MSQI005DASUS Phone

E17160 First Edition Model: ASUS_I005D / ASUS_I005DC First Edition / January 2021 ASUS Phone (Mobile Phone) Model: ASUS_I005D / ASUS_I005DC (ZS673KS) Front features Touch screen display Receiver & Speaker Front camera Proximity sensor and light sensor Fingerprint sensor LED indicator Speaker Before you start, ensure that you have read all the safety information and operating instructions in this User Guide to prevent injury or damage to your device. NOTES: • For the complete E-Manual and more detailed information, refer to https://www.asus.com/support/. • Illustrations are for reference only. Actual product appearance may vary. Side features AirTrigger touch sensor Power key Volume key AirTrigger touch sensor Microphone Nano SIM card slot Nano SIM card tray eject hole USB Type-C port Pogo Pin Microphone USB Type-C portAudio jack Microphone Rear cameras Rear cover NFC detection area Camera flash Microphone ROG Vision Rear Touch Rear Touch Rear features ASUS_I005D NOTES: • The USB Type-C port supports USB 2.0 transfer rate. The USB Type-C port on the left side of your ROG Phone supports USB 3.2 Gen 1 transfer rate. • Go to Settings > Advanced > AirTriggers to set AirTriggers. ASUS_I005DC Rear cameras Rear cover NFC detection area Camera flash Microphone Aura light AeroActive Cooler features Use the AeroActive Cooler to keep your ROG Phone working at a high frequency during heavy workloads by providing a better thermal solution, and offering the ultimate user experience. NOTES: • It is not recommended that you connect other devices to your ROG Phone when you install the phone on the AeroActive Cooler. • Docking your ROG Phone on an accessory with fan(s) will impact the audio quality when making phone calls and recording. Audio jack Fan Aura light Kickstand Cooler button Cooler button Pogo Pin To install AeroActive Cooler: 1. Align the female Pogo Pin on the side of your phone with the male Pogo Pin on the bottom of your AeroActive Cooler and gently push down your phone. 2. Push your phone backward until you hear a click. NOTES: • Only ASUS_I005D comes with the AeroActive Cooler. • Connect your AeroActive Cooler to the Pogo Pin of your ROG Phone. • You can use your AeroActive Cooler while using the bundled ROG Phone 5 Case. To use the kickstand of AeroActive Cooler: Open the kickstand on the back of the AeroActive Cooler to get optimal viewing experience. 3 1 2 Charging your ROG Phone To charge your ROG Phone: 1. Connect the USB connector into the power adapter’s USB port. 2. Connect the other end of the USB Type-C cable to your ROG Phone. 3. Plug the power adapter into a wall socket. or USB Type-C port 3 1 2 NOTES: • We recommend that you charge your ROG phone through one USB Type-C port at a time. • Only the USB Type-C port on the left side of your ROG Phone has Display Port functionality. • If you connect USB Type-C OTG or charging devices to both of the USB Type-C ports on your ROG Phone, the USB Type-C port on the left side of your ROG Phone will become the master and the charging current or OTG device on the bottom port will be limited. NOTES: • For safety purposes, use ONLY the bundled power adapter and cable to avoid damaging your device and prevent the risk of injury. • For safety purposes, use ONLY the bundled power adapter and cable to charge your ROG Phone. • The input voltage range between the wall outlet and this adapter is AC 100V - 240V. The output voltage of the AC power adapter for this device is +5V-20V3A, 60W. IMPORTANT! • When using your ROG Phone while it is plugged to a power outlet, the grounded power outlet must be near to the unit and easily accessible. • When charging your ROG Phone through your computer, ensure that you plug the USB Type-C cable to your computer’s USB port. • DO NOT charge your ROG phone underwater or when the USB connector is wet. • Avoid charging your ROG Phone in an environment with ambient temperature of above 35 ° C (95 ° F). 1. Push a pin into the hole on the Nano SIM card tray to eject it. Insert the Nano SIM card(s) into the card slot(s). Installing a Nano SIM card To install a Nano SIM card: 2. Push the tray to close it. Nano-SIM1 Nano-SIM2 CAUTION! • Do not use sharp tools or solvent on your device to avoid scratches on it. • Use only a standard Nano SIM card on your ROG Phone. Using NFC NOTE: NFC is only available in selected regions/countries. You can use NFC in the following two scenarios: Reader mode: Your phone reads information from a contactless card, NFC tag, or other NFC devices. Place the NFC area of your phone on the contactless card, NFC tag, or NFC device. Card Emulation mode: Your phone can be used like a contactless card. Place the NFC area of your phone on the NFC area of the NFC reader. NOTES: • Both Nano SIM card slots support GSM/GPRS/EDGE, WCDMA/ HSPA+/DC-HSPA+, FDD-LTE, TD-LTE, and 5G NR Sub-6 network bands. Both Nano SIM cards can connect to VoLTE (4G Calling) service. But only one can connect to 5G NR Sub- 6 data service at a time. • Actual network and frequency band usage depends on network deployment in your area. Contact your telecom carrier if 5G NR Sub-6 support and VoLTE (4G Calling) service are available in your area. Federal Communications Commission Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not ins…

Text truncated - open the document above for the full version.

ASUSTeK Computer Inc 1F, No. 15, Lide Rd.Beitou, Taipei Taiwan 112 Tel: +886-2-28943447, Fax: +886-2-28987364 February 17, 2021 Attestation We, ASUSTeK Computer Inc, hereby declare the difference between models under FCC ID: MSQI005D. The difference between model ASUS_I005D and ASUS_I005DC is the back cover design. Except this, no other difference applied. __________________ Jackson Yen [email protected]

ASUSTeK Computer Inc 1F, No. 15, Lide Rd.Beitou, Taipei Taiwan 112 Tel: +886-2-28943447, Fax: +886-2-28987364 Date: January 28, 2021 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd Columbia MD 21046-1609 Subject: Request for Confidentiality FCC ID: MSQI005D To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting confidentiality for exhibits filed with the commission supporting the application of equipment authorization for those items referenced above. ASUSTeK Computer Inc respectfully requests the Commission to withhold indefinitely from public disclosure the following attachments under Long-Term Confidentiality.  Schematic Diagrams  Block Diagrams  Part List  Operational Description  Tune-up Procedure The above listed documents contain detailed system and equipment descriptions that are proprietary and confidential information under ASUSTeK trade secret protection. Public disclosure of above documents would be harmful to our company and would provide competitors an unfair advantage. This information is not made publicly available even after commercial release of the device. In additional to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We request the commission to grant short-term confidentiality request on the following attachments for 180 days after the grant as outlined in Public Notice DA 04-1705.  External Photos  Internal Photos  Test Setup Photos  User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and that information will be available for public review once the grant of equipment authorization is issued. Sincerely, ________________ Jackson Yen [email protected]

ASUSTeK Computer Inc 1F, No. 15, Lide Rd.Beitou, Taipei Taiwan 112 Tel: +886-2-28943447, Fax: +886-2-28987364 Date: January 28, 2021 To whom it may concern, Please be notified that I, Jackson Yen , have designated Jones Tsai of Sporton International Inc. as the persons being responsible for this project and to sign the form 731 and other documentation. Any and all acts carried out in their professional capacity by Jones Tsai of Sporton International Inc. in connection with all processes required for FCC approval and any communication needed with the national authority, shall have the same legal authority as acts on our own behalf. We further certify that neither the applicant nor any party to this application, as defined in 47 CFR Ch. 1.2002 (b), is subject to a denial to Federal benefits, that include FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1998, 21 U.S.C. 862. This authorization is limited to the following product, and shall remain in place until completion of the certification, or until revoked, whichever is earlier: FCC ID: MSQI005D If you have any acknowledgement and response, please send it to Sporton International Inc. directly. Should you have any questions or comments regarding this matter, please don’t hesitate to contact me. Sincerely yours, Jackson Yen [email protected]

PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 1 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 1. External Photograph of EUT Brand Name: ASUS / Model Name: ASUS_I005D, ASUS_I005DC Sample 1 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 2 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 3 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 4 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 5 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 6 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 720510 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 7 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Sample 2 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 8 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 9 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 10 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 11 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 12 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 13 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 2. Photograph of Accessory Brand Name: ASUS / Model Name: ASUS_I005D, ASUS_I005DC Specification of Accessory AC Adapter Brand Name ROG Model Name A320R-200325C-US Battery Brand Name ASUS Model Name C21P2001 USB Cable 1 Brand Name ASUS Model Name LA9UC007-CS-R USB Cable 2 Brand Name ASUS Model Name LQ109006 Bumper Brand Name WISTEC ELECTRONIC Model Name 201223003 AeroActive Cooler 1 Brand Name ASUS Model Name I005 AeroActive Cooler 2 Brand Name ASUS Model Name I005 AeroActive Cooler 3 Brand Name ASUS Model Name I005 AeroActive Cooler 4 Brand Name ASUS Model Name I005 Remark: For accessories equipped with this EUT, please refer to the following photos. PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 14 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 720510 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 15 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 AC Adapter PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 16 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Battery PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 17 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 18 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Bumper PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 19 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 20 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 AeroActive Cooler 1 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 21 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 22 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 AeroActive Cooler 2 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 23 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 24 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 AeroActive Cooler 3 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 25 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 26 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 AeroActive Cooler 4 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 27 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01

1 E-Label Information 1. The information that will be displayed on the e-label and information that will remain in the user manual is shown below: Information on E-label In Manual FCC ID , IC ID Yes Yes 15.19 statement (“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”) Yes Yes Class A/B Digital Device user manual statements No Yes Images of the e-label screen are provided below: 2 3 2. Users are able to access the information in no more than three steps in a device’s menu. The actual Steps are: Settings> System> Regulatory labels No special access codes or permissions are required to go through the above steps beyond entering a user-defined password to protect against unauthorized access to the device. 3. The information is stored on the device, no special accessories or supplemental plug-ins (e.g., a SIM/USIM card) are required to access the information. Yes. 4. Users are provided specific instructions on how to access the information. Yes. 5. The above information must be programmed by the responsible party and the information must be secured in such a manner that third-parties cannot modify it. The e-label information is pre-programmed by the manufacturer. The user cannot modify the e-label formation. 6. When e-labeling is used, a physical temporary label is also required on the product, or a label on the packaging, at the time of importation, marketing, and sales. The physical label will be on the packaging box.

PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 28 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 3. Internal Photograph of EUT Brand Name: ASUS / Model Name: ASUS_I005D, ASUS_I005DC 720510 Sample 1 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 29 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Sample 2 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 30 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Sample 1 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 31 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 32 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 33 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 34 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 35 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 36 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 37 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 38 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 39 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 40 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 41 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 42 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 43 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 44 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 45 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 46 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 47 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 48 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 49 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01

PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 50 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 51 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 52 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 53 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 54 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 55 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 56 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 57 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 58 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 59 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 60 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 61 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 62 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 63 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 64 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 65 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 66 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 67 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 68 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 69 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Sample 2 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 70 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 71 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 72 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01

PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 73 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 74 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 0 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 75 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 1 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 76 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 2 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 77 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 3 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 78 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 4 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 79 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 5 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 80 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 6 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 81 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 8 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 82 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 9 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 83 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 Antenna 11 PHOTOGRAPHS OF EUT Report No.: EP082114 TEL : 886-3-327-3456 Page Number : 84 of 84 FAX : 886-3-328-4978 Issued Date : Jan. 29, 2021 Report Version : 01 ─────THE END──── NFC Antenna

Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2021/1/6 System Check_Head_750MHz DUT: D750V3-1107 Communication System: CW; Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750_210106 Medium parameters used: f = 750 MHz; σ = 0.902 mho/m; ε r = 42.8; ρ = 1000 kg/m 3 Ambient Temperature：23.4°C; Liquid Temperature：22.4°C DASY5 Configuration: - Probe: ES3DV3 - SN3169; ConvF(6.57, 6.57, 6.57); Calibrated: 2020/5/27 - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn915; Calibrated: 2020/6/22 - Phantom: SAM_Right; Type: QD000P40CD; Serial: TP:1815 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=50mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.490 mW/g Pin=50mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.9 V/m; Power Drift = -0.05 dB Peak SAR (extrapolated) = 0.618 W/kg SAR(1 g) = 0.420 mW/g; SAR(10 g) = 0.278 mW/g Maximum value of SAR (measured) = 0.495 mW/g 0 dB = 0.495mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2021/1/14 System Check_Head_750MHz DUT: D750V3-1107 Communication System: CW; Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750_210114 Medium parameters used: f = 750 MHz; σ = 0.895 mho/m; ε r = 43.5; ρ = 1000 kg/m 3 Ambient Temperature：23.2 °C; Liquid Temperature：22.2 °C DASY5 Configuration: - Probe: ES3DV3 - SN3169; ConvF(6.57, 6.57, 6.57); Calibrated: 2020/5/27 - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn915; Calibrated: 2020/6/22 - Phantom: SAM_Right; Type: QD000P40CD; Serial: TP:1815 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.56 mW/g Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 55.6 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 3.09 W/kg SAR(1 g) = 2.15 mW/g; SAR(10 g) = 1.45 mW/g Maximum value of SAR (measured) = 2.50 mW/g 0 dB = 2.50mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2021/1/18 System Check_Head_750MHz DUT: D750V3-1107 Communication System: CW; Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750_210118 Medium parameters used: f = 750 MHz; σ = 0.903 mho/m; ε r = 41.8; ρ = 1000 kg/m 3 Ambient Temperature：23.5 °C; Liquid Temperature：22.5 °C DASY5 Configuration: - Probe: ES3DV3 - SN3169; ConvF(6.57, 6.57, 6.57); Calibrated: 2020/5/27 - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn915; Calibrated: 2020/6/22 - Phantom: SAM_Right; Type: QD000P40CD; Serial: TP:1815 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=250mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 2.58 mW/g Pin=250mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 55.6 V/m; Power Drift = -0.15 dB Peak SAR (extrapolated) = 3.12 W/kg SAR(1 g) = 2.17 mW/g; SAR(10 g) = 1.46 mW/g Maximum value of SAR (measured) = 2.52 mW/g 0 dB = 2.52mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2021/1/21 System Check_Head_750MHz DUT: D750V3-1107 Communication System: CW; Frequency: 750 MHz;Duty Cycle: 1:1 Medium: HSL_750_210121 Medium parameters used: f = 750 MHz; σ = 0.894 mho/m; ε r = 40.3; ρ = 1000 kg/m 3 Ambient Temperature：23.1°C; Liquid Temperature：22.1°C DASY5 Configuration: - Probe: ES3DV3 - SN3169; ConvF(6.57, 6.57, 6.57); Calibrated: 2020/5/27 - Sensor-Surface: 3mm (Mechanical Surface Detection) - Electronics: DAE4 Sn915; Calibrated: 2020/6/22 - Phantom: SAM_Right; Type: QD000P40CD; Serial: TP:1815 - Measurement SW: DASY52, Version 52.10 (4);SEMCAD X Version 14.6.14 (7483) Pin=50mW/Area Scan (61x61x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (interpolated) = 0.485 mW/g Pin=50mW/Zoom Scan (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 23.9 V/m; Power Drift = -0.06 dB Peak SAR (extrapolated) = 0.613 W/kg SAR(1 g) = 0.417 mW/g; SAR(10 g) = 0.276 mW/g Maximum value of SAR (measured) = 0.491 mW/g 0 dB = 0.491mW/g Test Laboratory: Sporton International Inc. SAR/HAC Testing Lab Date: 2021/1/06 System Check_Head_835MHz DUT: D835V2-4d167 Communication System: CW; Frequency: 835 MHz;Duty Cycle: 1:1 Medium: HSL_8…
