MSQWLHGWSWL500Residential WLAN Gatweway

SpaceLink Home Gateway WL-500 User’s Manual ® 2SpaceLink Home Gateway No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”). ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved. Copyright Information Product Name:SpaceLink Home Gateway (WL-500) Manual Revision:1.00 E1062 Release Date:Aug 2002 SpaceLink Home Gateway3 ASUSTeK COMPUTER INC. (Asia-Pacific) Address:150 Li-Te Road, Peitou, Taipei, Taiwan 112 General Tel:+886-2-2894-3447 General Fax:+886-2-2894-3449 General Email:[email protected] Technical Support MB/Others (Tel):+886-2-2890-7121 (English) Notebook (Tel):+886-2-2890-7122 (English) Desktop/Server (Tel): +886-2-2890-7123 (English) Support Fax:+886-2-2890-7698 Support Email:[email protected] Web Site:www.asus.com.tw Newsgroup:cscnews.asus.com.tw ASUS COMPUTER INTERNATIONAL (America) Address:6737 Mowry Avenue, Mowry Business Center, Building 2, Newark, CA 94560, USA General Fax:+1-510-608-4555 General Email:[email protected] Technical Support Support Fax:+1-510-608-4555 Web Site:www.asus.com Support Email:[email protected] ASUS COMPUTER GmbH (Europe) Address:Harkortstr. 25, 40880 Ratingen, BRD, Germany General Fax:+49-2102-442066 General Email:[email protected] (for marketing requests only) Technical Support Support Hotline:MB/Others: +49-2102-9599-0 Notebook (Tel):+49-2102-9599-10 Support Fax:+49-2102-9599-11 Support (Email):www.asuscom.de/de/support (for online support) Web Site:www.asuscom.de Copyright Information 4SpaceLink Home Gateway Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: •This device may not cause harmful interference, and •This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. WARNING! The use of a shielded-type power cord is required in order to meet FCC emission limits and to prevent interference to the nearby radio and television reception. It is essential that only the supplied power cord be used. Use only shielded cables to con- nect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the Federal Register, National Archives and Records Administration, U.S. Government Printing Office. Canadian Department of Communications This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Safety Statements SpaceLink Home Gateway5 Safety Information In order to maintain compliance with the FCC RF exposure guidelines, this equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. Use only with supplied antenna. Unauthorized antenna, modification, or attachments co…

Text truncated - open the document above for the full version.

SpaceLink Home Gateway WL-500 User’s Manual ® 2SpaceLink Home Gateway No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”). ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT. Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT. Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved. Copyright Information Product Name:SpaceLink Home Gateway (WL-500) Manual Revision:1.00 E1062 Release Date:Aug 2002 SpaceLink Home Gateway3 ASUSTeK COMPUTER INC. (Asia-Pacific) Address:150 Li-Te Road, Peitou, Taipei, Taiwan 112 General Tel:+886-2-2894-3447 General Fax:+886-2-2894-3449 General Email:[email protected] Technical Support MB/Others (Tel):+886-2-2890-7121 (English) Notebook (Tel):+886-2-2890-7122 (English) Desktop/Server (Tel): +886-2-2890-7123 (English) Support Fax:+886-2-2890-7698 Support Email:[email protected] Web Site:www.asus.com.tw Newsgroup:cscnews.asus.com.tw ASUS COMPUTER INTERNATIONAL (America) Address:6737 Mowry Avenue, Mowry Business Center, Building 2, Newark, CA 94560, USA General Fax:+1-510-608-4555 General Email:[email protected] Technical Support Support Fax:+1-510-608-4555 Web Site:www.asus.com Support Email:[email protected] ASUS COMPUTER GmbH (Europe) Address:Harkortstr. 25, 40880 Ratingen, BRD, Germany General Fax:+49-2102-442066 General Email:[email protected] (for marketing requests only) Technical Support Support Hotline:MB/Others: +49-2102-9599-0 Notebook (Tel):+49-2102-9599-10 Support Fax:+49-2102-9599-11 Support (Email):www.asuscom.de/de/support (for online support) Web Site:www.asuscom.de Copyright Information 4SpaceLink Home Gateway Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: •This device may not cause harmful interference, and •This device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the Federal Communications Commission (FCC) rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. WARNING! The use of a shielded-type power cord is required in order to meet FCC emission limits and to prevent interference to the nearby radio and television reception. It is essential that only the supplied power cord be used. Use only shielded cables to con- nect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. Reprinted from the Code of Federal Regulations #47, part 15.193, 1993. Washington DC: Office of the Federal Register, National Archives and Records Administration, U.S. Government Printing Office. Canadian Department of Communications This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Safety Statements SpaceLink Home Gateway5 Safety Information In order to maintain compliance with the FCC RF exposure guidelines, this equipment should be installed and operated with minimum distance 20 cm between the radiator and your body. Use only with supplied antenna. Unauthorized antenna, modification, or attachments co…

Text truncated - open the document above for the full version.

Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Measurement of MPE 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT EUT : ASUS SpaceLink Wireless Home Gateway Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Model No. : WL-500 Granted FCC ID : MSQWLHGWSWL500 Frequency Range : 2.412 GHz ~ 2.462GHz Antenna Kit : 1 external dipole antenna Supported Channel: 11 Channel Modulation Skill : DBPSK, DQPSK, CCK Data Cable : RJ45: Non-shielded, 10-meter, No ferrite bead Power Type : AC to DC Switching Adapter Input: 100 ~ 240VAC, 50/60Hz, 0.3A Output: +5VDC, 2A Applicant : ASUSTeK Computer Inc. 4/F, 150 Li-Te Rd., Peitou, Taipei, Taiwan, R.O.C. Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, Equation for Predicting RF Fields: Friis Transmission Formula: 23 22 /10074.7 )20(4 156.35 4 cmmW R PG S − ×= × == ππ Where: S = power density (in appropriate units, e.g. mW/cm2) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 (dB antenna gain/10) G = Log -1 (0 / 10) = 1 SPECIFICATION-ELECTRIC * PART NO. ASUS’S : 12-230002000 FLN’S : 323-1000-120 l CUSTOMER’S NAME . l PART NAMESTD 2.45GHz DIPOLE ANTENNA SWIVEL (WL500) 1. WORKING FREQUENCE 2.400 – 2.500GHz 2. ELECTRIC WAVE 1/2ë ; DIPOLE 3. IMPEDANCE 50 Ohm , Nominal 4. V.S.W.R. 2.0 MAX 5. GAIN O dBi . 6. RADIATION Omni 7. POLARIZATION VERTICAL 8. POWER HANDLING 1 W MAX

Test Report -------------------------------------------------------------------------------- 1/42 Report No.: A5415562 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of WIRELESS LAN GATEWAY Applicant : ASUSTeK Computer Inc. Model No. : WL500 EUT : ASUS SpaceLink Home Gateway FCC ID : MSQWLHGWSWL500 Report No. : A5415562 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report -------------------------------------------------------------------------------- 3/42 Report No.: A5415562 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents I. GENERAL ......................................................................................................................... 5 1.1 Introduction .................................................................................................................. 5 1.2 Description of EUT ....................................................................................................... 5 1.3 Description of Support Equipment ................................................................................. 6 1.4 Configuration of System Under Test .............................................................................. 7 1.5 Verify the Frequency and Channel ................................................................................. 8 1.6 Test Procedure ............................................................................................................. 9 1.7 Location of the Test Site ................................................................................................ 9 1.8 General Test Condition .................................................................................................. 9 II. Section 15.203 : Antenna Requirement............................................................................. 10 III. Section 15.207: Power Line Conducted Emissions for AC Powered Units .................... 11 3.1 Test Condition & Setup ................................................................................................ 11 3.2 List of Test Instruments ................................................................................................ 11 3.3 Test Configuration ........................................................................................................ 12 3.4 Test Result of Conducted Emissions ............................................................................. 13 IV. Section 15.247(a) : Technical Description of the EUT..................................................... 16 V. Section 15.247(a)(2): Bandwidth for Direct Sequence System ...................................... 17 5.1 Test Condition & Setup ................................................................................................ 17 5.2 Test Instruments Configuration ...................................................................................... 17 5.3 List of Test Instruments ................................................................................................ 17 5.4 Test Result of Bandwidth .............................................................................................. 18 VI. Section 15.247(b) : Power Output .................................................................................... 22 6.1 Test Condition & Setup ................................................................................................ 22 6.2 List of Test Instruments ................................................................................................ 22 6.3 Test Result ................................................................................................................... 23 VII. Section 15.247(c) : Spurious Emissions (Radiated) ........................................................ 24 7.1 Test Condition & Setup ................................................................................................ 24 7.2 List of Test Instruments ................................................................................................ 25 7.3 Test Instruments Configuration ...................................................................................... 26 7.4 Test Result of Spurious Radiated Emissions .................................................................. 27 7.5 Test Result of Band-edge Compliance............................................................................ 34 VIII.Section 15.247(d) : Power Spectral Density ................................................................... 37 8.1 Test Condition & Setup ................................................................................................ 37 8.2 Test Instruments Configuration ...................................................................................... 37 8.3 List of Test Instruments.................................................................................................. 37 8.4 Test Result of Power Spectral Density .......................................................................... 38 Test Report -------------------------------------------------------------------------------- 4/42 Report No.: A5415562 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Appendix A: Set Up Procedure ............................................................................................... 42 Test Report -------------------------------------------------------------------------------- 5/42 Report No.: A5415562 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 GENERAL 1.1 Introduction The following measurement report is submitted on behalf of Applicant in support of a WLAN Home Gateway certification in accordance with Part 2 Subpart J and Part 15 Subpart A and C of the Commission's Rules and Regulations. 1.2 Description of EUT EUT : ASUS SpaceLink Wireless Home Gatewa…

Text truncated - open the document above for the full version.

Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test setup photos Asus SpaceLink Wireless Home Gateway (Test report no.: A5415562) FCC ID: MSQWLHGWSWL500 Test Instruments Configuration of Conducted Emissions Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test Instruments Configuration of Bandwidth Test Configuration of Bandwidth for Direct Sequence System P.S.: Notebook computer to control the EUT at maximal power output and channel Number and set antenna kit Test Condition & Setup of Power Output EUT Spectrum Analyzer (RBW:100kHz; VBW: 100kHz) EUT BOONTON 4532 RF Power Meter Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test Instruments Configuration of the Spurious Radiated Emissions Front View of the Test Configuration Rear View of the Test Configuration The test configuration for frequency between 1GHz to 18GHz is same as above. Training Research Co., Ltd. 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. TEL: 886-2-26935155 FAX: 886-2-26934440 TRCSince1985 ® Test Instruments Configuration of Power Spectral Density Test Configuration of Power Spectral Density P.S.: Notebook computer to control the EUT at maximal power output and channel number and set antenna kit EUT Spectrum Analyzer (RBW:3kHz; VBW: 10kHz)
