N6AFJEE0302Energy Saving Lamp

User’s Manual This light device has been tested and found to comply with the limits for Consumer RF Lighting Device, pursuant to Part 18 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. 1 Use only on 120V/60Hz. 2 Never disassemble or modify-any changes could void the user’ authority to operate this device. 3 Not for use in totally enclosed recessed fixtures. 4 Risk of electric shock-do not use with where directly exposed to water. 5 This device is not intended for use with emergency exit fixtures or emergency exit lights. 6 This product may cause interference to radio equipment and should not be installed near maritime safety communications equipment or other critical navigation or communication equipment operating between 0.45-30MHz. 7 To prevent burns, do not touch the bulb during operation or immediately after switching off. 8 Not for use with dimmers, electronic timer or photocell devices or occupancy sensor.

Block Diagram

F IGURE 1 E NERGY S AVING L AMP (M/N: JLS MINI-I 18W) G ENERAL A PPEARANCE F IGURE 2 E NERGY S AVING L AMP (M/N: JLS MINI-I 20W) G ENERAL A PPEARANCE F IGURE 3 E NERGY S AVING L AMP (M/N: JLS MINI-I 23W) G ENERAL A PPEARANCE F IGURE 4 E NERGY S AVING L AMP (M/N: JLS MINI-I 26W) G ENERAL A PPEARANCE

Label Location Information Refer to the below red arrow: (For example) JOINLUCK FCC ID: N6AFJEE0302

Label Drawing JOINLUCK FCC ID: N6AFJEE0302

F IGURE 1 E NERGY S AVING L AMP (M/N: JLS MINI-I 18W) C OVER R EMOVED F IGURE 2 E NERGY S AVING L AMP (M/N: JLS MINI-I 18W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 3 E NERGY S AVING L AMP (M/N: JLS MINI-I 18W) M AIN B OARD (S OLDERED S IDE ) F IGURE 4 E NERGY S AVING L AMP (M/N: JLS MINI-I 20W) C OVER R EMOVED F IGURE 5 E NERGY S AVING L AMP (M/N: JLS MINI-I 20W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 6 E NERGY S AVING L AMP (M/N: JLS MINI-I 20W) M AIN B OARD (S OLDERED S IDE ) F IGURE 7 E NERGY S AVING L AMP (M/N: JLS MINI-I 23W) C OVER R EMOVED F IGURE 8 E NERGY S AVING L AMP (M/N: JLS MINI-I 23W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 9 E NERGY S AVING L AMP (M/N: JLS MINI-I 23W) M AIN B OARD (S OLDERED S IDE ) F IGURE 10 E NERGY S AVING L AMP (M/N: JLS MINI-I 26W) C OVER R EMOVED F IGURE 11 E NERGY S AVING L AMP (M/N: JLS MINI-I 26W) M AIN B OARD (C OMPONENT S IDE ) F IGURE 12 E NERGY S AVING L AMP (M/N: JLS MINI-I 26W) M AIN B OARD (S OLDERED S IDE )

Schematics

Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0302 Page 1 of 24 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03011 Application for FCC Certificate On Behalf of Fujian Joinluck Electronic Enterprise Co., Ltd. Energy Saving Lamp Model No.: JLS MINI-I 18W JLS MINI-I 20W JLS MINI-I 23W JLS MINI-I 26W FCC ID: N6AFJEE0302 Prepared For : Fujian Joinluck Electronic Enterprise Co., Ltd. Cangshan Industrial Area, Cangshan District, Fuzhou, Fujian, China. Prepared By : Audix Technology (Shanghai) Co., Ltd. 3F 34Bldg 680 Guiping Rd, Caohejing Hi-Tech Park, Shanghai, China 200233. Tel : +86-21-64955500 Fax : +86-21-64955491 Report No. : ACI-F03011 Date of Test : Jan 27, 2003 Date of Report : Feb 08, 2003 Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0302 Page 2 of 24 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03011 TABLE OF CONTENTS Page 1 GENERAL INFORMATION.......................................................................................................... 4 1.1 Description of Equipment Under Test........................................................................................4 1.2 Description of Test Facility ........................................................................................................ 4 1.3 Measurement Uncertainty .......................................................................................................... 4 2 AC POWERLINE CONDUCTED EMISSION TEST ................................................................. 5 2.1 Test Equipment........................................................................................................................... 5 2.2 Block Diagram of Test Setup ..................................................................................................... 5 2.3 Conducted Emission Limits ....................................................................................................... 5 2.4 Test Configuration...................................................................................................................... 6 2.5 Operating Condition of EUT ...................................................................................................... 6 2.6 Test Procedures .......................................................................................................................... 6 2.7 Test Results ................................................................................................................................ 7 3 FIELDSTRENGTH TEST ............................................................................................................ 11 3.1 Test Equipment......................................................................................................................... 11 3.2 Block Diagram of Test Setup ................................................................................................... 11 3.3 Test Configuration.................................................................................................................... 11 3.4 Operating Condition of EUT .................................................................................................... 11 3.5 Test Procedure .......................................................................................................................... 12 3.6 Test Result ................................................................................................................................ 12 Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0302 Page 3 of 24 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03011 TEST REPORT FOR FCC CERTIFICATE Applicant : Fujian Joinluck Electronic Enterprise Co., Ltd. Manufacturer : Fujian Joinluck Electronic Enterprise Co., Ltd. EUT Description : Energy Saving Lamp (A) Model No.: JLS MINI-I 18W, JLS MINI-I 20W JLS MINI-I 23W, JLS MINI-I 26W (B) Serial No.: E03012701, E03012702, E03012703, E03012704 (C) Power Supply: 120V/60Hz Test Procedure Used: FCC RULES AND REGULATIONS PART 18 CONSUMER DEVICES (2002) AND MP-5/1986 The device described above is tested by Audix Technology (Shanghai) Co., Ltd. to determine the maximum emission levels emanating from the device. The maximum emission levels are compared to the FCC Part 18 RF Lighting Device limits both conducted emissions and field strength. The test results are contained in this test report and Audix Technology (Shanghai) Co., Ltd. is assumed full responsibility for the accuracy and completeness of these measurements. Also, this report shows that the EUT to be technically compliant with the FCC official limits. This report applies to above tested sample only. This report shall not be reproduced in part without written approval of Audix Technology (Shanghai) Co., Ltd. This report must not be used by the applicant to claim product endorsement by NVLAP or any agency of the U.S. Government. Date of Test : Jan 27, 2003 Prepared by : Test Engineer : CATHRIN YIN (Assistant) SOLON GONG (Engineer) Reviewer : Approved Signatory : SAMMY CHEN (Engineer) BYRON KWO (Assistant Manager) Fujian Joinluck Electronic Enterprise Co., Ltd. FCC ID: N6AFJEE0302 Page 4 of 24 Audix Technology (Shanghai) Co., Ltd. Report No: ACI-F03011 1 GENERAL INFORMATION 1.1 Description of Equipment Under Test Description : Energy Saving Lamp Type of EUT : ; Production … Pre-product … Pro-type Model Number : JLS MINI-I 18W, JLS MINI-I 20W JLS MINI-I 23W, JLS MINI-I 26W Applicant : Fujian Joinluck Electronic Enterprise Co., Ltd. Cangshan Industrial Area, Cangshan District, Fuzhou, Fujian, China. Manufacturer : Fujian Joinluck Electronic Enterprise Co., Ltd. Cangshan Industrial Area, Cangshan District, Fuzhou, Fujian, China. Test Model Apparent Power (V ̇ A) Real Power (W) JLS MINI-I 18W 35.72 19.80 JLS MINI-I 20W 38.20 21.30 JLS MINI-I 23W 45.10 24.60 JLS MINI-I 26W 51.20 29.00 1.2 Description of Test Facility Site Description : Sept. 17, 1998 file on (Semi-Anechoic Chamber) Feder…

Text truncated - open the document above for the full version.

Test Set-Up Photos 1. Conducted Emission Test (M/N: JLS MINI-I SERIES) 2. Field strength Test (M/N: JLS MINI-I SERIES)
