  1. Home/
  2. ASUSTeK Computer Inc/
  3. MSQ-RK903

MSQ-RK903ASUS Home Gateway

ASUSTeK Computer Inc
ASUS Home Gateway - FCC ID MSQ-RK903 - ASUSTeK Computer Inc
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Apr 01, 2015
Application Purpose
Original Equipment
Date of Application
Mar 30, 2015
Equipment Note
ASUS Home Gateway
Frequency Range
2402.00000000 - 2480.00000000
Company
ASUSTeK Computer Inc
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Cover Letter(s)

↗
↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

E10086 First Edition February 2015 ASUS HG100 Quick Start Guide IMPORTANT! • Follow the instructions presented in this user guide. • The power adapter may vary per region or country. • Do not use damaged cable, power adapters, and other peripherals. Thanks for your purchase! ASUS HG100 provides you with the most powerful home security system, complete control over your home, and energy saving solutions. Package contents NOTE: If any of the following items is damaged or missing, contact your retailer. The illustrated items below are for reference only. Actual product specifications may vary per country or model. ASUS HG100 Power adapter Power cable ASUS Tablet Technical documentations and warranty card 2 Product specifications Dimension152*67*167 mm Weight256g ButtonPower on/off button; AP router reset button PortPower, Micro USB, HDMI, Ethernet Miracast1920 x 1088 Pixels MemoryDRAM 2GB; NAND Flash 16GB Wireless Protocol WiFi 802.11b/g/n; ZigBee PRO (Future Support: Bluetooth, Z-wave, Thread) Zigbee ModuleCEL’s MeshConnect (TM) EM357 Module PowerAC 100V-240V P2PRemote Control CloudASUS Cloud Service (No webstorage) NOTE: Specifications subject to change without notice. ASUS Cloud Service ASUS Cloud Service is a self learning cloud that automatically gathers data about the user, memorizes the setting preferences of the use, and computes the data gathered to provide energy saving solutions based on the user habit. NOTE: ASUS Cloud Service needs to gather at least three (3) months of user data before using it for the first time. 3 Product overview Front View LED status indicator The LED status indicator helps identify the current status of your ASUS HG100. Refer to the following table for details: ColorStatus Solid Blue HG100 and AP-Router connected Fast Blinking Blue HG100 and AP-Router not connected Fast Blinking Red Warning Slow Blinking Blue Connecting device 4 Ethernet port Back View Power input port HDMI port Micro USB expansion port* NOTE: The micro USB expansion port is reserved for expansions only. Bottom View Power button Reset button 5 Using your HG100 Setting up hardware 1. Connect the bundled power cable to the power adapter. 2. Plug the power adapter into a power source. 3. Connect the power cable into your ASUS HG100’s power input port. NOTE: The power adapter may vary per region or country. IMPORTANT! Power adapter information: • Input voltage: 100-240Vac • Input frequency: 60Hz • Rating output current: 3.42A (65W) • Rating output voltage: 19V 6 4. Press press and hold the power button for about six (6) seconds until your HG100 powers on. Downloading ASUS Smart Home APP 1. Connect your phone to the Internet, then log on or sign up for a Google account. 2. Open Play Store on your phone. 3. Search for ASUS Smart Home, then select INSTALL. You can also Scan the following QR code to download the ASUS Smart Home App onto your smartphone: 7 Using ASUS Smart Home APP 1. Run the ASUS Smart Home App. 2. Enter your ASUS ID, Password, and tap Sign in. If you do not have an account yet, tap Sign Up. IMPORTANT! Ensure you have Internet connection before choosing any of the following sign in options. 3. Choose the Home Box you would like to connect and follow the onscreen instructions. 8 Home Control The Home Control screen allows you to view your connected devices and home places. You can also turn the connected devices ON or OFF on the Home Control screen. Adding devices Add devices to your Home Control screen by tapping My Device, then tap the icon, and then follow the onscreen instructions. Adding Places Grouping devices by place makes it easier to manage and control. Group your connected devices by tapping My Place, then tap the icon, and then follow the onscreen instructions. 9 Home Action The Home Action screen allows you to view the actions you set to perform when a condition is triggered. You can also turn the actions ON or OFF on the Home Action screen. Adding actions You can add actions to perform when a condition is triggered. Add actions by tapping the icon on the Home Action screen, and then follow the onscreen instructions. 10 Peripheral products Connect various products to your ASUS HG100 to turn your home into a smart home and change your way of life. Smart life Smart life gives you complete control over your home appliances. Connect smart home appliances and transform your home into a convenient smart home. Green life Green life provides you with power saving solutions. Connect smart energy devices and keep track of the power consumption in your home. Security life Security life allows you to monitor your home at anytime. Connect smart security devices and receive notifications whenever an alarm has been triggered. For a complete list of supported products, please refer to ASUS website: http://www.asus.com/ 11 Federal Communications Commission Interference Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving anten…

Text truncated - open the document above for the full version.

External Photos

Report No.: 14C0096R-RFUSP01V00 Page : 1 of 2 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 2 of 2 (3) EUT Photo

ID Label/Location Info

ASUSTeK Computer Inc FCC ID.: MSQ-RK903 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Tel : +886-2-28943447 FCC ID Label

ID Label/Location Info

ASUSTeK Computer Inc FCC ID.: MSQ-RK903 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Tel : +886-2-28943447 The FCC ID Label will be placed on the equipment as shown in the photograph below.

Internal Photos

Report No.: 14C0096R-RFUSP01V00 Page : 1 of 13 Attachment 2 : EUT Detailed Photographs (4) EUT Photo (5) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 2 of 13 (6) EUT Photo (7) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 3 of 13 (8) EUT Photo (9) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 4 of 13 (10) EUT Photo (11) EUT Photo WLAN/BT Module Report No.: 14C0096R-RFUSP01V00 Page : 5 of 13 (12) EUT Photo (13) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 6 of 13 (14) EUT Photo (15) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 7 of 13 (16) EUT Photo (17) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 8 of 13 (18) EUT Photo (19) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 9 of 13 (20) EUT Photo (21) EUT Photo (22) EUT Photo Zigbee Module Report No.: 14C0096R-RFUSP01V00 Page : 10 of 13 Report No.: 14C0096R-RFUSP01V00 Page : 11 of 13 (23) EUT Photo (24) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 12 of 13 (25) EUT Photo (26) EUT Photo Report No.: 14C0096R-RFUSP01V00 Page : 13 of 13 (27) EUT Photo (28) EUT Photo

RF Exposure Info

Report No. 14C0096R-RFUSP02V00 Page: 1 of 3 RF Exposure Evaluation declaration Product Name ASUS Home Gateway Model No. HG100 FCC ID MSQ-RK903 Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date of Receipt Nov. 28, 2014 Date of Declaration Jan. 22, 2015 Report No. 14C0096R-RFUSP02V00 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No. 14C0096R-RFUSP02V00 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78% RH. Report No. 14C0096R-RFUSP02V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : ASUS Home Gateway Test Item : RF Exposure Evaluation Test Site : No.3 OATS Operation Frequency Maximum Conducted output power 23.56dBm Antenna gain -1.55dBi Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 226.9865 0.031603 Power density is lower than the limit (1 mW/cm2).

Test Report

Report No.: 14C0096R-RFUSP04V00 Page: 1 of 42 FCC Test Report Product Name ASUS Home Gateway Model No. HG100 FCC ID. MSQ-RK903 Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date of Receipt Nov. 28, 2014 Issued Date Jan. 22, 2015 Report No. 14C0096R-RFUSP04V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 14C0096R-RFUSP04V00 Page: 2 of 42 Test Report Issued Date: Jan. 22, 2015 Report No.: 14C0096R-RFUSP04V00 Product Name ASUS Home Gateway Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Manufacturer Gemtek Technology Co., Ltd. Model No. HG100 FCC ID. MSQ-RK903 EUT Rated Voltage AC 100-240V~50/60Hz EUT Test Voltage AC 120V/60Hz Trade Name ASUS Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2013 ANSI C63.10: 2009, KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By : ( Senior Adm. Specialist / Joanne Lin ) Tested By : ( Engineer / Nova Chu ) Approved By : ( Director / Vincent Lin ) Report No.: 14C0096R-RFUSP04V00 Page: 3 of 42 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ...............................................................................................................4 1.1. EUT Description......................................................................................................................................4 1.2. Operational Description...........................................................................................................................6 1.3. Tested System Details..............................................................................................................................7 1.4. Configuration of Tested System ..............................................................................................................7 1.5. EUT Exercise Software ...........................................................................................................................7 1.6. Test Facility .............................................................................................................................................8 2. CONDUCTED EMISSION ..................................................................................................................9 2.1. Test Equipment ........................................................................................................................................9 2.2. Test Setup ................................................................................................................................................9 2.3. Limits.....................................................................................................................................................10 2.4. Test Procedure .......................................................................................................................................10 2.5. Uncertainty ............................................................................................................................................10 2.6. Test Result of Conducted Emission .......................................................................................................11 3. PEAK POWER OUTPUT ..................................................................................................................13 3.1. Test Equipment ......................................................................................................................................13 3.2. Test Setup ..............................................................................................................................................13 3.3. Limit .....................................................................................................................................................13 3.4. Test Procedure .......................................................................................................................................13 3.5. Uncertainty ............................................................................................................................................13 3.6. Test Result of Peak Power Output .........................................................................................................14 4. RADIATED EMISSION .....................................................................................................................15 4.1. Test Equipment ......................................................................................................................................15 4.2. Test Setup ..............................................................................................................................................15 4.3. Limits.....................................................................................................................................................16 4.4. Test Procedure .......................................................................................................................................18 4.5. Uncertainty ............................................................................................................................................18 4.6. Test Result of Radiated Emission ..........................................................................................................19 5. RF ANTENNA CONDUCTED TEST................................................................................................23 5.1. Test Equipment ....................................…

Text truncated - open the document above for the full version.

Test Report

Report No.: 14C0096R-RFUSP02V00 Page : 1 of 70 FCC Test Report Product Name ASUS Home Gateway Model No HG100 FCC ID. MSQ-RK903 Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date of Receipt Nov. 28, 2014 Issue Date Jan. 22, 2015 Report No. 14C0096R-RFUSP02V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 14C0096R-RFUSP02V00 Page : 2 of 70 Test Report Issue Date: Jan. 22, 2015 Report No.: 14C0096R-RFUSP02V00 Product Name ASUS Home Gateway Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Manufacturer Gemtek Technology Co., Ltd. Model No. HG100 FCC ID. MSQ-RK903 EUT Rated Voltage AC 100-240V~50/60Hz EUT Test Voltage AC 120V/60Hz Trade Name ASUS Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2013 ANSI C63.10: 2009, KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By : ( Senior Adm. Specialist / Joanne Lin ) Tested By : ( Engineer / Nova Chu ) Approved By : ( Director / Vincent Lin ) Report No.: 14C0096R-RFUSP02V00 Page : 3 of 70 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. Tested System Details....................................................................................................................8 1.4. Configuration of Tested System ....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................11 2.4. Test Procedure .............................................................................................................................11 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................13 3.1. Test Equipment............................................................................................................................14 3.2. Test Setup ....................................................................................................................................14 3.3. Limits ..........................................................................................................................................14 3.4. Test Procedure .............................................................................................................................14 3.5. Uncertainty ..................................................................................................................................14 3.6. Test Result of Peak Power Output...............................................................................................15 4. Radiated Emission .....................................................................................................................17 4.1. Test Equipment............................................................................................................................18 4.2. Test Setup ....................................................................................................................................19 4.3. Limits ..........................................................................................................................................20 4.4. Test Procedure .............................................................................................................................21 4.5. Uncertainty ..................................................................................................................................21 4.6. Test Result of Radiated Emission................................................................................................22 5. RF antenna conducted test........................................................................................................33 5.1. Test Equipment............................................................................................................................34 5.2. Test Setup ....................................................................................................................................34 5.3. Lim…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: 14C0096R-RFUSP01V00 Page : 1 of 3 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 14C0096R-RFUSP01V00 Page : 2 of 3 Front View of Radiated Test Back View of Radiated Test Report No.: 14C0096R-RFUSP01V00 Page : 3 of 3 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)

Contact Information

Applicant

Jackson Yen(Associate Vice President)
[email protected]+886-2-28943447Fax: +886-2-28987364

Technical Contact

QuieTek CorporationMaggie Chen
[email protected]

No. 5-22, Rueishu Keng, Linkou Dist., · New Taipei City · Taiwan

Test Firm

DEKRA Testing and Certification Co., Ltd.Sky Hsu
[email protected]886-2-86013788Fax: 886-2-86013789

Technical Specifications

#Rule PartsFrequency RangePower Output
215C2.40 GHz - 2.48 GHz7.70 mW
Confidentiality
Long Term
Grant Notes
Power Output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device contains Bluetooth transmitter.
