MQ4WUG2660802.11b/g Wireless LAN USB2.0 Adapter

802.11b/g Wireless LAN USB 2.0 Adapter User’s Manual REGULATORY STATEMENTS FCC Certification The United States Federal Communication Commission (FCC) and the Canadian Department of Communications have established certain rules governing the use of electronic equipment. Part15, Class B This device complies with Part 15 of FCC rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interface. 2) This device must accept any interface received, including interface that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the distance between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. CAUTION: 1) To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 cm must be maintained between the antenna of this device and all persons. 2) This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This device is intended only for OEM integrators under the following conditions: 1) The antenna must be installed such that 20 cm is maintained between the antenna and users. For laptop installations, the antenna must be installed to ensure that the proper spacing is maintained in the event the users places the device in their lap during use (i.e. positioning of antennas must be placed in the upper portion of the LCD panel only to ensure 20 cm will be maintained if the user places the device in their lap for use) and 2) The transmitter module may not be co-located with any other transmitter or antenna. As long as the 2 conditions above are met, further transmitter testing will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. End Product Labeling This transmitter module is authorized only for use in devices where the antenna may be installed such that 20 cm may be maintained between the antenna and users (for example access points, routers, wireless ASDL modems, certain laptop configurations, and similar equipment). The final end product must be labeled in a visible area with the following: "Contains TX FCC ID: {MQ4WUG2660}". RF Exposure Manual Information That Must be Included The users manual for end users must include the following information in a prominent location "IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter." Additional Information That Must be Provided to OEM Integrators The end user should NOT be provided any instructions on how to remove or install the device. Table of Contents INTRODUCTION..............................................................................................1 FEATURES........................................................................................................1 SOFTWARE INSTALLATION.........................................................................2 STEP 1: INSTALL THE DRIVER & UTILITY............................................................2 For Windows 98, 2000, ME and XP users..............................................2 HARDWARE INSTALLATION.......................................................................5 Verify...................................................................................................5 NETWORK CONNECTION.............................................................................7 IN WINDOWS 98SE/ME.....................................................................................7 IN WINDOWS 2000/XP....................................................................................10 IP ADDRESS...................................................................................................12 Configuration Utility........................................................................................13 STATION.........................................................................................................15 ACCESS POINT................................................................................................23 - 1 - INTRODUCTION The specific product as below, 802.11b/g Wireless LAN USB 2.0 Adapter, with its designed features and specified description, meets special requirements for limited modular approval ob FCC public notice DA 00-1407. The 802.11b+g Wireless LAN USB Adapter complies with IEEE 802.11g standard that offers a data rate up to 5…

Text truncated - open the document above for the full version.

FCC ID: MQ4WUG2660 Date: Nov. 9, 2004 Modular Approval Request Letter Dear Sir, There’s an 802.11b/g Wireless LAN USB 2.0 Adapter that would like to have your authorization as a modular approval. The specific product as below, 802.11b/g Wireless LAN USB 2.0 Adapter , with its designed features and specified description, meets special requirements for full modular approval on FCC Public Notice DA 00-1407 by cross-reference list below. Company : AboCom Systems, Inc. Model Name : 802.11b/g Wireless LAN USB 2.0 Adapter Model Number : WUG2660 FCC ID : MQ4WUG2660 Requirement of Public Notice DA00-1407 Reference to WUG2660 1. The modular transmitter must have its own RF shielding. The module has its own RF shielding. Please see external photo.pdf 2. The modular transmitter must have buffered modulation/data inputs. The modular has buffered data inputs, it is integrated in chip 24C32. Please see diagram.pdf 3. The modular transmitter must have its own power supply regulation. All power lines derived from the host device are regulated before energizing other circuits internal to the WUG2660. Please see circuit.pdf 4. The modular transmitter must comply with the antenna requirements of Section 15.203 and 15.204(c). The WUG2660 meets the FCC antenna requirements. It has a unique connector. Please see external photo.pdf 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. The WUG2660 was tested in a stand-alone configuration via a USB extender. Please see conducted set-up photo.pdf and spurious set-up photo.pdf 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. The label position of WUG2660 is clearly indicated. Please see the label.pdf 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. The WUG2660 is compliant with all applicable FCC rules. Detail instructions are given in the Users Manual. Please see Installation guide.pdf 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). The WUG2660 comply with applicable RF exposure requirements. Please see RF safety evaluation. pdf Yours sincerely, Jerry Liu Supervisor Intertek Testing Service Taiwan Ltd.

Photo 1: External photo of EUT WUG2660 Photo 2: External photo of EUT WUG2660 Photo 3: External photo of EUT WUG2660 Photo 4: External photo of EUT Antenna 1 Photo 5: External photo of EUT Antenna 2 Photo 6: External photo of EUT Antenna 3 Photo 7: External photo of EUT Cable

Label location 54.0mm 2 1 . 0 m m

Photo 1: Internal photo of EUT WUG2660 Photo 2: Internal photo of EUT WUG2660 Photo 3: Internal photo of EUT WUG2660

FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 1 of 5 Jackey Chiu Maximum Permissible Exposure (MPE) Evaluation Report Report No. : EME-041008 Model No. : WUG2660 Issued Date : Nov. 5, 2004 Applicant : AboCom Systems, Inc. 1F, No. 21, Yanfa 2 nd Rd., SBIP, HsinChu City 300, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 5 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result in this report only applies to the tested sample. Project Engineer Reviewed By Jerry Liu FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 2 of 5 Table of Contents Summary of Tests.........................................................................................................3 1. Introduction..............................................................................................................4 2. RF Exposure Limit....................................................................................................4 3. RF Exposure calculations..........................................................................................5 4. Test results................................................................................................................5 FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 3 of 5 Summary of Tests MPE Evaluation meet FCC OET No. 65: 1997/ IEEE C95.1-1999 802.11b/g Wireless LAN USB 2.0 Adapter-Model: WUG2660 FCC ID: MQ4WUG2660 Test Reference Results MPE Evaluation FCC Guidelines for Human Exposure IEEE C95.1 Complies FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 4 of 5 1. Introduction The EUT operates in the 2.4GHz ISM band. Due to the EUT (include antenna) at its normal operation distance is at least 20 cm from the human body, the EUT was defined as a Mobile Device. The EUT operates in the 2.4GHz ISM band. The EUT (antenna included) is compliant with modular approval and the normal operation distance (after installing in other device, such as router or access point), 20cm from the human body; therefore, the EUT is defined as a Mobile Device. The reason to do the MPE Evaluation is to avoid the RF hazard to human body. The maximum output power and gain of the antenna were used to calculate the limited Power density (S) at 20cm distance away from the product. The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. 2. RF Exposure Limit According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in 1.1307(b). Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) (A) Limits for Occupational / Control Exposures 30-300 61.4 0.163 1.0 6 300-1500 - - F/300 6 1500-100,000 - - 5 6 (B) Limits for General Population / Uncontrolled Exposure 30-300 27.5 0.073 0.2 30 300-1500 - - F/1500 30 1500-100,000 - - 1.0 30 F= Frequency in MHz FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 5 of 5 3. RF Exposure calculations From § FCC 1.1310 table 1, the maximum permissible RF exposure for an uncontrolled environment is 1mW/(cm 2 ) Power density (S) is calculated by the following formula: S = (P * G)/4πR 2 where, S = Power density (mW/cm 2 ) P = Output power to antenna (mW) R = Distance between radiating structure and observation point (cm) G = Gain of antenna in numeric π = 3.1416 Example: Assume a mobile device operates at 2412MHz and its maximum output power is 50mW, and the maximum gain of antenna is 1 (numeric) /0dBi. then the power density (S) = (50 * 1)/4*π*20 2 = 0.00995 (mW/cm 2 ) 4. Test results Test Mode: 802.11b operation mode (DSSS Modulation) Channel Channel Frequency (MHz) Maximum antenna gain (numeric)* Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 1 2412 2 76.73 0.03046 1.0 6 2437 2 77.44 0.03074 1.0 11 2462 2 76.20 0.03025 1.0 Note: “*” The antenna gain is the maximum gain among three antennas. Test Mode: 802.11g operation mode (OFDM Modulation) Channel Channel Frequency (MHz) Maximum antenna gain (numeric)* Output power to antenna (mW) Power density (mW/cm 2 ) Limit of power density (mW/cm 2 ) 1 2412 2 96.16 0.03817 1.0 6 2437 2 95.49 0.03790 1.0 11 2462 2 95.06 0.03773 1.0 Note: “*” The antenna gain is the maximum gain among three antennas. The Notice in Installation Manual has been stated as below: While installing and operating this transmitter, the radio frequency exposure limit of 1mW/(cm*cm) may be exceeded at distances close to the transmitter. therefore, the user must maintain a minimum distance of 20 cm from the device at all time.

FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 1 of 85 Jackey Chiu EMC TEST REPORT Report No. : EME-041008 Model No. : WUG2660 Issued Date : Nov. 5, 2004 Applicant : AboCom Systems, Inc. 1F, No. 21, Yanfa 2 nd Rd., SBIP, HsinChu City 300, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 85 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). Project Engineer Reviewed By Jerry Liu FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 2 of 85 Table of Contents Summary of Tests.........................................................................................................4 1. General information.................................................................................................5 1.1 Identification of the EUT...................................................................................5 1.2 Additional information about the EUT...............................................................5 1.3 Antenna description...........................................................................................6 1.4 Peripherals equipment........................................................................................7 2. Test specifications....................................................................................................8 2.1 Test standard......................................................................................................8 2.2 Operation mode.................................................................................................8 2.3 Test equipment...................................................................................................9 3. Minimum 6dB Bandwidth test.................................................................................10 3.1 Operating environment......................................................................................10 3.2 Test setup & procedure......................................................................................10 3.3 Measured data of Minimum 6dB Bandwidth test results....................................10 4. Maximum Output Power test...................................................................................17 4.1 Operating environment......................................................................................17 4.2 Test setup & procedure......................................................................................17 4.3 Measured data of Maximum Output Power test results......................................18 5. Radiated Emission test.............................................................................................19 5.1 Operating environment......................................................................................19 5.2 Test setup & procedure......................................................................................19 5.3 Emission limits.................................................................................................20 5.4 Radiated spurious emission test data.................................................................21 5.4.1 Measurement results: frequencies equal to or less than 1 GHz........................22 5.4.2 Measurement results: frequency above 1GHz.................................................28 6. Power Spectrum Density test...................................................................................46 6.1 Operating environment......................................................................................46 6.2 Test setup & procedure......................................................................................46 6.3 Measured data of Power Spectrum Density test results......................................46 7. Emission on the band edge §FCC 15.247(C)............................................................53 7.1 Band-edge (Conducted method)........................................................................54 7.2 Band-edge (Radiated method)...........................................................................58 FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 3 of 85 8. Power Line Conducted Emission test §FCC 15.207.................................................82 8.1 Operating environment......................................................................................82 8.2 Test setup & procedure......................................................................................82 8.3 Emission limit...................................................................................................83 8.5 Uncertainty of Conducted Emission..................................................................83 8.5 Power Line Conducted Emission test data.........................................................84 FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 4 of 85 Summary of Tests 802.11b/g Wireless LAN USB 2.0 Adapter-Model: WUG2660 FCC ID: MQ4WUG2660 Test Reference Results Minimum 6dB Bandwidth test 15.247(a)(2) Complies Maximum Output Power test 15.247(b) Complies Radiated Spurious Emission test 15.205, 15.209 Complies Power Spectrum Density test 15.247(d) Complies Power Line Conducted Emission test 15.207 Complies FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 5 of 85 1. General information 1.1 Identification of the EUT Applicant : AboCom Systems, Inc. Product : 802.11b/g Wireless LAN USB 2.0 Adapter Model No. : WUG2660 FCC ID. : MQ4WUG2660 Frequency Range : 2400 MHz to 2483.5MHz Channel Number : 11 Channels Frequency of Each Channel : 2412MHz, 2417MHz, 2422MHz, 2427MHz, 2432MHz, 2437MHz, 2442MHz, 2447MHz, 2452MHz, 2457MHz, 2462MHz Type of Modulation : DSSS, OFDM Rated Power : 5Vdc Powe…

Text truncated - open the document above for the full version.

FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 1 of 84 Jackey Chiu EMC TEST REPORT Report No. : EME-041008 Model No. : WUG2660 Issued Date : Nov. 5, 2004 Applicant : AboCom Systems, Inc. 1F, No. 21, Yanfa 2 nd Rd., SBIP, HsinChu City 300, Taiwan Test By : Intertek Testing Services Taiwan Ltd. No. 11, Lane 275, Ko-Nan 1 Street, Chia-Tung Li, Shiang-Shan District, Hsinchu City, Taiwan This test report consists of 85 pages in total. It may be duplicated completely for legal use with the allowance of the applicant. It shall not be reproduced except in full, without the written approval of Intertek Laboratory. The test result(s) in this report only applies to the tested sample(s). Project Engineer Reviewed By Jerry Liu FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 2 of 84 Table of Contents Summary of Tests.........................................................................................................4 1. General information.................................................................................................5 1.1 Identification of the EUT...................................................................................5 1.2 Additional information about the EUT...............................................................5 1.3 Antenna description...........................................................................................6 1.4 Peripherals equipment........................................................................................7 2. Test specifications....................................................................................................8 2.1 Test standard......................................................................................................8 2.2 Operation mode.................................................................................................8 2.3 Test equipment...................................................................................................9 3. Minimum 6dB Bandwidth test.................................................................................10 3.1 Operating environment......................................................................................10 3.2 Test setup & procedure......................................................................................10 3.3 Measured data of Minimum 6dB Bandwidth test results....................................10 4. Maximum Output Power test...................................................................................17 4.1 Operating environment......................................................................................17 4.2 Test setup & procedure......................................................................................17 4.3 Measured data of Maximum Output Power test results......................................17 5. Radiated Emission test.............................................................................................18 5.1 Operating environment......................................................................................18 5.2 Test setup & procedure......................................................................................18 5.3 Emission limits.................................................................................................19 5.4 Radiated spurious emission test data.................................................................20 5.4.1 Measurement results: frequencies equal to or less than 1 GHz........................21 5.4.2 Measurement results: frequency above 1GHz.................................................27 6. Power Spectrum Density test...................................................................................45 6.1 Operating environment......................................................................................45 6.2 Test setup & procedure......................................................................................45 6.3 Measured data of Power Spectrum Density test results......................................45 7. Emission on the band edge §FCC 15.247(C)............................................................52 7.1 Band-edge (Conducted method)........................................................................53 7.2 Band-edge (Radiated method)...........................................................................57 FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 3 of 84 8. Power Line Conducted Emission test §FCC 15.207.................................................81 8.1 Operating environment......................................................................................81 8.2 Test setup & procedure......................................................................................81 8.3 Emission limit...................................................................................................82 8.5 Uncertainty of Conducted Emission..................................................................82 8.5 Power Line Conducted Emission test data.........................................................83 FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 4 of 84 Summary of Tests 802.11b/g Wireless LAN USB 2.0 Adapter-Model: WUG2660 FCC ID: MQ4WUG2660 Test Reference Results Minimum 6dB Bandwidth test 15.247(a)(2) Complies Maximum Output Power test 15.247(b) Complies Radiated Spurious Emission test 15.205, 15.209 Complies Power Spectrum Density test 15.247(d) Complies Power Line Conducted Emission test 15.207 Complies FCC ID. : MQ4WUG2660 Report No.: EME-041008 Page 5 of 84 1. General information 1.1 Identification of the EUT Applicant : AboCom Systems, Inc. Product : 802.11b/g Wireless LAN USB 2.0 Adapter Model No. : WUG2660 FCC ID. : MQ4WUG2660 Frequency Range : 2400 MHz to 2483.5MHz Channel Number : 11 Channels Frequency of Each Channel : 2412MHz, 2417MHz, 2422MHz, 2427MHz, 2432MHz, 2437MHz, 2442MHz, 2447MHz, 2452MHz, 2457MHz, 2462MHz Type of Modulation : DSSS, OFDM Rated Power : 5Vdc Powe…

Text truncated - open the document above for the full version.

Photo 1: Radiated Emission Test Set-up EUT with antenna 1 WUG2660 Photo 2: Radiated Emission Test Set-up EUT with antenna 1 WUG2660 Photo 3: Radiated Emission Test Set-up EUT with antenna 1 WUG2660 Photo 4: Radiated Emission Test Set-up EUT with antenna 2 WUG2660 Photo 5: Radiated Emission Test Set-up EUT with antenna 2 WUG2660 Photo 6: Radiated Emission Test Set-up EUT with antenna 2 WUG2660 Photo 7: Radiated Emission Test Set-up EUT with antenna 3 WUG2660 Photo 8: Radiated Emission Test Set-up EUT with antenna 3 WUG2660 Photo 9: Radiated Emission Test Set-up EUT with antenna 3 WUG2660
