MVAHP4090-001TWireless Audio Transmitter

HP4090 User Manual (Preliminary) green ~ END ~ This device complies with Part 15 of the FCC Rules. Operation of this device is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WARNING: Modification of this device to receive cellular radio-telephone service signals is prohibited under FCC rules and Federal Law. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment

Produkte Products Prüfbericht - Nr.: Test Report No.: 16009858 001 Seite 2 von 17 Page 2 of 17 TEST SUMMARY 5.1 CONDUCTED EMISSION FOR FCC PART 15 PER SECTION 15.207(A) RESULT: Pass 5.2 RADIATED EMISSION FOR FCC PART 15 PER SECTION 15.209(A) RESULT: Pass 5.3 FUNDAMENTAL AND HARMONICS RADIATED EMISSION FOR FCC PART 15 PER SECTION 15.249(A) RESULT: Pass Produkte Products Prüfbericht - Nr.: Test Report No.: 16009858 001 Seite 3 von 17 Page 3 of 17 Contents 1 GENERAL REMARKS........................................................................................................... 4 1.1 C OMPLEMENTARY MATERIALS......................................................................................... 4 2 TEST SITES.......................................................................................................................... 4 2.1 T EST FACILITIES................................................................................................................ 4 2.2 L IST OF TEST AND MEASUREMENT INSTRUMENTS........................................................... 5 2.3 TRACE ABILITY................................................................................................................... 5 2.4 CALIBRATION..................................................................................................................... 5 2.5 M EASUREMENT UNCERTAINTY.......................................................................................... 6 2.6 L OCATION OF ORIGINAL DATA........................................................................................... 6 2.7 STATUS OF FACILITY USED FOR TESTING........................................................................... 6 3 G ENERAL PRODUCT INFORMATION................................................................................... 6 3.1 PRODUCT FUNCTION AND INTENDED USE......................................................................... 7 3.2 RATINGS AND SYSTEM DETAILS........................................................................................ 7 3.3 I NDEPENDENT OPERATION MODES................................................................................... 7 3.4 SUBMITTED DOCUMENTS................................................................................................... 8 4 T EST SET-UP AND OPERATION MODE............................................................................... 8 4.1 P RINCIPLE OF CONFIGURATION SELECTION..................................................................... 8 4.2 T EST OPERATION AND TEST SOFTWARE........................................................................... 8 4.3 S PECIAL ACCESSORIES AND AUXILIARY EQUIPMENT....................................................... 8 4.4 COUNTERMEASURES TO ACHIEVE EMC COMPLIANCE.................................................... 8 4.5 TEST SET-UP........................................................................................................................ 9 5 T EST RESULTS E M I S S I O N ..................................................................................... 11 5.1 CONDUCTED EMISSION FOR FCC PART 15 PER SECTION 15.207(A) ............................. 11 5.2 RADIATED EMISSION FOR FCC PART 15 PER SECTION 15.209(A) ................................. 12 5.3 FUNDAMENTAL AND HARMONICS RADIATED EMISSION FOR FCC PART 15 PER SECTION 15.249(A)....................................................................................................................................... 13 6 PHOTOGRAPHS OF THE TEST SET-UP.............................................................................. 13 7 LIST OF TABLES................................................................................................................ 13 8 L IST OF PHOTOGRAPHS.................................................................................................... 13 Produkte Products Prüfbericht - Nr.: Test Report No.: 16009858 001 Seite 4 von 17 Page 4 of 17 1 General Remarks 1.1 Complementary Materials All attachments are integral parts of this test report. This applies especially to the following appendix: Appendix 1: Test result 2 Test Sites 2.1 Test Facilities Shenzhen SMQ Shenzhen Bureau of Quality Technical Supervision Shenzhen Academy of Metrology and Quality Inspection Bldg, of Shenzhen Academy of Metrology and Quality Inspection Longzhu Road, Nanshan, Shenzhen, P.R. China Produkte Products Prüfbericht - Nr.: Test Report No.: 16009858 001 Seite 5 von 17 Page 5 of 17 2.2 List of Test and Measurement Instruments Table 1: List of Test and Measurement Equipment Kind of Equipment Manufacturer Type S/N Calibrated until Antenna Chase CBL6112B 2591 29.01.2008 Horn Antenna Rohde & Schwarz HF906 100014 29.01.2008 3m Semi-anechoic chamber Albatross Projects 9X6X6 ---- 29.01.2008 EMI Test Receiver Rohde & Schwarz ESI26 838786/013 29.01.2008 Communications Test Set Rohde & Schwarz CMU200 1100.0008.02 29.01.2008 Communications Test Set HP HP8920A 3438A05187 29.01.2008 EMI Test Receiver Rohde & Schwarz ESCS30 100003 29.01.2008 AMN Rohde & Schwarz ESH3-Z5 100002 29.01.2008 2.3 Trace ability All measurement equipment calibrations are traceable to NIST or where calibration is performed outside the United States, to equivalent nationally recognized standards organizations 2.4 Calibration Equipment requiring calibration is calibrated periodically by the manufacturer or according to manufacturer’s specifications. Additionally all equipment is verified for proper performance on a regular basis using in house standards or comparisons. Produkte Products Prüfbericht - Nr.: Test Report No.: 16009858 001 Seite 6 von 17 Page 6 of 17 2.5 Measurement Uncertainty Uncertainty for conducted emissions measurements is ± 3.5dB. Uncertainty for radiated emissions measurements is ± 4.5dB (30MHz-1GHz), ± 4.6dB (>1GHz). The reported expanded uncertainty is based on a standard uncertainty multiply by a coverage factor k=2, providing a level of confidenc…
