User Guide WL-335G IEEE 802.11g/b WLAN AP, Client, Repeater, P2P, PMP Table of Contents Table of Contents .......................................................... 3 1. Introduction............................................................................................. 5 2. Quick Start......................................................................................... 5 3. Operating Modes............................................... ................................ 6 3.1 Introduction to Operating Modes................................................... 6 3.1.1 Traveler’s AP Mode............................................................. 6 3.1.2 Repeater Mode................................................................... 7 3.1.3 Point-to-Point (P2P) Mode.................................................. 8 3.1.4 Point-to-Multipoint (PMP) Mode.......................................... 9 3.1.5 Client Mode......................................................................... 10 4. Wireless Security Support...................................................................... 11 5. Mode Selection ....................................................................................... 12 6. AP Setup................................................................................................... 13 6.1 Basic Setup.................................................................................... 13 6.2 Security Setup............................................................................... 14 6.3 Advanced Settings......................................................................... 16 6.3.1 Adding a Repeater............................................................... 18 6.4 Access Filter.................................................................................. 18 7. Repeater Setup...................................................................................... 21 7.1 Basic Setup.................................................................................. 21 7.2 Security Setup............................................................................... 22 7.3 Advanced Settings......................................................................... 23 7.4 Access Filter.................................................................................. 23 8. Point-to-Point (P2P) Setup...................................................................... 24 8.1 Basic Setup ................................................................................... 24 8.2 Security Setup ............................................................................ 25 8.3 Advanced Settings ......................................................................... 25 9. Point-to-Multipoint (PMP) Setup ............................................................ 26 9.1 Basic Setup ...................................................................................... 26 9.2 Security Setup .................................................................................. 27 9.3 Advanced Settings ........................................................................... 27 10. Client Mode Setup ................................................................................. 28 10.1 Basic Setup .................................................................................... 28 10.2 MAC Cloning .................................................................................. 29 11. Status Page ............................................................................................ 30 12. Admin Page............................................................................................. 30 12.1 Firmware Upgrade ......................................................................... 31 12.2 Update Password............................................................................ 31 12.3 Reboot.......................................................................................... 31 12.4 Reset to Default.............................................................................. 31 13. Lan Page................................................................................................. 32 14. Utility....................................................................................................... 34 14.1 Configuration Utility ........................................................................ 34 14.2 Firmware Restoration ..................................................................... 34 15. Telnet Management................................................................................ 36 15.1 Telnet step by step ......................................................................... 36 Appendix...................................................................................... 37 1. Introduction This document is the user manual for the SMC WTK-G product.. 2. Quick Start The default IP address of the WTK-G is 192.168.2.25. The login is “admin” and password is “smcadmin”. 1. Connect the SMC WTK-G to a PC using an ethernet cable. 2. Plug in the 5V power supply. 3. Make sure the PC has a IP address on the 192.168.2.xxx subnet, such as 192.168.2.100. 4. Open your web browser and navigate to 192.168.2.25. 5. Type “admin” for the login field and “smcadmin” for the password. 6. The default out-of-box operating mode is Access Point (AP) mode. To switch to Repeater, P2P, PMP or Client mode, go to the Mode page and select the desired mode. Click Apply. The board will reboot into the desired mode. 7. After the board reboots, go to the Mode page and click Setup. Configure the applicable properties for that mode, such as security, SSID, channel, etc. 8. The SMC WTK-G should now be ready to use. 3. Operating Modes 3.1 Introduction to Operating Modes 3.1.1 Traveler’s AP Mode The Access Point (AP) mode is by default the out-of-box operational mode. When the user resets the system to the default manufacturing settings, the operational mo…
Text truncated - open the document above for the full version.
ASUSTeK COMPUTER INC. Tel : +886-2-28943447 Fax : +886-2-28950114 www.asus.com Request for Confidentiality Federal Communications Commission Authorization and Evaluation Division Subject: Confidentiality Request regarding application for certification of FCC ID : MSQWL335G Dear Madam or Sir: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: z Schematics z Part List z Block diagram z Operational description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. ASUSTeK COMPUTER INC. Tel : +886-2-28943447 Fax : +886-2-28950114 www.asus.com Pursuant to DA 04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: z External Photos z Internal Photos z Test Setup Photos z User’s Manual Sincerely, Lawrence Yu / Manager ASUSTek Computer Inc.
External Photos of Pocket Wireless Access Point 1/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of Pocket Wireless Access Point 2/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of Adapter 3/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440
LABEL Sample and Location information -------------------------------------------------- 2/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Position:
LABEL Sample and Location information -------------------------------------------------- 1/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 LABEL Format:
Internal Photos of Pocket Wireless Access Point 4/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Pocket Wireless Access Point 5/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Pocket Wireless Access Point 6/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of Pocket Wireless Access Point 7/7 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440
Measurement of Maximum Permissible Exposure----------------------------------------- 1/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Measurement of Maximum Permissible Exposure 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT FCC ID : MSQWL335G Product name : Pocket Wireless Access Point Model : WL-335G; SMCWTK-G Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Frequency Range : 2.412 GHz ~ 2.462GHz Supported Channel : 11 Channels Modulation Skill : DBPSK, DQPSK, CCK, OFDM Power Type : Powered by the adapter, Model: DSA-0051-03 FCH 40100F I/P: 100-240VAC, 50/60Hz, 0.2A O/P: +4VDC, 1.0A 188cm length, non-shielded, incorporates a ferrite core Measurement of Maximum Permissible Exposure----------------------------------------- 2/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, Equation for Predicting RF Fields: Friis Transmission Formula: 2 22 /05090.0 )20(4 3335.1867.191 4 cmmW R PG S= × == ππ Estimated safe separation: cm PG R512.4 4 3335.1867.191 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 4.512 cm." Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 ( dB antenna gain / 10 ) G = Log -1 (1.25 / 10) = 1.3335 WL-335G Antenna Measurement 1. without covering 2. with covering 2.9 GHz 10 dB/ -80 dB 20 dB CH110 dB/REF 0 dB START2 GHzSTOP3 GHz100 MHz/ MAGdB FIL 1k 1k FIL 1k 1k CPL OFS S11 1 2 3 1: -15.96 dB 2.4 GHz 2: -18.15 dB 2.45 GHz 3: -24.51 dB 2.5 GHz 〈 0 dB Date: 27.AUG.03 06:49:40 2.9 GHz 10 dB/ -80 dB 20 dB CH110 dB/REF 0 dB START2 GHzSTOP3 GHz100 MHz/ MAGdB FIL 1k 1k FIL 1k 1k CPL OFS S11 1 2 3 1: -36.18 dB 2.4 GHz 2: -31.77 dB 2.45 GHz 3: -22.13 dB 2.5 GHz 〈 0 dB Date: 27.AUG.03 06:50:41 3. Smith Chart 00.20.512510 -5 -2 -1 -0.5 0.5 1 2 5 CH1 ↑ 1 U START2 GHzSTOP3 GHz FIL 1k 1k FIL 1k 1k CPL OFS S11 1 2 3 1: 47.39 Í j593.9 m Í 2.4 GHz 2: 51.68 Í j3.431 Í 2.45 GHz 3: 55.91 Í j9.069 Í 2.5 GHz Date: 27.AUG.03 08:38:17
Test Report ----------------------------------------------------------------------------------1/54 Report No.: A5415890, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of Pocket Wireless Access Point Applicant:ASUSTek Computer Inc. EUT:Pocket Wireless Access Point Model No. : WL-335G; SMCWTK-G FCC ID:MSQWL335G Report No.:A5415890 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report ----------------------------------------------------------------------------------2/54 Report No.: A5415890, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 CERTIFICATION We here by verify that: The test data, data evaluation, test procedures and equipment configurations shown in this report were made mainly in accordance with the procedures given in ANSI C63.4 (2003) as a reference. All test were conducted byTraining Research Co., Ltd., 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with the technical requirements set forth in the FCC Rules Part 15 Subpart B (Declaration of Conformity) and C Section 15.247. Applicant:ASUSTek Computer Inc. Applicant address:4F, No. 150, Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Product Name:Pocket Wireless Access Point Model Name : WL-335G; SMCWTK-G FCC ID:MSQWL335G Report No.:A5415890 Test Date:October 7, 2004 Prepared by:Approved by: Jack TsaiFrank Tsai Conditions of issue : (1) This test report shall not be reproduced except in full, without written approval of TRC. And the test result contained within this report only relate to the sample submitted for testing. (2) This report must not be used by the client to claim product endorsement by NVLAP or any agency of U.S. Government. (3) This test report, measurements made by TRC are traceable to the NIST only Conducted and Radiated Method. NVLAP LAB CODE: 200174-0 Test Report ----------------------------------------------------------------------------------3/54 Report No.: A5415890, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Federal Communications Commission Declaration of Conformity (DoC) for the following equipment: Product name: Pocket Wireless Access Point Model name : WL-335G; SMCWTK-G Trade name: ASUS; SMC Is herewith confirmed and found to comply with the requirements of CFR 47 part15 Subpart B - Unintentional Radiators regulation. The results of electromagnetic mission evaluation are shown in the report number : A5415890 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation ManufacturerUSA local representative Company name: ASUSTeK Computer Inc.To be determined Computer address: 4/F, 150, Li-Te Rd., Peitou, Taipei, Taiwan ZIP / Postal code 112 Contact person: Lawrence Yu Title: Manager Internet e-mail address: [email protected] Tel / Fax: 886-2-28943447 / 886-2-28950113 Test Report ----------------------------------------------------------------------------------4/54 Report No.: A5415890, FCC Part 15.247 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I.GENERAL..................................................................................................................... 6 1.1Introduction ........................................................................................................... 6 1.2Description of EUT ............................................................................................... 6 1.3Test method ........................................................................................................... 6 1.4Description of Support Equipment ........................................................................ 7 1.5Configuration of System Under Test .................................................................... 10 1.6Verify the Frequency and Channel ....................................................................... 12 1.7Test Procedure ...................................................................................................... 13 1.8Location of the Test Site ....................................................................................... 13 1.9General Test Condition ........................................................................................ 13 II.Section 15.101(a) : Equipment Authorization of Unintentional Radiators.............. 14 III. Section 15.203 : Antenna Requirement........................................................................ 15 IV. Section 15.207 : Power Line Conducted Emissions for AC Powered Units........... 16 4.1Test Condition & Setup ........................................................................................ 16 4.2List of Test Instruments ........................................................................................ 17 4.3Test Result of Conducted Emissions .................................................................... 18 Standby mode ................................................................................................................... 18 IEEE 802.11b ................................................................................................................... 19 IEEE 802.11g ................................................................................................................... 20 V.Section 15.247(a) : Technical Description of the EUT................................................ 22 VI. Section 15.247(a)(2) : Bandwidth for Direct Sequence System................................ 23 6.1Test Cond…
Text truncated - open the document above for the full version.
Test Setup Photos ------------------------------------------------------------------------ 1/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement: Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 2/2 Applicant: ASUSTeK Computer Inc. FCC ID: MSQWL335G Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement: Front View of the Test Configuration Rear View of the Test Configuration
