N99REMOTERemote Car Alarm/Starter

CompuStar SHF 2W AS USER'S GUIDE Firstech, Inc. 230 E. Potter St. Suite #8, Anchorage, AK. 99518 1-888-820-3690 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the users's authority to operate this device. 1 --------------------------------------------------------------------- INTRODUCTION Thank you very much for purchasing far advanced LIQUID CRYSTAL BOTH DIRECTION REMOTE CAR ALARM START(CompuStar SHF2AS) of Firstech, Inc. We are constantly researching and developing in order to meet satisfaction for the requirements of progressive clients. 1. This product is automatic reservation type for manual vechicle. In case of manual vechicle, after parking with pulling the key out the engine does not stop running until closing the door after getting off. 2. If the all operation of the vechicle does not accord with this user's guide, consult us or installation agency. 3. We make it a rule to deal with this product at agencies appointed to handle MAGICAR products. in case of other salesperson, be sure to get identificatiion. Refer to regional MAGICAR direct agencies. 4. Because it is an electronic product, so avoid strong impact or permitting water. 5. When the vichile is not automatic, be sure not to choose automatic option(dip- switch no.1 in system). ('Automatic(vehicle)'means the car starts always P and N position.) Problems due to ignorance above things, installation fault or user's fault, we are not responsible them. 2 -------------------------------------------------------------------------------- ----- +-------------- MAJOR FUNCTIONS -------------+ | | | This product is 3 dimensional far advanced auto controller with viewing through | | remote controller screen and adopting inter-communication between vechicle and | | remote controller. | | | | When the vehile is located at the place where can not be seen or heard the | | speaker sound, you can get the confirmation through screen and sound of the | | remote controller. | | Automatic start reservation type for manual vehicle. | | Without remote controller, functions can be cleared(Vallet mode) with only key. | | Maintain the code memory against cut-off the power(vehicle battery discharge | | or battery exchange). | | Will be settled additional remote controller immediately. | | High efficiency and subminiature rod antenna. | | Perfect operating between -20 C and +50 C | | CMOS micro chip / crystal oscillator. | | CAR CALL(Car paging) function. | | Can keep silent at the car when the vehicle gotten sudden impact or stolen. | | Remote controller provides screen and emergency sound. | | every 24 hours start mode. | | For turbo-engine function. | | Clients can change various auto-function of door and all options with remote | | controller. | | Start(Engine) kill function at panic state. | 3 +------------------------------------------------------------------------------- ---------+ CONTENTS Buttons function --------------------------------------- 5p Functions description Lock the door ------------------------------------- 6p Unlock the door ----------------------------------- 7p Self emergency ------------------------------------ 8p Engine starting reservation ----------------------- 9p Cancel engine starting reservation ---------------- 10p Remote engine starting ---------------------------- 11p Trunk open ---------------------------------------- 12p Query the state of vehicle ----------------------- 13p Mute mode ----------------------------------------- 14p Vallet function(1) -------------------------------- 15p Vallet function(2) ----------- -------------------- 16p Option(Auto-function of door lock) ---------------- 17p Paging function ----------------------------------- 18p Car-Call/Panic function --------------------------- 18p Every 24H-start function -------------------------- 19p Turbo function ------------------------------------ 20p Client control ----------------------------------------- 21p How to change option(Auto-function of door lock) ------- 22p Wiring diagram ----------------------------------------- 23p Code injection ----------------------------------------- 24p 4 ------------------------------------------------------------------------- ---- BUTTONS FUNCTION +-----------+------------------+----------------------------------------+-- ------+ | BUTTON | PRESS | FUNCTION |DESCRIP.| +-----------+------------------+----------------------------------------+-- ------+ | I | one touch | door lock(arming)/unlock(disarm) | 6p | +-----------+------------------+----------------------------------------+-- ------+ | I - | 2 sec. | speaker sound and emergency light for | 8p | | | | 30 sec.stat(engine) is killed until | | | | | disarmed | | +-----------+------------------+----------------------------------------+-- ------+ | II- | 2 sec. | remote starting on/off | 11 p | +-----------+------------------+----------------------------------------+-- ------+ | III- | 2 sec. | trunk open | 12 p | +-----------+------------------+----------------------------------------+-- ------+ | IV | one touch | query the state of vehicle | 13 p | +-----------+------------------+----------------------------------------+-- ------+ | I+II | one touch | mute mode approach/reinstate | 14 p | | | at the same time | | | +-----------+------------------+----------------------------------------+-- ------+ | I+III | one touch | valet mode approach/reinstate | 15 p | | | at the same time | | | +-----------+------------------+----------------------------------------+-- ------+ | I+IV | one touch | change door automatic option | 17 p | | | at the same time | | | +-----------+------------------+----------------------------------------+-- ------…
