FCC ID: MSQ-G35CZ Date: May 22, 2020 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application as outlined below: Type of Confidentiality Requested Exhibit ☒ Permanent Block Diagrams ☐ Short Term External Photos ☐ Short Term Internal Photos ☒ Permanent Operation Description/Theory of Operation ☐ Permanent Parts List & Placement/BOM ☐ Permanent Tune-Up Procedure ☒ Permanent Schematics ☐ Short Term Test Setup Photos ☐ Short Term User’s Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Sincerely, ------------------------------------------------------ Jackson Yen / Associate Vice President ASUSTeK COMPUTER INC.

Declaration of Authorization We Name: ASUSTeK COMPUTER INC. Address: 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan City: Taipei Country: Taiwan Declare that: Name Representative of agent: Vincent Lin Agent Company name: DEKRA Testing and Certification Co., Ltd. Address: No.5-22, Ruishukeng, Linkou Dist., City: New Taipei City 24451, Country: Taiwan, R.O.C. is authorized to apply for certification of the following product(s): Product Name: Desktop PC Model: G35CZ FCC ID: MSQ-G35CZ IC: 3568A-G35CZ Trademark: ASUS on our behalf. This is valid until May 22, 2021, or until FCC and IC certification are completed, whichever comes sooner. Date: 2020/05/22 City: Taipei Name: Jackson Yen Function: Associate Vice President Signature:

Report No.: 2040330R-E3032110103 Page: 1 of 33 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 2040330R-E3032110103 Page: 2 of 33 (3) EUT Photo (4) EUT Photo Report No.: 2040330R-E3032110103 Page: 3 of 33 (5) EUT Photo

ASUSTeK COMPUTER INC. FCC ID.: MSQ-G35CZ 1F, No. 15, Lide Rd, Beitou, Taipei, Taiwan Tel : +886-2-28943447 FCC ID Label

ASUSTeK COMPUTER INC. FCC ID.: MSQ-G35CZ 1F, No. 15, Lide Rd, Beitou, Taipei, Taiwan Tel : +886-2-28943447 The FCC ID will be placed on the equipment as shown in the photograph below.

Report No.: 2040330R-E3032110103 Page: 1 of 31 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 2040330R-E3032110103 Page: 2 of 31 (3) EUT Photo (4) EUT Photo Report No.: 2040330R-E3032110103 Page: 3 of 31 (5) EUT Photo (6) EUT Photo Report No.: 2040330R-E3032110103 Page: 4 of 31 (7) EUT Photo (8) EUT Photo Report No.: 2040330R-E3032110103 Page: 5 of 31 (9) EUT Photo (10) EUT Photo_NFC Tag Report No.: 2040330R-E3032110103 Page: 6 of 31 (11) EUT Photo (12) EUT Photo Report No.: 2040330R-E3032110103 Page: 7 of 31 (13) EUT Photo (14) EUT Photo Report No.: 2040330R-E3032110103 Page: 8 of 31 (15) EUT Photo (16) EUT Photo_NFC Tag NFC Chip NFC Loop Antenna Report No.: 2040330R-E3032110103 Page: 9 of 31 (17) EUT Photo_NFC Tag (18) EUT Photo Report No.: 2040330R-E3032110103 Page: 10 of 31 (19) EUT Photo (20) EUT Photo Report No.: 2040330R-E3032110103 Page: 11 of 31 (21) EUT Photo (22) EUT Photo Report No.: 2040330R-E3032110103 Page: 12 of 31 (23) EUT Photo (24) EUT Photo Report No.: 2040330R-E3032110103 Page: 13 of 31 (25) EUT Photo (26) EUT Photo Report No.: 2040330R-E3032110103 Page: 14 of 31 (27) EUT Photo (28) EUT Photo Report No.: 2040330R-E3032110103 Page: 15 of 31 (29) EUT Photo (30) EUT Photo Report No.: 2040330R-E3032110103 Page: 16 of 31 (31) EUT Photo (32) EUT Photo Report No.: 2040330R-E3032110103 Page: 17 of 31 (33) EUT Photo (34) EUT Photo Report No.: 2040330R-E3032110103 Page: 18 of 31 (35) EUT Photo (36) EUT Photo Report No.: 2040330R-E3032110103 Page: 19 of 31 (37) EUT Photo (38) EUT Photo Report No.: 2040330R-E3032110103 Page: 20 of 31 (39) EUT Photo (40) EUT Photo Report No.: 2040330R-E3032110103 Page: 21 of 31 (41) EUT Photo_Antenna (42) EUT Photo_Antenna Report No.: 2040330R-E3032110103 Page: 22 of 31 (43) EUT Photo_Antenna (44) EUT Photo_Antenna Report No.: 2040330R-E3032110103 Page: 23 of 31 (45) EUT Photo (46) EUT Photo Report No.: 2040330R-E3032110103 Page: 24 of 31 (47) EUT Photo (48) EUT Photo Report No.: 2040330R-E3032110103 Page: 25 of 31 (49) EUT Photo (50) EUT Photo Report No.: 2040330R-E3032110103 Page: 26 of 31 (51) EUT Photo (52) EUT Photo Report No.: 2040330R-E3032110103 Page: 27 of 31 (53) EUT Photo (54) EUT Photo Report No.: 2040330R-E3032110103 Page: 28 of 31 (55) EUT Photo (56) EUT Photo Report No.: 2040330R-E3032110103 Page: 29 of 31 (57) EUT Photo (58) EUT Photo Report No.: 2040330R-E3032110103 Page: 30 of 31 (59) EUT Photo (60) EUT Photo Report No.: 2040330R-E3032110103 Page: 31 of 31 (61) EUT Photo

Report No.: 2040330R-E3082100013 Page: 1 of 5 RF Exposure Evaluation declaration Product Name : Desktop PC Model No. : G35CZ FCC ID : MSQ-G35DX Applicant : ASUSTeK Computer Inc Address : 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan Date of Receipt : Apr. 14, 2020 Date of Declaration : May 19, 2020 Report No. : 2040330R-E3082100013 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.: 2040330R-E3082100013 Page: 2 of 5 Issued Date: May 19, 2020 Report No.: 2040330R-E3082100013 Product Name Desktop PC Applicant ASUSTeK Computer Inc Address 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan Manufacturer ASUSTeK Computer Inc Model No. G35CZ FCC ID. MSQ-G35DX Trade Name ASUS Applicable Standard KDB 447498 D01 v06 Minimum test separation distance ≥ 20 cm For low power devices Test Result Complied Documented By : ( Senior Adm. Specialist / Genie Chang ) Tested By : ( Supervisor / Wen Lee ) Approved By : ( Director / Vincent Lin ) Report No.: 2040330R-E3082100013 Page: 3 of 5 1. GENERAL INFORMATION 1.1. EUT Description Product Name Desktop PC Model No. G35CZ Trade Name ASUS FCC ID MSQ-G35DX Frequency Range 13.56MHz Modulation ASK Antenna Type Loop Antenna Contain FCC ID PD9AX201NG (WLAN) 1.2. Antenna List : No. Manufacturer Part No. Antenna Type Peak Gain 1 AGEO ANTA0AA13761WLAN1 (Main, Aux) PIFA Antenna -2.13dBi for 2.4 GHz -6.02dBi for 5.15~5.25GHz -4.46dBi for 5.25~5.35GHz -3.55dBi for 5.47~5.725GHz -3.7dBi for 5.725~5.825GHz 2 ACON AYP6Y-100063 (Main, Aux) PIFA Antenna -2.32dBi for 2.4 GHz -5.50dBi for 5.15~5.25GHz -4.74dBi for 5.25~5.35GHz -3.36dBi for 5.47~5.725GHz -4.24dBi for 5.725~5.825GHz Note: Only the higher gain antenna was tested and recorded in this report. Report No.: 2040330R-E3082100013 Page: 4 of 5 2. RF Exposure Evaluation 2.1. Standard Applicable According to KDB 447498 D01 (7.1), A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. 2.2. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 3.0-30 1842/f 4.89/f 900/f 2 6 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 1.34-30 824/f 2.19/f 180/f 2 30 300-1500 -- -- F/1500 30 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneously transmitting antennas incorporated in a host device is ≤ 1.0. Report No.: 2040330R-E3082100013 Page: 5 of 5 2.3. Test Result of RF Exposure Evaluation Product : Desktop PC Test Item : RF Exposure Evaluation WLAN 2.4G Peak Gain: -2.13dBi; WLAN 5G Peak Gain: -3.36dBi Band Frequency Maximum Tune UP AV Power (dBm) Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) Limit (mW/cm2) Pass/Fail WLAN 2.4G 21 125.893 0.0153 1 Pass WLAN 5G 21 125.893 0.0116 1 Pass BT 2.4G 10.5 11.220 0.0014 1 Pass Note: The Maximum AV power is refer to to Original RF Exposure report FCC ID: PD9AX201NG. RFID: Frequency (MHz) H-Field (dBuV/3m) H-Field (ERP) (dBm) H-Field (ERP) (mW) Power Density at R = 20 cm (mW/cm2) Limit (mW/cm2) Pass/Fail 13.56 42.38 -54.99878745 0.0000032 0.0000000006 0.979 Pass Note: The H-Field is refer to report No.: 2040330R-E3032110103 from the DEKRA 2.4. Calculations for Multi-Transsmitter Worst Case Mode Max Power (mW) Power Density at R = 20 cm (mW/cm 2 ) Result Limit Pass/Fail WLAN 125.893 0.0153 0.017 1 Pass BT 11.220 0.0014 RFID 0.0000032 0.0000000006

Report No.: 2040330R-E3032110103 Page: 1 of 33 FCC Test Report Product Name Desktop PC Model No. G35CZ FCC ID MSQ-G35CZ Applicant ASUSTeK COMPUTER INC. Address 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan Date of Receipt Apr. 14, 2020 Issued Date May 18, 2020 Report No. 2040330R-E3032110103 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of DEKRA Testing and Certification Co., Ltd. Measurement uncertainties evaluated for each testing system and associated connections are given here to provide the system information for reference. Compliance determinations do not take into account measurement uncertainties for each testing system, but are based on the results of the compliance measurement. Report No.: 2040330R-E3032110103 Page: 2 of 33 Te s t R e p o r t Issued Date: May 18, 2020 Report No.: 2040330R-E3032110103 Product Name Desktop PC Applicant ASUSTeK COMPUTER INC. Address 1F., No. 15, Lide Rd., Beitou Dist., Taipei City 112, Taiwan Manufacturer ASUSTeK COMPUTER INC. Model No. G35CZ FCC ID. MSQ-G35CZ EUT Rated Voltage 100-120/200-240Vac, 9/4.5A, 50/60Hz EUT Test Voltage AC 120 V / 60 Hz Trade Name ASUS Applicable Standard FCC CFR Title 47 Part 15 Subpart C ANSI C63.4: 2014, ANSI C63.10: 2013 Test Result Complied Documented By : ( Senior Adm. Specialist / Genie Chang ) Tested By : ( Engineer / Trista Huang ) Approved By : ( Director / Vincent Lin ) Report No.: 2040330R-E3032110103 Page: 3 of 33 TA B L E O F C O N T E N T S Description Page 1. GENERAL INFORMATION ..................................................................................................... 4 1.1. EUT Description ............................................................................................................................ 4 1.2. Operational Description ................................................................................................................ 5 1.3. Tested System Datails.................................................................................................................... 6 1.4. Configuration of tested System ..................................................................................................... 7 1.5. EUT Exercise Software ................................................................................................................. 7 1.6. Test Facility ................................................................................................................................... 8 1.7. List of Test Equipment .................................................................................................................. 9 2. Conducted Emission .................................................................................................................. 12 2.1. Test Setup .................................................................................................................................... 12 2.2. Limits .......................................................................................................................................... 13 2.3. Test Procedure ............................................................................................................................. 13 2.4. Uncertainty .................................................................................................................................. 13 2.5. Test Result of Conducted Emission ............................................................................................. 14 3. Radiated Emission ..................................................................................................................... 16 3.1. Test Setup .................................................................................................................................... 16 3.2. Limits .......................................................................................................................................... 17 3.3. Test Procedure ............................................................................................................................. 18 3.4. Uncertainty .................................................................................................................................. 19 3.5. Test Result of Radiated Emission ................................................................................................ 20 4. Band Edge .................................................................................................................................. 26 4.1. Test Setup .................................................................................................................................... 26 4.2. Limits .......................................................................................................................................... 27 4.3. Test Procedure ............................................................................................................................. 27 4.4. Uncertainty .................................................................................................................................. 27 4.5. Test Result of Band Edge ............................................................................................................ 28 5. Frequency Tolerance ................................................................................................................. 30 5.1. Test Setup .................................................................................................................................... 30 5.2. Limits ...................................…

Text truncated - open the document above for the full version.

Report No.: 2040330R-E3032110103 Page : 1 of 3 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 2040330R-E3032110103 Page : 2 of 3 Front View of Radiated Test Back View of Radiated Test Report No.: 2040330R-E3032110103 Page : 3 of 3 Front View of Radiated Test-LOOP Back View of Radiated Test-LOOP
