MSQ-CMBT00Wireless-AC3100 Dual Band Gigabit Router

ASUSTeK Computer Inc

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Nov 30, 2015
Application Purpose: Original Equipment
Date of Application: Nov 30, 2015
Equipment Note: Wireless-AC3100 Dual Band Gigabit Router
Frequency Range: 5745.00000000 - 5825.00000000
Company: ASUSTeK Computer Inc
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

CM-‐32 User manual Prepare your CM-‐32 1. Use the coaxial cable provided by your cable service provider to connect the cable port on the CM-‐32 to the cable wall outlet or a line splitter. 2. Connect the power adapter to the CM-‐32 and plug the power adapter into an electrical outlet. The Power LED lights white. Login and setup Wi-‐Fi 1. When the 2.4 GHz and 5 GHz LED light white, the hardware is ready for setup Wi-‐Fi. 2. Use the Ethernet cable supplied to connect a computer to one of the Ethernet LAN ports on the CM-‐32. You may also connect to the CM-‐32 via Wi-‐Fi. Use the default Wi-‐Fi network name and password on the product label. 3. Launch a web browser. You will be directed to the ASUS Setup Wizard. If not, navigate to http://router.asus.com or http://192.168.1.1. 4. Follow the instructions to complete setup. Activate your Internet service 1. Visit your cable Internet provider’s website and follow the onscreen instructions to activate your Internet service. CM-‐32 is certified by Charter, Comcast, Cox and Time Warner Cable services. Charter 1-‐888-‐438-‐2427 https://install.charter.com/ Comcast 1-‐800-‐266-‐2278 https://www.comcast.com/activate Cox 1-‐877-‐891-‐2899 https://activation.cox.net/ Time Warner Cable 1-‐800-‐892-‐2253 https://www.timewarnercable.com/ 2. The Downstream and Upstream LED light white when the cable connection succeeded. 3. If the CM-‐32 still does not connect to the Internet, contact your cable Internet provider by phone and: • Provide your CM-‐32’s serial number and MAC address on the box label and have your service provider confirm it is active. • If your CM-‐32 is visible to your service provider but you still have no Internet connection, reboot the CM-‐32 and check online status again. • If your CM-‐32 is not visible to your Internet provider or your Internet provider cannot support troubleshooting, launch web browser and navigate to http://router.asus.com or http://192.168.1.1, go to Cable > CM debug info, click Save to create a .txt log file. Then, go to System log > General log, click Save to create a .txt file as well. Send the two files to [email protected], and we will reply to you as soon as possible. Connect to the CM-‐32’s Wi-‐Fi network 1. Use your Wi-‐Fi device to search for the CM-‐32’s Wi-‐Fi network name (SSID). The SSID is on the product label on the rear cover of the CM-‐32. 2. Enter the password on the product label to join the network. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: -‐ Reorient or relocate the receiving antenna. -‐ Increase the separation between the equipment and receiver. -‐ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -‐ Consult the dealer or an experienced radio/TV technician for help. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-‐located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Cover Letter(s)

Date: 2015-12-23 Re: Supersede request for FCC ID: MSQ-CMBT00; Granted on 12/01/2015 To Whom It May Concern: We regret to inform you that due to product specification revision, we have submitted the wrong Software Operating Descriptio_rev exhibit to the filing. To prevent misunderstanding to the public, we would like to request the FCC to supersede the exhibit described as Software Operating Description_rev 2. If you have any questions, feel free to contact us. Thank you. Sincerely yours, ----------------------------------- Jackson Yen, Associate Vice President Tel: +886-2-28987364 Fax: +886-2-28943447 E-mail: [email protected]

External Photos

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2 Page 3 Page 4 Page 5

ID Label/Location Info

CM-32_AC2600

ID Label/Location Info

Wireless-AC2600 Dual Band Cable Modem Router Model: CM-32_AC2600 Input: 19V 2.37A FCC ID: MSQ-CMBT00 Wi-Fi network 2.4 GHz: Name: XXXXXXXXXXX Password: XXXXXXXXXXX Wi-Fi network 5 GHz: Name: XXXXXXXXXXX Password: XXXXXXXXXXX F/W ver.: 3.0.04.368 H/W ver.: A1 PIN code:XXXXXXXX MAC:XXXXXXXXXXXX SN:XXXXXXXXXXXX E187242 F2

Internal Photos

Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14

RF Exposure Info

Report No.: SA150802C01 Page No. 1 / 7 Report Format Version: 6.1.1 RF Exposure Report Report No.: SA150802C01 FCC ID: MSQ-CMBT00 Test Model: CM-32_AC2600 Received Date: Aug. 02, 2015 Test Date: Nov. 19 ~ Nov. 30, 2015 Issued Date: Nov. 30, 2015 Applicant: ASUSTek COMPUTER INC. Address: 4F, NO. 150, LI-TE RD. PEITOU, TAIPEI 112, TAIWAN Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location: No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: SA150802C01 Page No. 2 / 7 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 3 1 Certificate of Conformity ...................................................................................................................... 4 2 RF Exposure .......................................................................................................................................... 5 2.1 Limits for Maximum Permissible Exposure (MPE) .............................................................................. 5 2.2 MPE Calculation Formula ................................................................................................................... 5 2.3 Classification ....................................................................................................................................... 5 3 Calculation Result of Maximum Conducted Power ........................................................................... 6 Report No.: SA150802C01 Page No. 3 / 7 Report Format Version: 6.1.1 Release Control Record Issue No. Description Date Issued SA150802C01 Original release. Nov. 30, 2015 Report No.: SA150802C01 Page No. 4 / 7 Report Format Version: 6.1.1 1 Certificate of Conformity Product: Wireless-AC3100 Dual Band Gigabit Router Brand: ASUS Test Model: CM-32_AC2600 Sample Status: Engineering sample Applicant: ASUSTek COMPUTER INC. Test Date: Nov. 19 ~ Nov. 28, 2015 Standards: FCC Part 2 (Section 2.1091) KDB 447498 D03 IEEE C95.1 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. Prepared by : , Date:Nov. 30, 2015 Celine Chou / Specialist Approved by : , Date:Nov. 30, 2015 Ken Liu / Senior Manager Report No.: SA150802C01 Page No. 5 / 7 Report Format Version: 6.1.1 2 RF Exposure 2.1 Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE Calculation Formula Pd = (Pout*G) / (4*pi*r 2 ) where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 Classification The antenna of this product, under normal use condition, is at least 32cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA150802C01 Page No. 6 / 7 Report Format Version: 6.1.1 3 Calculation Result of Maximum Conducted Power Frequency Band (MHz) Mode Max Power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) 2412-2462 Beamforming off Mode 802.11b 28.65 8.72 32 0.424 1 802.11g 28.77 8.72 32 0.436 1 802.11n (HT20) 29.35 8.72 32 0.498 1 802.11n (HT40) 24.64 8.72 32 0.168 1 Beamforming on Mode 802.11n (HT20) 26.56 8.72 32 0.262 1 802.11n (HT40) 22.31 8.72 32 0.099 1 5180-5240 Beamforming off Mode 802.11a 22.38 9.41 32 0.117 1 802.11n (HT20) 22.28 9.41 32 0.115 1 802.11n (HT40) 22.23 9.41 32 0.113 1 802.11ac (VHT80) 19.85 9.41 32 0.066 1 Beamforming on Mode 802.11ac (VHT20) 21.90 9.41 32 0.105 1 802.11ac (VHT40) 20.62 9.41 32 0.078 1 802.11ac (VHT80) 19.12 9.41 32 0.055 1 5745-5825 Beamforming off Mode 802.11a 27.46 10.37 32 0.472 1 802.11n (HT20) 27.42 10.37 32 0.467 1 802.11n (HT40) 26.34 10.37 32 0.364 1 802.11ac (VHT80) 25.20 10.37 32 0.280 1 Beamforming on Mode 802.11ac (VHT20) 25.…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF150802C01 Page No. 1 / 155 Report Format Version: 6.1.1 FCC Test Report Report No.: RF150802C01 FCC ID: MSQ-CMBT00 Test Model: CM-32_AC2600 Received Date: Aug. 02, 2015 Test Date: Nov. 19 ~ Nov. 30, 2015 Issued Date: Nov. 30, 2015 Applicant: ASUSTek COMPUTER INC. Address: 4F, NO. 150, LI-TE RD. PEITOU, TAIPEI 112, TAIWAN Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150802C01 Page No. 2 / 155 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 5 1 Certificate of Conformity ...................................................................................................................... 6 2 Summary of Test Results ..................................................................................................................... 7 2.1 Measurement Uncertainty ................................................................................................................... 7 2.2 Modification Record ............................................................................................................................ 7 3 General Information .............................................................................................................................. 8 3.1 General Description of EUT ................................................................................................................ 8 3.2 Description of Test Modes ................................................................................................................. 10 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................ 11 3.3 Duty Cycle of Test Signal .................................................................................................................. 15 3.4 Description of Support Units ............................................................................................................. 19 3.4.1 Configuration of System under Test .................................................................................................. 19 3.5 General Description of Applied Standards ........................................................................................ 19 4 Test Types and Results (For 2.4GHz Band) ...................................................................................... 20 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 20 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 20 4.1.2 Test Instruments ................................................................................................................................ 21 4.1.3 Test Procedures ................................................................................................................................. 22 4.1.4 Deviation from Test Standard ............................................................................................................ 22 4.1.5 Test Set Up ........................................................................................................................................ 23 4.1.6 EUT Operating Conditions ................................................................................................................. 23 4.1.7 Test Results ....................................................................................................................................... 24 4.2 Conducted Emission Measurement .................................................................................................. 43 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 43 4.2.2 Test Instruments ................................................................................................................................ 43 4.2.3 Test Procedures ................................................................................................................................. 44 4.2.4 Deviation from Test Standard ...............................................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: RF150802C01-1 Page No. 1 / 59 Report Format Version:6.1.1 FCC Test Report Report No.: RF150802C01-1 FCC ID: MSQ-CMBT00 Test Model: CM-32_AC2600 Received Date: Aug. 02, 2015 Test Date: Nov. 19 ~ Nov. 30, 2015 Issued Date: Nov. 30, 2015 Applicant: ASUSTek COMPUTER INC. Address: 4F, NO. 150, LI-TE RD. PEITOU, TAIPEI 112, TAIWAN Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan, R.O.C. Test Location: No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, TAIWAN (R.O.C.) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150802C01-1 Page No. 2 / 59 Report Format Version:6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ...................................................................................................................... 5 2 Summary of Test Results ..................................................................................................................... 6 2.1 Measurement Uncertainty ................................................................................................................... 6 2.2 Modification Record ............................................................................................................................ 6 3 General Information .............................................................................................................................. 7 3.1 General Description of EUT ................................................................................................................ 7 3.2 Description of Test Modes ................................................................................................................... 8 3.2.1 Test Mode Applicability and Tested Channel Detail ............................................................................. 9 3.3 Duty Cycle of Test Signal ................................................................................................................... 11 3.4 Description of Support Units ............................................................................................................. 13 3.4.1 Configuration of System under Test .................................................................................................. 13 3.5 General Description of Applied Standards ........................................................................................ 13 4 Test Types and Results ...................................................................................................................... 14 4.1 Radiated Emission and Bandedge Measurement ............................................................................. 14 4.1.1 Limits of Radiated Emission and Bandedge Measurement .............................................................. 14 4.1.2 Test Instruments ................................................................................................................................ 15 4.1.3 Test Procedures ................................................................................................................................. 16 4.1.4 Deviation from Test Standard ............................................................................................................ 16 4.1.5 Test Set Up ........................................................................................................................................ 17 4.1.6 EUT Operating Conditions ................................................................................................................. 17 4.1.7 Test Results ....................................................................................................................................... 18 4.2 Conducted Emission Measurement .................................................................................................. 34 4.2.1 Limits of Conducted Emission Measurement .................................................................................... 34 4.2.2 Test Instruments ................................................................................................................................ 34 4.2.3 Test Procedures ................................................................................................................................. 35 4.2.4 Deviation from Test Standard .......................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

1 PHOTOGRAPHS OF THE TEST CONFIGURATION Conducted Emission Test 2 Radiated Emissions Test Above 1GHz 3 Radiated Emissions Test Below 1GHz

Contact Information

Applicant

Jackson Yen(Associate Vice President)

[email protected]+886-2-28943447Fax: +886-2-28987364

Test Firm

Bureau Veritas CPS (H.K.) Ltd., Taoyuan BranchRichard Chen

[email protected]+886-3-2600884Fax: +886-3-2115834

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	5.75 GHz - 5.83 GHz	557.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 32 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. This device has 20 MHz, 40 MHz and 80 MHz bandwidth modes.
