MSQDCW615Cable Router

Federal Communications Commission Declaration of Conformity (DoC) For the Following Equipment: Product name : Wireless Cable Gateway Model name : DCW615 Trade name : ASUS Is herewith confirmed and found to comply with the requirements of CFR 47 part15 Subpart B - Unintentional Radiators regulation. The results of electromagnetic mission evaluation are shown in the report number : A5415840 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation Marketing or Importer USA local representative Company name: ASUSTeK Computer Inc. To be determined Computer address: 4/F, 150, Li-Te Rd., Peitou, Taipei, Taiwan ZIP / Postal code 112 Contact person: Lawrence Yu Title: R & D Engineer Internet e-mail address: [email protected] Tel / Fax: 886-2-28943447 / 886-2-28950113

RCA DCW615 Cable Router Quick Guide (Draft User’s Manual) 1 Table of Contents INTRODUCTION......................................................................................................................................................................................................3 Overview..............................................................................................................................................................................................................3 Features................................................................................................................................................................................................................3 PREPARATIONS.......................................................................................................................................................................................................7 System Requirements............................................................................................................................................................................................7 Installing a Network Card....................................................................................................................................................................................7 Installing the TCP/IP Protocol............................................................................................................................................................................9 USING THE ROUTER...........................................................................................................................................................................................14 The Front Panel.................................................................................................................................................................................................14 The Rear Panel...................................................................................................................................................................................................15 CONNECT THE ROUTER....................................................................................................................................................................................17 Overview............................................................................................................................................................................................................17 Connecting Your Hardware Together and Booting Up......................................................................................................................................17 CONFIGURE YOUR PCS......................................................................................................................................................................................19 Overview............................................................................................................................................................................................................19 Configuring Windows 95, 98, and Millennium PCs..........................................................................................................................................20 2 Configuring Windows 2000 PCs........................................................................................................................................................................23 Configuring Windows XP PCs...........................................................................................................................................................................24 CONFIGURE THE ROUTER................................................................................................................................................................................26 PRODUCT SPECFICATIONS...............................................................................................................................................................................30 3 Introduction Overview Thank you for purchasing the RCA DCW615 Cable Router. This cable router delivers the highest performance in data over cable technology. Ideal for home and small business users, this easy-to-use communication device offers reliable connectivity as well as remarkable data transfer rates – 100 times faster than a 56K dial-up modem. Once the cable router is powered up, you are online to enjoy real-time 3D animation, video conferencing, and perform other data intensive operations. Features DOCSIS Features l Cable Modem (CM) is 1.0 and non 1.1 upgradeable l Concatenation, Fragmentation, Payload Header suppression, IGMP and BPI and BPI Plus are supported features for DOCSIS 1.1 l 4/16/32/64/128/256/512/1024 QAM Downstream Receiver l 2/4/8/16/32/64/128/256 QAM Advanced TDMA Upstream Transmitter l Both IP and LLC filters are supported l Sixteen (16) destination address filters and 256 multicast/unicast DA filters 4 l Sixteen (16) independent upstream queues for multiple QoS support USB Features l OS (Win2K, XP, WinME) supported for USB interface Wireless Features l Supports at least one beacon/DTIM interval of within the range 20-1000s l Supports reception of fragmented packets l Supports reception of RTS and generation of CTS Firewall Features l tateful Packet Inspection against both Denial of Service and Distributed Denial of Service attacks and will protect against the following: ÿ Reassembly attacks ÿ SYN Attack (SYN Flood) ÿ ICMP Flood ÿ Ping of Death Attack ÿ Tear Drop Attack ÿ IP Spoofing Attack ÿ LAND Attack ÿ Jolt ÿ Winnuke Attack (Netbios out-of-bound) 5 ÿ OverDrop ÿ BONK, BOINK ÿ Blind Spoofing ÿ Echo/Chargen ÿ Storm ÿ Smurf Attack ÿ Mime Flood l De-Militarized Zone (DMZ) which allows a computer on the LAN to expose all of its ports to the WAN that are …

Text truncated - open the document above for the full version.

FCC ID: MSQDCW615 User Manual additionally: 15.21 CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Prohibition of co-location This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. 15.105 Federal Communications Commission (FCC) Requirements, Part 15 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ---Reorient or relocate the receiving antenna. ---Increase the separation between the equipment and receiver. ---Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ---Consult the dealer or an experienced radio/TV technician for help. Caution Statement of the FCC Radio Frequency Exposure This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65C and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247(b)(4) addressing RF Exposure from radio frequency devices. The radiation output power of this Wireless LAN device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation—as a mobile device but use in a body-worn way is strictly prohibit. When using this device, a certain separation distance between antenna and nearby persons has to be kept to ensure RF exposure compliance. In order to comply with the RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than 20cm. Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, or the substitution of the connecting cables and equipment other than manufacturer specified. It is the responsibility of the user to correct any interference caused by such unauthorized modification, substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. MPE Statement (Safety Information) Your device contains a low power transmitter. When device is transmitted it sends out Radio Frequency (RF) signal. Safety Information CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Use on the supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations.

Training Research Co., Ltd. No. 2, Lane 194, Huan-Ho St., Hsi-Chih, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® March 21, 2003 Re: ASUSTek Computer Inc. FCC ID: MSQDCW615 Dear Timothy: To: Mr. Timothy R. Johnson, In responses to your ATCB comments on 2003/3/15. Q1: The attachment is photo of PCMCOA card for FCC ID QDWAB008WN100 Q2 and Q3: The confidential letter is can including parts list and operation description. Please you check again. Q3: See attachment file, I have upload to your web. Q4: Up-load e-file for schematics of PCMCIA card Q5: Calculations of MPE. See up-loaded file. Q6: New Doc form. See up-loaded file. Q7: New update manual, See up-loaded file Q8: See up-loaded file. Q9: Firstly, the band-edge plots apply to VBW=RBW= 100KHz then perform radiated emission testing in FCC ID: MSQDCW615. (Peak Mode : VBW=RBW= 1MHz , Averaged Mode: VBW=1MHz and RBW= 10Hz.) See up-loaded file. Q10: Applied to current limits. Best regards, Jack Tsai [email protected] Training Research Co., Ltd.

Training Research Co., Ltd. No. 2, Lane 194, Huan-Ho St., Hsi-Chih, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® April 2, 2003 Re: ASUSTek Computer Inc. FCC ID: MSQDCW615 Dear Timothy: To: Mr. Timothy R. Johnson, In responses to your ATCB comments on 2003/3/25. Q1 and Q2: New update manual, See up-loaded file Q3: They are always packaged together when export (sold). So, we change label statement. See attached format of label. Q4: Applied to current limits. Best regards, Jack Tsai [email protected] Training Research Co., Ltd.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 15, 2003 RE: ASUSTek Computer Inc. FCC ID: MSQDCW615 After a review of the submitted information, I have a few comments on the above referenced Application. 1) Please provide a photograph of the label of the PC card which shows its FCC ID Number. Note the label of the cable modem references FCC ID: QDWAB008WN100. 2) The operational description was uploaded as confidential, but not listed in the confidentiality letter. Please confirm if this exhibit is considered confidential and if so, please updated the confidentiality letter. 3) The parts list is not necessary. Please correct the confidentiality letter by removing this. 4) Please provide the schematics for the PCMCIA card. 5) Since the device is mobile, please provide a standard MPE calculation exhibit. The one provided is not preferred since the device should easily meet with standard calculations. 6) The DoC statement page must also include the following: A statement similar to that contained in Section 15.19(a)(3) that the product complies with Part 15 of the regulations. 7) The users manual is missing the statements required by 15.21 and 15.105. Additionally, the users manual is missing information regarding RF exposure statements. 8) Please explain what precautions are built into the device so that it only functions with the particular PCMCIA card specified. 9) Please provide information regarding the VBW and RBW of the plots provided at the bandedge. Additionally, compliance at the 2.4835 GHz (Channel 11) band has not been shown. It appears that the plot for the 2.4 GHz was provided twice. 10) Although conducted emissions were performed, it is also recommended that the conducted emissions meet the future limits (CISPR) that will be required in the next few years. Please confirm if additional test data will be provided for this, or proceed with the current data. This is because the grant will be issued with one of the following grant notes depending on which set of limits it is shown to have met: Current Limits NOTE: The manufacture and importation of this device must cease on July 10, 2005 pursuant to 15.37(j) or 18.123 transition provisions adopted under FCC 02-157 (ET Docket 98-80). Future Limits (CISPR) NOTE: This device has shown compliance with the conducted emissions limits in 15.107, 15.207, or 18.307 adopted under FCC 02-157 (ET Docket 98-80) and may be marketed after July 11, 2005 and is not affected by the 15.37(j) or 18.123 transition provisions. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be z Page 2March 15, 2003 considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

American Telecommunications Certification Body Inc. 6731 Whittier Ave, McLean, VA 22101 March 25, 2003 RE: ASUSTek Computer Inc. FCC ID: MSQDCW615 After a review of the submitted information, I have a few comments on the above referenced Application. 1) The users manual is missing the prohibition of co-location information as part of the RF exposure statements. Please add the following to the users manual, " This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter". 2) Please remove the reference to "portable" in the Caution Statement of the FCC Radio Frequency Exposure portion of the users manual. This device is considered as a mobile device only. 3) The label states the TX is optional. Please explain if the PCMCIA card is always included with the Cable Modem when sold. Are they always packaged together? If not, please explain how the device is built (using software/hardware blocks, etc) so that a user can only use the PCMCIA cards intended by the manufacturer and not any PCMCIA card they desire. 4) The conducted emissions provided do not show any reading from 150 kHz to 450 kHz. Due to the data given in the tables and the test method specified in 4.1 of the test report, it appears that the device was only tested from 450 kHz - 30 MHz to the older FCC limits. Please confirm if additional test data will be provided to show compliance with the new limits (0.150 - 0.450 MHz was not previously tested), or if we should proceed using the current data. This is because the grant will be issued with one of the following grant notes depending on which set of limits it is shown to have met: Current Limits NOTE: The manufacture and importation of this device must cease on July 10, 2005 pursuant to 15.37(j) or 18.123 transition provisions adopted under FCC 02-157 (ET Docket 98-80). Future Limits (CISPR) NOTE: This device has shown compliance with the conducted emissions limits in 15.107, 15.207, or 18.307 adopted under FCC 02-157 (ET Docket 98-80) and may be marketed after July 11, 2005 and is not affected by the 15.37(j) or 18.123 transition provisions. Timothy R. Johnson Examining Engineer mailto: [email protected] The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information may result in application termination. Correspondence should be considered part of the permanent submission and may be viewed from the Internet after a Grant of Equipment Authorization is issued. Please do not respond to this correspondence using the email reply button. In order for your response to be processed expeditiously, you must submit your documents through the AmericanTCB.com website. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the sender.

LABEL Format: This device complies with Part 15 of the FCC Rules Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation FCC ID: (Including Tx, FCC ID: QDWAB008WN100 ) LABEL Size: 80 x 40 mm LABEL Position: Tested to Comply With FCC Standard FOR HOME OR OFFICE USE MSQDCW615

Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Measurement of MPE 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT EUT : Wireless Cable Router Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Model No. : DCW615 Granted FCC ID : MSQDCW615 Frequency Range : 2.412 GHz ~ 2.462GHz Supported Channel: 11 Channel Modulation Skill : DBPSK, DQPSK, CCK Power Type : Powered by the PCMCIA slot of the client’s device Applicant : ASUSTeK Computer Inc. No. 150, Li-te Rd., Peitou, Taipei, Taiwan, R.O.C. Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, Equation for Predicting RF Fields: Friis Transmission Formula: 23 22 /10855.7 )20(4 08.156.36 4 cmmW R PG S − ×= × == ππ Estimated safe separation: cm PG R773.1 4 08.156.36 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 1.391 cm." Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (0.34 / 10) =1.08

Test Report ------------------------------------------------------------------------------ 1/47 Report No.: A5415840 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of Wireless Cable Router Applicant : ASUSTek Computer Inc. Model No. : DCW615 EUT : Wireless Cable Router FCC ID : MSQDCW615 Report No. : A5415840 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report ------------------------------------------------------------------------------ 3/47 Report No.: A5415840 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I. GENERAL ..................................................................................................................... 5 1.1 Introduction .............................................................................................................. 5 1.2 Description of EUT .................................................................................................. 5 1.3 Description of Support Equipment ........................................................................... 6 1.4 Configuration of System Under Test ........................................................................ 9 1.5 Verify the Frequency and Channel .......................................................................... 13 1.6 Test Procedure ........................................................................................................ 14 1.7 Location of the Test Site ......................................................................................... 14 1.8 General Test Condition ........................................................................................... 14 II. Section 15.101(a) : Equipment Authorization of Unintentional Radiators................ 15 III. Section 15.203 : Antenna Requirement........................................................................ 16 IV. Section 15.207 : Power Line Conducted Emissions for AC Powered Units ............. 17 4.1 Test Condition & Setup ........................................................................................... 17 4.2 List of Test Instruments ........................................................................................... 17 4.3 Test Configuration .................................................................................................. 18 4.4 Test Result of Conducted Emissions ....................................................................... 19 V. Section 15.247(a) : Technical Description of the EUT................................................. 20 VI. Section 15.247(a)(2) : Bandwidth for Direct Sequence System ................................. 21 6.1 Test Condition & Setup ........................................................................................... 21 6.2 Test Instruments Configuration ............................................................................... 21 6.3 List of Test Instruments ........................................................................................... 21 6.4 Test Result of Bandwidth ......................................................................................... 22 VII. Section 15.247(b) : Power Output ............................................................................... 26 7.1 Test Condition & Setup ........................................................................................... 26 7.2 List of Test Instruments ........................................................................................... 27 7.3 Test Result .............................................................................................................. 27 Test Report ------------------------------------------------------------------------------ 4/47 Report No.: A5415840 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 VIII. Section 15.247(c) : Spurious Emissions (Radiated) ................................................. 28 8.1 Test Condition & Setup ........................................................................................... 28 8.2 List of Test Instruments ........................................................................................... 29 8.3 Test Instruments Configuration ............................................................................... 30 8.4 Test Result of Spurious Radiated Emissions ........................................................... 32 8.5 Test Result of Bandedge........................................................................................... 37 IX. Section 15.247(d) : Power Spectral Density ................................................................ 40 9.1 Test Condition & Setup ........................................................................................... 40 9.2 Test Instruments Configuration ............................................................................... 40 9.3 List of Test Instruments............................................................................................ 40 9.4 Test Result of Power Spectral Density .................................................................... 41 X. Output Signal Test ......................................................................................................... 45 10.1 Test Condition & Setup ........................................................................................ 45 10.2 Test Configuration of Output Signal Test............................................................... 45 10.3 Output Signal Test Result....................................................................................... 46 Appendix A: Set Up Procedure .......................................................................................... 47 Test Report ------------------------------------------------------------------------------ 5/47 Report No.: A5415840 Traini…

Text truncated - open the document above for the full version.

Test Report -------------------------------------------------------------------------------- 37/47 Report No.: A5415840 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 8.5 Test Result of the Bandedge If any 100 kHz bandwidth outside these frequency bands, the radio frequency power that is produced by the modulation products of the spreading sequence, the information sequence and the carrier frequency shall be either at least 20 dB below that in any 100 kHz bandwidth within the band that contains the highest level of the desired power or shall not exceed the general levels specified id 15.209(a), We perform this section by the conducted manner, the RBW is set to 100kHz and VBW>RBW. We’d made the observation up to 10 th harmonics and the criterion is all the harmonic/spurious emissions must be 20dB below the highest emission level measured. If the emissions fall in the restricted bands stated in the Part15.205(a) must also comply with the radiated emission limits specified in Part15.209(a). (Peak mode: RBW=VBW=1MHz. Average mode: RBW=1MHz, VBW=10Hz) The following pages show our observations referring to the channel 1 and 11 respectively. Test Condition & Setup: same as 3.1 Test Report -------------------------------------------------------------------------------- 38/47 Report No.: A5415840 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Channel 1 Channel 11 Test Report -------------------------------------------------------------------------------- 39/47 Report No.: A5415840 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 This is the hard copy of our bandedge measurement generated by our bandedge testing program. The pictures shown above is the bandedge of channel 1 and 11. 1. The lob right and left by the fundamental side is already 20dB below t…
