N69-835100GO7 3G GPS Tracker

Geotab, Inc. | www.geotab.com | T: (877) 436-8221 | Copyright 2012 – All Rights Reserved | Rev0.2 - 04/2013 1 Geotab GO7™ : The World’s Only Expandable Plug-&-Play Platform GO7™ Hardware Device GO7™ is a small yet extremely powerful telematics measurement tool. GO7™ offers state of the art GPS technology, g-force monitoring, IOX™ expandability, and engine and battery health assessments. Using Geotab’s patented tracking algorithm, it accurately recreates the vehicle’s trips and analyzes incidents. Like all of Geotab products, GO7™ offers in-vehicle alerts to notify drivers instantly of infractions. GO7™ is truly a plug and play technology – it requires no dash mounted antennas and no splicing of wires. Top Features  Small form factor device  Easy plug-and-play installation  IOX™ (Input-Output-Expander)  Intelligent in-vehicle driver coaching  Breakthrough accident detection and notification  Ultra-accurate engine diagnostics  High quality recording (CAN-BUS)  Live vehicle data  Fastest GPS acquisition time  Compatible with Geotab’s GPS fleet management software solutions Built-in accelerometer Geotab, Inc. | www.geotab.com | T: (877) 436-8221 | Copyright 2012 – All Rights Reserved | Rev0.2 - 04/2013 2 Technical Specifications and Features Compliance RoHS compliant, lead free Size 75 mm (L) x 50 mm (W) x 23 mm (H) Weight 70 g (0.15 lb) Housing Flame retardant black ABS Environmental Tests Operating Temperature: -30 to +70 °C 32 Mb Non-volatile Flash Memory Store  Main Data Memory: Records 4,650 miles (7,500 km) of city driving (40,000 logs).  Accident Data Memory: Buffer records over 100 minutes of second-by-second data (6,000 logs). Last 72 records (1.2 minutes) are sent instantly on accelerometer triggered accident-level events. Engine Management Diagnostics supported on:  CAN: ISO 15765  Diesel Engines: SAE J1939 & J1708  Legacy OBD: SAE J1850 PWM/VPW, ISO 9141-2, and ISO 14230 KWP2000.  On-Board Single Wire CAN (GM J2411)  CCD bus (Chrysler)  Medium Speed CAN (Ford)  Variable Input Output Module (non-standard) Adapter packs available for heavy duty vehicles. Operating Voltage 8 V to 36 V Current  Operating Mode: 120 mA  Sleep Mode: 2.7 mA.  Internal current draw measurement Resettable over-current protection to I/O expanders (IOX) Recording Parameters Patented, curve-based GPS/voltage/accelerometer/ engine data logging algorithm for fewer, more accurate data points. I/O Expandability Support (IOX™)  Driver ID  Garmin  Iridium  Auxiliary  Hours of Service (HOS)  Serial Port for 3 rd party device integration And more! Over The Air (OTA) Support  Firmware Updates: For maintenance, new features, and custom-applications  Parameters: For turning additional features on/off Almanac/Ephemeris Data: For quicker GPS latch In-cab Buzzer  Driver Feedback: Harsh braking, harsh acceleration, harsh corners, over-revving, excessive idling and speeding, engine based seatbelt violations (when available), and custom.  Test Mode: Diagnostic beeps for system of GPS and wireless connection. Clock Internal clock is set by initial GPS latch and counts seconds for time based activity during sleep mode including heartbeat and voltage recording. Geotab, Inc. | www.geotab.com | T: (877) 436-8221 | Copyright 2012 – All Rights Reserved | Rev0.2 - 04/2013 3 Voltage Recording Curve based voltage logging to detect weak batteries, failing alternators, and failing starters. Heartbeat Device wakes out of sleep mode at pre-defined intervals to send buffered data, such as position and voltage data. Antennas (GPS and cellular) Internal Accelerometer 3-axis accelerometer for low-voltage digital output linear MEMS, housed in an LGA package. Full scale (±2g, ±4g, ±8g and ±16g), capable of measuring accelerations with an output data rate of 100 Hz or 400 Hz. Installation Simple plug and play Intelligent Ignition Detect Non-engine based ignition detect based on voltage and movement allowing for 2-wire installation. Perfect for older vehicles with no engine information and covert installation for asset recovery. GPS Receiver UBX-G6010-ST  Voltage: 2.5 V to 3.6 V  50-channel u-Blox 6 engine  Under 1 second Time-To-First Fix for hot and aided starts.  Hybrid GPS/SBAS engine (WAAS, EGNOS, MSAS)  3GPP compliant A-GPS: AssistNow Online and AssistNow Offline services Cellular Module  GO7 2G: MT6252A chipset(M5206 2G Module) o GSM/GPRS: 850/900/1800/1900  GO7 3G: MT6276A chipset(M7600 3G Module) o GSM/GPRS : 850/900/1800/1900 o UMTS: Band I/Band II/Band V  Voltage: 3.8 V  CurrentConsumption: 500 mA @ 4.2 V (2G) 400 mA @ 4.2 V (3G)  Embedded TCP/IP stack Certifications: PTCRB. Other certifications pending. Installation Instructions Before installing your GO7™ device, ensure no dash warning lights are on in the vehicle while it is running. Also verify device compatibility with your vehicle type with your reseller. GO7™ Installation 1. Locate the vehicle’s engine diagnostic port typically found in the driver’s area at or below knee level. Note: Commercial vehicles with diesel engines use a different connector system. Contact your reseller for diesel connector applications or for extension harnesses should it be necessary to locate your GO7™ away from the engine diagnostic port location. Geotab, Inc. | www.geotab.com | T: (877) 436-8221 | Copyright 2012 – All Rights Reserved | Rev0.2 - 04/2013 4 2. Align the receiver end of the GO7™ with the engine diagnostic port and simply push in place, ensuring that the device is secure.You will hear 6 quick beeps and all three lights on the GO7™ will flash briefly. 3. Start the vehicle and allow it to run for approximately 3 minutes. During this time period, you will notice the Red LED will power on and illuminate on the face of the device. Shortly afterwards the Green and Blue LEDs will illuminate as the device links up with the cellular and GPS networks. This initial start-up may take several minutes to complete, and assumes the vehicle is parked outdoo…
