MSQ15TNE785Eee PC

Eee PC User Manual Windows ® 7 Edition Eee PC 1015 Series E5984 iiTable of Contents Table of Contents About This User’s Manual ......................................................................................................iv Notes for This Manual .............................................................................................................iv Safety Precautions.....................................................................................................................v Transportation Precautions ...................................................................................vi Charging Your Batteries..........................................................................................vii Airplane Precautions ...............................................................................................vii Chapter 1: Knowing the Parts Top Side ....................................................................................................................................1-2 Bottom Side .............................................................................................................................1-5 Front Side .................................................................................................................................1-6 Right Side .................................................................................................................................1-7 Left Side ....................................................................................................................................1-8 Keyboard Usage ...................................................................................................................1-10 Special Function Keys .........................................................................................1-10 Touchpad Usage ..................................................................................................................1-12 Chapter 2: Getting Started Powering on your Eee PC ...................................................................................................2-2 First-time Startup ..................................................................................................................2-3 Desktop .....................................................................................................................................2-5 Network Connection ............................................................................................................2-6 Configuring a wireless network connection.................................................2-6 Local Area Network ................................................................................................2-7 Browsing web pages ...........................................................................................2-10 Chapter 3: Using the Eee PC ASUS Update ...........................................................................................................................3-2 Updating the BIOS through the Internet .......................................................3-2 Updating the BIOS through a BIOS file ...........................................................3-3 Bluetooth Connection (on selected models) ..............................................................3-4 Super Hybrid Engine ............................................................................................................3-6 Super Hybrid Engine Modes...............................................................................3-6 ASUS Eee PCiii Eee Docking ............................................................................................................................3-7 Access .........................................................................................................................3-7 Sharing .......................................................................................................................3-8 Experience ................................................................................................................3-8 Tools ............................................................................................................................3-8 Boingo (on selected models) ............................................................................................3-9 Graphic Switch (for 1015PN only)....................................................................................3-9 Microsoft® Office Trial (on selected models) .............................................................3-10 Chapter 4: System Recovery System Recovery....................................................................................................................4-2 Boot Booster............................................................................................................................4-5 Appendix Declarations and Safety Statements ..............................................................................A-2 Copyright Information ......................................................................................................A-13 Limitation of Liability ........................................................................................................A-14 Service and Support ..........................................................................................................A-14 ivTable of Contents About This User’s Manual You are reading the Eee PC User’s Manual. This User’s Manual provides information regarding the various components in the Eee PC and how to use them. The following are major sections of this User’s Manual: 1. Knowing the Parts Provides information on the Eee PC’s components. 2. Getting Started Provides information on getting started with the Eee PC. 3. Using the Eee PC Provides information on using the Eee PC’s utilities. 4. System Recovery Gives you information on system recovery. 5. Appendix Gives…

Text truncated - open the document above for the full version.

ASUSTeK Computer Inc. Date: August, 27, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID: MSQ15TNE785 ATTESTATION FCC ID: MSQ15TNE785 Product: Eee PC Model: Eee PC 1015T We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA.

RF_160, Issue 02 ASUSTeK Computer Inc. We Name: ASUSTeK Computer Inc. Address: No.150, Li-te Rd City: ......... Peitou, Taipei ................................................................ Country:.........Taiwan ............................................................................ Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: ......Eee PC............ ...................... Type designation: ......Eee PC 1015T ...... ..................... Trademark: ... ASUS .................................................... on our behalf. Date: ...... 2010/08/27.............. City: ...... Peitou, Taipei .......................... Name: ...... Jackson Yen ................................ (2) Function: .......Associate Vice President /EMC & Safety Department............ Signature: Tel: .......+886-2-28943447 Extension:3106.......... Fax: ...... +886-2-28987364 Email: ...... [email protected] Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

ASUSTeK Computer Inc. No.150, Li-te Rd Peitou, Taipei Ta i w a n Attestation for FCC Declaration of Conformity FCC ID: MSQ15TNE785H Date: 2010/08/27 Please be notified that we, the undersigned, ASUSTEK COMPUTER INC. declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DOC. The test report number supporting the DOC is 108241R-ITUSP01V02. Testing in regards to this report was done by QuieTek Corp., located at No.5-22, Rueishu Keng, Rueiping Tsuen, Linkou Shiang, Taipei County 244, Taiwan, which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827.

ASUSTeK COMPUTER INC. FCC ID: MSQ15TNE785 4FL., No.150, Li-te Rd., Peitou, Taipei, Taiwan, R.O.C. Tel : 886-2-2894-3447 Federal Communications Commission Authorization and Evaluation Division August. 27 , 2010 Confidential Statement We have understood that the following request for confidential documents has been and viewable since the date of grant, since it has been granted. Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics : (Eee PC 1015T) Schem Block Diagram: (Eee PC 1015T) BlkDia Operational Description: (Eee PC 1015T) OPDes Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 DFR § 2.803 and the importation rules in 47 CFR § 2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices . . We are requesting the commission to grant forty-five days short-term confidentiality request on the following attachments: External Photos: (Eee PC 1015T) Expho Internal Photos: (Eee PC 1015T) Inpho Test Setup Photos: (Eee PC 1015T) Tsup User Manual: (Eee PC 1015T) UserMan It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued.

Eee PC (M/N:Eee PC 1015T) EUT Photograph-External Photographs (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo

1015T F4 15G1023256C0 Wireless Module: AW-NE785H FCC ID: MSQ15TNE785 CCAE08LP1590T0 15G1023256B0 3568A-15TNE785

Eee PC (M/N: Eee PC 1015T) EUT Photograph-Internal photograph (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo (9) EUT Photo (10) EUT Photo (11) EUT Photo

Report No：108S013R-HPUS-P03V01 Page: 1 of 49 SAR Test Report Product Name : Eee PC Model No. : Eee PC 1015T FCC ID : MSQ15TNE785 IC ID : 3568A-15TNE785 Applicant : ASUSTEK COMPUTER INC. Address : 4FL., NO.150, Li-Te Rd., Peitou, Taipei, Taiwan, R. O. C Date of Receipt : Aug. 19, 2010 Date of Test : Aug. 19, 2010 ~ Aug. 22, 2010 Issued Date : Aug. 23, 2010 Report No. : 108S013R-HPUS-P03V01 Report Version : V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of Quie Tek Corporation. Report No：108S013R-HPUS-P03V01 Page: 2 of 49 Test Report Certification Issued Date: Aug. 23, 2010 Report No: 108S013R-HPUS-P03V01 Product Name : Eee PC Applicant : ASUSTEK COMPUTER INC. Address : 4FL., NO.150, Li-Te Rd., Peitou, Taipei, Taiwan, R. O. C Manufacturer : PROTEK (Shanghai) Limited Address : NO.3768 Xiu Yan Rd.Kang Qiao Town, PuDong Dist, Shang Hai FCC ID : MSQ15TNE785 IC : 3568A-15TNE785 Model No. : Eee PC 1015T Trade Name : ASUS EUT Voltage : 19Vdc Applicable Standard : FCC OET65 Supplement C June 2001 IEEE Std. 1528-2003, 47CFR § 2.1093, RSS102 Issue 4 Test Result : Max. SAR Measurement (1g) 0.026 W/kg Performed Location : Suzhou EMC laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone, Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392, IC Lab Code: 4075B Documented By : (Engineering ADM: Alice Ni) Tested By : (Engineering Supervisor: Marlin Chen) Approved By : (Engineering Manager: Dream Cao) Report No：108S013R-HPUS-P03V01 Page: 3 of 49 Laboratory Information We , QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited by the following accreditation Bodies in compliance with ISO 17025, EN 45001 and Guide 25: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://tw.quietek.com/modules/myalbum/ The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : +886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou Testing Laboratory : No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL : +86-512-6251-5088 / FAX : 86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No：108S013R-HPUS-P03V01 Page: 4 of 49 TABLE OF CONTENTS Description Page 1. General Information ...................................................................................................6 1.1. EUT Description ....................................................................................................6 1.2. Test Environment...................................................................................................6 2. SAR Measurement System ........................................................................................7 2.1. DASY5 System Description...................................................................................7 2.1.1. Applications .......................................................................................................8 2.1.2. Area Scans ........................................................................................................8 2.1.3. Zoom Scan (Cube Scan Averaging) ..................................................................8 2.1.4. Uncertainty of Inter-/Extrapolation and Averaging .............................................8 2.2. DASY5 E-Field Probe............................................................................................9 2.2.1. Isotropic E-Field Probe Specification .................................................................9 2.3. Boundary Detection Unit and Probe Mounting Device........................................10 2.4. DATA Acquisition Electronics (DAE) and Measurement Server ..........................10 2.5. Robot................................................................................................................... 11 2.6. Light Beam Unit ................................................................................................... 11 2.7. Device Holder......................................................................................................12 2.8. SAM Twin Phantom.............................................................................................12 3. Tissue Simulating Liquid .........................................................................................13 3.1. The composition of the tissue simulating liquid ...................................................13 3.2. Tissue Calibration Result.....................................................................................13 3.3. Tissue Dielectric Parameters for Head and Body Phantoms ...............................14 4. SAR Measurement Procedure .................................................................................15 4.1. SAR System Validation........................................................................................15 4.1.1. Validation Dipoles............................................................................................15 4.1.2. Validation Result..............................................................................................15 4.2. SAR Measurement Procedure....................…

Text truncated - open the document above for the full version.

Test Report Industry Canada RSS-Gen Issue 2/RSS-210 Issue 7 FCC Part15 Subpart C Product Name : Eee PC Model No. : Eee PC 1015T FCC ID : MSQ15TNE785 IC : 3568A-15TNE785 Applicant ： ASUSTEK COMPUTER INC. Address ： 4FL., NO.150, Li-Te Rd., Peitou, Taipei, Taiwan, R. O. C Date of Receipt : Aug. 19, 2010 Test Date : Aug. 20, 2010 ~ Aug. 24, 2010 Issued Date : Aug. 25, 2010 Report No. : 108S013R-RF-US-P05V02 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：108S013R-RF-US-P05V02 Page: 2 of 111 Test Report Certification Issued Date : Aug. 25, 2010 Report No. : 108S013R-RF-US-P05V02 Product Name : Eee PC Applicant : ASUSTEK COMPUTER INC. Address : 4FL., NO.150, Li-Te Rd., Peitou, Taipei, Taiwan, R. O. C Manufacturer : PROTEK (SHANGHAI) LTD Address : NO.3768 Xiu Yan Rd.Kang Qiao Town, PuDong Dist, Shang Hai Model No. : Eee PC 1015T FCC ID : MSQ15TNE785 IC : 3568A-15TNE785 EUT Voltage : 19Vdc Trade Name : ASUS Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2008 ANSI C63.4: 2009 ANSI C63.10: 2009 RSS-Gen Issue 2/RSS-210 Issue 7 Test Result : Complied Performed Location : Suzhou EMC laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392, IC Lab Code: 4075B Documented By : ( Engineering ADM: Alice Ni ) Reviewed By : ( Engineering Supervisor: Marlin Chen ) Approved By : ( Engineering Manager: Dream Cao ) Report No：108S013R-RF-US-P05V02 Page: 3 of 111 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://www.quietek.com/tw/emc/accreditations/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3 rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No：108S013R-RF-US-P05V02 Page: 4 of 111 TABLE OF CONTENTS Description Page 1. General Information .................................................................................................6 1.1. EUT Description ......................................................................................................6 1.2. Mode of Operation...................................................................................................8 1.3. Tested System Details .............................................................................................9 1.4. Configuration of Tested System .............................................................................10 1.5. EUT Exercise Software.......................................................................................... 11 2. Technical Test ........................................................................................................12 2.1. Summary of Test Result.........................................................................................12 2.2. Test Environment...................................................................................................14 3. Conducted Emission..............................................................................................15 3.1. Test Equipment......................................................................................................15 3.2. Test Setup..............................................................................................................15 3.3. Limit.......................................................................................................................16 3.4. Test Procedure......................................................................................................16 3.5. Uncertainty ............................................................................................................16 3.6. Test Result.............................................................................................................17 4. Radiated Emission.................................................................................................19 4.1. Test Equipment......................................................................................................19 4.2. Test Setup..............................................................................................................20 4.3. Limit.......................................................................................................................21 4.4. Test Procedure...............................................…

Text truncated - open the document above for the full version.

Eee PC (M/N: Eee PC 1015T) Test Photograph of CE&RE Test Mode: Transmitting Description: Front View of Conducted Emission Test Setup Test Mode: Transmitting Description: Back View of Conducted Emission Test Setup Test Mode : Transmitting Description : Front View of Radiated Emission Test Setup for Below 1GHz Test Mode : Transmitting Description : Back View of Radiated Emission Test Setup for Below 1GHz Test Mode : Transmitting Description : Front View of Radiated Emission Test Setup for 1~18GHz Test Mode : Transmitting Description : Back View of Radiated Emission Test Setup for 1~18GHz Test Mode : Transmitting Description : Front View of Radiated Emission Test Setup for Above 18GHz Test Mode : Transmitting Description : Back View of Radiated Emission Test Setup for Above 18GHz SAR Test Setup Photographs & EUT Photographs Test Setup Photographs Depth of the liquid in the phantom – Zoom in Note: The position used in the measurements were according to IEEE 1528 - 2003
