Report No. 042L057FI Page: 6 of 64 Version:1.0 1.2. Operational Description EUT is a Notebook P.C with 11 channels. This device provided four kinds of transmitting speed 1, 2, 5.5 and 11Mbps. The device of RF carrier is DQPSK, DB PSK and CCK (IEEE 802.11b) or eight kinds of transmitting speed 6, 9, 12, 18, 24, 36, 48 and 54Mbps. The device of RF carrier is OFDM (IEEE 802.11g). The device adapts direct sequence spread spectrum modulation. The antenna was Connector provides diversity function to improve the receiving function. This Notebook P.C, compliant with IEEE 802.11b and IEEE 802.11g, is a high-efficiency Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direst Sequence Spread Spectrum (DSSS) radio transmission, the Notebook P.C Wired Equivalent Protection (WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any IEEE 802.11b and IEEE 802.11g network. Test Mode: Mode 1: Transmitter 802.11b Mode 1: Transmitter 802.11g

Report No. 042L057FI Page: 1 of 3 Version: 1.0 RF Exposure Evaluation declaration Product Name : Notebook P.C Model No.: M2400N FCC ID: MSQM2NWM3B2200 Applicant : ASUSTeK COMPUTER INC. Address : No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Date of Receipt : Feb. 05, 2004 Date of Declaration: Jan. 29, 2004 Report No. : 042L057FI The declaration results relate only to the samples calculated. The declaration shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 042L057FI Page: 2 of 3 Version: 1.0 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18°Cand 78％ RH. Report No. 042L057FI Page: 3 of 3 Version: 1.0 1.3. Test Result of RF Exposure Evaluation Product : Notebook P.C Test Item : RF Exposure Evaluation Test Site : No.3 OATS Antenna Gain Antenna Gain: The maximum Gain measured in fully anechoic chamber is 0dBi in linear scale. 802.11b Output Power Into Antenna & RF Exposure Evaluation Distance (0dBi): Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 2.5 cm (mW/cm2) 1 2411.80 101.1579 1.2880 6 2438.10 74.8170 0.9526 11 2460.80 73.2825 0.9331 802.11g Output Power Into Antenna & RF Exposure Evaluation Distance (0dBi): Channel Frequency (MHz) Output Power to Antenna (mW) Power Density at R = 2.5 cm (mW/cm2) 1 2411.80 36.2243 0.4612 6 2435.20 34.0408 0.4334 11 2460.80 32.5087 0.4139 The distance r (4 th column) calculated from the Fries transmission formula is far shorter than 2.5 cm separation requirement.

Report No. : ES/2004/30001 Page : 1 of 48 TEST REPORT Equipment Under Test : Notebook P.C. Model No. : M2400N FCC ID : MSQM2NWM3B2200 Applicant : ASUSTeK COMPUTER INC. Address of Applicant : 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Date of Receipt : 2004.03.05 Date of Test(s) : 2004.03.10-2004.03.12 Date of Issue : 2004.03.12 Standards: FCC OET Bulletin 65 supplement C, ANSI/IEEE C95.1 , C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Taiwan E&E Services or testing done by SGS Taiwan E&E Services in connection with distribution or use of the product described in this report must be approved by SGS Taiwan E&E Services in writing. Tested by : Dikin Yang Date : 2004/03/12 Approved by : Robert Chang Date : 2004/03/12 Report No. : ES/2004/30001 Page : 2 of 48 Contents 1. General Information 1.1 Testing Laboratory 4 1.2 Details of Applicant 4 1.3 Description of EUT(s) 4 1.4 Test Environment 5 1.5 Operation description 5 1.6 Evaluation procedures 6 1.7 The SAR Measurement System 7 1.8 System Components 9 1.9 SAR System Verification 10 1.10 Tissue Simulant Fluid for the Frequency Band 2.4 to 2.5 GHz 11 1.11 Test Standards and Limits 12 2. Instruments List 14 3. Summary of Results 15 4. Measurements 17 802.11b Configuration 1 4.1.1 Rear Side position, lowest channel 17 4.1.2 Rear Side position, middle channel 18 4.1.3 Rear Side position, highest channel 19 Configuration 2 4.1.4 Bottom face position, lowest channel 20 4.1.5 Bottom face position, middle channel 21 4.1.6 Bottom face position, highest channel 22 Configuration 3 4.1.7 LCD panel position, lowest channel 23 4.1.8 LCD panel position, middle channel 24 4.1.9 LCD panel position, highest channel 25 802.11g Configuration 1 4.2.1 Rear Side position, lowest channel 26 4.2.2 Rear Side position, middle channel 27 4.2.3 Rear Side position, highest channel 28 Configuration 2 4.2.4 Bottom face position, lowest channel 29 4.2.5 Bottom face position, middle channel 30 4.2.6 Bottom face position, highest channel 31 Configuration 3 4.2.7 LCD panel position, lowest channel 32 4.2.8 LCD panel position, middle channel 33 4.2.9 LCD panel position, highest channel 34 4.3 System Performance Validation 35 Report No. : ES/2004/30001 Page : 3 of 48 APPENDIX 1. Photographs of Test Setup 36 2. Photographs of EUT 39 3. Probe Calibration certificate 42 4. Uncertainty Analysis 46 5. Phantom description 47 6. System Validation from Original equipment supplier 48 Report No. : ES/2004/30001 Page : 4 of 48 1. General Information 1.1 Testing Laboratory SGS Taiwan Ltd. ( FCC Registration number: 573967 ) 1F, No. 134, Wukung Road, Wuku industrial zone Taipei county , Taiwan , R.O.C. Telephone : +886-2-2299-3279 Fax : +886-2-2298-0488 Internet : http://www.sgs.com.tw 1.2 Details of Applicant Name : ASUSTeK COMPUTER INC. Address : 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. 1.3 Description of EUT(s) Equipment Type Notebook P.C. Test Procedure FCC OET Bulletin 65, Supplement C TX Frequency range 2412-2462 MHz FCC ID MSQM2NWM3B2200 Model No. M2400N Number Of Channel 11 Modulation Direct Sequence Spread Spectrum (DSSS) DEVICE CATEGORY PORTABLE DEVICES EXPOSURE CATEGORY GENERAL POPULATION / UNCONTROLLED EXPOSURE 802.11b 11 Mbps Transfer Rate 802.11g6 Mbps 802.11b0.27 W/kg Max. SAR(1g) Measured 802.11g 0.146 W/kg Antenna Type Semi-PIFA I/O Port Mini PCI Report No. : ES/2004/30001 Page : 5 of 48 Power Supply 19Vdc from AC adapter NOTE: 1. The mini PCI card, which brand is Intel and the model name is WM3B2200BG, is specified to this EUT. 2. The EUT is powered by the following adapter: Brand DELTA Model ADP-65DB Input 100-240Vac 1.5A 50-60Hz Output 19Vdc 3.42A 3. For more detailed features description, please refer to the manufacturer's specifications or User's Manual. 1.4 Test Environment Ambient temperature : 22.4° C Tissue Simulating Liquid : 21.6° C Relative Humidity : 47 % 1.5 Operation Configuration 802.11b 802.11g Channel Frequency Under Test And Its Conducted Output Power 20.05dBm (2412MHz) 18.74dBm (2437MHz) 18.65dBm (2462MHz) 15.59dBm (2412MHz) 15.32dBm (2437MHz) 15.12dBm (2462MHz) Antenna Configuration Internal Antenna Antenna Position The Antenna is located at the LCD panel; and near the keyboard.(Fig 7) EUT Power Source From The Host Equipment HOST Power Source Fully Charged Battery The following test configurations have been applied in this test report: Configuration 1: Rear Side of the EUT is paralleled with flat phantom, Spacing between EUT and phantom - In contact (0 cm). (Fig.2) Configuration 2: Bottom face of the EUT is paralleled with flat phantom. Spacing between EUT and phantom - In contact (0 cm) . (Fig.3) Configuration 3: The LCD panel of EUT contact to the flat phantom. The transmitted antenna of the EUT located under the reference point of the flat Report No. : ES/2004/30001 Page : 6 of 48 phantom, Spacing between EUT and phantom - In contact (0 cm) (Fig.4) NOTE: 1. Please reference “APPENDIX 1” for the photos of test configuration. 2. All test Configuration have been complied with the body worn configuration. 3. The Notebook has been installed the controlling software that could control the EUT transmitted channel and power. But that software is just for test software, not for normal user. 1.6 EVALUATION PROCEDURES The entire evaluation of the spatial peak values is performed within the Post-processing engine (SEMCAD). The sy…

Text truncated - open the document above for the full version.

Report No. 042L057FI Page: 1 of 64 Version:1.0 Test Report Product Name : Notebook P.C Model No.: M2400N FCC ID: MSQM2NWM3B2200 Applicant : ASUSTeK COMPUTER INC. Address : No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Date of Receipt : Feb. 05, 2004 Date of Test : Jan. 29, 2004 Report No. : 042L057FI The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 042L057FI Page: 2 of 64 Version:1.0 Test Report Certification Test Date : Jan. 29, 2004 Report No. : 042L057FI Test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Product Name : Notebook P.C Applicant : ASUSTeK COMPUTER INC. Address : No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Manufacturer : ASUSTeK COMPUTER INC. Model No. : M2400N Rated Voltage : AC 120V/60Hz Trade Name : ASUS Measurement Standard : FCC CFR Title 47 Part 15 Subpart C: 2003 Measurement Procedure : ANSI C63.4: 2001 Test Result : Complied Documented By : ( Gina Chen ) Tested By : ( Tom Hsieh ) Approved By : ( Gene Chang ) Accredited by NIST (NVLAP) NVLAP Lab Code: 200533-0 Report No. 042L057FI Page: 3 of 64 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................6 1.3. Tested System Datails....................................................................................................................7 1.4. Configuration of tested System .....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................10 2.4. Test Procedure .............................................................................................................................11 2.5. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................24 3.1. Test Equipment............................................................................................................................24 3.2. Test Setup ....................................................................................................................................24 3.3. Limits ..........................................................................................................................................24 3.4. Test Result of Peak Power Output...............................................................................................25 4. Radiated Emission .....................................................................................................................27 4.1. Test Equipment............................................................................................................................27 4.2. Test Setup ....................................................................................................................................27 4.3. Limits ..........................................................................................................................................28 4.4. Test Procedure .............................................................................................................................29 4.5. Test Result of Radiated Emission................................................................................................30 5. Band Edge ..................................................................................................................................42 5.1. Test Equipment............................................................................................................................42 5.2. Test Setup ....................................................................................................................................42 5.3. Limits ..........................................................................................................................................43 5.4. Test Procedure .............................................................................................................................43 5.5. Test Result of Band Edge ............................................................................................................44 6. Occupied Bandwidth ................................................................................................................…
