MU4RP1103AM/FM WEATHER TV BAND RADIO

OWNER'S MANUAL AM / FM / TV Bands Instant Weather Portable Radio with LCD Clock RP1103 Visit our web site at www.emersonradio.com RP1103_010505.p655/1/2005, 13:5116 1 TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. I MPORTANT SAFETY INSTRUCTIONS 1.)Read these instructions. 2.)Keep these instructions. 3.)Heed all warnings. 4.)Follow all instructions. 5.)Do not use this apparatus near water. 6.)Clean only with dry cloth. 7.)Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8.)Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9.)Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10.)Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11.)Only use attachments / accessories specified by the manufacturer. 12.)Unplug this apparatus during lightning storms or when unused for long periods of time. 13.)Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 14.)This appliance shall not be exposed to dripping or splashing water and no object filled with liquids such as vases shall be placed on the apparatus. 15.)Do not overload wall outlet. Use only power source as indicated. 16.)Use replacement parts as specified by the manufacturer. 17.)The product may be mounted to a wall only if recommended by the manufacturer. 18.)Upon completion of any service or repairs to this product, ask the service technician to perform safety checks. ! CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrow- head symbol, within an equi- lateral triangle is intended to alert the user to the presence of uninsulated ‘dangerous voltage’ within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is in- tended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompany- ing the appliance. WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK), NO USER SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. CAUTION The Caution Marking was located at the bottom enclosure of the apparatus. RP1103_010505.p655/1/2005, 11:491 2 Before We Begin Thank you for purchasing this Emerson audio product. The Emerson brand is your assurance of quality, performance and value. Our engineers have included many useful and convenient features in this product. Please be sure to read this Owner’s Manual completely to make sure you are getting the maximum benefit from each feature. This product was manufactured using the highest quality components and standards of workmanship. It was tested by Emerson inspectors and found to be in perfect working order before it left our factory. However, there is always the chance that some problem may occur because of rough handling during shipment to the retail store or to the final consumer. If, after reading this Manual, you experience any problems with the operation of this product, please refer to the instructions for obtaining service at the end of this Manual. Emerson and Emerson retailers are committed to your satisfaction. Once again, thanks for purchasing this Emerson audio product. For future reference, record the serial number in the space provided. Model No: RP1103 Serial No: RP1103_010505.p655/1/2005, 11:492 3 • Avoid installing this unit in places exposed to direct sunlight or close to heat radiating appliances such as electric heaters, on top of other stereo equipment that radiates too much heat, places lacking ventilation or dusty areas, places subject to constant vibration and/or humid or moist areas. FCC Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operati…

Text truncated - open the document above for the full version.

F F C C C C - - T T E E S S T T R R E E P P O O R R T T REPORT NO.: 40844/4/200F FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 2 of 23 FCC listed testlab acc. to Section 2.948 of the FCC - Rules in compliance with the requirements of ANSI C63.4 - 2001 Product : AM/FM/Weather/TV Band Radio Product Class : Communication Receiver (Super Hetrodyne) Brand Name : Emerson Model : RP1103 Importer : LASCO INDUSTRIES LIMITED FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 3 of 23 TABLE OF CONTENTS 1. Cover sheet 2. Introduction 3. Table of Contents 4. Laboratory Report 5. Summary of Testresults 6. Test Equipment List 7. Radiated Emission Testprocedure (> 30MHz) 8. Radiated Emission Testprocedure (9kHz – 30MHz) 9-18. Interference Radiation (Datasheet) 19. Notes for Radiation Measurement (acc. to ANSI C63.4 - 2001) 20-22. Interference Voltage (Datasheet) 23. Notes for Voltage Measurement (acc. to ANSI C63.4 - 2001) FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 4 of 23 LABORATORY - REPORT APPLICANT: ADDRESS: LASCO INDUSTRIES LIMITED Unit 2 & 4, 9/F, Century Centre 44-46 Hung To Road, Kwun Tong, Kowloon, HONG KONG DATE OF SAMPLE RECEIVED: 2004-12-22 DATE OF TESTING: 2005-01-11 to 2005-01-12 DESCRIPTION OF SAMPLE: Product: AM/FM/Weather/TV Band Radio Product class: Communication Receiver (Super Hetrodyne) Brand name: Emerson Model number: RP1103 Rating: AC 120V 60Hz or DC 6V ('AA' Size Battery x 4) INVESTIGATIONS REQUESTED: Measurements to the relevant clauses of F.C.C. Rules and Regulations Part 15 Subpart B – ‘Unintentional Radiators’ RESULTS: See the attached test sheets CONCLUSIONS From the measurement data obtained, the tested sample was considered to have COMPLIED with the requirements for the relevant clauses of Federal Communications Commission Rules as specified above. _____________________________ Authorized Signature Remark: 1. Purpose of those tests in this report is to provide the applicant with the necessary test data of their device for the submission to FCC with application for Equipment Authorization under the FCC Equipment Authorization Program. The tests themselves are not Approval Tests. 2. The conducted emissions test (if applicable) has considered the limits in Sections 15.107 and 15.207 adopted under FCC 02-157 (ETDocket 98-80). The product may be marketed after July 11, 2005, and is not affected by the 15.37(j) transition provisions. FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 5 of 23 Summary of Test Results Interference Radiation: Test result: O.K. Test data: See attached data sheet Interference Voltage: Test result: O.K. Test data: See attached data sheet PHOTOGRAPH OF THE SAMPLE FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 6 of 23 TEST EQUIPMENT LIST Equipment Manufacturer Model Serial No. Remark Test Receiver Rohde & Schwarz ESH 3 863497/015 150KHz – 30MHz Test Receiver Rohde & Schwarz ESH 3 892580/006 9KHz – 30MHz Test Receiver Rohde & Schwarz ESVP 860688/022 25MHz – 1,000 MHz Test Receiver Rohde & Schwarz ESVP 863512/012 25MHz – 1,000 MHz Test Receiver Rohde & Schwarz ESHS30 839667/002 9KHz – 30MHz Test Receiver Rohde & Schwarz ESVS30 828525/006 25MHz – 1000MHz Spectrum Analyzer with Q. Peak Advantest R3132 140101852 9KHz – 3GHz Spectrum Analyzer with Q. Peak Tektronix 2712 B023006 0.15MHz – 1000MHz Interface for Spectrum 2712 Tektronix TD3F14A -- -- Impulse Limiter Rohde & Schwarz ESH-3-Z2 -- -- Artificial Mains Network (LISN) Schwarzbeck NSLK 8127 8127312 2 x 10A, 50Ω, 50μH 9KHz-30MHz Artificial Mains Network (LISN) Schwarzbeck NSLK 8127 8127309 2 x 10A, 50Ω, 50μH 9KHz-30MHz Antenna System Schwarzbeck BBA 9106 / UHALP 9107 -- 30MHz – 1000MHz Antenna Mast System Schwarzbeck AM9104 -- Max. 4 meters height Loop Antenna Rohde & Schwarz HFH2-Z2 871336/48 9KHz-30MHz Turntable with Controller Drehtisch DT312 -- φ120 cm FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 7 of 23 Radiated Emission Testprocedure (> 30MHz) Equipment under test (on turntable) Test receiver ESVP R & S Required test distance: 3m Antenna system Schwarzbeck BBA 9106/ UHALP 9107 FCC – Test Report No. 40844/4/200F Date: 2005-01-21 Page 8 of 23 Radiated Emission Test Procedure ( 9kHz – 30MHz) Test distance : 3 m Loop antenna HFH2-Z2 Rohde & Schwarz Equipment under test (on turntable) Test Receiver ESH3 Rohde & Schwarz 141U1 Interference Radiation 30MHz to 1000MHzDate : 2005-01-21 According:FCC Part 15 Subpart B (15.109)Page 9 of 23 IECC Ref:40844/4/200F Model:RP1103Test Equipment Applicant:LASCO INDUSTRIES LIMITEDReceiver: ESVP Rohde & Schwarz Antenna: Schwarzbeck BBA 9106 Ser.Nr.:1 and UHALP 9107 Oper. Mode:FM Mode InterFreq:10.7MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction - factor (dB) Testresult dBμV/m Limit dB(μV/m) 89.8100.5123H10.433.443.5 201.0220H16.536.543.5 301.5318H16.334.346.0 402.04<16H18.3<34.346.0 502.55<16H19.7<35.746.0 603.06<16H20.9<36.946.0 703.57<16H22.4<38.446.0 804.08<16H23.8<39.846.0 904.59<16H25.1<41.146.0 98.3109.0122H11.733.743.5 218.0220H17.037.046.0 327.0318H16.834.846.0 436.04<16H18.8<34.846.0 545.05<16H20.2<36.246.0 654.06<16H21.7<37.746.0 763.07<16H23.2<39.246.0 872.08<16H24.7<40.746.0 981.09<16H26.2<42.254.0 108.0118.7121H12.733.743.5 237.4220H17.437.446.0 356.1318H17.535.546.0 474.84<16H19.4<35.446.0 593.55<16H20.8<36.846.0 712.26<16H22.6<38.646.0 830.97<16H24.1<40.146.0 949.68<16H25.8<41.846.0 The measurements indicate that the test unit meets the FCC requirements. 141U1 Interference Radiation 30MHz to 1000MHzDate : 2005-01-21 According:FCC Part 15 Subpart B (15.109)Page 10 of 23 IECC Ref:40844/4/200F Model:RP1103Test Equipment Applicant:LASCO INDUSTRIES LIMITEDReceiver: ESVP Rohde & Schwarz Antenna: Schwarzbeck BBA 9106 Ser.Nr.:1 and UHALP 9107 Oper. Mode:FM Mode InterFreq:10.7MHz Receiving - frequency (MHz) Oscillator- frequency (MHz) Har- monics Reading dBμV Polari- zation Correction - factor (dB) Testresult dBμV/m Limit dB(μV/m) 89.8100.5121V10…

Text truncated - open the document above for the full version.
