Eee PC User Manual Eee PC 1018 Series 15G06Q261000 E5751 Notes for This Manual A few notes and warnings are used throughout this guide, allowing you to complete certain tasks safely and effectively. These notes have different degrees of importance as follows: WARNING! Important information that must be followed for safe operation. IMPORTANT! Vital information that must be followed to prevent damage to data, components, or persons. TIP: Tips for completing tasks. NOTE: Information for special situations. ASUS is devoted to creating environment-friendly products/ packagings to safeguard comsumers’ health while minimizing the impact on the environment. In order to reduce the use of substances harmful to the environment, the Eee PC™ product package does not come with the Eee PC™ support DVD. The reduction of the number of the manual pages complies with the reduction of carbon emission. For system recovery, refer to the section Using Recovery Partition for the instruction on the F9 recovery. For the detailed user manual and related information, refer to the user manual from the Window® desktop or visit the ASUS Support Site at http://support.asus.com/ ASUS Eee PC 2 Transportation Precautions To prepare your Eee PC for transport, you should turn it OFF and disconnect all external peripherals to prevent damage to the connectors. The hard disk drive’s head retracts when the power is turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should not transport your Eee PC while the power is still ON. Close the display panel to protect the keyboard and display panel. The Eee PC’s surface is easily dulled if not properly cared for. Be careful not to rub or scrape surfaces when transporting your Eee PC. You can put your Eee PC in a carrying case for protection from dirt, water, shock, and scratches. There are three main types of airport security devices: X-ray machines (used on items placed on conveyor belts), magnetic detectors (used on people walking through security checks), and magnetic wands (hand- held devices used on people or individual items). You can send your Eee PC and diskettes through airport X-ray machines. However, it is recommended that you do not send your Eee PC or diskettes through airport magnetic detectors or expose them to magnetic wands. Airplane Precautions Contact your airline if you want to use the Eee PC on the airplane. Most airlines have restrictions for using electronic devices. Most airlines allow electronic use only between and not during takeoffs and landings. Charging Your Batteries If you intend to use battery power, be sure to fully charge your battery pack before going on long trips. Remember that the power adapter charges the battery pack as long as it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge the battery pack when the Eee PC is in use. Remember to fully charge the battery (8 hours or more) before first use and whenever it is depleted to prolong battery life. The battery reaches its maximum capacity after a few full charging and discharging cycles. ASUS Eee PC  Top Side The top side may vary in appearance depending on models. The keyboard differs for each territory. OFFON 5 7 8 9 10 11 2 3 4 1 6 12 13 ASUS Eee PC  7 Camera Cover Switch The camera cover switch allows you to open and close the protective camera cover. Slide the switch to the left to close the camera cover. Slide the switch to the right to open the camera cover. Microphone (Built-in) Built-in Camera Camera Indicator Display Panel Express Gate Button (on selected models) When the Eee PC is turned off, pressing this button will launch Express Gate. Express Gate is an ASUS exclusive OS that provides you with quick access to the Internet and key applications without entering the Windows® OS. Super Hybrid Power button Under the Windows OS, this button functions as the Super Hybrid Power button. The button toggles power savings between various power saving modes. You can also control the function by press <Fn> + <Space Bar>. Wireless/Bluetooth Button (BT on selected models) The wireless/bluetooth button toggles the internal wireless LAN or Bluetooth ON or OFF. When enabled, the corresponding wireless/ bluetooth indicator lights up. You can also press <Fn> + <F2> to toggle the internal wireless LAN or Bluetooth ON or OFF. Audio Speaker System Audio features are software controlled. Status Indicators Battery Charge Indicator The battery charge indicator (LED) shows the battery charging status as follows: 1 2 3 4 5 6 8 9 ASUS Eee PC 5 Powered ON With Adapter Without Adapter High battery power (95%–100%) Green ONOff Medium battery power (11%–94%) Orange ONOff Low battery power (0%–10%) Orange BlinkingOrange Blinking Powered OFF / Standby mode With Adapter Without Adapter High battery power (95%–100%) Green ONOff Medium battery power (11%–94%) Orange ONOff Low battery power (0%–10%) Orange Blinking Off Hard Disk Drive (HDD) Indicator The hard disk drive indicator blinks when data is written to or read from the disk drive. Wireless/Bluetooth Indicator This is only applicable on models with built-in wireless LAN/ Bluetooth (on selected models). When the built-in wireless LAN/ Bluetooth is enabled, this indicator lights. Capital Lock Indicator Indicates that capital lock [Caps Lock] is activated when lighted. Power Switch (Windows) The power switch allows powering ON and OFF the Eee PC and recovering from STR. Press the switch once to turn ON and hold it to turn OFF the Eee PC. The power switch only works when the display panel is opened. Power Indicator The power indicator lights when the Eee PC is turned ON and blinks slowly when the Eee PC is in the Suspend-to-RAM (Sleep) mode. This indicator is OFF when the Eee PC is turned OFF. Keyboard 10 11 ASUS Eee PC 6 Fingerprint Scanner (on selected models) The built-in fingerprint scanner allows use of security software using your fingerprint as your identification key. Touch…

Text truncated - open the document above for the full version.

ASUSTeK Computer Inc. Date: May, 21, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID: MSQE18NE785H ATTESTATION FCC ID: MSQE18NE785H Product: Eee PC Model: Eee PC 1018PB We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA.

ASUSTeK Computer Inc. No.150, Li-te Rd Peitou, Taipei Ta i wa n Attestation for FCC Declaration of Conformity FCC ID: MSQE18NE785H Date: 2010/05/21 Please be notified that we, the undersigned, ASUSTEK COMPUTER INC. declares that the product which bears the above FCC ID is also compliant with the FCC requirements for DOC. The test report number supporting the DOC is 104393R-ITUSP01V02. Testing in regards to this report was done by QuieTek Corp., located at No.5-22, Rueishu Keng, Rueiping Tsuen, Linkou Shiang, Taipei County 244, Taiwan, which has been accredited in accordance to all of the requirements of 47CFR 2.948 (d) and (e) of the FCC rules and KDB349827.

ASUSTeK COMPUTER INC. FCC ID: MSQE18NE785H 4FL., No.150, Li-te Rd., Peitou, Taipei, Taiwan, R.O.C. Tel : 886-2-2894-3447 Federal Communications Commission Authorization and Evaluation Division May. 21 , 2010 Confidential Statement We have understood that the following request for confidential documents has been and viewable since the date of grant, since it has been granted. Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics : (Eee PC 1018PB) Schem Block Diagram: (Eee PC 1018PB) BlkDia Operational Description: (Eee PC 1018PB) OPDes Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 DFR § 2.803 and the importation rules in 47 CFR § 2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices . . We are requesting the commission to grant forty-five days short-term confidentiality request on the following attachments: External Photos: (Eee PC 1018PB) Expho Internal Photos: (Eee PC 1018PB) Inpho Test Setup Photos: (Eee PC 1018PB) Tsup User Manual: (Eee PC 1018PB) UserMan It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued.

RF_160, Issue 02 ASUSTeK Computer Inc. We Name: ASUSTeK Computer Inc. Address: No.150, Li-te Rd City: ......... Peitou, Taipei ............................................................... . Country: ......... Taiwan ........................................................................... . Declare that: Name Representative of agent: Gene Chang (1) Agent Company name: QuieTek Corp. Address: Fl.2, No.345, Xin-hu 2 nd Rd., Nei-hu District City: Taipei Country Taiwan is authorized to apply for Certification of the following product(s): Product description: ...... Eee PC ............ ..................... . Type designation: ...... Eee PC 1018PB ...... ..................... Trademark: ... ASUS ....................................... . ............ on our behalf. Date: ...... 2010/05/21 ............ .. City: ...... Peitou, Taipei ........................ .. Name: ...... Jackson Yen ...... ........................ .. (2) Function: .......Associate Vice President /EMC & Safety Department............ Signature: Tel: . ...... +886-2-28943447 Extension:3106 ......... . Fax: ...... +886-2-28987364 Email: ...... [email protected] Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

Eee PC (M/N:Eee PC 1018PB) EUT Photograph-External Photographs (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo

Eee PC/ 15G102321960 F4 1018PB

Eee PC (M/N: Eee PC 1018PB) EUT Photograph-Internal photograph (1) EUT Photo (2) EUT Photo (3) EUT Photo (4) EUT Photo (5) EUT Photo (6) EUT Photo (7) EUT Photo (8) EUT Photo

Report No：104393R-HPUSP09V01 Page: 1 of 22 SAR Test Report Product Name ：Eee PC Model No. ：Eee PC 1018PB Applicant ：ASUSTEK COMPUTER INC. Address ：No.150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C Date of Receipt ：2010/04/22 Issued Date ：2010/04/30 Report No. ：104393R-HPUSP09V01 Report Version ：V1.0 The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：104393R-HPUSP09V01 Page: 2 of 22 Test Report Certification Issued Date: 2010/04/30 Report No.:104393R-HPUSP09V01 Product Name ： Eee PC Applicant ： ASUSTEK COMPUTER INC. Address ： No.150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C Manufacturer ： 1. PEGATRON CORP TAOYUAN MFG 2. PROTEK(SHANGHAI)LTD 3. FULIN ELECTRONICAL TECHONOLOGY (CHANGSHU) CO LTD 4. FUXIANG PRECISION INDUSTRIAL (KUNSHAN) CO LTD Model No. ： Eee PC 1018PB Trade Name ： ASUS FCC ID ： MSQE18NE785H IC ID ： 3568A-E18NE785H Applicable Standard ： FCC Oet65 Supplement C June 2001 IEEE Std. 1528-2003 47CFR § 2.1093 Test Result ： Max. SAR Measurement (1g) 0.088 W/kg Application Type ： Certification The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Documented By ： (Adm. Assistant / Anny Chou ) Tested By ： (Engineer / Jung Chang) Approved By ： (Manager / Vincent Lin) Report No：104393R-HPUSP09V01 Page: 3 of 22 TABLE OF CONTENTS Description Page 1. General Information.......................................................................................5 1.1 EUT Description ............................................................................................................5 1.2 Antenna List ................................................................................................................... 5 1.3 Test Environment ...........................................................................................................6 2. SAR Measurement System..........................................................................7 2.1 DASY5 System Description .......................................................................................... 7 2.1.1 Applications ................................................................................................................ 8 2.1.2 Area Scans................................................................................................................... 8 2.1.3 Zoom Scan (Cube Scan Averaging)............................................................................ 8 2.1.4 Uncertainty of Inter-/Extrapolation and Averaging .................................................... 8 2.2 DASY5 E-Field Probe ................................................................................................... 9 2.2.1 Isotropic E-Field Probe Specification ......................................................................... 9 2.3 Boundary Detection Unit and Probe Mounting Device ............................................... 10 2.4 DATA Acquisition Electronics (DAE) and Measurement Server ............................... 10 2.5 Robot ............................................................................................................................ 11 2.6 Light Beam Unit........................................................................................................... 11 2.7 Device Holder ..............................................................................................................12 2.8 SAM Twin Phantom .................................................................................................... 12 3. Tissue Simulating Liquid...........................................................................13 3.1 The composition of the tissue simulating liquid .......................................................... 13 3.2 Tissue Calibration Result ............................................................................................. 13 3.3 Tissue Dielectric Parameters for Head and Body Phantoms ....................................... 14 4. SAR Measurement Procedure..................................................................15 4.1 SAR System Validation................................................................................................ 15 4.1.1 Validation Dipoles..................................................................................................... 15 4.1.2 Validation Result ....................................................................................................... 15 4.2 SAR Measurement Procedure ...................................................................................... 16 5. SAR Exposure Limits..................................................................................17 6. Test Equipment List.....................................................................................18 7. Measurement Uncertainty..........................................................................19 8. Peak Conducted Power Measurement....................................................20 9. Test Results..............................................................................................................21 9.1 SAR Test Results Summary ......................................................................................... 21 Report No：104393R-HPUSP09V01 Page: 4 of 22 Appendix ............................................................................................................................ 22 Appendix A. SAR System Validation Data Appendix B. SAR measurement Data Appendix C. Test Setup Photographs & EUT Photographs Appendix D. Probe Calibration Data Appendix E. Dipole Calibration Data Report No：104393R-HPUSP09V01 Page: 5 of 22 1. General Information 1.1 EUT Description Product Name Eee PC Trade Name ASUS Model No. Eee PC 1018PB FCC ID MSQE18NE785H IC ID 3568A-E18NE785H TX Frequency 2412MHz ~ 2462MHz WLAN Modul…

Text truncated - open the document above for the full version.

Test Report Industry Canada RSS-Gen Issue 2/RSS-210 Issue 7 FCC Part15 Subpart C Product Name : Eee PC Model No. : Eee PC 1018PB FCC ID : MSQE18NE785H IC : 3568A-E18NE785H Applicant ： ASUSTEK COMPUTER INC. Address ： NO.150, Li-Te Rd., Peitou, Taipei, Taiwan, R. O. C Date of Receipt : Apr. 27, 2010 Test Date : Apr. 28, 2010 ~ May. 05, 2010 Issued Date : May. 10, 2010 Report No. : 104S058R-RF-US-P05V01 Report Version : V1.0 The test results relate only to the samples tested. The test results shown in the test report are traceable to the national/international standard through the calibration of the equipment and evaluated measurement uncertainty herein. This report must not be used to claim product endorsement by TAF, NVLAP or any agency of the Government. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. Report No：104S058R-RF-US-P05V01 Page: 2 of 2 Test Report Certification Issued Date : May. 10, 2010 Report No. : 104S058R-RF-US-P05V01 Product Name : Eee PC Applicant : ASUSTEK COMPUTER INC. Address : NO.150, Li-Te Rd., Peitou, Taipei, Taiwan, R. O. C Manufacturer(1) : PEGATRON CORP TAOYUAN MFG Address(1) : 5, SHING YEH ST., KWEI SHAN HSIANG, TAOYUAN 333, TAIWAN Manufacturer(2) : PROTEK (SHANGHAI) LTD Address(2) : 3768 XIU YAN RD KANG QIAO TOWN PU DONG NEW District, Shanghai, China Manufacturer(3) : FULIN ELECTRONICAL TECHONOLOGY (CHANGSHU) CO LTD Address(3) : HUANGPU RD DONGNAN ECONOMICAL DEVELOPMENT ZONE CHANGSHU JIANGSU CHINA Manufacturer(4) : FUXIANG PRECISION INDUSTRIAL (KUNSHAN) CO LTD Address(4) : 299 NANSONG RD YU SHAN TOWN KUN SHAN JIANGSU CHINA Model No. : Eee PC 1018PB FCC ID : MSQE18NE785H IC : 3568A-E18NE785H EUT Voltage : 19Vdc Trade Name : ASUS Applicable Standard : FCC CFR Title 47 Part 15 Subpart C: 2008 ANSI C63.4: 2003 RSS-Gen Issue 2/RSS-210 Issue 7 Test Result : Complied Performed Location : SuZhou EMC laboratory No.99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., SuZhou, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Registration Number: 800392, IC Lab Code: 4075B Documented By : ( Engineering ADM: Alice Ni ) Reviewed By : ( Engineering Supervisor: Marlin Chen ) Approved By : ( Engineering Manager: Dream Cao ) Report No：104S058R-RF-US-P05V01 Page: 3 of 3 Laboratory Information We, QuieTek Corporation, are an independent EMC and safety consultancy that was established the whole facility in our laboratories. The test facility has been accredited/accepted(audited or listed) by the following related bodies in compliance with ISO 17025, EN 45001 and specified testing scope: The related certificate for our laboratories about the test site and management system can be downloaded from QuieTek Corporation’s Web Site : http://www.quietek.com/tw/emc/accreditations/accreditations.htm The address and introduction of QuieTek Corporation’s laboratories can be founded in our Web site : http://www.quietek.com/ If you have any comments, Please don’t hesitate to contact us. Our contact information is as below: HsinChu Testing Laboratory : No.75-2, 3rd Lin, Wangye Keng, Yonghxing Tsuen, Qionglin Shiang, Hsinchu County 307, Taiwan, R.O.C. TEL:+886-3-592-8858 / FAX:+886-3-592-8859 E-Mail : [email protected] LinKou Testing Laboratory : No. 5-22, Ruei-Shu Valley, Ruei-Ping Tsuen, Lin-Kou Shiang, Taipei, Taiwan, R.O.C. TEL : 886-2-8601-3788 / FAX : 886-2-8601-3789 E-Mail : [email protected] Suzhou (China) Testing Laboratory : No. 99 Hongye Rd., Suzhou Industrial Park Loufeng Hi-Tech Development Zone., Suzhou,China. TEL : +86-512-6251-5088 / FAX : +86-512-6251-5098 E-Mail : [email protected] Taiwan R.O.C. :BSMI, NCC, TAF Germany :TUV Rheinland Norway :Nemko, DNV USA :FCC, NVLAP Japan :VCCI Report No：104S058R-RF-US-P05V01 Page: 4 of 4 TABLE OF CONTENTS Description Page 1. General Information .................................................................................................6 1.1. EUT Description ......................................................................................................6 1.2. Mode of Operation...................................................................................................8 1.3. Tested System Details .............................................................................................9 1.4. Configuration of Tested System .............................................................................10 1.5. EUT Exercise Software.......................................................................................... 11 2. Technical Test ........................................................................................................12 2.1. Summary of Test Result.........................................................................................12 2.2. Test Environment...................................................................................................14 3. Conducted Emission..............................................................................................15 3.1. Test Equipment......................................................................................................15 3.2. Test Setup..............................................................................................................15 3.3. Limit.......................................................................................................................16 3.4. Test Procedure......................................................................................................16 3.5. Uncertainty ............................................................................................................16 3.6. Test Result.............................................................................................................17 4. Radiated Emission.................................................................................................19 4.1. Test Equipment......................................................…
