MVAHP3190A-001TFM CORDLESS HEADPHONES

ENGLISH ESPAÑOL FRANÇAIS FM CORDLESS HEADPHONES CASQUE FM SANS FIL AURICULARES INALÁMBRICOS FM HA-W600RF-J/C INSTRUCTIONS MANUEL D’INSTRUCTIONS MANUAL DE INSTRUCCIONES For customer Use: Enter below the Model No. and Serial No. which are located on the top or bottom of the cabinet. Retain this information for future reference. Model No. Serial No. LNT0066-001A HAW600RF_J.indb 3HAW600RF_J.indb 306.6.16 11:11:29 AM06.6.16 11:11:29 AM Warnings, cautions and others Mises en garde, precautions et indications diverses Avisos, precauciones y otras notas FCC INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not approved by JVC could void user’s authority to operate the equipment. Contact Address: JVC AMERICAS CORP. JVC COMPANY OF AMERICA 1700 Valley Road, Wayne, N.J. 07470 Telephone: 1 (800) 252-5722 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/ TV technician for help. G-1 HAW600RF_J.indb 2HAW600RF_J.indb 206.6.16 11:11:30 AM06.6.16 11:11:30 AM IC INFORMATION This device complies with RSS-210 of the IC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation of the device. CAUTION: Changes or modifications not approved by JVC could void user’s authority to operate the equipment. Contact Address: JVC CANADA INC. 21 Finchdene Square, Toronto, ON M1X 1A7 Telephone: (416) 293-1311 e-mail: [email protected] Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Industry Canada’s RSS-210. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Remarque: L’appareil a été testé et jugé conforme aux limites des appareils numériques de classe B, aux termes de la réglementation RSS-210 de l’industrie du Canada. Ces limites ont pour but d’assurer une protection raisonnable contre les interférences parasites lorsque l’appareil est utilisé dans une installation résidentielle. Cet appareil engendre, utilise et peut émettre une énergie radioélectrique et, s’il n’est pas installé et utilisé en stricte conformité avec ces instructions, il peut provoquer des interférences parasites dans les liaisons radiophoniques. Ceci ne garantit pas pour autant qu’une installation particulière n’émettra aucune interférence. Si l’appareil engendre des interférences parasites avec la réception radio ou télévision, ce qui pourra être déterminé en éteignant puis en rallumant l’appareil, il est conseillé à l’utilisateur d’essayer de corriger les interférences en prenant l’une des mesures ci-dessous: • Modifier l’orientation ou changer l’emplacement de l’antenne de réception. • Eloigner davantage l’appareil du récepteur. • Brancher l’appareil dans une prise d’un circuit différent de celui auquel le récepteur est raccordé. • Demander l’aide de son agent ou d’un technicien radio/télévision qualifié. INFORMATION SUR IC Cet appareil est conforme à la RSS-210 du réglement de la IC. Le fonctionnement est sujet aux deux conditions suivantes: (1) Cet appareil ne peut causer d’interférences nuisi-bles (2) Cet appareil reçoit toute interférence même les interférences qui peuvent occasioner un mauvais fonctionnement. ATTENTION: Les changements ou les modifications non approuvés par JVC risquent de retirer à l’utilisateur le droit d’utiliser l’appareil. Contact Adresse: JVC CANADA INC. 21 Finchdene Square, Toronto, ON M1X 1A7 Téléphone: (416) 293-1311 e-mail: [email protected] G-2 HAW600RF_J.indb 3HAW600RF_J.indb 306.6.16 11:11:32 AM06.6.16 11:11:32 AM G-3 ENGLISH This product’s performance would be degraded under a strong electro-static environment. And the function would be self-recoverable after the above case. This product’s performance would be degraded since the disturbance from the mains cord. And the funct…

Text truncated - open the document above for the full version.

Uni-Art Precise Products Ltd. Confidentiality Letter Date: _2013.02.26_ Subject: Confidentiality Request for FCC ID: MVAHP3190A-001T , MVAHP3190-001R and IC ID: 2597A-HP3190A Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC/IC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term User’s Manual Uni-Art Precise Products Ltd . has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of ___120 ___ days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify TUV Rheinland in the event information regarding the product or the product is made available to the public. TUV Rheinland will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04- 1705. Sincerely, By:_________________________ _Simon Chan_(Sales Manager_)_______ (Signature/Title) (Print name)

Page 1 of 3 Type Designation: HP3190A HA-W600RF No. J22320-001 External Photos Report Number: 17030908 001 Page 2 of 3 Type Designation: HP3190A HA-W600RF No. J22320-001 External Photos Report Number: 17030908 001 Page 3 of 3 Type Designation: HP3190A HA-W600RF No. J22320-001 External Photos Report Number: 17030908 001

98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 49(W) X 34(H)mm For Transmitter 98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 26.5(W) X32(H)mm For Receiver HP3190A-0M9-1 98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 49.5(W) X12(H)mm 98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 49.5(W) X12(H)mm 8 CAN RSS-Gen/CNR-Gen MVAHP3190A-001T 2579A-HP3190A ARKON HP3190A ARKON HP3190A MODEL HP3190A ARKON HP3190A FM CORDLESS HEADHPONES

98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 49(W) X 34(H)mm For Transmitter 98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 26.5(W) X32(H)mm For Receiver HP3190A-0M9-1 (HA-W600RF) 98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 49.5(W) X12(H)mm 98-14-HP3190A Background: BLACK Text: WHITE Coating: P.P. Size : 49.5(W) X12(H)mm 8 CAN RSS-Gen/CNR-Gen MVAHP3190A-001T 2579A-HP3190A FM CORDLESS HEADHPONES JVC KENWOOD Corporation HA-W600RF JVC KENWOOD Corporation HA-W600RF JVC KENWOOD Corporation HA-W600RF

L R TRANSMITTER BASE HEADPHONE 8 JVC KENWOOD Corporation V W OD o p ra n H 0 J C KEN O C r o tio A-W60 RF CAN RSS -Gen /CNR -Gen J KE NW D Co or t A- 0R VC OO rp a ion H W6 0 F

Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 37 von 40 Page 37 of 40 6. Safety Human exposure 6.1 Radio Frequency Exposure Compliance 6.1.1 Electromagnetic Fields RESULT: Pass Test standard : RSS-102 Issue 4 FCC KDB Publication 447498 v05 The maximum peak output power of the transmitter is 0.12mW (-9.23dBm) only, which less than 20mW. Hence the EUT is exempted from routine evaluation limits (SAR Evaluation) according to clause 2.5.1 of RSS-102 Issue 4. The maximum peak output power of the tranmister is 0.12 mW, which far below than the SAR exclusion threshold level (Appendix B, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and >50 mm): MHz 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 mm 900 158 218 278 338 398 458 518 578 638 698 758 818 878 938 998 mW Therefore the transmistter is deemed comply with the requirement without SAR testing.

Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 2 von 40 Page 2 of 40 TEST SUMMARY 5.1.1 20DB BANDWIDTH AND 99% BANDWIDTH RESULT: Pass 5.1.2 FUNDAMENTAL & HARMONICS RADIATED EMISSION RESULT: Pass 5.1.3 RADIATED EMISSIONS RESULT: Pass 5.1.4 CONDUCTED EMISSION RESULT: Pass 6.1.1 ELECTROMAGNETIC FIELDS RESULT: Pass Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 3 von 40 Page 3 of 40 Contents 1. GENERAL REMARKS ......................................................................................................... 4 1.1 COMPLEMENTARY MATERIALS .......................................................................................... 4 2. TEST SITES ...................................................................................................................... 4 2.1 TEST FACILITIES ............................................................................................................... 4 2.2 LIST OF TEST AND MEASUREMENT INSTRUMENTS ............................................................... 5 2.3 TRACEABILITY .................................................................................................................. 6 2.4 CALIBRATION ................................................................................................................... 6 2.5 MEASUREMENT UNCERTAINTY........................................................................................... 6 2.6 LOCATION OF ORIGINAL DATA ........................................................................................... 6 2.7 STATUS OF FACILITY USED FOR TESTING ........................................................................... 6 3. GENERAL PRODUCT INFORMATION .................................................................................... 7 3.1 PRODUCT FUNCTION AND INTENDED USE ........................................................................... 7 3.2 RATINGS AND SYSTEM DETAILS ........................................................................................ 7 3.3 INDEPENDENT OPERATION MODES .................................................................................... 7 3.4 NOISE GENERATING AND NOISE SUPPRESSING PARTS ....................................................... 7 3.5 SUBMITTED DOCUMENTS................................................................................................... 8 4. TEST SET-UP AND OPERATION MODES .............................................................................. 9 4.1 PRINCIPLE OF CONFIGURATION SELECTION ........................................................................ 9 4.2 TEST OPERATION AND TEST SOFTWARE ............................................................................ 9 4.3 SPECIAL ACCESSORIES AND AUXILIARY EQUIPMENT .......................................................... 9 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE ......................................................... 9 4.5 TEST SETUP DIAGRAM .................................................................................................... 10 5. TEST RESULTS ............................................................................................................... 12 5.1 TRANSMITTER REQUIREMENT & TEST SUITES .................................................................. 12 5.1.1 20dB Bandwidth and 99% Bandwidth .................................................................................... 12 5.1.2 Fundamental & Harmonics Radiated Emission ...................................................................... 16 5.1.3 Radiated emissions ............................................................................................................... 29 5.1.4 Conducted emission .............................................................................................................. 30 6. SAFETY HUMAN EXPOSURE ............................................................................................. 37 6.1 RADIO FREQUENCY EXPOSURE COMPLIANCE ................................................................... 37 6.1.1 Electromagnetic Fields .......................................................................................................... 37 7. PHOTOGRAPHS OF THE TEST SET-UP .............................................................................. 38 8. LIST OF TABLES ............................................................................................................. 40 9. LIST OF PHOTOGRAPHS .................................................................................................. 40 Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 4 von 40 Page 4 of 40 1. General Remarks 1.1 Complementary Materials None. 2. Test Sites 2.1 Test Facilities Accurate Technology Co., Ltd. (FCC Registration No.: 752051) (Test site Industry Canada No.: 5077A-2) F1, Bldg. A, Changyuan New Material Port Keyuan Rd., Science & Industry Park, Nanshan Shenzhen, P.R. China The tests at the test site have been conducted under the supervision of a TÜV engineer. Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 5 von 40 Page 5 of 40 2.2 List of Test and Measurement Instruments Table 1: List of Test and Measurement Equipment Kind of Equipment Manufacturer Type S/N Calibrated until Transmitter spurious emissions & Receiver spurious emissions Spectrum Analyzer Agilent E7405A MY45115511 2014-01-07 Test Receiver Rohde & Schwarz ESCS30 100307 2014-01-07 Bilog Antenna Schwarzbeck VULB9163 9163-323 2014-01-07 Loop Antenna Schwarzbeck FMZB1516 1516131 2014-01-07 Horn Antenna Schwarzbeck BBHA9120D 9120D-655 2014-01-07 Horn Antenna Schwarzbeck BBHA9170 9170-359 2014-01-07 50 Coaxial Switch Anritsu Corp MP59B 6200506474 2014-01-07 RF Coaxial Cable SUHNER N-3m No.8 2014-01-07 RF Coaxial Cable RESENBERGER N-3.5m No.9 2014-01-07 RF Coaxial Cable SUHNER N-6m No.10 2014-01-07 RF Coaxial Cable RESENBERGER N-12m No.11 2014-01-07 RF Coaxial Cable RESENB…

Text truncated - open the document above for the full version.

Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 38 von 40 Page 38 of 40 7. Photographs of the Test Set-Up Photograph 1: Setup for Conducted Emission Photograph 2: Setup for Radiated Emissions below 1GHz Produkte Products Prüfbericht - Nr.: Test Report No. 17030908 001 Seite 39 von 40 Page 39 of 40 Photograph 3: Setup for Radiated Emissions above 1GHz
