ZenWiFi Hybrid MoCA Mesh Router Model: XC5 Quick Start Guide 1 Plug the adapter into the DCIN port. 2 The power LED will light up when your hardware is ready. Hardware Explanations XC5 Overview Before Setup ASUS Router App AiMesh Setup Steps Troubleshooting 1 Find two ZenWiFi XC5, and power them on. 2 Use a network cable to connect your modem to the WAN port of either ZenWiFi XC5. This ZenWiFi XC5 will be the AiMesh router, and the other ZenWiFi XC5 will be the AiMesh node. 3 The LED turns solid blue to indicate that ZenWiFi XC5 is ready for setup. Preparing to set up an AiMesh WiFi system AiMesh Setup Steps AiMesh router AiMesh node Download free ASUS Router APP to set up and manage your router(s). Prepare 01 Place your ZenWiFi XC5 router and node within 3 meters of each other during the setup process. AiMesh node 02 Keep your AiMesh node powered on and standby for AiMesh system settings. Launch ASUS Router APP, and then follow the on-screen instructions to finish the AiMesh setup. Launching ASUS Router APP 03 If your AiMesh router cannot find any AiMesh node nearby or synchronization fails, please check the following and try again. a Move your AiMesh node closer to the AiMesh router. Ensure that it is within 3 meters. b Your AiMesh node is powered on. DC Power adapter DC Output: +12V with max 1.5A current Operating Temperature 0~40 o CStorage0~70 o C Operating Humidity 50~90%Storage20~90% Specifications: LAN port DCIN port WAN/LAN port within 3 meters AiMesh router AiMesh node E21994 MoCA port MoCA Link LED WAN/LAN port Connect your modem to this port with a net- work cable. LAN port Connect a network cable into this port to establish LAN connection. MoCA port Connect a coaxial cable into this port to estab- lish MoCA connection. MPS/WPS combo button Reset button Solid white: MoCA network is connected. Blinking white: Transmitting or receiving data via MoCA connection MoCA link LED indications MPS/WPS combo button Press this button to start WPS or MPS MoCA pairing. WPS pairing: Press the button on XC5 and a new wire- less client to establish Wi-Fi connection. MPS pairing (add a new XC5): Press the button on XC5 in the existing Mesh System first and then press the MPS button on the new XC5 mesh router. After a short time, the new XC5 will be integrated into your existing Mesh System. MPS pairing (add a new MoCA device): Press the button on XC5 in the existing Mesh System first and then press the MPS button on the new MoCA device. After a short time, the new MoCA device will be integrated into your existing MoCA network. Reset button: Press this button to reset or restore the system to its factory settings. Relocation THE BEST PERFORMANCE Locate the AiMesh router and node close to your existing coaxial port. NOTES: For better transmission quality, ensure that you use RG6 coaxial cables in the network environment. The operating frequency range of MoCA 2.5 is 1,125MHz ~ 1,675MHz. Since some splitters may not be able to work properly (e.g., abnormal transmission) within the range, please make sure that the operating frequency of the splitter you use in the network matches that of MOCA 2.5. To minimize Wi-Fi interference, keep the routers away from devices like cordless phones, Bluetooth devices and microwave ovens. Q1: Could XC5 be used with a MoCA adapter, or join an existing MoCA network? A: Yes. XC5 is compatible with MoCA-compliant devices. To activate MPS, press and hold the MPS/WPS combo button for 3 seconds and wait for the front LED to blink blue. ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components, as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed recycling information in different regions. REACH Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC RF Caution Statement: WARNING : Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. WARNING! Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Prohibition of Co-location This device and its antenna(s) must not be co-located or operating in …
