Nexus Player TV500I User Manual ASUS Package Content Nexus Player Remote AAA battery * 2 for remote Power adapter Quick Start Guide Safety & Warranty Booklet Nexus Play Top view Nexus Player Bottom view Bluetoothġ Pairing buttonġ HDMI outputġ Micro USBġ Power inputġ Remote Front view Microphone for voice inputġ Microphone button for voice search ġ D-pad buttons (4 directions)ġ Back ġ Home ġ Play/Pauseġ Select buttonġ Remote Rear view Battery capġ Install Your Player A. Connect your Player to TV ================================================================= IMPORTANT l User only the bundled power adapter to the correct power outlet with the correct input rating. The output voltage of this power adapter is DC 12V, 1.5A. l Peel the protective film off from the power adapter before installation. ================================================================= Install Your Player B. Pair your remote with Player through wireless Bluetooth technology to enjoy Internet TV contents. Install Your Player C. Pair your gamepad with Player through wireless Bluetooth technology to enjoy game console-like APP games. Gamedpad (sold separately )ġ HDMIġ Safety + Warranty English / Français Safety + Warranty ENGLISH Contents Contents Federal Communications Commission Statement 1-3 RF Exposure warning 1-5 Canada, Industry Canada (IC) Notices 1-7 EC Declaration of Conformity 1-9 ASUS Recycling/Takeback services 1-11 Regional notice for California 1-12 Copyright information 1-13 Limitation of liability 1-15 Service and support 1-17 Warranty period of the Product 1-18 1-3 This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance 1.0 Federal Communications Commission Statement Federal Communications Commission Statement 1-4 with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by doing one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Warranty and Safety / 1.0 Federal Communications Commission Statement 1-5 2.0 RF Exposure warning This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. RF Exposure warning 1-6 This device is operates in the 5150-5250 MHz frequency range, and is restricted to indoor use only. Outdoor operation in this range is prohibited. This device is slave equipment. It does not detect radar and is not intended for an-hoc operation in DFS band. Warranty and Safety / 2.0 RF Exposure warning 1-7 3.0 Canada, Industry Canada (IC) Notices Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. The IC ID for this device is 3568A-TV500I. CAN ICES-3(B)/NMB-3(B). Canada, Industry Canada (IC) Notices 1-8 Under Industry Canada regulations, the radio transmitter(s) in this device may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication. Radio Frequency (RF) Exposure Information The radiated output power of the Wireless Device is below the Industry Canada (IC) radio frequency exposure limits. The Wireless Device should be used in such a manner such that the potential for human contact during normal operation is minimized. This device has also been evaluated and shown compliant with the IC RF Exposure limits under mobile exposure conditions. (antennas are greater than 20cm from a person’s body). Warranty and Safety / 3.0 Canada, avis d’Industrie Canada (IC) 1-9 4.0 EC Declaration of Conformity This product is compliant with the regulations of the R&TTE Directive 1999/5/EC. The Declaration of Conformity can be downloaded from http://support.asus.com. EC Declaration of Conformity CE Mark Warning CE marking for devices with wireless LAN/ Bluetooth This equipment complies with the requirements of Directive 1999/5/ EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommuni…

Text truncated - open the document above for the full version.

Report No.: 1480461R-RFUSP25V00 Page : 1 of 13 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 2 of 13 (3) EUT Photo (4) EUT Photo 120mm

ASUSTeK COMPUTER INC. FCC ID.: MSQ-TV500I 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Tel : +886-2-28943447 FCC ID Label

ASUSTeK COMPUTER INC. FCC ID.: MSQ-TV500I 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Tel : +886-2-28943447 The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below.

Report No.: 1480461R-RFUSP25V00 Page : 3 of 13 (5) EUT Photo (6) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 4 of 13 (7) EUT Photo (8) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 5 of 13 (9) EUT Photo (10) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 6 of 13 (11) EUT Photo (12) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 7 of 13 (13) EUT Photo (14) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 8 of 13 (15) EUT Photo (16) EUT Photo (BT+WiFi Antenna) Report No.: 1480461R-RFUSP25V00 Page : 9 of 13 (17) EUT Photo (WiFi Antenna) (18) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 10 of 13 (19) EUT Photo (20) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 11 of 13 (21) EUT Photo (22) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 12 of 13 (23) EUT Photo (24) EUT Photo Report No.: 1480461R-RFUSP25V00 Page : 13 of 13 (25) EUT Photo (26) EUT Photo

Report No.: 1480461R-RFUSP01V00 Page: 1 of 3 RF Exposure Evaluation declaration Product Name Nexus Player Model No. TV500I FCC ID MSQ-TV500I Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date of Receipt Aug. 20, 2014 Date of Declaration Oct. 06, 2014 Report No. 1480461R-RFUSP01V00 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1480461R-RFUSP01V00 Page: 2 of 3 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No.: 1480461R-RFUSP01V00 Page: 3 of 3 1.3. Test Result of RF Exposure Evaluation Product : Nexus Player Test Item : RF Exposure Evaluation Test Site : No.3 OATS Operation Frequency 2412-2462MHz, 2402-2480MHz 5745-5825MHz, 5755-5795MHz 5180-5240MHz, 5190-5230MHz 5300-5700MHz, 5270-5670MHz 5720MHz, 5710MHz 5210-5290MHz, 5530-5690MHz, 5775MHz Maximum Conducted output power 22.52dBm Antenna gain 3.86dBi Output Power Into Antenna & RF Exposure Evaluation Distance: Output Power to Antenna (mW) Power Density at R = 20 cm (mW/cm2) 178.6488 0.086443 Power density is lower than the limit (1 mW/cm2).

Report No.: 1480461R-RFUSP01V00-A Page: 1 of 43 FCC Test Report Product Name Nexus Player Model No. TV500I FCC ID. MSQ-TV500I Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date of Receipt Aug. 20, 2014 Issued Date Oct. 06, 2014 Report No. 1480461R-RFUSP01V00-A Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1480461R-RFUSP01V00-A Page: 2 of 43 Test Report Issued Date: Oct. 06, 2014 Report No.: 1480461R-RFUSP01V00-A Product Name Nexus Player Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Manufacturer Digitek (Chongqing) Limited Model No. TV500I FCC ID. MSQ-TV500I EUT Rated Voltage AC 100-240V, 50/60Hz EUT Test Voltage AC 120V/60Hz Trade Name nexus; ASUS Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2013 ANSI C63.10: 2009, KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By: ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Jack Hsu ) Approved By : ( Director / Vincent Lin ) Report No.: 1480461R-RFUSP01V00-A Page: 3 of 43 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION ...............................................................................................................4 1.1. EUT Description......................................................................................................................................4 1.2. Operational Description...........................................................................................................................6 1.3. Tested System Details..............................................................................................................................7 1.4. Configuration of Tested System ..............................................................................................................7 1.5. EUT Exercise Software ...........................................................................................................................7 1.6. Test Facility .............................................................................................................................................8 2. CONDUCTED EMISSION ..................................................................................................................9 2.1. Test Equipment ........................................................................................................................................9 2.2. Test Setup ................................................................................................................................................9 2.3. Limits.....................................................................................................................................................10 2.4. Test Procedure .......................................................................................................................................10 2.5. Uncertainty ............................................................................................................................................10 2.6. Test Result of Conducted Emission .......................................................................................................11 3. PEAK POWER OUTPUT ..................................................................................................................13 3.1. Test Equipment ......................................................................................................................................13 3.2. Test Setup ..............................................................................................................................................13 3.3. Limit .....................................................................................................................................................13 3.4. Test Procedure .......................................................................................................................................13 3.5. Uncertainty ............................................................................................................................................13 3.6. Test Result of Peak Power Output .........................................................................................................14 4. RADIATED EMISSION .....................................................................................................................15 4.1. Test Equipment ......................................................................................................................................15 4.2. Test Setup ..............................................................................................................................................15 4.3. Limits.....................................................................................................................................................16 4.4. Test Procedure .......................................................................................................................................17 4.5. Uncertainty ............................................................................................................................................17 4.6. Test Result of Radiated Emission ..........................................................................................................18 5. RF ANTENNA CONDUCTED TEST................................................................................................22 5.1. Test Equipment ................................…

Text truncated - open the document above for the full version.

Report No.: 1480461R-RFUSP25V00 Page: 1 of 142 FCC Test Report Product Name Nexus Player Model No TV500I FCC ID. MSQ-TV500I Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date of Receipt Aug. 20, 2014 Issue Date Oct. 09, 2014 Report No. 1480461R-RFUSP25V00 Report Version V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration report of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF or any agency of the government. The test report shall not be reproduced without the written approval of QuieTek Corporation. Report No.: 1480461R-RFUSP25V00 Page: 2 of 142 Test Report Issue Date: Oct. 09, 2014 Report No.: 1480461R-RFUSP25V00 Product Name Nexus Player Applicant ASUSTeK COMPUTER INC. Address 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Manufacturer Digitek (Chongqing) Limited Model No. TV500I EUT Rated Voltage AC 100-240V, 50/60Hz EUT Test Voltage AC 120V/60Hz Trade Name nexus; ASUS Applicable Standard FCC CFR Title 47 Part 15 Subpart C: 2013 ANSI C63.10: 2009, KDB 558074 D01 DTS Meas Guidance v03r02 Test Result Complied Documented By: ( Senior Adm. Specialist / Rita Huang ) Tested By : ( Engineer / Jack Hsu ) Approved By : ( Director / Vincent Lin ) Report No.: 1480461R-RFUSP25V00 Page: 3 of 142 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................7 1.3. Tested System Details....................................................................................................................8 1.4. Configuration of Tested System ....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................11 2.4. Test Procedure .............................................................................................................................11 2.5. Uncertainty ..................................................................................................................................11 2.6. Test Result of Conducted Emission.............................................................................................12 3. Maximum Conducted Power....................................................................................................16 3.1. Test Equipment............................................................................................................................16 3.2. Test Setup ....................................................................................................................................16 3.3. Limits ..........................................................................................................................................16 3.4. Test Procedure .............................................................................................................................16 3.5. Uncertainty ..................................................................................................................................16 3.6. Test Result of Maximum Conducted Power................................................................................17 4. Radiated Emission .....................................................................................................................25 4.1. Test Equipment............................................................................................................................25 4.2. Test Setup ....................................................................................................................................26 4.3. Limits ..........................................................................................................................................27 4.4. Test Procedure .............................................................................................................................28 4.5. Uncertainty ..................................................................................................................................28 4.6. Test Result of Radiated Emission................................................................................................29 5. RF Antenna conducted test .......................................................................................................54 5.1. Test Equipment............................................................................................................................54 5.2. Test Setup ....................................................................................................................................54 5.3. Limits .................................…

Text truncated - open the document above for the full version.

Report No.: 1480461R-RFUSP25V00 Page: 102 of 142 7. Occupied Bandwidth 7.1. Test Equipment Equipment Manufacturer Model No./Serial No. Last Cal. Spectrum Analyzer R&S FSP40 / 100170 Jun, 2014 Spectrum Analyzer Agilent E4407B / US39440758 Jun, 2014 X Spectrum Analyzer Agilent N9010A / MY48030495 Apr., 2014 Note: 1. All equipments are calibrated with traceable calibrations. Each calibration is traceable to the national or international standards. 2. The test instruments marked with “X” are used to measure the final test results. 7.2. Test Setup 7.3. Limits The minimum bandwidth shall be at least 500 kHz. 7.4. Test Procedure The EUT was setup according to ANSI C63.10, 2009; tested according to DTS test procedure of KDB558074 for compliance to FCC 47CFR 15.247 requirements. Set RBW = 1-5% of the emission bandwidth, VBW≥3*RBW 7.5. Uncertainty ± 150Hz SMA EUT Spectrum Analyzer RF Cable Report No.: 1480461R-RFUSP25V00 Page: 103 of 142 7.6. Test Result of Occupied Bandwidth Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 802.11b 1Mbps (2412MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 1 2412.00 10150 >500 Pass Figure Channel 1: Report No.: 1480461R-RFUSP25V00 Page: 104 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 802.11b 1Mbps (2437MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 6 2437.00 10200 >500 Pass Figure Channel 6: Report No.: 1480461R-RFUSP25V00 Page: 105 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 1: Transmit - 802.11b 1Mbps (2462MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 11 2462.00 10200 >500 Pass Figure Channel 11: Report No.: 1480461R-RFUSP25V00 Page: 106 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 802.11g 6Mbps (2412MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 1 2412.00 15200 >500 Pass Figure Channel 1: Report No.: 1480461R-RFUSP25V00 Page: 107 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 802.11g 6Mbps (2437MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 6 2437.00 15200 >500 Pass Figure Channel 6: Report No.: 1480461R-RFUSP25V00 Page: 108 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 2: Transmit - 802.11g 6Mbps (2462MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 11 2462.00 15200 >500 Pass Figure Channel 11: Report No.: 1480461R-RFUSP25V00 Page: 109 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 3: Transmit - 802.11a 6Mbps (5745MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 149 5745.00 15400 >500 Pass Figure Channel 149: Report No.: 1480461R-RFUSP25V00 Page: 110 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 3: Transmit - 802.11a 6Mbps (5785MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 157 5785.00 15200 >500 Pass Figure Channel 157: Report No.: 1480461R-RFUSP25V00 Page: 111 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 3: Transmit - 802.11a 6Mbps (5825MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 165 5825.00 14300 >500 Pass Figure Channel 165: Report No.: 1480461R-RFUSP25V00 Page: 112 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 4: Transmit - 802.11n-20BW_14.4Mbps(2.4G Band) (2412MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 1 2412.00 17750 >500 Pass Figure Channel 1: (Chain A) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 1 2412.00 17700 >500 Pass Figure Channel 1: (Chain B) Report No.: 1480461R-RFUSP25V00 Page: 113 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 4: Transmit - 802.11n-20BW_14.4Mbps(2.4G Band) (2437MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 6 2437.00 17700 >500 Pass Figure Channel 6: (Chain A) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 6 2437.00 17700 >500 Pass Figure Channel 6: (Chain B) Report No.: 1480461R-RFUSP25V00 Page: 114 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 4: Transmit - 802.11n-20BW_14.4Mbps(2.4G Band) (2462MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 11 2462.00 17700 >500 Pass Figure Channel 11: (Chain A) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 11 2462.00 17700 >500 Pass Figure Channel 11: (Chain B) Report No.: 1480461R-RFUSP25V00 Page: 115 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 5: Transmit - 802.11n-20BW_14.4Mbps(5G Band) (5745MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 149 5745.00 17650 >500 Pass Figure Channel 149: (Chain A) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 149 5745.00 17750 >500 Pass Figure Channel 149: (Chain B) Report No.: 1480461R-RFUSP25V00 Page: 116 of 142 Product : Nexus Player Test Item : Occupied Bandwidth Data Test Site : No.3 OATS Test Mode : Mode 5: Transmit - 802.11n-20BW_14.4Mbps(5G Band) (5785MHz) Channel No. Frequency (MHz) Measurement Level (kHz) Required Limit (kHz) Result 157 5785.00 17700 >500 Pass Figure Channel 157: (Chain A) Channel No. Frequency (MHz) Measu…

Text truncated - open the document above for the full version.

Report No.: 1480461R-RFUSP25V00 Page : 1 of 4 Attachment 1: EUT Test Setup Photographs Front View of Radiated Test Back View of Radiated Test Report No.: 1480461R-RFUSP25V00 Page : 2 of 4 Front View of Radiated Test Back View of Radiated Test Report No.: 1480461R-RFUSP25V00 Page : 3 of 4 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn) Report No.: 1480461R-RFUSP25V00 Page : 4 of 4 Front View of Radiated Test (Horn) Back View of Radiated Test (Horn)
