MSQ-PCEN10ASUS 150Mbps 802.11 b/g/n Wireless PCI-E card

ASUSTeK Computer Inc

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jan 30, 2011
Application Purpose: Original Equipment
Date of Application: Jan 30, 2011
Equipment Note: ASUS 150Mbps 802.11 b/g/n Wireless PCI-E card
Frequency Range: 2422.00000000 - 2452.00000000
Company: ASUSTeK Computer Inc
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wireless Local Area Network Card (For 802.11 g/b/n Wireless Networks) PCE-N10 User Manual January 2011 Copyright © 2009 ASUSTeK Computer Inc. All Rights Reserved. No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK Computer Inc. (“ASUS”). Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. Manufacturer contact information ASUSTeK Computer Inc. (Asia-Pacific) Company address: Telephone: Fax: E-mail: Web site: 15 Li-Te Road, Beitou, Taipei 11259 +886-2-2894-3447 +886-2-2890-7798 [email protected] http://www.asus.com.tw ASUS Computer International (America) Company address: General (tel): General (fax): Web site address: +1-510-739-3777 +1-510-608-4555 800 Corporate Way, Fremont, CA 94539, USA http://usa.asus.com Technical support General support: Support (fax): Online support: +1-502-995-0883 +1-502-933-8713 http://vip.asus.com/eservice/techserv.aspx ASUS Computer GmbH (Germany & Austria) Company address: General (tel): General (fax): Web site address: Online contact: +49-02102-95990 +49-02102-959911 Harkortstr. 21-23, 40880 Ratingen, Germany http://www.asuscom.de http://www.asuscom.de/sales Technical support Components: Fax: Online support: +49-02102-95990 +49-02102-959911 http://vip.asus.com/eservice/techserv.aspx?SLanguage=de-de PCE-N10 WLAN Card User Manual Table of contents 1. Introduction ..........................................................................................1 1.1 Package contents ............................................................................1 1.2 System requirements .......................................................................1 1.3 Hardware .........................................................................................1 2. Installing the PCE-N10 driver and utilities ..........................................2 3. Configuring PCE-N10 using ASUS utility............................................3 3.1 Connecting to a wireless network manually .....................................3 3.2 Connecting to a wireless network using WPS .................................4 3.3 Soft AP mode (Windows ® XP/Vista) .................................................5 & 6 4. Software information ......................................................................... 7 4.1 ASUS WLAN Control Center ......................................................... 7 4.2 ASUS WLAN Card Setting Utility ................................................... 7 5. Configuring PCE-N10 using Windows® WZC service ......................13 6. Troubleshooting .................................................................................14 7. Glossary..............................................................................................16 ASUS WLAN Card 1 PCE-N10 WLAN Card User Manual ASUS WLAN Card Notice Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:  Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. FCC Caution: Any …

Text truncated - open the document above for the full version.

Cover Letter(s)

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 1 Rev 2.0 SPORTON International Inc. No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw 1/26/2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SPORTON International Inc. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product Name: ASUS 150Mbps 802.11 b/g/n Wireless PCI-E card Model Number: PCE-N10 We affirm that between SIEMIC and SPORTON International Inc., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Signature: Name / title: Wayne Hsu / Vice Manager Contact information / address: No. 52, Hwa Ya 1st Rd., Kwei-Shan Hsiang, TaoYuan Hsien, Taiwan, R.O.C. / Ph: 886-3-327-3456 / FAX: 886-3-327-0973 / www.sporton.com.tw

External Photos

FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C1 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 APPENDIX C. Photographs of EUT FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C2 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C3 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C4 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C5 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C6 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C7 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C8 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C9 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC TEST REPORT SPORTON International Inc. PAGE NUMBER : C10 OF C10 TEL : 886-2-2696-2468 ISSUED DATE : Jan. 21, 2011 FAX : 886-2-2696-2255

ID Label/Location Info

FCC ID: MSQ-PCEN10 Model:PCE-N10 35 * 25 mm r :1mm 28x5 28x5 CCXXxxYYyyyZzW

Internal Photos

RF Exposure Info

FCC TEST REPORT Report No.: FR0D0219-01AC Page No. : A1 of A3 FCC ID : MSQ-PCEN10 Appendix A. Maximum Permissible Exposure FCC TEST REPORT Report No.: FR0D0219-01AC Page No. : A2 of A3 FCC ID : MSQ-PCEN10 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m²) = 377 2 E E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. FCC TEST REPORT Report No.: FR0D0219-01AC Page No. : A3 of A3 FCC ID : MSQ-PCEN10 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11b/g: 17.72dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 5 3.162278 17.72 59.1562 0.0372

RF Exposure Info

Page No. : A1 of A3 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI Appendix A. Maximum Permissible Exposure Page No. : A2 of A3 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI 1. Maximum Permissible Exposure 1.1. Applicable Standard Systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess limit for maximum permissible exposure. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as a mobile device whereby a distance of 0.2 m normally can be maintained between the user and the device. (A) Limits for Occupational / Controlled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-3.0 614 1.63 (100)* 6 3.0-30 1842 / f 4.89 / f (900 / f)* 6 30-300 61.4 0.163 1.0 6 300-1500 F/300 6 1500-100,000 5 6 (B) Limits for General Population / Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/ cm²) Averaging Time |E|²,|H|² or S (minutes) 0.3-1.34 614 1.63 (100)* 30 1.34-30 824/f 2.19/f (180/f)* 30 30-300 27.5 0.073 0.2 30 300-1500 F/1500 30 1500-100,000 1.0 30 Note: f = frequency in MHz ; *Plane-wave equivalent power density 1.2. MPE Calculation Method E (V/m) = d GP30 Power Density: Pd (W/m²) = 377 2 E E = Electric field (V/m) P = Peak RF output power (W) G = EUT Antenna numeric gain (numeric) d = Separation distance between radiator and human body (m) The formula can be changed to Pd = 2 377 30 d GP   From the peak EUT RF output power, the minimum mobile separation distance, d=0.2m, as well as the gain of the used antenna, the RF power density can be obtained. Page No. : A3 of A3 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI 1.3. Calculated Result and Limit Antenna Type : Dipole Antenna Max Conducted Power for IEEE 802.11n: 16.00 dBm Test Mode Min. User Distance (cm) Gain (dBi) Numeric Gain Conducted Power (dBm) Conducted Power (mW) Power Density (mW/cm2) 2.4G 20 5 1.122018 16.00 39.8107 0.0251

Test Report

SPORTON International Inc. Report Format Version: a F FCC TEST REPORT Report No. : FR0D0219-01AC FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : ASUS 150Mbps 802.11b/g/n Wireless PCI-E card Model No. : PCE-N10 Brand Name : ASUS Filing Type : New Application Applicant : ASUSTek COMPUTER INC. No.150, Li-Te Rd., Peitou, Taipei, Taiwan FCC ID : MSQ-PCEN10 Manufacturer : ASUSTek COMPUTER INC. No.150, Li-Te Rd., Peitou, Taipei, Taiwan Received Date : Dec. 20, 2010 Final Test Date : Dec. 29, 2010 Statement Test result included is only for the 802.11b/g part of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AC Table of Contents 1 SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2 GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Product Details ................................................................................................................................................................................... 3 2.2 Table for Filed Antenna ....................................................................................................................................................................... 3 2.3 Table for Carrier Frequencies ............................................................................................................................................................. 3 2.4 Table for Test Modes .......................................................................................................................................................................... 4 2.5 Table for Testing Locations ................................................................................................................................................................. 4 2.6 Table for Supporting Units .................................................................................................................................................................. 4 2.7 Table for Parameters of Test Software Setting .................................................................................................................................... 5 2.8 EUT Operation during Test ................................................................................................................................................................. 5 2.9 Test Configuration ............................................................................................................................................................................... 6 3 TEST RESULT ......................................................................................................................................................... 7 3.1 AC Power Line Conducted Emissions Measurement .......................................................................................................................... 7 3.2 Maximum Peak Output Power Measurement .................................................................................................................................... 11 3.3 Test Procedures................................................................................................................................................................................ 11 3.4 Power Spectral Density Measurement .............................................................................................................................................. 13 3.5 6dB Spectrum Bandwidth Measurement ........................................................................................................................................... 19 3.6 Radiated Emissions Measurement .................................................................................................................................................... 25 3.7 Band Edge and Fundamental Emissions Measurement .................................................................................................................... 43 3.8 Antenna Requirements ..................................................................................................................................................................... 48 4 LIST OF MEASURING EQUIPMENTS .................................................................................................................. 49 5 TEST LOCATION ................................................................................................................................................... 51 6 TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 52 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE ................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF EUT ......................................................................................…

Text truncated - open the document above for the full version.

Test Report

SPORTON International Inc. Report Format Version: a F FCC TEST REPORT Report No. : FR0D0219-01AI FCC RADIO TEST REPORT according to 47 CFR FCC Part 15 Subpart C § 15.247 Equipment : ASUS 150Mbps 802.11b/g/n Wireless PCI-E card Model No. : PCE-N10 Brand Name : ASUS Filing Type : New Application Applicant : ASUSTek COMPUTER INC. No.150, Li-Te Rd., Peitou, Taipei, Taiwan FCC ID : MSQ-PCEN10 Manufacturer : ASUSTek COMPUTER INC. No.150, Li-Te Rd., Peitou, Taipei, Taiwan Received Date : Dec. 16, 2010 Final Test Date : Dec. 29, 2010 Statement Test result included is only for the 802.11n of the product. The test result in this report refers exclusively to the presented test model / sample. Without written approval of SPORTON International Inc., the test report shall not be reproduced except in full. The measurements and test results shown in this test report were made in accordance with the procedures and found in compliance with the limit given in ANSI C63.4-2003 and 47 CFR FCC Part 15 Subpart C. The test equipment used to perform the test is calibrated and traceable to NML/ROC. SPORTON International Inc. No. 52 Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON International Inc. Page No. : i of ii TEL : 886-2-2696-2468 Issued Date : Jan. 21, 2011 FAX : 886-2-2696-2255 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI Table of Contents 1 SUMMARY OF THE TEST RESULT ....................................................................................................................... 2 2 GENERAL INFORMATION ...................................................................................................................................... 3 2.1 Product Details ................................................................................................................................................................................... 3 2.2 Table for Filed Antenna ....................................................................................................................................................................... 3 2.3 Table for Carrier Frequencies ............................................................................................................................................................. 4 2.4 Table for Test Modes .......................................................................................................................................................................... 5 2.5 Table for Testing Locations ................................................................................................................................................................. 5 2.6 Table for Supporting Units .................................................................................................................................................................. 5 2.7 Table for Parameters of Test Software Setting .................................................................................................................................... 6 2.8 EUT Operation during Test ................................................................................................................................................................. 6 2.9 Test Configuration ............................................................................................................................................................................... 7 3 TEST RESULT ......................................................................................................................................................... 8 3.1 AC Power Line Conducted Emissions Measurement .......................................................................................................................... 8 3.2 Maximum Peak Output Power Measurement .................................................................................................................................... 13 3.3 Test Procedures................................................................................................................................................................................ 13 3.4 Power Spectral Density Measurement .............................................................................................................................................. 15 3.5 6dB Spectrum Bandwidth Measurement ........................................................................................................................................... 21 3.6 Radiated Emissions Measurement .................................................................................................................................................... 27 3.7 Band Edge and Fundamental Emissions Measurement .................................................................................................................... 45 3.8 Antenna Requirements ..................................................................................................................................................................... 50 4 LIST OF MEASURING EQUIPMENTS .................................................................................................................. 51 5 TEST LOCATION ................................................................................................................................................... 53 6 TAF CERTIFICATE OF ACCREDITATION ........................................................................................................... 54 APPENDIX A. MAXIMUM PERMISSIBLE EXPOSURE ................................................................................. A1 ~ A3 APPENDIX B. TEST PHOTOS ........................................................................................................................ B1 ~ B6 APPENDIX C. PHOTOGRAPHS OF EUT .............................................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Page No. : B1 of B6 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI Appendix B. Test Photos Page No. : B2 of B6 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI 1 Photographs of Conducted Emissions Test Configuration FRONT VIEW REAR VIEW Page No. : B3 of B6 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI SIDE VIEW Page No. : B4 of B6 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI 2 Photographs of Radiated Emissions Test Configuration For radiated emissions 9kHz~30MHz FRONT VIEW REAR VIEW Page No. : B5 of B6 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI For radiated emissions 30MHz~1GHz FRONT VIEW REAR VIEW Page No. : B6 of B6 FCC ID : MSQ-PCEN10 F FCC TEST REPORT Report No. : FR0D0219-01AI For radiated emissions above 1GHz FRONT VIEW REAR VIEW

Contact Information

Applicant

Jackson Yen(Associate Vice President)

[email protected]+886-2-28943447Fax: +886-2-28987364

Test Firm

Sporton International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.42 GHz - 2.45 GHz	40.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
