N9STY-S-001-1Bluetooth Speaker

Operating Instructions For Bluetooth Speaker There are two ways to play music through the blue tooth speaker – SD Card or through your portable device 1. To play through your SD Card 1) Make sure the bluetooth speaker is plugged and push mode button until a red light appears on top of the speaker. 2) SD Card – plug your SD card into the backside of the speaker. ** note** The SD Card must be pre-loaded with the music you desire to play. ** Note** Under SD mode, You can increase the volume FURTHER by using the volume buttons on the top of the speaker (as shown below). Make sure you hold down the volume button in order to adjust the volume setting (long press) The music on the SD card can also be controlled through the buttons on top of the speaker as shown below. Use “short press” to activate this. Pause/play Switch between SD Card and Blue tooth mode Power ON/OFF REVERSE – to previous song FAST FORWARD – to next song 2. TO PLAY THROUGH YOUR WIRELESS DEVICE: 1) Make sure the bluetooth speaker is plugged in and push mode button until a blue light appears on top of the speaker. 2) Make sure the blue-tooth name “ Glo-TEC” is highlighted on your device. 3) Ensure the bluetooth setting is activated on your device and paired with the speaker before playing music. 4) After you select your music and it begins playing through the blue tooth speaker. 5) you can adjust the volume of the blue tooth speaker by increasing the volume on your wireless device. You can also increase the volume FURTHER by using the volume buttons on the top of the speaker. Make sure you hold down the volume button in order to adjust the volume setting (long press) FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this device must accept any interference received, including interference that may cause undesired operation. Note:“Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.” The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

TOYO ELECTRIC MFG. CO., LTD. SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 TOYO ELECTRIC MFG. CO., LTD. SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 2013/04/23 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _____ TOYO ELECTRIC MFG. CO., LTD. _____hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product ： Bluetooth Speaker Trade Name ： TOYO Model Name： TY-S-001 Serial Model： N/A FCC ID : N9STY-S-001-1 We affirm that between SIEMIC and ___ TOYO ELECTRIC MFG. CO., LTD. ___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature Client’s name / title : Dennis Wang / Manger Contact information / address : 9TH, FL 30 SEC 3 RENAI RD DAAN DISTRICT, TAIPEI 106 TAIWAN

TOYO ELECTRIC MFG. CO., LTD. SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 TOYO ELECTRIC MFG. CO., LTD. SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 2013/04/23 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: N9STY-S-001-1 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature Client’s name / title : Dennis Wang / Manger Contact information / address : 9TH, FL 30 SEC 3 RENAI RD DAAN DISTRICT, TAIPEI 106 TAIWAN

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8

一． FCC Label Model: TY-S-001 Date Code: 0513 120V AC 60Hz , 0.1 A, 12 Watts Module Use Frequency Range: 2402MHz-~2480MHz TOYO Electric Mfg. Co., Ltd FCC ID: N9STY-S-001-1 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this device must accept any interference received, including interference that may cause undesired operation.

Photo 9 Photo 10 Photo 11 Photo 12

FCC ID: N9STY-S-001-1 RF EXPOSURE TEST SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,16 where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation17  The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: N9STY-S-001-1 Maximum measured transmitter power Output Power(Max Conducted): BT(1Mbps): 1.070dBm BT EDR(2Mbps): -1.142dBm BT EDR(3Mbps): -0.855dBm The max.output power E.I.R.P is 1.070dBm=1.28mW, Frequency is 2.441GHz So (1.28/5)* √2.441=0.399≤ 3.0 Conclusion: No SAR is required.

FCC RADIO TEST REPORT FCC ID: N9STY-S-001-1 Product： Bluetooth Speaker Trade Name： TOYO Model Name： TY-S-001 Serial Model： N/A Report No.： NTEK-2013NT0506090F Prepared for TOYO ELECTRIC MFG. CO., LTD. 9TH, FL 30 SEC 3 RENAI RD DAAN DISTRICT, TAIPEI 106 TAIWAN Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park, Sanwei Community,Xixiang Street Bao‟an District, Shenzhen P.R. China Tel.: +86-0755-61156588 Fax.: +86-0755-61156599 Website:www.ntek.org.cn Page 2 of 83 Report No.: NTEK-2013NT0506090F TEST RESULT CERTIFICATION Applicant’s name ................. : TOYO ELECTRIC MFG. CO., LTD. Address ................................. : 9TH, FL 30 SEC 3 RENAI RD DAAN DISTRICT, TAIPEI 106 TAIWAN Manufacture's Name ............ : T&Y ELECTRIC(SHENZHEN)Co., LTD. Address ................................. : ANLIANG INDUSTRIAL ZONE, HENGGANG, LONGGANG DISTRICT, GUANGDONG, CHINA Product description Product name............................ : Bluetooth Speaker Model and/or type reference : TY-S-001 Serial Model： N/A Standards ............................. : FCC Part15.247 Test procedure ............................... : ANSI C63.4-2003 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 20 Apr. 2013 ~05 May. 2013 Date of Issue .......................................... : 06 May. 2013 Test Result.............................................. : Pass Testing Engineer : (Apple Huang) Technical Manager : (Tom Zhang) Authorized Signatory : (Bovey Yang) Page 3 of 83 Report No.: NTEK-2013NT0506090F Table of Contents Page 1 . SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 6 1.2 MEASUREMENT UNCERTAINTY 6 2 . GENERAL INFORMATION 7 2.1 GENERAL DESCRIPTION OF EUT 7 2.2 DESCRIPTION OF TEST MODES 9 2.3 TABLE OF PARAMETERS OF TEXT SOFTWARE SETTING 9 2.4 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 11 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 12 3 . EMC EMISSION TEST 13 3.1 CONDUCTED EMISSION MEASUREMENT 13 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 13 3.1.2 TEST PROCEDURE 14 3.1.3 DEVIATION FROM TEST STANDARD 14 3.1.4 TEST SETUP 14 3.1.5 EUT OPERATING CONDITIONS 14 3.1.6 TEST RESULTS 15 3.2 RADIATED EMISSION MEASUREMENT 17 3.2.1 RADIATED EMISSION LIMITS 17 3.2.2 TEST PROCEDURE 18 3.2.3 DEVIATION FROM TEST STANDARD 18 3.2.4 TEST SETUP 19 3.2.5 EUT OPERATING CONDITIONS 20 3.2.6 TEST RESULTS (BELOW 30 MHZ) 21 3.2.7 TEST RESULTS (BETWEEN 30M – 1000 MHZ) 22 3.2.8 TEST RESULTS (ABOVE 1000 MHZ) 24 3.2.9 TEST RESULTS (RESTRICTED BANDS REQUIREMENTS) 42 4 . NUMBER OF HOPPING CHANNEL 54 4.1 APPLIED PROCEDURES / LIMIT 54 4.1.1 TEST PROCEDURE 54 4.1.2 DEVIATION FROM STANDARD 54 4.1.3 TEST SETUP 54 4.1.4 EUT OPERATION CONDITIONS 54 4.1.5 TEST RESULTS 55 5 . AVERAGE TIME OF OCCUPANCY 56 Page 4 of 83 Report No.: NTEK-2013NT0506090F Table of Contents Page 5.1 APPLIED PROCEDURES / LIMIT 56 5.1.1 TEST PROCEDURE 56 5.1.2 DEVIATION FROM STANDARD 56 5.1.3 TEST SETUP 57 5.1.4 EUT OPERATION CONDITIONS 57 5.1.5 TEST RESULTS 58 6 . HOPPING CHANNEL SEPARATION MEASUREMENT 60 6.1 APPLIED PROCEDURES / LIMIT 60 6.1.1 TEST PROCEDURE 60 6.1.2 DEVIATION FROM STANDARD 60 6.1.3 TEST SETUP 60 6.1.4 EUT OPERATION CONDITIONS 60 6.1.5 TEST RESULTS 61 7 . BANDWIDTH TEST 67 7.1 APPLIED PROCEDURES / LIMIT 67 7.1.1 TEST PROCEDURE 67 7.1.2 DEVIATION FROM STANDARD 67 7.1.3 TEST SETUP 67 7.1.4 EUT OPERATION CONDITIONS 67 7.1.5 TEST RESULTS 68 8 . PEAK OUTPUT POWER TEST 74 8.1 APPLIED PROCEDURES / LIMIT 74 8.1.1 TEST PROCEDURE 74 8.1.2 DEVIATION FROM STANDARD 74 8.1.3 TEST SETUP 74 8.1.4 EUT OPERATION CONDITIONS 74 8.1.5 TEST RESULTS 75 9 . ANTENNA REQUIREMENT 81 9.1 STANDARD REQUIREMENT 81 9.2 EUT ANTENNA 81 10 . EUT TEST PHOTO 82 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Page 5 of 83 Report No.: NTEK-2013NT0506090F 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247(a)(1) Hopping Channel Separation PASS 15.247(b)(1) Peak Output Power PASS 15.247(c) Radiated Spurious Emission PASS 15.247(a)(iii) Number of Hopping Frequency PASS 15.247(a)(iii) Dwell Time PASS 15.247(a)(1) Bandwidth PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report Page 6 of 83 Report No.: NTEK-2013NT0506090F 1.1 TEST FACILITY NTEK Testing Technology Co., Ltd Add. : 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street, Bao‟an District, Shenzhen P.R. China. FCC Registration No.:238937; IC Registration No.:9270A-1 CNAS Registration No.:L5516 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 7 of 83 Report No.: NTEK-2013NT0506090F 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment Bluetooth Speaker Trade Name TOYO Model Name TY-S-001 Serial Model N/A Model Difference N/A Product Description The EUT is a Bluetooth Speaker Operation Frequency: 2402~2480 MHz Modulation Type: BT(1Mbps): GFSK BT EDR(2Mbps):∏/4-DQPSK BT EDR(3Mbps): 8-DPSK Bit Rate of Transmit…
