MSQAM1LWireless Mouse

FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, Pursuant to Part 15 the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Industry Canada Statement: This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement indésirable. 低功率電波輻射性電機管理辦法: 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或 變更設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善 至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 Product Specification Frequency: 2403MHz ~ 2480 MHz (78 channel) Modulation Type: GFSK Frequency Deviation: +/- 320 KHz Power rated: 3V (Keyboard) / 3V (Mouse) / 5V (Dongle) Battery: Keyboard – 2 pieces of AAA Batteries Mouse – 2 pieces of AAA Batteries Operation distance: Keyboard – 10M without signal disturbance and no direction limit Mouse – 10M without signal disturbance and no direction limit Mouse resolution: 1000 DPI Operating temperature: 0°C ~ +40°C Storage temperature: -40°C ~ +65°C Dongle Label: Connection 安裝接收器 Please plug dongle into PC USB port, the keyboard & mouse are already pre-binding without any setup process. 請將接收器插入到電腦 USB port，鍵盤和滑鼠即可工作不需要任何安裝程序。 The function keys in below columns will only be supported in AIO system. 下列框框中的功能鍵僅能使用於華碩的AIO 電腦系統

Page 1 CONSTRUCTION PHOTOS OF EUT

REV. E 08590230L MG-0859 MG-0859253-00859L- SCALE: 1 : 1 DWG NO.: NOTES NOTES NOTES MODEL NO. MODEL NO.: REMARKPART NO. MAT.: TOL: UNIT: MM Q'TYSIZE: A4 SPEC: APPROVEDCHECKEDDESIGNED NAME: FINISH: REV LTRREV . DIMENSIONDATEDESIGNAPPROVE B C SPEC. ID LABEL NOTES: (FOR MOUSE) ASUS/BLACK 08/05-'11 08/05-'11 08/05-'11 CLAIRE MAGGIE T.S. JERRY MG0859-FCC()-X2 VENDOR UL MARK. 1. MATERIAL: SYNTHETIC PAPER t=0.1mm (WITH GLUE) (UL/CSA APPROVED) 2. BACKGROUND COLOR: PANTONE Process Black C 3. TEXT & SYMBOLS COLOR: WHITE 4. FINISHED: ADHESIVE. 5. LABEL VENDOR HAS TO BE APPRD. BY UL/CSA 6. THIS PRODUCT/COMPONENT MUST COMPLY WITH CHICONY SPECIFICATION "ISO 361" R31018 M/N(/): AM1L Part No.: XXXXXXXXXXX ** XXX XX XXXXXXXX XXXXXXXXXXX FCC ID: MSQAM1L N13219 Made in China(/) S/N: : Input Rating(/): 3V 60mA IC: 3568A-AM1L CMIIT ID: XXXXXXXXXX ********************* Wireless mouse (/)

Page 2 Page 3 Page 4

FCC ID: MSQAM1L Report No.: RF110719D06-1 Operational Description The transmitter of the EUT (Wireless Mouse) is powered by 3Vdc from batteries. The type of antenna is PCB Strip antenna. The output power of this device is very low. Under normal use condition, the transmitter and the receiver are quite close, so high EIRP power is neither necessary nor allowed because of interference.

Report No.: RF110719D06-1 1 Report Format Version 4.0.0 FCC TEST REPORT REPORT NO.: RF110719D06-1 MODEL NO.: AM1L FCC ID: MSQAM1L RECEIVED: Jul. 19, 2011 TESTED: Jul. 19, 2011 ISSUED: Jul. 27, 2011 APPLICANT: ASUSTek computer Inc. ADDRESS: NO. 15, LI-TE RD., PEITOU, TAIPEI, TAIWAN, R.O.C. ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB LOCATION: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien, 244 Taiwan This test report consists of 24 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by TAF or any government agencies. The test results in the report only apply to the tested sample. Report No.: RF110719D06-1 2 Report Format Version 4.0.0 Table of Contents RELEASE CONTROL RECORD..............................................................................3 1. CERTIFICATION...........................................................................................4 2. SUMMARY OF TEST RESULTS...................................................................5 2.1 MEASUREMENT UNCERTAINTY...............................................................5 3. GENERAL INFORMATION...........................................................................6 3.1 GENERAL DESCRIPTION OF EUT............................................................6 3.2 DESCRIPTION OF TEST MODES..............................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................7 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL:.............8 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS.............................9 3.4 DESCRIPTION OF SUPPORT UNITS........................................................9 4. TEST TYPES AND RESULTS.....................................................................10 4.1 CONDUCTED EMISSION MEASUREMENT............................................10 4.2 RADIATED EMISSION MEASUREMENT.................................................10 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT...............................10 4.2.2 TEST INSTRUMENTS..............................................................................11 4.2.3 TEST PROCEDURES...............................................................................12 4.2.4 DEVIATION FROM TEST STANDARD.....................................................12 4.2.5 TEST SETUP............................................................................................13 4.2.6 EUT OPERATING CONDITIONS..............................................................13 4.2.7 TEST RESULTS........................................................................................14 4.3 BAND EDGES MEASUREMENT..............................................................19 4.3.1 LIMITS OF BAND EDGES MEASUREMENT............................................19 4.3.2 TEST INSTRUMENTS..............................................................................19 4.3.3 TEST PROCEDURE.................................................................................19 4.3.4 DEVIATION FROM TEST STANDARD.....................................................19 4.3.5 EUT OPERATING CONDITION................................................................19 4.3.6 TEST RESULTS........................................................................................19 5. PHOTOGRAPHS OF THE TEST CONFIGURATION..................................22 6. INFORMATION ON THE TESTING LABORATORIES................................23 7. APPENDIX A – MODIFICATIONS RECORDERS FOR ENGINEERING CHANGES TO THE EUT BY THE LAB.......................................................24 Report No.: RF110719D06-1 3 Report Format Version 4.0.0 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED RF110719D06-1 Original release Jul. 27, 2011 Report No.: RF110719D06-1 4 Report Format Version 4.0.0 1. CERTIFICATION PRODUCT: Wireless Mouse BRAND NAME: ASUS MODEL NO.: AM1L APPLICANT: ASUSTek computer Inc. TESTED: Jul. 19, 2011 TEST ITEM: ENGINEERING SAMPLE STANDARDS: FCC Part 15, Subpart C (Section 15.249) ANSI C63.4-2003 ANSI C63.10-2009 The above equipment has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE: ( Celia Chen / Senior Specialist ) APPROVED BY : , DATE: ( Ken Liu / Manager ) Report No.: RF110719D06-1 5 Report Format Version 4.0.0 2. SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 15, Subpart C (Section 15.249) STANDARD SECTION TEST TYPE AND LIMIT RESULT REMARK 15.207 Conducted Emission Test N/A Power supply is 3Vdc from batteries 15.209 15.249 15.249 (d) Radiated Emission Test Band Edge Measurement Limit: 50dB less than the peak value of fundamental frequency or meet radiated emission limit in section 12.209 PASS Minimum passing margin is –11.5dB at 2390.00MHz 2.1 MEASUREMENT UNCERTAINTY Where relevant, the following measurement uncertainty levels have been estimated for tests performed on the EUT as specified in CISPR 16-4-2: This uncertainty represents an expanded uncertainty expressed at approximately the 95% confidence level using a coverage factor of k=2. Measurement Frequency Uncertainty 30MHz ~ 1GHz 3.87 dB Radiated emissions Above 1GHz 3.36 dB Report No.: RF110719D06-1 6 Report Format Version 4.0.0 3. GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT EUT Wireless Mouse MODEL NO. AM1L FCC ID MSQAM1L POWER SUPPLY 3Vdc from batteries MODULATION TYPE GFSK OPERATING …

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
