MSQWL120GV2Wireless Mini-PCI Modular

ASUSTeK Computer Inc

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: May 26, 2005
Application Purpose: Original Equipment
Date of Application: May 26, 2005
Equipment Note: Wireless Mini-PCI Modular
Frequency Range: 2412.00000000 - 2462.00000000
Company: ASUSTeK Computer Inc
Country: Taiwan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Wireless Local Area Network Card WL-120g V2 (For 802.11g and 802.11b Wireless Networks) ® User’s Manual 2ASUS WLAN Card No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”). ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Copyright © 2003 ASUSTeK COMPUTER INC. All Rights Reserved. Copyright Information Product Name:ASUS WLAN Card (WL-120g) Manual Revision:1 Release Date:October 2003 ASUS WLAN Card3 Copyright Information ASUSTeK COMPUTER INC. (Asia-Pacific) Address:150 Li-Te Road, Peitou, Taipei, Taiwan 112 General Tel:+886-2-2894-3447 General Fax:+886-2-2894-3449 Web Site:www.asus.com.tw Technical Support MB/Others (Tel):+886-2-2890-7121 (English) Notebook (Tel):+886-2-2890-7122 (English) Desktop/Server (Tel): +886-2-2890-7123 (English) Support Fax:+886-2-2890-7698 ASUS COMPUTER INTERNATIONAL (America) Address:44370 Nobel Drive, Fremont, CA 94538, USA General Fax:+1-502-933-8713 General Email:[email protected] Web Site:usa.asus.com Technical Support Support Fax:+1-502-933-8713 General Support:+1-502-995-0883 Notebook Support:+1-510-739-3777 x5110 Support Email:[email protected] ASUS COMPUTER GmbH (Germany and Austria) Address:Harkortstr. 25, 40880 Ratingen, BRD, Germany General Email:[email protected] (for marketing requests only) General Fax:+49-2102-9599-31 Web Site:www.asuscom.de Technical Support Components:+49-2102-9599-0 Notebook PC:+49-2102-9599-10 Support Fax:+49-2102-9599-11 Support Email:www.asuscom.de/support (for online support) ASUSTeK COMPUTER (Middle East and North Africa) Address:P.O. Box 64133, Dubai, U.A.E. General Tel:+9714-283-1774 General Fax:+9714-283-1775 Web Site:www.ASUSarabia.com 4ASUS WLAN Card Table of Contents 1. Introduction ............................................................................. 7 Overview .............................................................................................. 7 The ASUS Wireless LAN Family ..................................................... 8 The ASUS WLAN™ Family .................................................................. 8 System Requirements ........................................................................ 10 The Product Package ......................................................................... 10 2. Installation ............................................................................. 11 Installing the ASUS WLAN Card Driver .............................................. 11 Verifying Drivers ............................................................................ 12 Installing the ASUS WLAN Card Utilities ............................................ 13 ASUS WLAN Utility Quick Start .......................................................... 15 Reading the ASUS WLAN Status Indicators ................................. 17 Orientating the Antenna ................................................................ 18 3. Software Reference .............................................................. 19 Chapter Overview ............................................................................... 19 Windows XP Wireless Options ..................................................... 20 Control Center Utility .......................................................................... 21 Site Monitor Utility ......................................................................... 24 Wireless Settings Utility ...................................................................... 26 Status - Status Tab ....................................................................... 27 Status - Connection Tab ............................................................... 31 Status - IP Config Tab ................................................................... 32 Config - Basic Tab ......................................................................... 33 Config - Encryption Tab ................................................................ 35 Survey - Site Survey Tab .............................................................. 38 About - Version Info Tab ............................................................... 39 Link State ...................................................................................... 40 ASUS WLAN Card5 Table of Contents Exit Wireless Settings ....................................................…

Text truncated - open the document above for the full version.

External Photos

External Photos of Wireless Mini-PCI Modular---------------------------------------1/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of Wireless Mini-PCI Modular---------------------------------------2/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of Wireless Mini-PCI Modular---------------------------------------3/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antennas of Wireless Mini-PCI Modular-----------------------------------------------4/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antenna#1: A3E-L / A3E-R Antennas of Wireless Mini-PCI Modular-----------------------------------------------5/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antenna#2: W3 Antennas of Wireless Mini-PCI Modular-----------------------------------------------6/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antenna#3: A6K-L / A6K-R Antennas of Wireless Mini-PCI Modular-----------------------------------------------7/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antenna#4: A7R / A7L Antennas of Wireless Mini-PCI Modular-----------------------------------------------8/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antenna#5: A5L / A5R Antennas of Wireless Mini-PCI Modular-----------------------------------------------9/9 Applicant: ASUSTeK Computer Inc.FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Antenna#6: A3L / A3R

ID Label/Location Info

LABEL Sample and Location Information ------------------------------------------------ 1/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Position:

ID Label/Location Info

LABEL Sample and Location Information ------------------------------------------------ 2/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Position:

Internal Photos

RF Exposure Info

Measurement of Maximum Permissible Exposure -------------------------------------- 1/8 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Measurement of Maximum Permissible Exposure 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT FCC ID : MSQWL120GV2 Product name : Wireless Mini-PCI Modular Model : WL-120g V2 Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Frequency Range : 2.412 GHz ~ 2.462GHz Supported Channel : 11 Channels Modulation Skill : DBPSK, DQPSK, CCK, OFDM Power Type : Powered by mini-PCI interface Measurement of Maximum Permissible Exposure -------------------------------------- 2/8 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, Equation for Predicting RF Fields: Friis Transmission Formula: 2 22 /04883.0 )20(4 633.1314.150 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R41965.4 4 633.1314.150 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 4.42cm" Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 ( dB antenna gain / 10 ) G = Log -1 (2.13 / 10) = 1.63305 Measurement of Maximum Permissible Exposure -------------------------------------- 3/8 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Appendix Antenna Specification (Ant#1 A3E-L / A3E-R) JOINSOON ELECTRONICS MFG. CO., LTD. QUICK REFERENCE DATA for A3E-R Antenna Patch Dimension 31.6*31.6 mm A3E-R Antenna A3N –R Cable Length 540 mm, Color BLACK Connector I-PEX Peak Gain -5.0Peak Gain dBi VSWR Polarization Linear Impedance 50 Operating Temperature -40~90 Maximum Power 1W 2 JOINSOON ELECTRONICS MFG. CO., LTD. Frequency Range 2.4~2.5GHz4.9-5.85GHz Impedance 50Ohms nomimal VSWR 2.0 Peak Gain : -5.0dBi peak gain 3dBi Standard Connector I-PEX Connector 3 JOINSOON ELECTRONICS MFG. CO., LTD. PEAK GAIN( H-H + H-V ) Antenna 2.4GHz 2.45GHz 2.5GHz R 1.67 1.76 1.25 PEAK GAIN( H-H + H-V ) Antenna 4.9GHz 5.15GHz 5.35GHz 5.45GHz 5.725GHz 5.875GH R -1.12 1.03 0.75 0.31 -0.87 -0.85 PEAK GAIN( H-H + H-V ) Antenna 2.4GHz 2.45GHz 2.5GHz R -2.55 -2.61 -2.57 PEAK GAIN( H-H + H-V ) Antenna 4.9GHz 5.15GHz 5.35GHz 5.45GHz 5.725GHz 5.875GH R -4.77 -4.54 -4.21 -4.06 -4.43 -4.63 4 JOINSOON ELECTRONICS MFG. CO., LTD. QUICK REFERENCE DATA for A3E-L Antenna Patch Dimension 31.6*31.6 mm A3E-Left Antenna A3N –Down Cable Length 620 mm, Color GRAY Connector I-PEX Peak Gain -5.0Peak Gain dBi VSWR Polarization Linear Impedance 50 Operating Temperature -40~90 Maximum Power 1W 5 JOINSOON ELECTRONICS MFG. CO., LTD. Frequency Range 2.4~2.5GHz4.9-5.85GHz Impedance 50Ohms nomimal VSWR 2.0 Peak Gain : -5.0dBi peak gain 3dBi Standard Connector I-PEX Connector 6 JOINSOON ELECTRONICS MFG. CO., LTD. PEAK GAIN( H-H + H-V ) Antenna 2.4GHz 2.45GHz 2.5GHz L 1.32 1.21 1.47 PEAK GAIN( H-H + H-V ) Antenna 4.9GHz 5.15GHz 5.35GHz 5.45GHz 5.725GHz 5.875GH L -1.94 -1.12 -0.32 0.56 -1.34 -2.21 AVG GAIN( H-H + H-V ) Antenna 2.4GHz 2.45GHz 2.5GHz L -3.31 -3.32 -3.27 AVG GAIN( H-H + H-V ) Antenna 4.9GHz 5.15GHz 5.35GHz 5.45GHz 5.725GHz 5.875GH L -4.91 -4.82 -4.43 -4.21 -4.73 -4.85 7 Measurement of Maximum Permissible Exposure -------------------------------------- 4/8 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL120GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Appendix Antenna Specification (Ant#2 W3) 1 l Product type l WLAN antenna l Model number l ASUS / W3 l Revision l R02 l Part No. / Yageo / Main / Aux l CAN4313 379 012501B / 022501B l Part No. / Yageo / Bluetooth l CAN4313 379 012451B l Part No. / ASUS / Main / Aux l 14-151019000 / 14-151019100 l Part No. / ASUS / Bluetooth l 14-152049000 Yageo (Taiwan) Ltd. 16, west 3rd Street, N.E.P.Z Kaohsiung, 811 Taiwan, R.O.C Yegeo Electronics (China) Co, Ltd No. 10, Zhu Yuan Road, Suzhou New District, Suzhou, PRC R01 Nov. 20, 04 R02 Nov. 26, 04 2.45/5GHz Multi Band Antenna with Cable & Connector for IEEE802.11b, 11g, 11a, UNII Yageo Part Number: Main / Aux: CAN4313 379 012501B/02250 CAN4313 379 012451B (BT) BY / Howard.Ch…

Text truncated - open the document above for the full version.

Test Report

Test Report -------------------------------------------------------------------------------1/71 Report No.: A5415050216, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of WIRELESS MINI-PCI MODULAR Applicant:ASUSTek Computer Inc. EUT:Wireless Mini-PCIModular Model:WL-120g V2 FCC ID:MSQWL120GV2 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report -------------------------------------------------------------------------------2/71 Report No.: A5415050216, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 CERTIFICATION We here by verify that: The test data, data evaluation, test procedures and equipment configurations shown in this report were made mainly in accordance with the procedures given in ANSI C63.4 (2003) as a reference. All test were conducted by Training Research Co., Ltd., 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with the technical requirements set forth in the FCC Rules Part 15 Subpart B (Declaration of Conformity) and C Section 15.247. Applicant:ASUSTek Computer Inc. Applicant Address:4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. FCC ID:MSQWL120GV2 Report No.:A5415050216 Test Date:May 18, 2005 Prepared by:Approved by: Jack TsaiFrank Tsai Conditions of issue : (1) This test report shall not be reproduced except in full, without written approval of TRC. And the test result contained within this report only relate to the sample submitted for testing. (2) This report must not be used by the client to claim product endorsement by NVLAP or any agency of U.S. Government. (3) This test report, measurements made by TRC are traceable to the NIST only Conducted and Radiated Method. NVLAP LAB CODE: 200174-0 Test Report -------------------------------------------------------------------------------3/71 Report No.: A5415050216, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I.GENERAL................................................................................................................... 5 1.1 Introduction............................................................................................................. 5 1.2 Description of EUT .................................................................................................. 5 1.3 Test method ............................................................................................................. 5 1.4 Description of Support Equipment ............................................................................ 6 1.5 Configuration of System Under Test ......................................................................... 8 1.6 Verify the Frequency and Channel ............................................................................ 9 1.7 Test Procedure....................................................................................................... 10 1.8 Location of the Test Site ......................................................................................... 10 1.9 General Test Condition ........................................................................................... 10 II.Section 15.203 : Antenna Requirement....................................................................... 11 III.Section 15.207 : Power Line Conducted Emissions for AC Powered Units ............. 12 3.1 Test Condition & Setup.......................................................................................... 12 3.2 List of Test Instruments ........................................................................................... 13 3.3 Test Result of Conducted Emissions ........................................................................ 14 Antenna#4............................................................................................................... 14 Antenna#6............................................................................................................... 18 IV.Section 15.247(a) : Technical Description of the EUT................................................ 22 V.Section 15.247(a)(2) : Bandwidth for Direct Sequence System ................................ 23 5.1 Test Condition & Setup .......................................................................................... 23 5.2 Test Instruments Configuration ................................................................................ 23 5.3 List of Test Instruments ........................................................................................... 23 5.4 Test Result of Bandwidth ........................................................................................ 23 Channel 01 ............................................................................................................... 24 Channel 06 ............................................................................................................... 25 Channel 11 ............................................................................................................... 26 Test Report -------------------------------------------------------------------------------4/71 Report No.: A5415050216, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 VI.Section 15.247(b) : Power Output ............................................................................... 27 6.1 Test Condition & Setup.......................................................................................... 27 6.2 List of Test Instruments ........................................................................................... 27 6.3 Test Result........................................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Test Setup Photos ------------------------------------------------------------------------ 1/4 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL520GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement for Antenna#4 (A7L/A7R) Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 2/4 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL520GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement for Antenna#6 (A3L/A3R) Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 3/4 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL520GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement for Antenna#4 (A7L/A7R) Front View of the Test Configuration Rear View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 4/4 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL520GV2 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement for Antenna#6 (A3L/A3R) Front View of the Test Configuration Rear View of the Test Configuration

Contact Information

Applicant

Jackson Yen(Associate Vice President)

[email protected]+886-2-28943447Fax: +886-2-28987364

Test Firm

Training Research Co., LtdJack Tsai

[email protected]886-2-26935155Fax: 886-2-26934440

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	150.00 mW

Modular Type

Single Modular Approval

Confidentiality

Long Term

Grant Notes

Modular approval. Power listed is conducted. Approval is limited to OEM installation for mobile operating configurations only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device.
