MSQP01MAASUS Tablet

Charging your ASUS Tablet Speaker/Headset port Rear camera Volume button Power button USB 3.0 port MicroSD card slot To charge your ASUS Tablet: Connect the USB cable to the power adapter. Plug the power adapter into a grounded power outlet. Plug the USB connector into your ASUS Tablet. Charge your ASUS Tablet for eight (8) hours before using it in battery mode for the first time. User Guide ASUS Tablet E10444 First Edition / July 2015 Charging your device Ensure to fully charge your ASUS Tablet before using it in battery mode for extended periods. Remember that the power adapter charges your ASUS Tablet as long as it is plugged into an AC power source. Be aware that it takes much longer to charge the ASUS Tablet when it is in use. IMPORTANT! Do not leave the ASUS Tablet connected to the power supply once it is fully charged. ASUS Tablet is not designed to be left connected to the power supply for extended periods of time. Airplane precautions Contact your airline provider to learn about related inflight services that can be used and restrictions that must be followed when using your ASUS Tablet in-flight. IMPORTANT! You can send your ASUS Tablet through x-ray machines (used on items placed on conveyor belts), but do not expose them from magnetic detectors and wands. Safety precautions This ASUS Tablet should only be used in enviroments with ambient temperatures between 0°C to 35°C (32°F to 95°F). Long time exposure to extremely high or low temperature may quickly deplete and shorten the battery life. To ensure the battery’s optimal performance, ensure that it is exposed within the recommended environment temperature. Your ASUS Tablet Audio speaker Light sensor Front camera Touch screen panel IMPORTANT! • Use only the bundled power adapter and USB cable to charge your ASUS Tablet. Using a different power adapter may damage your ASUS Tablet. • Peel the protective film off from the power adapter and USB cable before charging the ASUS Tablet to prevent risk or injury. • Ensure that you plug the power adapter to the correct power outlet with the correct input rating. The output voltage of this adapter is DC 5.2 V, 1.35 A. • When using your ASUS Tablet while plugged-in to a power outlet, the grounded power outlet must be near the unit and easily accessible. • Do not place objects on top of your ASUS Tablet. NOTES: • Your ASUS Tablet can be charged via the USB port on the computer only when it is in sleep mode (screen off ) or turned off. • Charging through the USB port of a computer may take longer time to complete. • If your computer does not provide enough power for charging your ASUS Tablet, charge your ASUS Tablet via the grounded power outlet instead. • To use your Z Stylus (optional), ensure to enable it under system settings. Installing a microSD card* * The memory card slot supports microSD, microSDHC, and microSDXC card formats. Memory card slot Appendices Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by doing one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 15060-5720xxxx RF Exposure Information (SAR) This device meets the government’s requirements for exposure to radio waves. This device is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The exposure standard employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the EUT transmitting at the specified power level in different channels. The highest SAR value for the device as reported to the FCC is 1.14 W/kg when placed next to the body. The FCC has granted an Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: MSQP01MA. support.asus.com Model name: P01MA (Z580CA/Z8050CA) ManufacturerASUSTek COMPUTER INC. Address, City4F, No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN Authorized Representative in Europe ASUS COMPUTER GmbH Address, CityHARKORT STR. 21-23, 40880 RATINGEN CountryGERMANY Proper disposal Risk of explosion if battery is replaced by an incorrect type. Dispose…

Text truncated - open the document above for the full version.

4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan 112 July 29, 2015 DTS-UNII Device Declaration Letter To whom it may concern, We have declared below featured for FCC equipment authorization, Device FCC ID: MSQP01MA (1) DFS Device -- Master Client with Radar detection capability , □ V Client without radar detection capability N/A _ (2) Active / Passive Scanning , ad-hoc mode access point capability Frequency Band (MHz) Active Scanning (the device can transmit a probe (beacon)) passive scanning (where the device is can listen only with no probes) Ad Hoc Mode or WIFI Direct capability Access point capability Channel 1 Yes No Yes No Channel 2 Yes No Yes No Channel 3 Yes No Yes No Channel 4 Yes No Yes No Channel 5 Yes No Yes No Channel 6 Yes No Yes Yes Channel 7 Yes No Yes No Channel 8 Yes No Yes No Channel 9 Yes No Yes No Channel 10 Yes No Yes No Channel 11 Yes No Yes No Channel 36 Yes No Yes No Channel 40 Yes No Yes No Channel 44 Yes No Yes No Channel 48 Yes No Yes No Channel 52 No Yes No No 4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan 112 Channel 56 No Yes No No Channel 60 No Yes No No Channel 64 No Yes No No Channel 100 No Yes No No Channel 104 No Yes No No Channel 108 No Yes No No Channel 112 No Yes No No Channel 116 No Yes No No Channel 132 No Yes No No Channel 136 No Yes No No Channel 140 No Yes No No Channel 144 Yes No Yes No Channel 149 Yes No Yes No Channel 153 Yes No Yes No Channel 157 Yes No Yes No Channel 161 Yes No Yes No Channel 165 Yes No Yes No (3) Country code selection ability - Yes , □ V No If yes, please explain how it was implemented: (please also help to provide detail of options for each country selection) (4) Meet 15.202 requirement - □ V Yes, No, Please check below: A master device is defined as a device operating in a mode in which it has the capability to transmit without receiving an enabling signal. In this mode it is able to select a channel and initiate a network by sending enabling signals to other devices □ V A client device is defined as a device operating in a mode in which the transmissions of the device are under control of the master. A device in client mode is not able to initiate a network.

Page 1 of 28 Report No.: 150630C22 CONSTRUCTION PHOTOS OF EUT Page 2 of 28 Report No.: 150630C22 Configuration 1 Page 3 of 28 Report No.: 150630C22 Page 4 of 28 Report No.: 150630C22 Configuration 2 Page 5 of 28 Report No.: 150630C22 Page 6 of 28 Report No.: 150630C22 Page 7 of 28 Report No.: 150630C22 Page 8 of 28 Report No.: 150630C22 Page 9 of 28 Report No.: 150630C22

Page 10 of 28 Report No.: 150630C22 Configuration 1 Page 11 of 28 Report No.: 150630C22 Page 12 of 28 Report No.: 150630C22 Page 13 of 28 Report No.: 150630C22 Page 14 of 28 Report No.: 150630C22 Page 15 of 28 Report No.: 150630C22 Page 16 of 28 Report No.: 150630C22 Page 17 of 28 Report No.: 150630C22 Page 18 of 28 Report No.: 150630C22 Page 19 of 28 Report No.: 150630C22 Page 20 of 28 Report No.: 150630C22 Page 21 of 28 Report No.: 150630C22 Page 22 of 28 Report No.: 150630C22 Page 23 of 28 Report No.: 150630C22 Page 24 of 28 Report No.: 150630C22 Page 25 of 28 Report No.: 150630C22 Configuration 2 Page 26 of 28 Report No.: 150630C22 Page 27 of 28 Report No.: 150630C22 Page 28 of 28 Report No.: 150630C22

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 29 Report No. : SA150630C22 Issued Date : Jul. 20, 2015 FCC SAR Test Report Report No. : SA150630C22 Applicant : ASUSTek COMPUTER INC. Address : 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN Product : ASUS Tablet FCC ID : MSQP01MA Brand : ASUS Model No. : P01MA Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 / KDB 865664 D02 v01r01 KDB 248227 D01 v02r01 / KDB 447498 D01 v05r02 / KDB 616217 D04 v01r01 Sample Received Date : Jun. 30, 2015 Date of Testing : Jul. 10, 2015 ~ Jul. 13, 2015 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Vera Huang / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 29 Report No. : SA150630C22 Issued Date : Jul. 20, 2015 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot .................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 Volume Scan Procedure ................................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................................... 16 3.4.5 SAR Averaged Meth…

Text truncated - open the document above for the full version.

Report No.: RF150630C22-2 1 of 37 Report Format Version 5.1.0 FCC TEST REPORT REPORT NO.: RF150630C22-2 MODEL NO.: P01MA FCC ID: MSQP01MA RECEIVED: Jun. 29, 2015 TESTED: Jun. 29, 2015 ~ Jul. 05,2015 ISSUED: Jul. 20, 2015 APPLICANT: ASUSTek COMPUTER INC. ADDRESS: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150630C22-2 2 of 37 Report Format Version 5.1.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..............................................................................................................4 1. CERTIFICATION ..................................................................................................................................5 2. SUMMARY OF TEST RESULTS .........................................................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................................................6 3. GENERAL INFORMATION ..................................................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................. 10 3.3 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 12 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 12 3.4 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 13 4. TEST TYPES AND RESULTS (FOR BLUETOOTH LE 4.0) ............................................................. 14 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 14 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 14 4.1.2 TEST INSTRUMENTS ................................................................................................. 15 4.1.3 TEST PROCEDURES ................................................................................................. 16 4.1.4 DEVIATION FROM TEST STANDARD ....................................................................... 16 4.1.5 TEST SETUP ............................................................................................................... 17 4.1.6 EUT OPERATING CONDITIONS ................................................................................ 17 4.1.7 TEST RESULTS........................................................................................................... 18 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 22 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 22 4.2.2 T EST INSTRUMENTS ................................................................................................ 22 4.2.3 TEST PROCEDURES ................................................................................................. 23 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 23 4.2.5 TEST SETUP ............................................................................................................... 23 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 23 4.2.7 TEST RESULTS........................................................................................................... 24 4.3 6dB BANDWIDTH MEASUREMENT ....................................................................................... 26 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................................ 26 4.3.2 TEST SETUP ............................................................................................................... 26 4.3.3 TEST INSTRUMENTS ................................................................................................. 26 4.3.4 TEST PROCEDURE .................................................................................................…

Text truncated - open the document above for the full version.

Report No.: RF150630C22 1 of 56 Report Format Version 5.2.1 FCC TEST REPORT (15.247) REPORT NO.: RF150630C22 MODEL NO.: P01MA FCC ID: MSQP01MA RECEIVED: Jun. 29, 2015 TESTED: Jun. 29, 2015 ~ Jul. 09,2015 ISSUED: Jul. 20, 2015 APPLICANT: ASUSTek COMPUTER INC. ADDRESS: 4F, No. 150, LI-TE Rd., PEITOU, TAIPEI 112, TAIWAN ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF150630C22 2 of 56 Report Format Version 5.2.1 TABLE OF CONTENTS RELEASE CONTROL RECORD ..............................................................................................................4 1. CERTIFICATION ..................................................................................................................................5 2. SUMMARY OF TEST RESULTS .........................................................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................................................6 3. GENERAL INFORMATION ..................................................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................. 10 3.3 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 12 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 12 3.4 DUTY CYCLE TEST SIGNAL ................................................................................................... 13 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 14 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ....................................................................... 15 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 15 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 15 4.1.2 TEST INSTRUMENTS ................................................................................................. 16 4.1.3 TEST PROCEDURES ................................................................................................. 17 4.1.4 DEVIATION FROM TEST STANDARD ....................................................................... 17 4.1.5 TEST SETUP ............................................................................................................... 18 4.1.6 EUT OPERATING CONDITIONS ................................................................................ 18 4.1.7 TEST RESULTS........................................................................................................... 19 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 32 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 32 4.2.2 TEST INSTRUMENTS ................................................................................................. 32 4.2.3 TEST PROCEDURES ................................................................................................. 33 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 33 4.2.5 TEST SETUP ............................................................................................................... 34 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 34 4.2.7 TEST RESULTS........................................................................................................... 35 4.3 6dB BANDWIDTH MEASUREMENT ....................................................................................... 39 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ........................................................ 39 4.3.2 TEST SETUP ............................................................................................................... 39 4.3.3 TEST INSTRUMENTS .................................................................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST Mode A 2 Mode B 3 RADIATED EMISSION TEST (For WLAN 2.4GHz / WLAN 5GHz Band 3, 4) Frequency Range below 1GHz Mode A 4 Mode B 5 Frequency Range above 1GHz Mode A 6 Mode B 7 RADIATED EMISSION TEST (For WLAN 5G Band 1, 2) Frequency Range below 1GHz Mode A 8 Mode B 9 Frequency Range above 1GHz Mode A 10 Mode B 11 RADIATED EMISSION TEST (For Bluetooth) Frequency Range below 1GHz 12 Frequency Range above 1GHz 13 RADIATED EMISSION TEST (For Touch Pen) 14

FCC SAR Test Report Report Format Version 5.0.0 Issued Date : Jul. 20, 2015 Report No. : SA150630C22 Appendix D. Photographs of EUT and Setup FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA150630C22 <Photographs of EUT> FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA150630C22 <Antenna Location> The separation distance for antenna to edge: Antenna To Top Side (mm) To Bottom Side (mm) To Left Side (mm) To Right Side (mm) WLAN / BT 3 186.5 3 81.8 EUT Top Side EUT Bottom Side EUT Right Side EUT Left Side WLAN / BT Antenna <EUT Front View> FCC SAR Test Report Report Format Version 5.0.0 Report No. : SA150630C22 <Photographs of SAR Setup> Rear Face of EUT with 0 cm Gap <w/o ZEN CLUTCH> Rear Face of EUT with 0 cm Gap <w/ ZEN CLUTCH> Top Side of EUT with 0 cm Gap <w/o ZEN CLUTCH> Top Side of EUT with 0 cm Gap <w/ ZEN CLUTCH> Left Side of EUT with 0 cm Gap <w/o ZEN CLUTCH>
