MSQUGPZ5Bluetooth Module

Your device will now be undetectable by other users, even when they search for other devices. Note • Other devices are still able to establish connections with your device even if you have enabled the Non-discoverable mode. Please enable "Non-connectable mode" if you wish to reject connections from other devices. Related topic: "Bluetooth Manager " Encrypting the content of your transmissions Since Bluetooth communication is conducted wirelessly, there is always the possibility that a third party may be able to intercept your transmissions. You can use encryption to render the content indecipherable to anyone who manages to intercept it. Important • Encrypting your transmissions will still not guarantee complete security. Accordingly, please be aware that transmitting data is conducted with an element of risk for the user. Procedure 1. Right-clickontheBluetoothiconinthetasktray,andclickon[Device Properties & Security]. The [Device Properties] window will appear. 2.Select [Link Level Enforced Security] in [Security Mode] under the [Security] tab, put a check next to [Encryption], and then click on the [OK] button Note • Once you have configured the security mode, a window will appear when you first make a connection to another device,prompting you to enter a Bluetooth passkey (PIN code). Please click on the [OK] button after you have entered the passkey. • The window in which you enter the passkey will not appear once you have connected more than two times to the device. Related topic: "Bluetooth Manager " Changing the default connection The "default connection" refers to the dial-up connection configured for use whenever a connection is made to the Internet. If several connections have been registered, you can change the default connection by following the procedure below. Procedure 1. Start Internet Explorer 2. Click on [Tools][Internet Options...] The [Internet Options] window will appear. 3. Click on the [Connections] tab In this window, "Direct Connection" isset as the default, and "Never dial a connection" has been selected. Change the settings so that "London A" will always be dialled when you connect to the Internet. 4. Select "Always dial my default connection" 5.Clickon"LondonA",andthenclickonthe[SetDefault]button "London A" has been changed to the default connection. Note • Alternatively, if you wish to connect to the Internet from a LAN in a company or other environment where a LAN can be accessed, select "Never dial a connection" if you have a dial-up configuration, but do not want dial-up to occur automatically. • When connecting to the Internet via a LAN, you must enter the appropriate LAN settings under [LAN Settings...]. Manually creating a virtual Bluetooth COM port In order for a PC to connect to and communicate with a Bluetooth device, the Bluetooth Utility will create a gateway for data to be exchanged between the respective devices. This gateway is known as a "port" (or "virtual COM port"). Since one virtual COM port will be allocatedto each device, trouble-free communication will still be possible even if several devices are being used. When you use the Bluetooth Utility, a virtual COM port will be automatically created on set-up; however, virtual COM ports can be created manually if so needed. Note • Bluetooth Managermust be active in order for you to be able to use Bluetooth Local COM. Clients and servers When Bluetooth communications are performed, there will always be a "client/server" relationship between the various devices. A "client" is a device that sends certain requests to another device, while a "server" is a device that provides a service on receipt of such requests from another device. For example, when a PC issues a print commandto a wireless printer, the PC functions as the client, while the printer functions as the server. When a PDA or other device attempts to receive files located on a PC by means of file transfer protocol, the PC functions as the server, while the PDA functions as the client. Virtual Bluetooth COM ports can be created both for clients and servers. • Bluetooth virtualCOM port for a client Virtual COM port used when your deviceis the client, and requests are sent to another device. • Bluetooth virtual COM port for a server Virtual COM port used when your device is the server, and requests are received from another device. Creating a virtual COM port Bluetooth virtual COM ports are created according to the procedure below. Procedure 1. Click on the [Printers and Other Hardware] icon in the Control Panel The [Printers and Other Hardware] window appears. 2.Double-click on the [Bluetooth Local COM] icon The main Bluetooth Local COM window will appear. Note oEven when the Control Panel appears in Classic view, please simply click on the [Bluetooth Local COM] icon. oNo such distinction between viewing formats exists in Windows 2000. 3.Click on the [Add...] button The [Bluetooth Local COM Wizard] window, from where you can create a virtual COM port, will appear. Start from this window when creating Bluetooth virtual COM ports for either servers or clients. Creating a Bluetooth virtual COM port for a client Creating a Bluetooth virtual COM port for a server Deleting a virtual COM port Please follow the procedure below to delete a virtual COM port when it is no longer needed. Note • You can only delete virtual COM ports created by the Bluetooth Local COM utility. 1. Select the port you wish to delete from the [Bluetooth Local COM] window, and then click on the [Delete] button A message will appear asking you to confirm that you wish to delete the port. 2. Click on the [Yes] button The port will be deleted. 3.Click on the [OK] button Creating a Bluetooth virtual COM port for a client Procedure 1. From the [Bluetooth Local COM Wizard] window, select "Create a Bluetooth virtual COM portforaclient",andthenclickonthe[Next]button The [Bluetooth Local COM - Create COM Port for Client (1/1)] window will appear. 2. Select [COM Port You Want to Cr…

Text truncated - open the document above for the full version.

Bluetooth Stack for Windows by Toshiba - Universal Edition User’s Guide December 28, 2004 TOSHIBA Corporation Introduction ........................................................................5 Trademarks.........................................................................6 What is Bluetooth? .............................................................7 Using PCs with Bluetooth built in ....................................10 Varieties of Bluetooth devices you can use ......................12 Contents of the Bluetooth Utility......................................15 Using the Bluetooth Utility...............................................20 Flow of operation .............................................................21 Basic settings....................................................................23 Express ModeSet-up........................................................24 Custom ModeSet-up........................................................26 Detecting Bluetooth devices.............................................28 Detecting Bluetooth devices.............................................31 Detecting services.............................................................34 Detecting services.............................................................38 Registering settingsinformation.......................................43 Registering settingsinformation.......................................45 One-touch connection to Bluetooth devices .....................47 Manually connecting to a Bluetooth device......................49 Changing a connection icon..............................................52 Changing a connection icon name....................................55 Connecting to the Internet using a modem station [DUN].....57 Connecting to the Internet using a mobile telephone [DUN].67 Connecting to a LAN using an access point (PAN) [PAN]...77 Connecting to aLAN (PAN) ............................................82 Connecting to a LAN using an access point (LAP) [LAP]....85 Connecting to aLAN (LAP).............................................93 Using a modem station for fax transmissions [FAX]............97 Receiving a fax...............................................................109 Sending a fax..................................................................111 Setting COM AutoConnect............................................116 Using a commercially available fax application.............118 Using a mobile telephone for fax transmissions [FAX]......121 Receiving a fax...............................................................133 Sending a fax..................................................................135 Printing documents and images [HCRP] [SPP]........................140 Printing images directly from a digital camera or other device [BIP]........................................................................149 Printing business card data [OPP].......................................155 Listening to music using the stereo headphones GAVDP A2DPAVRCP ...................................................................161 Using a wireless keyboard [HID]........................................169 Using a wireless mouse [HID]............................................174 Exchanging files with a PC or PDA [FTP].........................179 Sending images to a mobile telephone [BIP]......................191 Sending images to a PC or PDA [BIP]...............................196 Exchanging business card data with a PC or PDA [OPP]...203 Creating business card data in the vCARD format .........220 Using a Bluetooth-compatible camera [BIP]......................223 Using a headset to communicate [HSP]..............................229 Synchronising information using ActiveSync [SPP]..........238 Building a personal area network [PAN]...........................250 Making a device undiscoverable to other users ..............260 Encrypting the content of your transmissions.................262 Changing the default connection ....................................264 Manually creating a virtual Bluetooth COM port...........268 Creating a Bluetooth virtual COM port for a client ........273 Creating a Bluetooth virtual COM port for a server .......275 Sending business card data from Outlook ......................278 Bluetooth Settings ..........................................................285 Bluetooth Manager .........................................................289 Bluetooth Information Exchanger ..................................295 Bluetooth Properties .......................................................299 Bluetooth Local COM ....................................................318 Wireless FileTransfer ....................................................320 Troubleshooting..............................................................322 General operation of theBluetooth Utility .....................323 Using a wireless modem station .....................................326 Using an access point.....................................................331 Using a printer................................................................333 Using a keyboardor mouse ............................................334 Using a camera ...............................................................335 Using a PDA...................................................................336 Using a mobiletelephone ...............................................337 Using a Bluetooth Headset .............................................341 Glossary..........................................................................343 Introduction Thank you very much for selecting the Bluetooth Utility. This Help facility will show you how to use the Bluetooth Utility for configuring Bluetooth devices and how it can be used in other convenient ways. We hope that the Help facility will enable you to be able to make full use of the Bluetooth Utility. • What is Bluetooth? • What you need to know …

Text truncated - open the document above for the full version.

Certain modems require you to configure initialization commands separately. Please click on the [Additional initialization Command Settings] button, enter the initialization commands in the following window, and then click on the [OK] button. Note oPlease refer to the modem or mobile phone instruction manual for further details on the initialization commands. 7.Enter the connection name (optional),telephone number (of your provider's access point), user name and password (as issued by your provider), and then click on the [Finish] button. Important oThe sample entries shown in the window are provided solely for purpose of explanation. Please use your own telephone number, ID and password according to the arrangement with your provider. The settings will be registered, and an icon will appear in the [Bluetooth Settings] window. Connecting to the Internet You can connect to the Internet by following the procedure below if the connection destination registered when you configured the wireless modem has been set as the default connection destination . 1. Start your browser, e-mail application or other application Important oPlease enter the e-mail settings separately if you are going to use e-mail (the set-up method will vary with the application). 2. Enter the URL of the Web page you wish to display and then press the [Enter] key, or use the e-mail tool to send/receive items or perform other activities. The [Dial-up Connection] window will appear. 3.Click on the [Connect] button Important oA connection will be automatically established with the modem station if COM Auto Connect is available. If COM Auto Connect is not available, pleasemanually connect to the modem station. The following message will appear once you have connected to the Internet. 4.End the connection The window below will appear if you double-click on the icon in the task bar. Please click on the [Disconnect] button when you want to disconnect from the Internet. Alternatively, please right-click on the icon,andthenclickon[Disconnect]. Note • You can start an application to make an automatic connection to the Internet, but you can also make a manual connection using the connection destination icon. The procedure is described below. 1.From the [Bluetooth Settings] window, right-click on the connection destination icon, and then click on [Connect] from the menu that appears A window indicating that the connection is being established will appear. If the connection has been established successfully, the connection icon and task tray will appear as shown below. You will be able to browse Web pages using your browser and send and receive e-mail. Important oPlease enter the e-mail settings separately if you are going to use e-mail (the set-up method will vary with the application). 2.End the connection Right-click on the icon, and then click [Disconnect] to end the connection. The following message will appear. Click on the [Yes] button. When the icon appears as shown below, the connection will have ended. Connecting to the Internet using a mobile telephone [DUN] This section describes how to connect to the Internet via a telephone line, using a mobile telephone. Configuring a mobile telephone for use as a modem Connecting to the Internet Important • In order to connect to the Internet, you must have already signed up with a provider and obtained a connection ID and password. Please ensure you have confirmed the ID, password and telephone number of your provider's access point before you begin the set-up process. • A Bluetooth passkey (PIN code) is required for you to connect to the mobile telephone. Please make a note of your Bluetooth passkey before you start the set- up process. Configuring a mobile telephone for use as a modem Procedure 1. Turn on the mobile telephone, and set it to be connectable via Bluetooth Note oPlease refer to the mobile telephone instruction manual for information on how to operate the device. 2.Right-clickontheBluetoothiconinthetasktray,andthenclickon[Add New Connection] Note oAlternatively, click [Start][All Programs][Bluetooth][Bluetooth Settings], and then click on [New Connection] from the active [Bluetooth Settings] window. The [Add New Connection Wizard (Welcome to the Add New Connection Wizard)] window will appear. 3. Confirm that [Express Mode] has been selected, and then click on the [Next] button The [Add New Connection Wizard (Searching for Bluetooth devices)] window will appear. 4. Select the device name of the mobile telephone from [Device List], and then click on the [Next] button The [Add New Connection Wizard (Searching for Services)] window will appear. Once a service has been detected successfully, connection to the device and COM port creation will be performed automatically, after which the [Add New Connection Wizard (Modem Settings)] window will appear. 5. If you are connecting to a mobile telephone for the first time, enter the passkey for the wireless modem station under [Bluetooth Passkey (PIN code)],andthenclickonthe[OK]button Once the program has finished searching for the devices, the [Add New Connection Wizard (Device Selection)] window will appear. 6. Click on the [Next] button Certain modems require you to configure initialization commands separately. Please click on the [Additional Initialization Command Settings] button, enter the initialization commands in the following window, and then click on the [OK] button. Note oPlease refer to the modem or mobile phone instruction manual for further details on the initialization commands. 7.Enter the connection name (optional),telephone number (of your provider's access point), user name and password (as issued by your provider), and then click on the [Finish] button. Important oThe sample entries shown in the window are provided solely for purpose of explanation. Please use your own telephone number, ID and password according to the arrangement with your provider. The settings will be registered, and an icon will appear in …

Text truncated - open the document above for the full version.

Using a mobile telephone for fax transmissions[FAX] This section describes how to send a fax using a mobile telephone as a modem. Setting up the mobile telephone Installing a modem Setting fax information Sending a fax Receiving a fax Important • Please ensure that any drivers used to connect the PC to the mobile telephone have been installed. • A Bluetooth passkey (PIN code) is required for you to connect to the mobile telephone. Please make a note of your Bluetooth passkey before you start the set- up process. • A fax application is required for you to be able to send and receive faxes. The description below is based on a example using Microsoft Fax, which is installed with Windows XP as standard. If you are going to use a commercially available fax application , then please refer to the manual that came with the application for information on how to send and receive faxes. Setting up the mobile telephone Set up and register the mobile telephone as a fax service. Procedure 1.Turn on the mobile telephone, and set it to be connectable via Bluetooth Note oPlease refer to the instruction manual for information on how to operate the telephone. 2.Right-clickontheBluetoothiconinthetasktray,andthenclickon[Add New Connection] Note oAlternatively, click [Start][All Programs][Bluetooth][Bluetooth Settings], and then click on [New Connection] from the active [Bluetooth Settings] window. The [Add New Connection Wizard (Welcome to the Add New Connection Wizard)] window will appear. 3. Select [Custom Mode], and then click on the [Next] button The [Add New Connection Wizard (Searching for Bluetooth devices)] window will appear. Once the program has finished searching for the devices, the [Add New Connection Wizard (Select Device)] window will appear. 4. Select the device name of the mobile telephone from [Device List], and then click on the [Next] button The [Add New Connection Wizard (Searching for Services)] window will appear. 5. If you are connecting to the mobile telephone for the first time, enter the passkey for the device from the [Bluetooth Passkey (PIN Code)] window, and then click on the [OK] button. Once the program has finished searching for the services, the [Add New Connection Wizard (Select Service)] window will appear. 6.Select "Fax" under [Select Service], and then click on the [Next] button The [Add New Connection Wizard (Connecting to Remote Device)] screen will appear. The COM port and modem registration process will then be automatically performed. Once the COM port and modem (standard 33600 bpstype) registration is complete, the [Add New Connection Wizard (Setting Connection Name)] screen will appear. 7.Configure the type and name of the iconto appear after registration, and click on the [Next] button. Please click only on the [Next] button once you are satisfied with the configuration. The [Add New Connection Wizard (Completing the Add New Connection Wizard)] screen will appear. 8. Click on the [Finish] button The settings will be registered, and the icon will appear on the [Bluetooth Settings] screen. Setting fax information Configure send/receive settingsand register fax information. Procedure 1. Select [Start][Control Panel], and then double-click on the [Printers and Other Hardware] icon Note oIf the control panel is displayed in "Classic view", and you use Windows 2000, please start from Step (2). 2. Double-click on the [Printers and Faxes] icon The [Printers & Faxes] window will appear. 3. Click on "Set up faxing" in the [Printers and Faxes] window A window showing installed programs willappear, and a Fax icon will have been created in the [Printers and Faxes] screen. 4.Click on "Send a fax" under "Printer Tasks" on the left side of the window If you have not yet configured a fax device, the [Fax Configuration Wizard] window will appear. In the window you can enter settings pertaining to the sender (yourself). Note oIf the fax configuration information has already been registered, the [Send Fax Wizard] window, which can be viewed under "Sending a fax " below, will appear instead of the [Fax Configuration Wizard] window. 5.Enter the sender information, and click on the [Next] button Note oThe sender information that you configure here will be automatically appended as header information when you send a fax. The [Fax Configuration Wizard (Select Device for Sending or Receiving Faxes)] window will appear. 6.Select a device to be used for fax transmissions, enable the device for sending or receiving, and then click on the [Next] button Note oIf [Enable Receive] is selected, the device will be on standby for receiving faxes even if it is not sending or receiving anything, and therefore will be in continuous connection to the wireless modemwhenCOM Auto Connectis on). Please decide whether to select this option based on to the desired objective and/or frequency of transmission. The [Fax Configuration Wizard (Transmitting Subscriber Identification (TSID))] window will appear. 7. Click on the [Next] button It is important that you do not change the transmitter subscriber identification. The [Fax Configuration Wizard (Completing the Fax Configuration Wizard)] window will appear. 8.Click on the [Finish] button The fax information will be have been registered, and the [Fax Console] window will appear. This will complete the fax set-up process. Related topics: "Sending a fax" and "Receiving a fax" Receiving a fax This section describes what to do when a fax arrives after you have established a connection to a modem station. Important • The Fax service must be enabled for receiving in order for you to receive a fax. Please refer to "Using a mobile telephone " under "Troubleshooting" for information on how to change the send and receive settings once the fax service has been configured. • Please ensure you have connected to a modem station before you receive a fax (the device will be connected to the modem if "Enable Receive" has been selected orCOM Auto Connect has been activ…

Text truncated - open the document above for the full version.

Listening to music using the stereo headphones GAVDPA2DPAVRCP This section describes how to use the stereo headphones to listen to your favourite music or other audio files stored on your PC. Configuring the stereo headphones Connecting to the stereo headphones Listening to music or other audio files Playing music using remote control Copyright protection function Configuring the stereo headphones Procedure 1.Right-clickontheBluetoothiconinthetasktray,andclickon[AddNew Connection]. Note oAlternatively, click [Start][All Programs][Bluetooth][Bluetooth Settings], and then click on [New Connection] from the [Bluetooth Settings] screen that has opened. The [Add New Connection Wizard (Welcome to the Add New Connection Wizard)] will appear. 2. Switch ON the stereo headphones and activate "Discoverable" mode Please refer to the user guide for the stereo headphones for further information on how to operate them. 3. Confirm that [Express Mode] has been selected, and then click on the [Next] button The [Add New Connection Wizard (Searching for Bluetooth Devices)] screen will appear. Once the search for the devices has ended, the [Add New Connection Wizard (Select Device)] screen will appear. 4. Select the device name of the stereoheadphones from the list, and click on the [Next] button The [Add New Connection Wizard (Searching for Services)] screen will appear. 5. Configure the type and name of theicon to appear once registration is complete, and click on the [Next] button Please click the [Next] button once you are satisfied with the configuration. The [Add New Connection Wizard (Configure Connection Name)] screen will appear. 6.Click on the [Finish] button The settings will be registered, and the icon will appear on the [Bluetooth Settings] screen. Connecting to the stereo headphones You can connect to the stereo headphones from the icon registered in [Bluetooth Settings]. Please refer to the user guide for information on how to make a connection from the stereo headphones. Important • Please close the following audio applications before any connection is made between your stereo headphones and PC. oMusic/video playback applications oe-Conferencing applications oVoice-recognition applications Please finish connecting the stereo headphones before launching any of these applications. Listening to music or other audio files 1.Playing music or other audio files on your PC Important oPlease confirm the points below if you are unable to hear anything despite having properly connected the stereo headphones. Click [Start][All Programs][Accessories][Entertainment][Volume Control]. Remove the tick next to [Mute] if it has been ticked. If the volume is at its lowest setting, please adjust it to an appropriate level. oMusic playback may be interrupted if other Bluetooth devices are currently connected to your PC. When you are listening to music, it is recommended that the stereo headphones be the only connected device. oMusic playback may be interrupted if you are some distance away from the PC, or if there are any obstructions between you and the PC. oIf you are unable to hear any sound out of your stereo headphones while music or audio is currently playing in a related application, please stop the files being played, open [Sounds and Audio Devices] from the Control Panel, and change the default device to "Toshiba Bluetooth Wave." If you are still unable to hear any sound from the stereo headphones even after having set "Toshiba Bluetooth Wave" as the default device, please re-launch the application. 2. Finishing listening to music and disconnecting 1. Right-click on the icon for the currently connected mode from [Bluetooth Settings] on your PC,andclickon"Disconnect." A message confirming the disconnection may appear. 2.Clickonthe"Yes"buttonafterhaving followed the instructions in the message. The icon will indicate that thedevice has been disconnected. Important oPlease close the following audio applications before you disconnect the stereo headphones from your PC: ƒMusic/video playback applications ƒe-Conferencing applications ƒVoice-recognition applications Please completely disconnect the stereo headphones before launching any of these applications. Please refer to the user guide for information on terminating a connection from the stereo headphones. Playing music using remote control Music applications and video playback applications installed on your PC (e.g.,"Windows Media Player 9" and "InterVideo WinDVD") may be operated with the remote control button/switch on your stereo headphones. The remote control used with the stereo headphones must be compliant with the Bluetooth AVRCP profile. Please refer to the headphones user guide for further information. You can configure the application to be operated using the switch/button according to the following procedure. Procedure 1. Double-click on the Bluetooth icon in the taskbar Launches "Bluetooth Settings." 2. Click on [Bluetooth][Select AV Player] from the menu bar The [Select AV Player] screen will appear. 3.Select the application, and click on the [OK] button The functions and switch/button that can be operated may differ depending on the application used formusic/video playback as well as the version. The procedure below can be performed in order to change the position where the receive command is displayed or to not have the command displayed. Procedure 1. Double-click on the Bluetooth icon in the taskbar Launches "Bluetooth Settings." 2. Click on [Bluetooth][Select AV Player] from the menu bar. The [Select AV Player] screen will appear. 3. Select the appropriate item from the pull-down menu of positions where the receive command is to be displayed, and then click on the [OK] button. If the receive command appears but does not function properly, sometimes the problem may be rectified by changing the setting to "Do not display." The commands supported by this application are shown below. Please refer to the headphone user gui…

Text truncated - open the document above for the full version.
