MSQK017ASUS TABLET

User Guide E9024 ASUS Tablet First Edition / April 2014 Charging your device Ensure to fully charge your ASUS Tablet before using it in battery mode for extended periods. Remember that the power adapter charges your ASUS Tablet as long as it is plugged into an AC power source. Be aware that it takes much longer to charge the ASUS Tablet when it is in use. IMPORTANT! Do not leave the ASUS Tablet connected to the power supply once it is fully charged. ASUS Tablet is not designed to be left connected to the power supply for extended periods of time. Airplane precautions Contact your airline provider to learn about related inflight services that can be used and restrictions that must be followed when using your ASUS Tablet in-flight. IMPORTANT! You can send your ASUS Tablet through x-ray machines (used on items placed on conveyor belts), but do not expose them from magnetic detectors and wands. Safety precautions This ASUS Tablet should only be used in enviroments with ambient temperatures between 0°C to 35°C (32°F to 95°F). Long time exposure to extremely high or low temperature may quickly deplete and shorten the battery life. To ensure the battery’s optimal performance, ensure that it is exposed within the recommended environment temperature. ASUS Tablet 3 DRAFT v4 Package contents NOTES: • If any of the items is damaged or missing, contact your retailer. • The bundled power adapter varies with country or region. ASUS TabletPower adapter ASUS Tablet USER GUIDE Warranty cardUser guide ASUS Tablet 4 DRAFT v4 Touch screen panel Your ASUS Tablet Front view Front camera Audio speaker Microphone ASUS Tablet 5 DRAFT v4 Rear view Micro USB 2.0 port Volume button Power button Speaker/Headset portRear camera MicroSD card slot* * The microSD card slot supports microSD and microSDHC card formats. ASUS Tablet 6 DRAFT v4 Charging your ASUS Tablet To charge your ASUS Tablet: Charge your ASUS Tablet for eight (8) hours before using it in battery mode for the first time. Plug the micro USB connector into your ASUS Tablet. Plug the power adapter into a grounded power outlet. ASUS Tablet 7 DRAFT v4 NOTES: • Your ASUS Tablet can be charged via the USB port on a computer only when it is in sleep mode (screen off ) or turned off. • Charging through a USB port of a computer may take longer time to complete. • If your computer does not provide enough power for charging your ASUS Tablet, charge your ASUS Tablet via the grounded power outlet instead. IMPORTANT! • Use only the bundled power adapter and micro USB cable to charge your ASUS Tablet. Using a different power adapter may damage your ASUS Tablet. • Peel the protective film off from the power adapter and micro USB cable before charging the ASUS Tablet to prevent risk or injury. • Ensure to plug the power adapter to the correct power outlet with the correct input rating. The output voltage of this adapter is DC 5 V, 1 A. • When using your ASUS Tablet while plugged-in to a power outlet, the grounded power outlet must be near the unit and easily accessible. • Do not place objects on top of your ASUS Tablet. ASUS Tablet 8 DRAFT v4 Appendices Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by doing one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ASUS Tablet 9 DRAFT v4 • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co- located or operating in conjunction with any other antenna or transmitter. RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels. The highest SAR value for the device as reported to the FCC is 0.65 W/kg when placed next to the body. The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: MSQK017. ASUS Tablet 10 DRAFT v4 Canada, Industry Canada (IC) Notices This Class B digital apparatus complies with Canadian ICES-003, RSS-210, …

Text truncated - open the document above for the full version.

4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Date: April 18, 2014 Declaration We, ASUSTeK Computer Inc, declare that the device, FCC ID:MSQK017, Model Name:K017, does not support any non-US channels in all the operational mode(s) in North America. All non-US frequencies and Country code selection are disabled through proprietary software and is not user changeable. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours,

Page 1 of 9 Report No.: 140321C03 CONSTRUCTION PHOTOS OF EUT Page 2 of 9 Report No.: 140321C03 Page 3 of 9 Report No.: 140321C03 Page 4 of 9 Report No.: 140321C03 Page 5 of 9 Report No.: 140321C03 Page 6 of 9 Report No.: 140321C03 Page 7 of 9 Report No.: 140321C03 Page 8 of 9 Report No.: 140321C03 Page 9 of 9 Report No.: 140321C03

17 mm 38.72 mm 5.26mm US/CAN (美加) CS20 E187242 ASUS Tablet Made in China Model: K017 Input: + 5V 1A, 5W FCC ID: MSQK017 IC: 3568A-K017 000000000000 ME170C

FCC ID: MSQK017 Back cover of EUT Label Location

Page 1 of 11 Report No.: 140321C03 CONSTRUCTION PHOTOS OF EUT Page 2 of 11 Report No.: 140321C03 Page 3 of 11 Report No.: 140321C03 Page 4 of 11 Report No.: 140321C03 Page 5 of 11 Report No.: 140321C03 Page 6 of 11 Report No.: 140321C03 Page 7 of 11 Report No.: 140321C03 Page 8 of 11 Report No.: 140321C03 Page 9 of 11 Report No.: 140321C03 Page 10 of 11 Report No.: 140321C03 Page 11 of 11 Report No.: 140321C03

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 26 Report No. : SA140321C03 Issued Date : Apr. 07, 2014 FCC SAR Test Report Report No. : SA140321C03 Applicant : ASUSTek COMPUTER INC. Address : 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Product : ASUS Tablet (WiFi/Bluetooth/GPS) FCC ID : MSQK017 Brand : ASUS Model No. : K017 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 KDB 248227 D01 v01r02 / KDB 447498 D01 v05r02 / KDB 616217 D04 v01r01 KDB 648474 D04 v01r02 Sample Received Date : Mar. 21, 2014 Date of Testing : Apr. 01, 2014 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Vera Huang / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 26 Report No. : SA140321C03 Issued Date : Apr. 07, 2014 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot .................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 Volume Scan Procedure ................................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................................... 16 3.4.5 SAR Averaged Met…

Text truncated - open the document above for the full version.

Report No.: RF140321C03 1 of 66 Report Format Version 5.2.0 FCC TEST REPORT (BLUETOOTH) REPORT NO.: RF140321C03 MODEL NO.: K017 FCC ID: MSQK017 RECEIVED: Mar. 21, 2014 TESTED: Mar. 31, 2014 ~ Apr. 16, 2014 ISSUED: Apr. 17, 2014 APPLICANT: ASUSTek COMPUTER INC. ADDRESS: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140321C03 2 of 66 Report Format Version 5.2.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................................. 5 1. CERTIFICATION ................................................................................................................................. 6 2. SUMMARY OF TEST RESULTS ........................................................................................................ 7 2.1 MEASUREMENT UNCERTAINTY ............................................................................................. 8 3. GENERAL INFORMATION ................................................................................................................. 9 3.1 GENERAL DESCRIPTION OF EUT ........................................................................................... 9 3.2 DESCRIPTION OF TEST MODES ............................................................................................ 11 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................. 12 3.3 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 16 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 16 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 16 4. TEST TYPES AND RESULTS (FOR BLUETOOTH EDR) ............................................................... 17 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 17 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 17 4.1.2 TEST INSTRUMENTS ................................................................................................. 18 4.1.3 TEST PROCEDURES ................................................................................................. 19 4.1.4 DEVIATION FROM TEST STANDARD ....................................................................... 19 4.1.5 TEST SETUP ............................................................................................................... 20 4.1.6 EUT OPERATING CONDITIONS ................................................................................ 20 4.1.7 TEST RESULTS........................................................................................................... 21 <Duty cycle correction fator> ............................................................................................................ 24 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 26 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 26 4.2.2 TEST INSTRUMENTS ................................................................................................. 26 4.2.3 TEST PROCEDURES ................................................................................................. 27 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 27 4.2.5 TEST SETUP ............................................................................................................... 28 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 28 4.2.7 TEST RESULTS........................................................................................................... 29 4.3 NUMBER OF HOPPING FREQUENCY USED ........................................................................ 31 4.3.1 LIMIT OF HOPPING FREQUENCY USED ................................................................. 31 4.3.2 TEST SETUP ............................................................................................................... 31 4.3.3 TEST INSTRUMENTS ...........................................................................…

Text truncated - open the document above for the full version.

FCC SAR Test Report Report Format Version 5.0.0 Issued Date : Apr. 07, 2014 Report No. : SA140321C03 Appendix D. Photographs of EUT and Setup FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA140321C03 <Photographs of EUT> <Photographs of SAR Setup> Right Cheek Right Tilted Left Cheek Left Tilted FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA140321C03 Rear Face of EUT with 0 cm Gap Top Side of EUT with 0 cm Gap Left Side of EUT with 0 cm Gap

Report No.: RF140321C03 1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (For Bluetooth) Report No.: RF140321C03 2 CONDUCTED EMISSION TEST (For WLAN 2.4GHz) Report No.: RF140321C03 3 RADIATED EMISSION TEST (For WLAN 2.4GHz / Bluetooth EDR / Bluetooth LE)
