MVAHP4191A-001T900MHz Wireless Headphone

900MHz Wireless Headphone HP4190A User's Manual 1 INTRODUCTION This 900MHz compact stereo headphones takes advantage of the very latest advances in wireless transmission technology so that you can listen to music or the sound from your TV set both in the house and outdoors. All you have to do is connect the transmitter to any audio source: DVD player, CD player, TV set, VCR, Hi-Fi system or radio (range 50 meters). FEATURES 1. Auto Scanning system on headphone 2. Phase Lock Loop (PLL) transmission system on transmitter 3. Automatic battery recharging (batteries supplied). 4. 900MHz RF technology. 5. RF technology leaves you completely free to move around. 6. Transmission is not restricted solely to line of sight. 7. Rechargeable receiver headphones. 8. Charger built into the transmitter. 9. High quality stereo sound that is virtually interference-free. 10. Automatic Level Control (ALC) and Auto On/Off function. 2 COMPONENT IDENTIFICATION 3 COMPONENT IDENTIFICATION 1 RF transmitter 2 RF receiver headphones 3 Power On/Off switch 4 Power On indicator light 5 Charge contacts 6 12 V 200 mA mains adapter 7 Jack plug adapter (3.5 mm/6.3 mm diameter) 8 RCA socket audio adapter 9 Charge indicator light 10 Operating indicator light 11 Audio connection cable with 3.5 mm jack plug 12 Volume control knob (VOL) 13 AUTO SCAN indicator 14 AUTO SCAN button 15 Channel selector (CHANNEL 3 2 1) 16 DC IN connector 17 Audio input cable 18 AAA rechargeable batteries x 2 pcs. INSTALLATION TRANSMITTER 1. Connect the mains adapter provided to an electri cal outlet. 2. Connect the mains adapter cable to the DC IN inp ut connector located on the transmitter rear panel. 3. A cable is provided from the transmitter rear pa nel that can be 4 connected to the audio outputs (Left and Right) pre sent on a TV set, Hi-Fi system, VCR or radio-cassette player, or to a headphones/earphones output using the connector sup plied. The red Auto On indicator light will light up as so on as you have connected the power adapter to the mains outlet and the audio cable to a signal source. If the Auto On indicator light remains off, switch on the audio source and increase its output level until the red indicator l ight comes on. RECEIVER HEADPHONES 1. Remove the ear cushion holder on the receiver he adphones. You will find a battery compartment right there under the ho lder. 2. Insert a rechargeable HR03/AAA size batteries at both right / left earphone, taking care to ensure correct polarity. 3. Close the battery compartment cover and also put back the ear cushion holder. OPERATION 1. Switch on the sound source (TV set or audio comp onent) that the transmitter is connected to. 2. Place the headphones On/Off switch in the On pos ition. 3. Place the headphones on your head and adjust the volume to obtain the desired sound level. 4. If you cannot find the best reception frequency, press the "Auto Scan" button on the headphones. The corresponding indicat or light will come on. 5 NOTE: You should then be able to move around freely from one room to another without any interference. If interference does occu r (interruptions in the signal), press the "Auto Scan" button once to find a better reception channel. A For better stereo reception, stay approximately sev en meters away from the transmitter when you press the "Auto Scan" button. B If it is impossible to find a satisfactory frequenc y, change the setting on your transmitter, then press the "Auto Scan" button on the headphones to find the corresponding channel. To both protect the transmitter and save power, the transmitter automatically switches off after approximately four minutes if th e signal that it receives from the audio source is too weak for proper recept ion. If however the signal returns to an acceptable level, then the transmitte r automatically switches back on. CHARGING THE BATTERIES 1. Place the On/Off switch on the receiver headphon es in the Off position. 2. To recharge the headphone batteries, place the h eadphones on the transmitter, taking care to ensure that the charge contacts touch the transmitter's charge prongs. 3. The charge process starts automatically and the green indicator light comes on. Be sure to charge new batteries for 24 ho urs before using them for the first time in the headphones. 6 WARNING: Never attempt to recharge conventional dry cells. Never use another type of battery or non-rechargeab le batteries to replace the rechargeable (HR03/AAA) batteries supplied. Whe n the headphones are not in use, move the switch to the OFF position to avoid damaging the batteries. The batteries must always be fully charged before u se. An initial 24 hour charge is required to guarantee an acceptable servi ce life for the rechargeable batteries. Always ensure that the head phones are switched to the Off position while the batteries are charging. IMPORTANT: This unit should be operated with rechargeable batt eries only. When replacing the batteries or when disposing of the un it, always comply with applicable laws relating to the disposal of batteri es. Please place them in a proper disposal container to ensure that they are e liminated safely and in an environmentally-friendly way. Thank you. 7 REPLACING BATTERIES Rechargeable batteries have a long service life. If it is however necessary to replace them, proceed as described below: Only use rechargeable batteries of the type specifi ed under the “Technical specifications” heading. The rechargeable batteries supplied with the headph ones must absolutely not be taken apart, disposed of in an open fire or short circuited. 1. Carefully remove the cushion holder on the headp hone. 2. You will find a battery compartment at both left / right headphone. 3. Install the AAA side-charged rechargeable batter ies as provided. 4. Make sure to place with correct right + / - pola rity. 5. Put the cushion holder back onto the headphone. 8 TECHNICAL SPECIFICATIONS Transmission mode : UHF stereo Carrier frequency : 900MHz Operating vo…

Text truncated - open the document above for the full version.

HP4191A BLOCK DIAGRAM HP4191A-BLOCK-V0 MODEL NO: HP4191A BLOCK DIAGRAM FOR HP4191A DWG NO: SA4E3646 环雅精工制品有限公司 UNI-ART PRECISE PRODUCTS LTD. 环雅精工制品电子（深圳）有阴公司 UNI-ART PRECISE ELECTRONICS(SHENZHEN) LTD. TITLE: SHEET: 1 OF 1 PART NO: REV:0 LAYER: FILE NAME: APPROVED BY: CHECKED BY: DRAWN BY: THICKNESS: MATERIAL: 02D/E PART NO. REVISION RECORD CHG BYDATEDESCRIPTONREVISI0NECN NO. DATED: DATED: DATED: AUDIO IN JX2 ALC AMP IC2 LS22241 STEREO MODULATOR MCU IC1 JX903D UHF MODULE CRYSTAL 4.0 MHz ANT 912MHz AUTO POWER Q3,Q4,Q5 DC JACK 8V 200MA JX1 POWER FILTER L1,L2 CHARGE Q6,Q7,F4 UHF POWER SWITCH Q1,Q2 POWER FILTER L2,C7,C8 CH+ CH- CRYSTAL X1 7.6 MHz

Uni-Art Precise Products Ltd 1 1-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong FCC Confidentiality Request Number: CF303 Version: V01 Date: 01-02-2010 To the FCC and FCC TCB handling this application for certification Pursuant to 47 CFR Section 0.459(a) & (b), we, (the applicant / grantee) Company name Uni-Art Precise Products Ltd Addresss 11-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong City Hongkong Country request non-disclosure and confidential treatment for our certification under: Grantee Code Product Number FCC ID: MVA HP4191A-001T of the following materials submitted within this certification application: (please cross what is applicable, or add other documents) Operational Description Block Diagrams Schematics Diagrams Part list Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. We understand that pursuant to 47 CFR section 0.457(d)(1)(ii) disclosure of the applicant and all accompanying documentation will not be made before the date of the grant. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Hongkong April 29th.2012 Simon Chan Sales Manager

Uni-Art Precise Products Ltd 11-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong FCC Authorization Letter Number: CF304 Version: V01 Date: 01-02-2010 We, (the approval holder) Company name Uni-Art Precise Products Ltd Address 11-12/F,Yue Xiu Industrial Building,87 Hung To Road,Kowloon,Hong Kong City Hongkong Country declare that the following representative (agent): Name (person) Ruby zhang Function Supervisor Company name Compliance Certification Services (Shenzhen) Inc. Addresss No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China City Shenzhen Country China is hereby authorized to apply the following equipment for certification on our behalf: Product Description 900MHZ Wireless Headphone Type or Model(s) HP4190A Tradename or Brand(s) Arkon We also authorize Teleconformity, Mr. M. Koop, (address: Rietven 31, 7534NH Enschede, Netherlands) to process this application. Attestation: City and Country: Date: Name: (this must be a person) Function: Signature: (or official company stamp) Hongkong April 29th,2013 Simon Chan Sales Manager

Report No.: C130409Z05-RP1 Page 1/3 Report No.: C130409Z05-RP1 Page 2/ 5 . Report No.: C130409Z05-RP1 Page 3/ 5 . Report No.: C130409Z05-RP1 Page 4/ 5 . Report No.: C130409Z05-RP1 Page 5/ 5 .

Label sample and Location

Report No.: C130409Z05-RP1 Page 1/5 Report No.: C130409Z05-RP1 Page 2/5 . Report No.: C130409Z05-RP1 Page 3/5 . Report No.: C130409Z05-RP1 Page 4/5 . Report No.: C130409Z05-RP1 Page 5/5 .

900MHZ Wireless Headphone Introductions The device works on 900MHz band, Operating frequency is 912 MHz、913 MHz, use FM modulation. This 900MHz compact stereo headphones takes advantage of the very latest advances in wireless transmission technology so that you can listen to music or the sound from your TV set both in the house and outdoors. All you have to do is connect the transmitter to any audio source: DVD player, CD player, TV set, VCR, Hi-Fi system or radio (range 50 meters). TRANSMITTER 1. Connect the mains adapter provided to an electrical outlet. 2. Connect the mains adapter cable to the DC IN input connector located on the transmitter rear panel. 3. A cable is provided from the transmitter rear panel that can be connected to the audio outputs (Left and Right) present on a TV set, Hi-Fi system, VCR or radio-cassette player, or to a headphones/earphones output using the connector supplied. The red Auto On indicator light will light up as soon as you have connected the power adapter to the mains outlet and the audio cable to a signal source. If the Auto On indicator light remains off, switch on the audio source and increase its output level until the red indicator light comes on.

HP4191AP-008-0ITEM: DRWG:: BOM QUERY [PRODUCTION] 2013/4/15 REV: PLANER:PLR DESCRIPTION:900MHZ TX RECHARGEABLE,BLK/SIL UM:PC PLAN POLICE:N TOTAL WEIGHT:0.17365192 DATE: Page 1 Of 4 11:07TIME: *251SFG038-06-E10614-51C25N(&$38)9;00"1PCIBEPAS101022 / EPAS110039 0.000400 *241SFG038-06-E1056-51C46N(&$38)9;00"3(71PCIBEPAS101037 / EPAS110052 0.000200 *231SFG037-02-HP1181-02NLED BOARD 25.6X15X1.6MM 94V01PCIBEPAS0610030.000860SA4M0082 *221SFG037-01-HP4191A-01NMAIN BOARD 112X100X1.6MM 94V0 REV:A1PCIBEPAS00000.000000 *211SFG036-S02-E4148-19D1,D3,D4NHIGH-SPEED SWITCHING DIODES LL4148L3PCIBEPAS1101990.000035 *201SFG036-S01-E4001-29D2NSMD DIODE RECTIFIERS IN4001 M1 1A DO- 214AC 1PCIBEPAS1301000.000080 *191SFG036-03-E4302-27Z1,Z2NZENER DIODE 4.3V 1/4W +/-10% DO-35 BZX55C4V3 2PCIBEPAS1003740.000200 *181SFG035-S02-E8550-34Q1,Q6NSMD TRANS PNP S8550 SOT-232PCIBEPA G201000030.000060 *171SFG035-S01-E8050-24Q7NSMD TRANS NPN SS8050 SOT-23 L1PCIBEPAS0708340.000060 1A35-S01-E3904-24<35-S01-E3904-24>NSMD.TRAN.NPN MMBT3904 SOT-231.00PCIBEPAS1000070.000010 *161SFG99935-S01-E3904-32Q2NSMD.TRAN.NPN MMBT3904 SOT-231PCIBEPAS1000070.000010 *151SFG035-S01-E2412-32Q3,Q4,Q5NSMD.TRAN.NPN 2SC2412K SOT-23-3L3PCIBEPAS1000060.000010 *141SFG033-45-330M-09F2,F3,F4NCHOKE COIL 33UH +/-20% HANGSING3PCIBEPAS0416120.000240 *131SFG033-06-M406CLF1,LF2NMPX COIL M-406C2PCIBEPAS1206800.003880 *121SFG033-05-0103KC-09L1,L2NCHOKE COIL 1000UH +/-10% 8X10MM2PCIBEPA G201001460.002290 *111SFG031-28-E1202W1NLEAD WIRE AWG28 UL1007 120MM RED1PCIBEPAS0814590.000264 *101SFG031-28-E1200W2NLEAD WIRE UL1007 AWG28 120MM BLACK1PCIBEPAS0814600.000274 *91SFG031-18-E0850ANTNSOLID WIRE AWG18 85MM BLACK1PCIBEPAS0914870.001220 *81SFG022-04-E3809JX2N3.5MM STEREO JACK 3PIN EJ-35061PCIBEPAS0908930.000930 *71SFG022-04-E04701-09JX1NDC JACK 5.5/2.1MM1PCIBEPAS1010650.001500 *61SFG015-01-HP1681-1NCONTACT PIN2PCIBEPAS0508070.002000SA4M0475 *51SFG014-97-20050-2NWASHER HEAD SCREW 5 X 2 X 5 -T -N3PCIBEPAS1222710.000150A4M0964 *41SFG014-43-26100-8NSCREW P 4.4 X 2.6 X 10 -T-B4PCIBEPAS1102400.000214A4M0085 *31SFG01-12-HP1681-11NBOTTOM COVER,BLACK1PCIBEPAS0709800.047900SA2M0148 *21SFG01-01-HP1681-127NTOP COVER,GREY,W/PMS877C1PCIBEPAS0706830.085000 *11SFG003-01-HP1181-01NSWITCH COVER,BLACK1PCIBEPAS0617570.000050GA4M0123 SNLEVELPUSEQNPARTNODESIGNATIONCTDESCRIPTIONUSAGEUMQTMBEPAWeightDRWG HP4191AP-008-0ITEM: DRWG:: BOM QUERY [PRODUCTION] 2013/4/15 REV: PLANER:PLR DESCRIPTION:900MHZ TX RECHARGEABLE,BLK/SIL UM:PC PLAN POLICE:N TOTAL WEIGHT:0.17365192 DATE: Page 2 Of 4 11:07TIME: *491SFG039-53-1525R32,R34,R35,R36NCHIP RES. #0603 1.5K OHM 1/16W+/-5%4PCIB0.000000 *481SFG039-53-1055R19,R42NCHIP RES. #0603 1M OHM 1/16W +/-5%2PCIB0.000000 *471SFG039-53-1045R14,R15,R150,R29,R41 ,R45,R51,R53,R61,R79 NCHIP RES. #0603 100K OHM 1/16W+/-5%10PCIB0.000000 *461SFG039-53-1035R57,R58,R60NCHIP RES. #0603 10K OHM 1/16W +/-5%3PCIB0.000000 *451SFG039-53-1025R13,R17,R2,R46,R82NCHIP RES. #0603 1K OHM 1/16W +/-5%5PCIB0.000000 *441SFG039-53-0005L3,R4,R74NCHIP RES. #0603 0 OHM 1/16W +/-5%3PCIB0.000000 *431SFG038-S03-6816D5C39NCHIP CAP. #0603 680PF 50V +/-5% NPO1PCIB0.000004 *421SFG038-S03-5606D5C30,C31NCHIP CAP. #0603 56PF 50V +/-5%2PCIB0.000004 *411SFG038-S03-4726A5C28,C29NCHIP CAP. #0603 0.0047UF 50V +/-10% X7R2PCIB0.000004 *401SFG038-S03-4716A5C36,C37NCHIP CAP. #0603 470PF 50V +/-10%2PCIB0.000004 *391SFG038-S03-3336A5C120,C42NCHIP CAP. #0603 0.033UF 50V +/-10%2PCIB0.000004 *381SFG038-S03-3326A5C26,C27NCHIP CAP. #0603 0.0033UF 50V +/-10%2PCIB0.000004 *371SFG038-S03-2256A5C11,C12,C34,C35,C72NCHIP CAP.#0603 2.2UF 16V +/-10%5PCIBEPAS1000010.000004 *361SFG038-S03-2006D5C56,C57NCHIP CAP. #0603 20PF 50V +/-5%NPO2PCIB0.000004 *351SFG038-S03-10514A5C23NCHIP CAP #0603 1UF 25V+/-10% GRM188R61E105KA12D 1PCIBEPAS0708820.000004 *341SFG038-S03-1046A5C19,C20,C24,C3,C38,C 52,C64,C8 NCHIP CAP. #0603 0.1UF 50V +/-10%8PCIB0.000004 *331SFG038-S03-1036A5C40,C47,C5,C58,C6,C6 2 NCHIP CAP. #0603 0.01UF 50V +/-10% X7R6PCIB0.000004 *321SFG038-S03-1026D5R1NCHIP CAP. #0603 0.001UF 50V +/-5% NPO1PCIB0.000004 *311SFG038-S03-1016D548C1,C118,C13,C14,C15, C16,C21,C22,C4,C41,C 50,C51,C54,C55,C9 NCHIP CAP.#0603 100PF 50V+/-5% NPO15PCIBEPAS0303310.000004 *301SFG038-S03-0056C5C10NCHIP CAP. #0603 0.5PF 50V +/-0.25PF NPO1PCIB0.000004 *291SFG038-06-E47714BC48,C7N(&$38)9;00"3(72PCIBEPAS1104230.001220 *281SFG038-06-E4768-51C103,C44N(&$38)9;00"2PCIBEPAS101033 / EPAS110047/EPAS 110819 0.000400 *271SFG038-06-E10814-51C2N(&$38)9;00" 7587+ 1PCIBEPAS0502040.002300 *261SFG038-06-E10714-51C53N(&$38)9;00"1PCIBEPAS101032 / EPAS110049 0.000600 SNLEVELPUSEQNPARTNODESIGNATIONCTDESCRIPTIONUSAGEUMQTMBEPAWeightDRWG HP4191AP-008-0ITEM: DRWG:: BOM QUERY [PRODUCTION] 2013/4/15 REV: PLANER:PLR DESCRIPTION:900MHZ TX RECHARGEABLE,BLK/SIL UM:PC PLAN POLICE:N TOTAL WEIGHT:0.17365192 DATE: Page 3 Of 4 11:07TIME: *751SFG045-01-E22058-12SW2NSIDE KNOB SIDE SWITCH SK-22H05 L=8MM1PCIBEPA G201100880.001130 *741SFG044-S02-903D6-84IC1NSTEREO ENCODE CL903B SOP181PCIBEPAS1305990.000450 *731SFG044-01-22413-35IC2NI.C. LS22241FALC SOP 161PCIBEPAS0409120.000200 *721SFG042-06-E502-AVR1,VR2NEVND8AA 5K OHM 6MM 3PIN2PCIBEPAS0604920.000370 *711SFG04-02-HP1681NFOOT RUBBER,TRANSLUCENT8.8X3.3X2.62PCIBEPAS0508310.001000 *701SFG04-01-HP1681NFOOT RUBBER,TRANSLUCENT8.8X3.3X2.32PCIBEPAS0508320.001000 *691SFG039-7A-4725R87NCHIP RES. #1206 4.7K OHM 1/8W+/-5%1PCIB0.000009 *681SFG039-7A-1525R50,R54NCHIP RES. #1206 1.5K OHM 1/8W+/-5%2PCIB0.000009 *671SFG039-7A-1215R81,R84NCHIP RES.#1206 120 OHM 1/8W+/-5%2PCIB0.000009 *661SFG039-7A-0005R121,R124,R127,R128, R130,R59,R86,R89,R90 ,R91,R93,R94,R96,R97, R99 NCHIP RES. #1206 0R0 OHM 1/8W +/-5%15PCIB0.000009 *651SFG039-63-0005R80NCHIP RES. #0805 0 OHM 1/8W+/-5%1PCIB0.000005 *641SFG039-53-8225R27,R28NCHIP RES. #0603 8.2K OHM 1/16W+/-5%2PCIB0.000000 *631SFG039-53-6815R30NCHIP RES. #0603 680 OHM 1/16W +/-5%1PCIB0.000000 *621SFG039-53-474…

Text truncated - open the document above for the full version.

Schematic Diagram HP4191A HP4191A-SCH-V0 DWG NO: SA4E MODEL NO: HP4191A SCHEMATIC OF HP4191A Note: All resistance values are indicated in "ohm" All capacitance values are indicated in"pF" NC indicates do not place or no componet 环雅精工制品有限公司UNI-ART PRECISE PRODUCTS LTD. 环雅精工制品电子（深圳）有阴公司 UNI-ART PRECISE ELECTRONICS(SHENZHEN) LTD.TITLE: SHEET: 1 OF 1PART NO:REV:0 LAYER: FILE NAME:APPROVED BY:CHECKED BY:DRAWN BY:THICKNESS: MATERIAL: 02D/E PART NO. REVISION RECORD CHG BY DATE DESCRIPTON REVISI0N ECN NO. DATED:DATED:DATED: DC 8V/200MA 213 JX1 21 D2IN4001 C1 100P + C2 1000UF/25V C3104 C4 100P Q1 S8550 R21K R315K Q2 3904 C5 103 C6 103 L2 1MH + C7 470UF/25V C8104 C9100P 1 24 3 F1 NC ANT GND CLK DATA VCC MIXIN 12 65 3 4 UHF ANT C100.5P LR JX2 C11 225/16V C12 225/16V R5 150K R6150K C13 100P C14 100P 1 24 3 F2 1 24 3 F3 C15100P C16100P R7 47K R8 47K C18 NC R9 2.2K R10 2.2K R112.2KR122.2K 13 NF1 11 IN2 1 OUT1 2 GND 4 ALC 5 VCC 7 OUT2 15 IN1 12 NF2 IC2 LS22241 C41 100P R39 2K C42333 R40220 + C4447UF/16V R41100K R42 1M + C46 1UF/50V C47 103 + C48 470UF/25V R150100K R151 2K + C103 47UF/16V C118 100P R163 220 C120 333 R13 1K R14 100K R15100K Q3C2412 R16 4.7K R171K C19104 R18220 C20 104 Q4C2412 R19 1M C21 100P C22100P C23 105 21 D3IN4148 2 1 D4 IN4148 R2015K C24104 R213.9K + C25 10UF/16V R22 1.5M Q5C2412 2 1 3 VR1 5K 2 1 3 VR2 5K C26332C27332 C28472C29472 1 3 5 4 2 LF1 1 3 5 4 2 LF2 C3056PC3156P R2530KR2630K R278.2KR288.2K C17 NC C32 NC C33 NC C34 225/16V C35 225/16V C36 470P C37 470P CH.SET CHG_DET DSCI DSCO VDD CH1 CH0 PLL_CLK PLL_DATA RIN LIN MOD_OUT CHG_CTR GND RESET NC IN_USE AF_DET 1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 IC1 JX903D R29 100K R30 680 R32 1.5K R33 NC R34 1.5K C38 104 R351.5K R36 1.5K R3747K R38 2.2K R43 2.2K R44 3K C39 680P R45 100K R461K R47470K C40 103 R48 2.2K R493K C43 NC C45 NC C49 NC R51 100K R52 NC R53 100K C50 100P R55 NC C51 100P C52 104 + C53 100UF/16V R5610K R5710K 432 1 SW2-A SK23D01 C54 100P C55 100P X1 7.6M R58 10K C5620P C5720P R60 10K C62 103 R61 100K R62 NC R31 1.5K R63 3K TP1TP2 TP3 TP4 TP5 TP6 TP7 TP8 TP12 TP13 TP14 12 Z1 4.3V L1 1MH R590R740 21 LED1 RED 21 LED2 GREEN R23 NC R24 NC R1 1000P TP20 TP19 L3 0 C72225/16V C73 NC Q6 8550 12 3 4 F4 33uH Q7 8050 D1 IN4148 R85 330 R82 1K R78 3K R84 NC C58103p Z2 4.3V R83 15K C64103p R79 100K CH+ CH- R81 60R/1206 R80 0R R87 4.7K R50 1.5K R54 1.5K DC8V CHARGE DC8V CHG_DET CHARGE CHG_DET

Report No.: C130409Z05-RP1 FCC ID:MVAHP4191A-001T Page 1 / 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. FCC 47 CFR PART 15 SUBPART C for 900MHz Wireless Headphone Model: HP4190A Brand: Arkon Test Report Number: C130409Z05-RP1 Issued for: Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong Issued by: COMPLIANCE CERTIFICATION SERVICES (SHENZHEN) INC. No10-1, Mingkeda Logistics Park, No.18 Huanguan South Rd., Guan Lan Town, Baoan District, Shenzhen, China TEL: 86-755-28055000 FAX: 86-755-28055221 Issued Date: April 24, 2013 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test result of this report relate only to the tested sample identified in this report. Report No.: C130409Z05-RP1 FCC ID: MVAHP4191A-001T Page 2/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Revision History Rev. Issue No. Revisions Effect Page Revised By 00 C130409Z05-RP1 Initial Issue ALL Amay Tang Report No.: C130409Z05-RP1 FCC ID: MVAHP4191A-001T Page 3/26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. TABLE OF CONTENTS 1 TEST CERTIFICATION ................................................................................................. 4 2 EUT DESCRIPTION....................................................................................................... 5 3 TEST METHODOLOGY................................................................................................. 6 3.1. DESCRIPTION OF TEST MODES ...................................................................................... 6 4 TEST METHODOLOGY................................................................................................. 7 4.1. EUT EXERCISE ...................................................................................................................7 4.2. FCC PART 15.205 RESTRICTED BANDS OF OPERATIONS ........................................... 7 5 INSTRUMENT CALIBRATION ...................................................................................... 8 6 SETUP OF EQUIPMENT UNDER TEST ....................................................................... 8 6.1. DESCRIPTION OF SUPPORT UNITS................................................................................. 8 6.2. CONFIGURATION OF SYSTEM UNDER TEST ................................................................. 8 7 FACILITIES AND ACCREDITATIONS .......................................................................... 9 7.1. FACILITIES .......................................................................................................................... 9 7.2. ACCREDITATIONS ............................................................................................................. 9 7.3. MEASUREMENT UNCERTAINTY....................................................................................... 9 8 FCC PART 15.249 REQUIREMENTS ......................................................................... 10 8.1. BAND EDGES MEASUREMENT....................................................................................... 10 8.2. POWER LINE CONDUCTED EMISSIONS MEASUREMENT........................................... 14 8.3. SPURIOUS EMISSIONS MEASUREMENT....................................................................... 19 Report No.: C130409Z05-RP1 FCC ID:MVAHP4191A-001T Page 4 / 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 1 TEST CERTIFICATION Product 900MHz Wireless Headphone Model HP4190A Brand Arkon Tested April 9~22, 2013 Applicant Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong Manufacturer Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong APPLICABLE STANDARDS STANDARD TEST RESULT FCC 47 CFR Part 15 Subpart C No non-compliance noted DEVIATION FROM APPLICABLE STANDARD None We hereby certify that: The above equipment was tested by Compliance Certification Services Inc. The test data, data evaluation, test procedures, and equipment configurations shown in this report were made in accordance with the procedures given in ANSI C63.4 and the energy emitted by the sample EUT tested as described in this report is in compliance with the requirements of FCC Rules Part 15.207, 15.209, 15.249. The test results of this report relate only to the tested sample EUT identified in this report. Approved by: Reviewed by: Tom Gan Supervisor of EMC Dept. Compliance Certification Service Inc. Ruby Zhang Supervisor of Report Dept. Compliance Certification Service Inc. Report No.: C130409Z05-RP1 FCC ID:MVAHP4191A-001T Page 5 / 26 This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. 2 EUT DESCRIPTION Product 900MHz Wireless Headphone Model Number HP4190A Brand Name Arkon Model Discrepancy N/A Identify Number C130409Z05-RP1 EUT Power Rating DC8V supplied by the adapter Adapter Manufacturer / Model No. SUV-005-080-020-A2 Input: 100-240V,50/60Hz, 150mA Output: DC8.0V, 200mA DC output cable: Un-shielded, 2.20m Audio In Cable (TX) Unshielded, 1.80m Frequency Range 912.0 MHz, 913.0 MHz Transmit Power Peak: 90.97dBuV/m (Max.) AVG: 88.79 dBuV/m (Max.) Modulation Technique FM Number of Channels 2 Channel Antenna Specification Linear antenna with 0 dBi gain (Max) Temperature Range 0 ~ +55°C Note: 1. The sample selected for…

Text truncated - open the document above for the full version.

Report No.: C130409Z05-RP1 FCC ID: MVAHP4191A-001T Page 1/2 . PHOTOGRAPHS OF THE TEST CONFIGURATION Radiated Emissions Setup Photos Below 1GHz Above 1GHz Report No.: C130409Z05-RP1 FCC ID: MVAHP4191A-001T Page 2/2 . Power Line Conducted Emissions Setup Photos
