Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : B1 of B3 Appendix B. Maximum Permissible Exposure Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : B2 of B3 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.25 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) ＝ d GP30 Power Density: Pd (W/m²) ＝ 377 2 E E ＝ Electric field (V/m) P ＝ Peak RF output power (W) G ＝ EUT Antenna numeric gain (numeric) d ＝ Separation distance between radiator and human body (m) The formula can be changed to Pd ＝ 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : B3 of B3 1.3. Calculated Result and Limit For 5GHz UNII Band: Antenna Type : PIFA Antenna Max Conducted Power for IEEE 802.11n MCS8 40MHz Ant. 1 + Ant. 2: 16.91dBm Antenna Gain (dBi) Antenna Gain (numeric) Output Power (dBm) Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 5.10 3.2359 16.9132 49.1275 0.031643 1 Complies For 5GHz ISM Band: Antenna Type : PIFA Antenna Max Conducted Power for IEEE 802.11n MCS8 20MHz Ant. 1 + Ant. 2: 27.40dBm Antenna Gain (dBi) Antenna Gain (numeric) Output Power (dBm) Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 5.10 3.2359 27.3952 548.9343 0.353566 1 Complies For 2.4GHz Band: Antenna Type : PIFA Antenna Max Conducted Power for IEEE 802.11n MCS8 20MHz Ant. 1 + Ant. 2: 29.18dBm Antenna Gain (dBi) Antenna Gain (numeric) Output Power (dBm) Output Power ( mW ) Power Density (S) (mW/cm²) Limit of Power Density (S) (mW/cm²) Test Result 3.20 2.0893 29.1781 827.5734 0.344157 1 Complies CONCULSION: Both of the WLAN 2.4GHz Band and WLAN 5GHz Band can transmit simultaneously, the formula of calculatedthe MPE is: CPD1 / LPD1 + CPD2 / LPD2 + ......etc. < 1 CPD = Calculation power density LPD = Limit of power density Therefore, the worst-case situation is 0.353566 / 1 + 0.344157 / 1 = 0.697723, which isless than “1”. This confirmed that the device comply with FCC 1.1310 MPE limit.

Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : C1 of C3 Appendix C. Co-location Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : C2 of C3 1. Results of Radiated Emissions for Co-located Temperature 22°C Humidity 60% Test Engineer Johnson Chang Configurations 2.4G + 5G TX Horizontal Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : C3 of C3 Vertial

SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw Report Format Version: 01 FCC RADIO TEST REPORT Applicant’s company Abocom Systems, Inc Applicant Address No.77, Yu-Yih Rd., Chu-Nan, Miao-Lih County 35059, Taiwan R.O.C. FCC ID MQ4WRN500 Manufacturer’s company Abocom Systems, Inc Manufacturer Address No.77, Yu-Yih Rd., Chu-Nan, Miao-Lih County 35059, Taiwan R.O.C. Product Name 802.11a/b/g/n Compact Wireless Router Brand Name Abocom Model Name WRN500 Test Rule Part(s) 47 CFR FCC Part 15 Subpart E § 15.407 Test Freq. Range 5150 ~ 5250MHz Received Date Apr. 16, 2011 Final Test Date May 19, 2011 Submission Type Original Equipment Statement Test result included is for the IEEE 802.11n and IEEE 802.11a (5150 ~ 5250MHz) of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.10-2009 and 47 CFR FCC Part 15 Subpart E. The test equipment used to perform the test is calibrated and traceable to NML/ROC. Report No.: FR141604AA Report Format Version: 01 Page No. : i of ii FCC ID: MQ4WRN500 Issued Date :May 27, 2011 Table of Contents 1. CERTIFICATE OF COMPLIANCE ........................................................................................................................... 1 2. SUMMARY OF THE TEST RESULT ............................................................................................................................ 2 3. GENERAL INFORMATION..................................................................................................................................... 3 3.1. Product Details ........................................................................................................................................................................................... 3 3.2. Accessories ................................................................................................................................................................................................. 4 3.3. Table for Filed Antenna ............................................................................................................................................................................. 5 3.4. Table for Carrier Frequencies ................................................................................................................................................................... 5 3.5. Table for Test Modes .................................................................................................................................................................................. 6 3.6. Table for Testing Locations........................................................................................................................................................................ 6 3.7. Table for Supporting Units ......................................................................................................................................................................... 7 3.8. Table for Parameters of Test Software Setting ....................................................................................................................................... 7 3.9. Test Configurations..................................................................................................................................................................................... 8 4. TEST RESULT......................................................................................................................................................... 10 4.1. AC Power Line Conducted Emissions Measurement ......................................................................................................................... 10 4.2. 99% Occupied Bandwidth Measurement............................................................................................................................................ 14 4.3. Maximum Conducted Output Power Measurement......................................................................................................................... 21 4.4. Power Spectral Density Measurement.................................................................................................................................................. 24 4.5. Peak Excursion Measurement ................................................................................................................................................................ 30 4.6. Radiated Emissions Measurement......................................................................................................................................................... 35 4.7. Band Edge Emissions Measurement...................................................................................................................................................... 49 4.8. Frequency Stability Measurement......................................................................................................................................................... 53 4.9. Antenna Requirements ........................................................................................................................................................................... 55 5. LIST OF MEASURING EQUIPMENTS .................................................................................................................... 56 6. TEST LOCATION.................................................................................................................................................. 58 7. TAF CERTIFICATE OF ACCREDITATION......…

Text truncated - open the document above for the full version.

Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : 1 of 6 Appendix A. Test Photos Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : 2 of 6 1. Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : 3 of 6 SIDE VIEW Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : 4 of 6 2. Photographs of Radiated Emissions Test Configuration Test Configuration: 9kHz ~30MHz FRONT VIEW REAR VIEW Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : 5 of 6 Test Configuration: 30MHz~1GHz FRONT VIEW REAR VIEW Report No.: FR141604 FCC ID: MQ4WRN500 Page No. : 6 of 6 Test Configuration: Above 1GHz FRONT VIEW REAR VIEW
