MVASP4292-001RWireless 900MHz Speaker

Wireless audio transmitter SignalP ower DC IN CHANNEL 1 2 3 R AUDIO L IN Power LMR DC IN Bass Boost On / Off Auto Scan V olume + V olume - Introduction AR’s Wireless Speaker System eliminates the hardest part of adding speakers to your home— running and hiding hundreds of feet of speaker wire. The AR Wireless Speaker System’s RF signal travels with ease through walls, floors, ceilings and other obstacles, delivering high- quality sound virtually anywhere inside the house or out. With drift- and static-free reception along with outstanding range—up to 150 feet*—the possibilities for enjoying your AR Wireless Speaker System are nearly unlimited. The AR Wireless Speaker System is compatible with most audio sources, such as A/V receivers/amps, stereos, computers, TVs, DVD players, and portable devices (CD players, cassette players, MP3s etc.). This manual covers various connection options and detailed operating instructions for making the AR Wireless Speaker System a valued part of your lifestyle. If, after having reviewed the instructions, you have any questions, please call toll-free 1-800-732-6866 or visit www.araccessories.com. *Range may vary according to environment. Important Information RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. Product Information Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need them. These numbers are located on the product. Model No.: _____________________________________________________________________________________________ Purchase Date: _________________________________________________________________________________________ Dealer/Address/Phone: __________________________________________________________________________________ Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Clean only with dry cloth. 6. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 8. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 9. Unplug this apparatus during lightning storms or when unused for long periods of time. 10. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Care and Maintenance • Always use a soft cloth to clean the speaker and transmitter. Never use any product containing alcohol or other solvents as they may damage the surface. • Use caution when plugging the power transformers in an AC outlet to avoid the risk of electric shock. • If the speaker are used outside on a deck or patio, make sure you take them indoors in the event of a rainstorm to prevent possible damage. • Do not operate or store the system in extreme temperatures (below 32ºF/0ºC and above 122ºF/50ºC). • To avoid electrical shock, use this product with caution near water sources if powered with the AC adapter. Never submerge in water. Tour of the Speaker System Transmitter AC/DC 12V 200mA adapter Speaker AC/DC 9V 1200mA adapter 3.5mm to RCA cable Speaker Front Panel Power indicator blinks when the speaker is first powered on; it turns solid blue when the speaker is tuned to the transmitter Side Panel Bass Boost button turns the speaker’s bass enhancement on and off On/Off button turns the speaker on and off Auto Scan button rescans for the transmitter’s signal Volume +/– buttons adjust the volume level Bottom Panel L/M/R switch determines if the speaker plays sound in mono as a stand-alone speaker, or plays the left or right track in a stereo pair with an additional AW826 DC IN receives the small round end of the included 9V 1200mA AC power adapter; remove the protective cover to insert the adapter Battery Compartment Cover remove to install 6 AA batteries Carrying handle Transmitter Top Panel Signal indicator lights green when the audio is present and the transmitter is broadcasting Power indicator lights when the transmitter is on Back Panel CHANNEL 1 2 3 lets you find the best transmission frequency for your environment DC IN jack receives the small round end of the included 12V 200mA AC power adapter AUDIO IN (R / L) connects to your sound source using one of the connection options shown here Included Accessories Note: These power units should be plugged in so that they stay vertical or lie flat. Connecting the Speaker System Powering the Transmitter Connect the small, round plug from the transmitter AC power adapter to the transmitter’s DC IN jack. Plug the other end of the transmitter AC power adapter into any standard 120V AC wall outlet. Note: Be sure to use the AC power adapter rated 12V DC 200 mA (it has the smaller diameter plug). Transmitter (back panel) 120V AC wall outlet AC Power Adapter DC IN CHANNEL 1 2 3 R AUDIO L IN Note: There is no transmitter ON/OFF switch. The transmitter is designed to be left plugged in and powered at all times. If you will not be using the AW826 for an extended period of time, unplug the transmitter AC power adapter. Connecting to an Audio Source Connecting to an MP3 player, CD player, or computer 1. Plug the stereo plugs on the provided Y-adapter audio cable into the AUDIO IN jacks on the back of the transmitter (make sure to match the colors on the plugs and jacks). 2. Plug the mini-plug end of the provided Y-adapter into the headph…

Text truncated - open the document above for the full version.

Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road,Kowloon, Hong Kong March 19, 2010 Federal Communications Commission Authorization and Evaluation Division FCC ID：MVASP4292-001R Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the applicant hereby requests confidential treatment of information applied this application as outlined below: 1. Block Diagram 2. Circuit Diagram 3. Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application Sincerely, Signature Name/Title: Simon Chan / Sales Manager Company Name: Uni-Art Precise Products Ltd Address: 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong TEL: +00852-27908778 FAX: +00852-23436151 Email: [email protected]

Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road,Kowloon, Hong Kong March 19, 2010 FCC ID：MVASP4292-001R Dear Sir, I hereby have entrusted the following person to be a proxy regarding application for Type Certification. Compliance Certification Services Inc. Address: No10-1, Mingkeda Logistics Park, No.18 Huanguan South RD. Guan lan Town, Baoan District, Shenzhen China Name: Aven Zhou Job Title: Supervisor Email: [email protected] I am therefore responsible for the contents of the application. Brand Name and Model Name of the specified radio equipment: Acoustic Research/AW826 FCC ID: MVASP4292-001R Product Name: Wireless 900MHz Speaker Signature Name/Title: Simon Chan / Sales Manager Company Name: Uni-Art Precise Products Ltd Address: 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong TEL: +00852-27908778 FAX: +00852-23436151 Email: [email protected]

Reference No: Report No: SZ100305B03-EF Page 1 / 6 Reference No: Report No: SZ100305B03-EF Page 2 / 6 Reference No: Report No: SZ100305B03-EF Page 3 / 6 Reference No: Report No: SZ100305B03-EF Page 4 / 6 Reference No: Report No: SZ100305B03-EF Page 5 / 6 Reference No: Report No: SZ100305B03-EF Page 6 / 6

Label Location

Reference No: Report No: SZ100305B03-EF Page 1 / 10 Reference No: Report No: SZ100305B03-EF Page 2 / 10 Reference No: Report No: SZ100305B03-EF Page 3 / 10 Reference No: Report No: SZ100305B03-EF Page 4 / 10 Reference No: Report No: SZ100305B03-EF Page 5 / 10 Reference No: Report No: SZ100305B03-EF Page 6 / 10 Reference No: Report No: SZ100305B03-EF Page 7 / 10 Reference No: Report No: SZ100305B03-EF Page 8 / 10 Reference No: Report No: SZ100305B03-EF Page 9 / 10 Reference No: Report No: SZ100305B03-EF Page 10 / 10

Report No.: SZ100305B03-EF FCC ID : MVASP4292-001R This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Page 1 / 20 FCC DOC TEST REPORT for Wireless 900MHz Speaker Brand: Acoustic Research Model: AW826 Test Report Number: SZ100305B03-EF Issued Date: March 16, 2010 Issued for Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong. Issued by: Compliance Certification Services Inc. No. 81-1, Lane 210, Bade 2nd Rd., Lujhu Township Taoyuan County, Taiwan TEL: +886-3-3240332 FAX: +886-3-3245235 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF, A2LA, NVLAP, NIST or any government agencies. The test results in the report only apply to the tested sample. Report No.: SZ100305B03-EF FCC ID : MVASP4292-001R This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Page 2 Revision History Rev. Issue No. Revisions Effect Page Revised By 00 SZ100305B03-EF Initial Issue ALL Clinton Kao CCS Report Format Version 2.0 Report No.: SZ100305B03-EF FCC ID : MVASP4292-001R This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Page 3 TABLE OF CONTENTS 1 TEST RESULT CERTIFICATION ........................................................................................ 4 2 EUT DESCRIPTION ............................................................................................................ 5 3 TEST METHODOLOGY ...................................................................................................... 6 3.1. DECISION OF FINAL TEST MODE ....................................................................................................6 3.2. EUT SYSTEM OPERATION ............................................................................................................... 6 4 SETUP OF EQUIPMENT UNDER TEST ............................................................................. 7 4.1. DESCRIPTION OF SUPPORT UNITS................................................................................................ 7 4.2. CONFIGURATION OF SYSTEM UNDER TEST ................................................................................ 8 5 FACILITIES AND ACCREDITATIONS................................................................................ 9 5.1. FACILITIES.......................................................................................................................................... 9 5.2. ACCREDITATIONS ............................................................................................................................. 9 5.3. MEASUREMENT UNCERTAINTY ...................................................................................................... 9 6 CONDUCTED EMISSION MEASUREMENT..................................................................... 10 6.1. LIMITS OF CONDUCTED EMISSION MEASUREMENT................................................................. 10 6.2. TEST INSTRUMENTS ...................................................................................................................... 10 6.3. TEST PROCEDURES ....................................................................................................................... 11 6.4. TEST SETUP..................................................................................................................................... 12 6.5. Data Sample: ..................................................................................................................................... 13 6.6. TEST RESULTS ................................................................................................................................ 14 7 RADIATED EMISSION MEASUREMENT ......................................................................... 15 7.1. LIMITS OF RADIATED EMISSION MEASUREMENT...................................................................... 15 7.2. TEST INSTRUMENTS ...................................................................................................................... 15 7.3. TEST PROCEDURES ....................................................................................................................... 16 7.4. TEST SETUP..................................................................................................................................... 18 7.5. Data Sample: ..................................................................................................................................... 18 7.6. TEST RESULTS ................................................................................................................................ 19 Report No.: SZ100305B03-EF FCC ID : MVASP4292-001R This report shall not be reproduced except in full, without the written approval of Compliance Certification Services. Page 4 1 TEST RESULT CERTIFICATION Product: Wireless 900MHz Speaker Model: AW826 Brand: Acoustic Research Applicant: Uni-Art Precise Products Ltd 11-12/F, Yue Xiu Industrial Building, 87 Hung To Road, Kowloon, Hong Kong Manufacturer: Arkon (Sha Jing) Manufacturing Factory No. 50 Xin Sha Road, Sha Jing Town, Bao An District, Shenzhen, China Tested Date: March 05-16, 2010 Tested Voltage: DC9V powered by the by the battery or DC9V powered by the adapter EMISSION Standard Item ResultRemarks Conducted (Main Port) PASS Meet Class B limit FCC 47 CFR Part 15 Subpart B, ANSI C63.4-2003 Radiated PASS Meet Class B limit Note: 1. The statements of test result on the above are decided by the request of test standard only; the measurement uncerta…
