User Guide ASUS Tablet E10317 First Edition / June 2015 Charging your device Ensure to fully charge your ASUS Tablet before using it in battery mode for extended periods. Remember that the power adapter charges your ASUS Tablet as long as it is plugged into an AC power source. Be aware that it takes much longer to charge the ASUS Tablet when it is in use. IMPORTANT! Do not leave the ASUS Tablet connected to the power supply once it is fully charged. ASUS Tablet is not designed to be left connected to the power supply for extended periods of time. Airplane precautions Contact your airline provider to learn about related in-flight services that can be used and restrictions that must be followed when using your ASUS Tablet in-flight. IMPORTANT! You can send your ASUS Tablet through x-ray machines (used on items placed on conveyor belts), but do not expose them to magnetic detectors and wands. Safety precautions This ASUS Tablet should only be used in environments with ambient temperatures between 0°C to 35°C (32°F to 95°F). Long time exposure to extremely high or low temperature may quickly deplete and shorten the battery life. To ensure the battery’s optimal performance, ensure that it is exposed within the recommended environment temperature. Installing a microSD card Turn off your ASUS Tablet and remove the back cover before inserting the microSD card to the slot. Close the back cover before you turn on the device. Charging your ASUS Tablet To charge your ASUS Tablet: Connect the micro USB cable to the power adapter. Plug the power adapter into a grounded power outlet. Plug the micro USB connector into your ASUS Tablet. Charge your ASUS Tablet for eight (8) hours before using it in battery mode for the first time. IMPORTANT! • Use only the bundled power adapter and micro USB cable to charge your ASUS Tablet. Using a different power adapter may damage your ASUS Tablet. • Peel the protective film off from the power adapter and micro USB cable before charging the ASUS Tablet to prevent risk or injury. • Ensure that you plug the power adapter to the correct power outlet with the correct input rating. The output voltage of this adapter is DC 5.2 V, 1.35 A. • When using your ASUS Tablet while plugged-in to a power outlet, the grounded power outlet must be near the unit and easily accessible. • Do not use or expose your ASUS Tablet near liquids, rain, or moisture. • Do not use your ASUS Tablet near heating equipment or in places where there is likelihood of high temperature. • Keep your ASUS Tablet away from sharp objects. • Do not place objects on top of your ASUS Tablet. NOTES: • Your ASUS Tablet can be charged via the USB port on the computer only when it is in sleep mode (screen off ) or turned off. • Charging through the USB port of a computer may take longer time to complete. • If your computer does not provide enough power for charging your ASUS Tablet, charge your ASUS Tablet via the grounded power outlet instead. Appendices Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment causes harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by doing one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Label Location Declaration We state that the label of FCC ID: MSQP022 will be put under the back cover and it is visible to the users as they install the SD card. Micro USB 2.0 port Speaker/Headset port Rear camera Volume button Power button Groove Microphone Your ASUS Tablet Audio speaker Front camera Touch screen panel NOTE: The memory card slot supports microSD, microSDHC, and microSDXC card formats. 15060-56800000 support.asus.com Removing the back cover Locate the groove on the bottom-right corner and pull the back cover outwards until it is removed completely. Model name: P022 ManufacturerASUSTek COMPUTER INC. Address, City4F, No. 150, LI-TE RD., PEITOU, TAIPEI 112, TAIWAN Authorized Representative in Europe ASUS COMPUTER GmbH Address, CityHARKORT STR. 21-23, 40880 RATINGEN CountryGERMANY Proper disposal Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. ATTENTION! Danger d’explosion lorsque la batterie est remplacée de façon incorrecte. DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste. DO NOT throw the ASUS Tablet in municipal waste. This product has been designed to enable proper reuse of parts and recycling. The symbol of the …
