MSQW1NWM3B2200Notebook PC

ASUSTeK Computer Inc
Notebook PC - FCC ID MSQW1NWM3B2200 - ASUSTeK Computer Inc
Click to zoom

Application Details

Equipment Class
DTS - Digital Transmission System
Date of Grant
Mar 04, 2004
Application Purpose
Original Equipment
Date of Application
Mar 04, 2004
Equipment Note
Notebook PC
Frequency Range
2412.00000000 - 2462.00000000
Company
ASUSTeK Computer Inc
Country
Taiwan

Documents & Files

Select a file to view

Users Manual

↗

Attestation Statements

↗

Block Diagram

↗

Cover Letter(s)

↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

Operational Description

↗

Test Report

↗
↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Copyright Information No part of this manual, including the products and software described in it, may be reproduced, transmitted, tran- scribed, stored in a retrieval system, or translated into any language in any form or by any means, except documen- tation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COM- PUTER INC. (“ASUS”). ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MER- CHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIREC- TORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSI- NESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFOR- MATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LI- ABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Copyright © 2003 ASUSTeK COMPUTER INC. All Rights Reserved. Limitation of Liability Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property; or any other actual and direct damages resulted from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract price of each product. ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringe- ment under this Warranty Statement. This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible. UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-PARTY CLAIMS AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA; OR (3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RE- SELLER IS INFORMED OF THEIR POSSIBILITY. 1 Product Name:Notebook PC Hardware Manual Revision:1 E1541 Release Date:January 2004 Notebook PC Hardware User’s Manual 2 Safety Statements Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruc- tions, may cause harmful interference to radio communications. However, there is no guarantee that inter- ference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the Federal Register, National Archives and Records Administration, U.S. Government Printing Office. Power Safety Requirement Products with electrical current ratings up to 6A and weighing more than 3Kg must use approved power cords greater than or equal to: H05VV-F, 3G, 0.75mm 2 or H05VV-F, 2G, 0.75mm 2 . Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This Class B digital apparatus complies with Canadian ICES-003. (Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.) For use with AC Adaptor Model (Pour Utiliser Avec Modele): ADP-65DB (65W) WARNING! The use of a shielded-type power cord is required in order to meet FCC emission limits and to prevent interference to the nearby radio and television recep- tion. It is essential that only the supplied power cord be used. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for complia…

Text truncated - open the document above for the full version.

Attestation Statements

ASUSTeK COMPUTER INC. FCC ID.: MSQW1NWM3B2200 4FL., No.150, LI-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Tel: +886 2 2894 3447 Federal Communications Commission Mar. 04, 2004 Authorization and Evaluation Division ATTESTATION FCC ID: MSQW1NWM3B2200 Product: Notebook P.C. Model: W1S00N, W1B00N We don't provide any controls or software to allow operation outside the USA frequency band when we sell this product in USA. Sincerely, Warson Li / Lead Product Manager ASUSTek COMPUTER INC.

Block Diagram

55 44 33 22 11 D D C C B B A A PCI DDR SO-DIMM SUPER I/O PAGE 19 PAGE 31,32,33 HDD FWH PAGE 16,17,18 GIGA LAN3COM LPC PAGE 29 1.5V PAGE 27 2.5V CD ROM MINI-PCI 1 CRT PAGE 39 PAGE 24,25,26 PAGE 15 MDC PAGE 2,3 ATI M10 PAGE 24 PAGE 15 1.8V USB 2.0 PAGE 23 PAGE 14 SIR 1.2VS PAGE 42 AUDIO CODEC ODEM PAGE 22 PAGE 11,12,13 VCCP PAGE 41 PAGE 22 PAGE 8,9,10 CPU VCORE R5C593 PAGE 41 PAGE 7 PAGE 39 AUDIO DJ KEY PAGE 5,6 POWER PAGE 38 PAGE 42 3V , 5V , 12V LVDS POWER SEQUENCE PSB PAGE 41 PS2 CON DDR PAGE 21 PAGE 41 PAGE 37 1.25VS CLOCKGENERATOR HUB CPU CSP64 PAGE 40 PAGE 4 PAGE 20 INSTANT KEY MCH-M PAGE 28 ICH4-M TV OUT AGP BANIAS PAGE 19 KBC 38857 FAN + SENSOR CIR PAGE 22 MINI-PCI 2 PAGE 30 PAGE 15 PCMCIA 1394 CARD READER PAGE 15PAGE 14 Custom Tuesday, September 30, 2003 ASUSTeK COMPUTER INC BLOCK DIAGRAM 2.0 W1 S 00N,W1B00N Jerry Mou 150 P4PE-X R2.00 Size Project Name Rev Date: Sheet of Title : Engineer:

Cover Letter(s)

ASUSTeK COMPUTER INC. FCC ID.: MSQW1NWM3B2200 4FL., No.150, LI-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Tel: +886 2 2894 3447 ASUSTek COMPUTER INC. 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan Tel: +886 2 2894 3447 Fax:+886 2 2895 0113 Federal Communications Commission Mar. 04, 2004 Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant Hereby requests confidential treatment of information accompanying this Application As outlined below: Schematics The above materials contain trade secrets and proprietary information not customarily Released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Warson Li / Lead Product Manager ASUSTek COMPUTER INC.

External Photos

Report No.: 042L047FI Page : 1 of 9 Version:1.0 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo Report No.: 042L047FI Page : 2 of 9 Version:1.0 (3) EUT Photo (4) EUT Photo Report No.: 042L047FI Page : 3 of 9 Version:1.0 (5) EUT Photo (6) EUT Photo Report No.: 042L047FI Page : 4 of 9 Version:1.0 (7) EUT Photo (8) EUT Photo Report No.: 042L047FI Page : 5 of 9 Version:1.0 (9) EUT Photo (10) EUT Photo

ID Label/Location Info

ASUSTeK COMPUTER INC. FCC ID.: MSQW1NWM3B2200 4FL., No.150, LI-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Tel: +886 2 2894 3447 FCC ID AND DoC Label The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. Notebook P.C. ASUS Model No.: W1S00N, W1B00N TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan Notebook P.C. Model No.: W1S00N, W1B00N F F C C C C I I D D : : M M S S Q Q W W 1 1 N N W W M M 3 3 B B 2 2 2 2 0 0 0 0 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

ID Label/Location Info

ASUSTeK COMPUTER INC. FCC ID.: MSQW1NWM3B2200 4FL., No.150, LI-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Tel: +886 2 2894 3447 FCC ID AND DoC Label The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. Notebook P.C. ASUS Model No.: W1S00N, W1B00N TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan Notebook P.C. Model No.: W1S00N, W1B00N F F C C C C I I D D : : M M S S Q Q W W 1 1 N N W W M M 3 3 B B 2 2 2 2 0 0 0 0 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan

Internal Photos

Report No.: 042L047FI Page : 6 of 9 Version:1.0 (11) EUT Photo (12) EUT Photo Report No.: 042L047FI Page : 7 of 9 Version:1.0 (13) EUT Photo (14) EUT Photo Report No.: 042L047FI Page : 8 of 9 Version:1.0 (15) EUT Photo (16) EUT Photo Report No.: 042L047FI Page : 9 of 9 Version:1.0 (17) EUT Photo

Operational Description

Report No. 042L047FI Page: 6 of 64 Version:1.0 1.2. Operational Description EUT is a Notebook P.C with 11 channels. This device provided four kinds of transmitting speed 1, 2, 5.5 and 11Mbps. The device of RF carrier is DQPSK, DB PSK and CCK (IEEE 802.11b) or eight kinds of transmitting speed 6, 9, 12, 18, 24, 36, 48 and 54Mbps. The device of RF carrier is OFDM (IEEE 802.11g). The device adapts direct sequence spread spectrum modulation. The antenna was Connector provides diversity function to improve the receiving function. This Notebook P.C, compliant with IEEE 802.11b and IEEE 802.11g, is a high-efficiency Wireless LAN adapter. It allows your computer to connect to a wireless network and to share resources, such as files or printers without being bound to the network wires. Operation in 2.4GHz Direst Sequence Spread Spectrum (DSSS) radio transmission, the Notebook P.C Wired Equivalent Protection (WEP) algorithm is used. In addition, its standard compliance ensures that it can communicate with any IEEE 802.11b and IEEE 802.11g network. Test Mode: Mode 1: Transmitter 802.11b Mode 1: Transmitter 802.11g

Test Report

Report No. 042L047FI Page: 1 of 64 Version:1.0 Test Report Product Name : Notebook P.C Model No.: W1S00N, W1B00N FCC ID: MSQM1NWM3B2200BG Applicant : ASUSTeK COMPUTER INC. Address : 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Date of Receipt : Feb. 04, 2004 Date of Test : Jan. 31, 2004 Report No. : 042L047FI The test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Report No. 042L047FI Page: 2 of 64 Version:1.0 Test Report Certification Test Date: Jan. 31, 2004 Report No. : 042L047FI Test results relate only to the samples tested. The test report shall not be reproduced except in full without the written approval of QuieTek Corporation. This report must not be used to claim product endorsement by NVLAP any agency of the U.S. Government Product Name : Notebook P.C Applicant : ASUSTeK COMPUTER INC. Address : 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Manufacturer : ASUSTeK COMPUTER INC. Model No. : W1S00N, W1B00N Rated Voltage : AC 120V/60Hz Trade Name : ASUS Measurement Standard : FCC CFR Title 47 Part 15 Subpart C: 2003 Measurement Procedure : ANSI C63.4: 2001 Test Result : Complied Documented By : ( Grace Lin ) Tested By : ( Geddy Jery ) Approved By : ( Gene Chang ) Accredited by NIST (NVLAP) NVLAP Lab Code: 200533-0 Report No. 042L047FI Page: 3 of 64 Version:1.0 TABLE OF CONTENTS Description Page 1. GENERAL INFORMATION .....................................................................................................5 1.1. EUT Description............................................................................................................................5 1.2. Operational Description ................................................................................................................6 1.3. Tested System Datails....................................................................................................................7 1.4. Configuration of tested System .....................................................................................................8 1.5. EUT Exercise Software .................................................................................................................8 1.6. Test Facility ...................................................................................................................................9 2. Conducted Emission..................................................................................................................10 2.1. Test Equipment............................................................................................................................10 2.2. Test Setup ....................................................................................................................................10 2.3. Limits ..........................................................................................................................................10 2.4. Test Procedure .............................................................................................................................11 2.5. Test Result of Conducted Emission.............................................................................................12 3. Peak Power Output ...................................................................................................................24 3.1. Test Equipment............................................................................................................................24 3.2. Test Setup ....................................................................................................................................24 3.3. Limits ..........................................................................................................................................24 3.4. Test Result of Peak Power Output...............................................................................................25 4. Radiated Emission .....................................................................................................................27 4.1. Test Equipment............................................................................................................................27 4.2. Test Setup ....................................................................................................................................27 4.3. Limits ..........................................................................................................................................28 4.4. Test Procedure .............................................................................................................................29 4.5. Test Result of Radiated Emission................................................................................................30 5. Band Edge ..................................................................................................................................42 5.1. Test Equipment............................................................................................................................42 5.2. Test Setup ....................................................................................................................................42 5.3. Limits ..........................................................................................................................................43 5.4. Test Procedure .............................................................................................................................43 5.5. Test Result of Band Edge ............................................................................................................44 6. Occupied Bandwidth ..................................................................................…

Text truncated - open the document above for the full version.

Test Report

Report No. : ES/2004/20004 Page : 1 of 69 TEST REPORT Equipment Under Test : Notebook P.C. Model No. : W1S00N, W1B00N FCC ID : MSQW1NWM3B2200 Applicant : ASUSTeK COMPUTER INC. Address of Applicant : 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Date of Receipt : 2004.02.20 Date of Test(s) : 2004.02.24-2004.2.29 Date of Issue : 2004.02.29 Standards: FCC OET Bulletin 65 supplement C, ANSI/IEEE C95.1 , C95.3 In the configuration tested, the EUT complied with the standards specified above. Remarks: This report details the results of the testing carried out on one sample, the results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report. This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new system complies with all relevant standards. Any mention of SGS Taiwan E&E Services or testing done by SGS Taiwan E&E Services in connection with distribution or use of the product described in this report must be approved by SGS Taiwan E&E Services in writing. Tested by : Dikin Yang Date : 2004/02/29 Approved by : Robert Chang Date : 2004/02/29 Report No. : ES/2004/20004 Page : 2 of 69 Contents 1. General Information 1.1 Testing Laboratory 4 1.2 Details of Applicant 4 1.3 Description of EUT(s) 4 1.4 Test Environment 5 1.5 Operation description 5 1.6 Evaluation procedures 6 1.7 The SAR Measurement System 7 1.8 System Components 9 1.9 SAR System Verification 10 1.10 Tissue Simulant Fluid for the Frequency Band 2.4 to 2.5 GHz 11 1.11 Test Standards and Limits 12 2. Instruments List 14 3. Summary of Results 15 4. Measurements 19 802.11b Configuration 1 4.1.1 Left Side position, lowest channel 19 4.1.2 Left Side position, middle channel 20 4.1.3 Left Side position, highest channel 21 Configuration 2 4.1.4 Back of the LCD panel position, lowest channel 22 4.1.5 Back of the LCD panel position, middle channel 23 4.1.6 Back of the LCD panel position, highest channel 24 Configuration 3 4.1.7 LCD panel position, lowest channel 25 4.1.8 LCD panel position, middle channel 26 4.1.9 LCD panel position, highest channel 27 Configuration 4 4.1.10 Right Side position, lowest channel 28 4.1.11 Right Side position, middle channel 29 4.1.12 Right Side position, highest channel 30 Configuration 5 4.1.13 Back of the LCD panel position, lowest channel 31 4.1.14 Back of the LCD panel position, middle channel 32 4.1.15 Back of the LCD panel position, highest channel 33 Configuration 6 4.1.16 LCD panel position, lowest channel 34 4.1.17 LCD panel position, middle channel 35 4.1.18 LCD panel position, highest channel 36 Report No. : ES/2004/20004 Page : 3 of 69 802.11g Configuration 1 4.2.1 Left Side position, lowest channel 37 4.2.2 Left Side position, middle channel 38 4.2.3 Left Side position, highest channel 39 Configuration 2 4.2.4 Back of the LCD panel position, lowest channel 40 4.2.5 Back of the LCD panel position, middle channel 41 4.2.6 Back of the LCD panel position, highest channel 42 Configuration 3 4.2.7 LCD panel position, lowest channel 43 4.2.8 LCD panel position, middle channel 44 4.2.9 LCD panel position, highest channel 45 Configuration 4 4.2.10 Right Side position, lowest channel 46 4.2.11 Right Side position, middle channel 47 4.2.12 Right Side position, highest channel 48 Configuration 5 4.2.13 Back of the LCD panel position, lowest channel 49 4.2.14 Back of the LCD panel position, middle channel 50 4.2.15 Back of the LCD panel position, highest channel 51 Configuration 6 4.2.16 LCD panel position, lowest channel 52 4.2.17 LCD panel position, middle channel 53 4.2.18 LCD panel position, highest channel 54 4.3 System Performance Validation 55 APPENDIX 1. Photographs of Test Setup 56 2. Photographs of EUT 60 3. Probe Calibration certificate 63 4. Uncertainty Analysis 67 5. Phantom description 68 6. System Validation from Original equipment supplier 69 Report No. : ES/2004/20004 Page : 4 of 69 1. General Information 1.1 Testing Laboratory SGS Taiwan Ltd. ( FCC Registration number: 573967 ) 1F, No. 134, Wukung Road, Wuku industrial zone Taipei county , Taiwan , R.O.C. Telephone : +886-2-2299-3279 Fax : +886-2-2298-2698 Internet : http://www.sgs.com.tw 1.2 Details of Applicant Name : ASUSTeK COMPUTER INC. Address : 4FL., No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. 1.3 Description of EUT(s) Equipment Type Notebook P.C. Test Procedure FCC OET Bulletin 65, Supplement C TX Frequency range 2412-2462 MHz FCC ID MSQW1NWM3B2200 Model No. W1S00N, W1B00N Number Of Channel 11 Modulation Direct Sequence Spread Spectrum (DSSS) 802.11b 1, 2, 5.5, 11 Mbps Transfer Rate 802.11g6 Mbps 802.11b1.2 W/kg Max. SAR Measured 802.11g 0.646 W/kg Antenna Gain 2dB Antenna Type PIFA I/O Port Mini PCI Power Supply 19Vdc from AC adapter Report No. : ES/2004/20004 Page : 5 of 69 NOTE: 1. The mini PCI card, which brand is Intel and the model name is WM3B2200BG, is specified to this EUT. 2. The EUT is powered by the following adapter: Brand DELTA Model ADP-65DB Input 100-240Vac 1.5A 50-60Hz Output 19Vdc 3.42A 3. For more detailed features description, please refer to the manufacturer's specifications or User's Manual. 1.4 Test Environment Ambient temperature : 22.1° C Tissue Simulating Liquid : 21.9° C Relative Humidity : 50 % 1.5 Operation Configuration 802.11b 802.11g Channel Frequency Under Test And Its Conducted Output Power 20.36 dBm(2412MHz) 19.92 dBm 2437MHz) 19.57 dBm(2462MHz) 18.02 dBm(2412MHz) 17.68 dBm 2437MHz) 17.46 dBm(2462MHz) Antenna Configuration Internal Antenna Antenna Position The Antennas are located at both sides of the LCD; the left Antenna is the main antenna, and the ri ght one is the auxiliary. EUT Power Source From The Host Equipment HOST Power Source Fully Charged Battery The following test configurations…

Text truncated - open the document above for the full version.

Test Setup Photos

Report No.: 042L047FI Page : 1 of 3 Version:1.0 Attachment 1: EUT Test Setup Photographs Front View of Conducted Test Back View of Conducted Test Report No.: 042L047FI Page : 2 of 3 Version:1.0 Front View of Radiated Test Back View of Radiated Test Report No.: 042L047FI Page : 3 of 3 Version:1.0 Front View of Radiated Test (Horn)

Contact Information

Applicant

Jackson Yen(Associate Vice President)
[email protected]+886-2-28943447Fax: +886-2-28987364

Test Firm

DEKRA Testing and Certification Co., Ltd.Sky Hsu
[email protected]886-2-86013788Fax: 886-2-86013789

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.41 GHz - 2.46 GHz109.00 mW
Confidentiality
Long Term
Grant Notes
Power output listed is conducted. The antenna used for this device must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The maximum reported SAR value is: Body 1.2 W/kg
