritas CPS (H.K.) Ltd. Taoyuan BranchRichard Chen
[email protected]886-3-3183232Fax: 886-3-2115834

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz316.00 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted. Device is a 1Tx1R draft 802.11bgn Portable 3G Router. Collocated transmitter operating configurations have been evaluated as described in this filing; other collocation configurations require separate evaluation. SAR compliance for body-worn operating configurations is limited to the specific configurations tested for this filing. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly; other configurations require separate evaluation. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported body SAR value is: 0.15 W/kg.
