Goodyear Portable Tire Reader User Instructions Model G3AM Phase IV Engineering 2820 Wilderness Place, Suite C Boulder, Colorado 80301 303-443-6611 This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment is a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Goodyear Portable Tire Reader – User Instructions 1 GOODYEAR CONFIDENTIAL INFORMATION 7376 07/13/01 Goodyear Portable Tire Reader User Instructions Phase IV Engineering Product Description Definition: In this manual, the term tag is used to refer to the chip that is in the intelligent tire. Product Description: Model G3AM, portable Radio Frequency Identification Tag Reader. The serial number on the bottom of the Reader begins with “G3”, includes a sequence number, and ends with an "AM". The Reader has the following features: 1. Power Requirements. Reader uses one 12 volt rechargeable battery (Dewalt DW 9071, Extended Run Time). 2. Non-volatile memory. The Reader is equipped with non-volatile memory that maintains user settings and stored data even when the battery pack is removed. 3. Turning the Reader On and Off. Turn the Reader on by pressing the push-button (Trigger) on the bottom of the handle; pushing the trigger again will cause the Reader to attempt to read tags. The Reader automatically shuts itself off two minutes after the last key-press or trigger-press. There is no separate off switch. LIGHT 4 7 1 A Z 0 5 8 2 ENTER 6 9 3 EXIT MODE DELETE 4. Keypad and Display. See the picture above: The Reader has a 4-row by 16-character display that is used to display tag data including, tag ID, temperature and pressure. Menus Goodyear Portable Tire Reader – User Instructions 2 GOODYEAR CONFIDENTIAL INFORMATION 7376 07/13/01 used for setting Reader options are also shown on the Reader display. The keypad is used to select modes of operation (e.g. set date and time, choose display options, etc.). 5. Read Modes. The Reader has three read modes: 1) READ AND RECORD, 2) READ ONLY, and 3) ADD AIR PRESSURE. • READ AND RECORD: In this mode, whenever the Trigger is pressed, the Reader driver field is turned on briefly. The Reader attempts to read any tag in the read field during this time. When a tag is read the ID number, temperature and pressure are displayed. Data including the time, date, tag ID, temperature and pressure are stored in a data file. • READ AND RECORD WITH PRESSURE DATA ENTRY: This mode is the same as the READ AND RECORD MODE but includes the option to manually enter an air pressure (e.g. from a tire gauge) that will be stored in the data file with the other information associated with that tag read. • READ ONLY mode: This mode is the same as READ AND RECORD mode except no data are stored in Reader memory. 6. Display Light. The keypad contains a key which switches a display light on and off. It is not recommended that tags be read with the light on. 7. Data Storage. When the Reader is in either of the READ AND RECORD modes, the ID number, date, time, temperature, pressure, (and manually entered pressure if that mode is selected) for each valid read are stored in a sequential file in the Reader. The Reader memory can store up to 1000 reads. Subsequent reads will be displayed but will NOT be added to the date file. Stored data must be downloaded or erased by connecting the Reader to a computer via the RS232 (comm) port. The amount of Reader memory available is displayed on the ‘Status’ screen. 8. Time and Date. The Reader has an internal clock and battery that keep track of the time and date even when the Reader battery is removed. The time and date should be checked periodically and reset if necessary (see procedure below). First Time Operation of the Reader The Readers come with the handle section removed. To attach the handle, align the connector in the handle with the mating connector in the base of the Reader. Insert the handle until the handle and the base of the Reader touch. Tighten the two captive screws. A black plug is provided that snaps into the hole in the top of handle to cover the upper captive screw. Before using a Reader, insert a battery pack into the handle until it snaps into place. Note that the battery should be charged prior to first use. Battery Usage The battery pack should provide several hundred tag-reads between charges. When the battery requires recharging, the Reader will emit a Low Battery Signal during the read process. This signal is a single tone for approximately one second. Tags can be read after the Low Battery Signal, but the battery pack should be replaced and recharged as soon as possible after it occurs. A fully discharged battery takes about one hour to recharge. The battery pack is only partially discharged when the Low Battery Signal occurs, and recharging should take about one-half hour. The battery charger provides an indication when the battery is fully charged (see battery charger documentation). Basic Operation To turn on the Reader, push the Read push-button (Trigger) on the handle once. After the Reader is turned on, pushing the Read push-button will cause the Reader to interrogate tags. If the battery has been replaced since the Reader was last used, select the proper operating mode from the keypad before reading tags (see Reader Setup section below.) Goodyear Portable Tire Reader – User Instructions 3 GOODYEAR CONFIDENTIAL INFORMATION 7376 07/13/01 To read the tire, the antenna section should be placed directly over the “Wingfoot”, and i…

Text truncated - open the document above for the full version.

FCC ID: N4T-G3AM ENGINEERING STATEMENT For Certification of Phase IV Engineering Radio Frequency Identification Reader FCC ID: N4T-G3AM Model # G3/xxAM I am an Electromagnetic Compatibility test engineer for TUV Product Service, Boulder, Colorado. My education and experience are a matter of record with the Federal Communications Commission. TUV Product Service Corporation has been authorized by Phase IV Engineering Boulder, 2820 Wilderness Place - Suite C, Boulder, Colorado 80301, to make FCC Part 15 Certification measurements on the G3/xxAM. These tests were made by me or under my supervision at our Pinewood Springs Laboratory which is registered with the FCC under Paragraph 15 of the FCC Rules. Test data required by the FCC for FCC Part 15 Certification is included in this report. It is submitted that the above equipment meets FCC requirements and FCC Part 15 Certification is hereby requested. ________________________ Shawn Singh EMC Engineer TUV Product Service Dated: 14 September 1998

C:\Ready_To_Convert\Doc\7333.DOC PHASE IV ENGINEERING 2820 WILDERNESS PL., SUITE C BOULDER, CO 80301 PH: (303) 443-6611 FAX: (303) 443-8379 September 2, 1998 Request for Confidentiality FCC ID: N4T-G3AM Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Phase IV Engineering requests that all information including circuit description and block diagrams within this application, except information that must be publicly available, be withheld from public inspection. The information contained within this application is confidential to Phase IV Engineering and took considerable time, effort, and expertise to develop. If the information were available to other potential competing companies, they could forgo most of the development time and expense, providing them with a potentially damaging and unfair competitive advantage. Thank you, Gene R. Starkey General Partner Phase IV Engineering

PHASE IV ENGINEERING 2820 WILDERNESS PLACE, UNIT C BOULDER, CO 80301 PH: (303) 443-6611 FAX: (303) 443-8379 Date: July 29, 1998 AUTHORIZATION AGREEMENT FCC Part 15 Submission I, Richard S. Pollack of Phase IV Engineering, appoint TUV Product Service, Inc., to act as the authorized representative in the preparation of applications for registration of equipment under Part 15 of Rules and Regulations of the Federal Communications Commission. I certify that the information provided to TUV Product Service, Inc., properly describes the device or system for which equipment authorization is requested. APPLICANT ANTI-DRUG ABUSE CERTIFICATION The applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853 (a), or, in the case of a non-individual applicant (e.g. corporation, partnership, or other unincorporated association) no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a “party” for these purposes see 47 CFR 1.2002(b). This Authorization, dated this 29th day of July, 1998, expires on the 29th day of July, 1999 . By Richard S. Pollack SignaturePrinted TitleGeneral Partner ApplicantPhase IV Engineering (Federal Employer ID # 84-1190758) (Must agree with section I on FCC Form 731 - Applicant’s Full Business Name) 2820 Wilderness Pl., Suite C Address Boulder, CO 80301 City, State, Zip

C:\Ready_To_Convert\Doc\7335.DOC PHASE IV ENGINEERING 2820 WILDERNESS PL., SUITE C BOULDER, CO 80301 PH: (303) 443-6611 FAX: (303) 443-8379 September 2, 1998 Request for Confidentiality FCC ID: N4T-G3AM Federal Communications Commission Equipment Approval Services P.O. Box 358315 Pittsburgh, PA 15251-5315 Phase IV Engineering requests that all information including circuit description and block diagrams within this application, except information that must be publicly available, be withheld from public inspection. The information contained within this application is confidential to Phase IV Engineering and took considerable time, effort, and expertise to develop. If the information were available to other potential competing companies, they could forgo most of the development time and expense, providing them with a potentially damaging and unfair competitive advantage. Thank you, Gene R. Starkey General Partner Phase IV Engineering

PHASE IV ENGINEERING 2820 WILDERNESS PLACE, UNIT C BOULDER, CO 80301 PH: (303) 443-6611 FAX: (303) 443-8379 Date: July 29, 1998 AUTHORIZATION AGREEMENT FCC Part 15 Submission I, Richard S. Pollack of Phase IV Engineering, appoint TUV Product Service, Inc., to act as the authorized representative in the preparation of applications for registration of equipment under Part 15 of Rules and Regulations of the Federal Communications Commission. I certify that the information provided to TUV Product Service, Inc., properly describes the device or system for which equipment authorization is requested. APPLICANT ANTI-DRUG ABUSE CERTIFICATION The applicant certifies that, in the case of an individual applicant, he or she is not subject to a denial of federal benefits, that includes FCC benefits, pursuant to section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853 (a), or, in the case of a non-individual applicant (e.g. corporation, partnership, or other unincorporated association) no party to the application is subject to a denial of federal benefits, that includes FCC benefits, pursuant to that section. For the definition of a “party” for these purposes see 47 CFR 1.2002(b). This Authorization, dated this 29th day of July, 1998, expires on the 29th day of July, 1999 . By Richard S. Pollack SignaturePrinted TitleGeneral Partner ApplicantPhase IV Engineering (Federal Employer ID # 84-1190758) (Must agree with section I on FCC Form 731 - Applicant’s Full Business Name) 2820 Wilderness Pl., Suite C Address Boulder, CO 80301 City, State, Zip

FCC ID: N4T-G3AM File No. B241835201, Page 1 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 EMC EMISSION - TEST REPORT Test Report No. B835201 Issue Date10 September 1998 Model / Serial No. G3/xxAM / G3/021AM Product Type Radio Frequency Identification Reader Client Phase IV Engineering Manufacturer Phase IV Engineering License holder Phase IV Engineering Address 2820 Wilderness Place, Suite C Boulder, CO 80301 Test Criteria AppliedFCC Part 1515.209C Test Start Date:31 July 1998 Test End Date:31 July 1998 Test Result



PASS   FAIL Test Report Project No. B241835201 Total Pages including Appendices 41 _________________________________________________________________________________ Reviewed By : Felix J. ChavezReviewed By : Shawn Singh TÜV Product Service Inc is a subcontractor to TÜV Product Service, GmbH according to the principles outlined in ISO/IEC Guide 25 and EN 45001. TÜV Product Service Inc reports apply only to the specific samples tested under stated test conditions. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. TÜV Product Service Inc shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV Product Service Inc issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval of TÜV Product Service. This report shall not be used by the client to claim product endorsement by NVLAP or any agency of the US government. TÜV Product Service Inc and its professional staff hold government and professional organization certifications and are members of AAMI, ACIL, AEA, ANSI, IEEE, NVLAP, and VCCI FCC ID: N4T-G3AM File No. B241835201, Page 2 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 DIRECTORY - EMISSIONS Page(s) Documentation Test report1 - 3 Directory2 Test Regulations3 General Remarks3 Test-setup Photographs4-5 Test Equipment Used6-8 Appendix A Transmitter Data Sheets A1 - A2 Appendix B Detailed Test Data Sheets B1 - B16 Appendix C Test Plan/Constructional Data Form C1 - C12 Appendix D Measurement of Protocol D1 - D3 FCC ID: N4T-G3AM File No. B241835201, Page 3 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 EMISSIONS TEST REGULATIONS : The tests were performed according to following regulations :
- Federal Communication Commission part 15
- Class A - Class B
- Federal Communication Commission part 15, Subpart C
- 15.207
- 15.209 -------------------------------------------------------------------------------- All tests performed according to ANSI C63.4 Emission Test Results: Conducted emissions 150 kHz - 30 MHz Test Result



- PASS    - FAIL   - Not Applicable Passing Margin2 dBat0.4 MHz Remarks:EUT is battery operated. Radiated emissions (electric field) 30 MHz - 1000 MHz (Unintentional Radiator) Test Result



- PASS    - FAIL   - Not Applicable Passing Margin4.1 dBat66.5 MHz Remarks: Radiated emissions (magnetic field) 0.125 MHz - 1.250 MHz (Intentional Radiator) Test Result



- PASS    - FAIL   - Not Applicable Passing Margin19.4 dBat0.625 MHz Remarks: GENERAL REMARKS: Modifications required to pass: Test Specification Deviations: Additions to or Exclusions from: None FCC ID: N4T-G3AM File No. B241835201, Page 4 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 Test-setup photo(s) Radiated Emissions FCC ID: N4T-G3AM File No. B241835201, Page 5 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 Test-setup photo(s): Conducted Emissions FCC ID: N4T-G3AM File No. B241835201, Page 6 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 Test Equipment Used FCC ID: N4T-G3AM File No. B241835201, Page 7 of 8 TÜV PRODUCT SERVICE INC40 Meadow RoadPinewood Springs, Lyons, CO 80540 Tel: 303 786 7999 Fax: 303 449 3004Rev.No 1.0 Colorado Test Equipment 22-July-98 Report: B8352 Date: 31 July 1998Signature: Shawn Singh Temp: 20.8 deg. cRel. Humd.: 66%Atmo. Pressure: 81.0 kPa LocationManufacturerModel NumberSerial NumberCal DateCal Due PWAH SystemsSAS-200/51070506-Jul-9806-Jul-99 *PWAH SystemsSAS-200/512104 13-Jul-9813-Jul-99 PWAH SystemsSAS-200/54225603-Feb-9803-Feb-99 PWAvAntekAFT97-8434-10 100718-Nov-9718-Nov-98 PWAvantekAWT-18037100218-Nov-9718-Nov-98 PWbird40221825 PWbird40241863 PWbird40253702 PWBird4421-1031254 PWCalifornia Instr.850T6845808-Mar-9808-Mar-99 PWCalifornia Instr.9000TCA/3-150666+ PWCompaq470A 23605277 PWCompaq 575g545HSY20483 PWCompliance Des. RD-102-Mar-00 PWEMC Test Sys.314227-Jan-9827-Jan-99 PWEMCO1070-4 9206-1681 PWEMCO1080/10819206-1636 PWEMCO1090 1134 *PWEMCO3108 214919-Jun-99 PWEMCO 31087059203-245706-Jul-99 PWEMCO 3115 388620-Feb-9820-Feb-99 PWEMCO31469203-337618-Jun-9818-Jun-99 PWEMCO3825/29202-194515-Jul-9815-Jul-99 PWEMCO3825/29202-194608-Jul-9708-Jul-98 PWEMCO3825/29202-194623-Jul-9823-Jul-99 PWEMCO46109205-1199 PWEMCO46209110-1015 PWEMCO65022082 *PWEMCO65029205-273830-Oct-9729-Oct-00 PWEMCO71239205-1028 PWEMCO71239205-102911-Dec-9711-Dec-98 PWEMCO74059203-2175 PWFischerF-20114105-Mar-9805-Mar-99 PWFischerF-33-135604-May-9804-May-99 PWFischer Custom F-6127417-Jun-9717-Jun-98 *PWGishard600-1040 mb002 PWHewlett Packard 11940A2650A04527 PWHewlett Packard 11940A2650A04563 PWHewlett Packard 11941A2807A02957 *PWHewlett Packard 11947A2820A0027718-Nov-9718-Nov-98 PWHewlett Packard 11947A3107A0197517-Jun-9817-Jun-99 PWHewlett Packard 8444A2325A0789918-No…
