N9STY-T6MAIN CONTROLLER

User Instructions For Controller Device TY- T6 and TY-S-2400 1. Installation: FOR WALL MOUNTING Fasten the screws(pre-attached in the upper section of enclosure) and hook the unit to a wall ; Make sure the unit fits securely against the wall. FOR GROUND STAKIING Slide the ground stake into the slot on the base of the unit.Carefully press the stake into the ground. 2. Devices required: (a) iPhone, iPad, portable computer, desktop computer or other device with WiFi and blue tooth functioning capabilities 3.Features: (a) Regular mode (16 available functions) 16 Pre-programmed Settings Function 1 - Fast Chasing right to left from one light set to the other Function 2 - Fast Chasing left to right from one light set to another Function 3 - Slow to fast chasing right to left from one light set to another. Function 4 - Slow to fast chasing left to right from one light set to another. Function 5 - Flashing/Chasing combination Function 6 - Alternating flashing Function 7 - Bi-Directional Pulsing Function 8 - Bi-directional Chasing Function 9 - Steady on Function 10 - Strobing Function 11 - Random Flashing Function 12 - Bi-directional chasing with flashing Function 13 - Pulsing to Strobing feature. Function 14 - Bi-Directional Strobing Function 15 - Fade in / Fade out Function 16 - Combination Light Show (Continual looping of all the features) (b) Sensor mode As music plays through your blue tooth speaker, the lights will dance and flash to the rhythm of the music. (c ) Program mode - allows users to create their own program by selecting their desired lighting functions, time of each function and sequence. Free: Enhanced GloTEC Set Connectivity Category: WiFi multifunction controllable system with 16 pre-programmed settings, 10 user definable settings and one music sensor/synchronization mode Updated: Oct. 9, 2012 Sellers: retailers authorized by Roundtripping Ltd. (Lowes,.....etc.) Manufacturer: T & Y Electric (Shenzhen) Co. Ltd. Language: English 4. Operation Procedures: Plug your Christmas light strings or decorative lighting outfits into the outlets; (MAX 420 Watts total). Plug the main power cord into a power outlet (recommended to plug into a receptacle or extended receptacle protected by GFCI). (1) Regular mode (a) Access “App store” web site through compatible wireless device - iPhone, iPad, portable computer, desktop computer or other device with wi fi and blue tooth functioning capabilities (b) Download the program named “GloTEC” inside the App store. (c) Click in the “GloTEC” icon and log in. (d) After logging in, the prompts for the 16 built in functions will be displayed on the screen. (e) Select and click on the function you desire. In order to work properly and activate the function, the GloTEC receiver must be within 50 meters of your wireless device. To control the speed of the lights: (A) On the left hand side of the screen you will see a speed control bar which allows you to adjust the speed of the lights. This speed control bar can increase or decrease speed of the lights during most of the 16 pre-programmed functions or customized functions which are created by the user. This control bar will not have any effect on functions like steady burning, etc. that do not have any motion. (B) The speed rating can be adjusted from”0” (stop) to 100 (fastest setting). Use the arrows to move the control bar to your desired speed level. To control the brightness of the lights: (A) On the right hand side of the screen you will see a brightness control bar which allows you to adjust the brightness of the light set bulbs. This brightness control bar can increase or decrease the intensity of the light’s brightness during any of the 16 pre-programmed functions or customized functions which are created by the user. The brightness rating can be adjusted from “0” (very dim) to “100”(brightest setting). Use the arrows to move the control bar to your desired light brightness level (2) Sensor mode (a) Turn on the bluetooth speaker. When the “red lights” is on, the bluetooth speaker can play music sent from your iphone or ipod. When the “blue lights’ is on, the bluetooth speaker can play music from SD card. (b) Log in the “GloTEC” web site by clicking on the “GloTEC” icon and logging on. (c ) At the bottom of the screen you can see the”sensor mode” icon. Click on this “sensor mode icon”. (c ) Return to the Desk Top and click in the “Music icon” (?) (d) After you select your music and the music is playing though the blue tooth speaker, the lights and lighted decorations you have connected to the receiver will flash in synchronization to the music’s rhythm. (e) Inside the sensor mode there is the “volume” control bar which allows you to adjust the volume to your desired level. (3 ) Program mode (a) Log in the “GloTEC” web site by Clicking on the “GloTEC” icon and logging on. (b) At the bottom of the screen you can see the “program mode” icon. Click on this “program icon” (c ) After logging in, click on any “undefined” icon to begin creating your own light function. (d) At the top of the screen there is a horizontal bar showing the list of available functions. Select and click on your desired lighting function. (e) At the bottom of the screen is another control bar which allows you to adjust the duration of each lighting function you select, ranging from “1” to “60” seconds. (f) Select other functions you would like to include in your custom program along with a time duration. The maximum length of the entire program (combination of all the light settings you select) is 9 minutes. (g) Arrange them in a sequence which you would like them to play (h) Create a title/description for the program and then save it. ** repeat these steps when creating other custom programs** FCC Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference i…

Text truncated - open the document above for the full version.

Letter for Confidentiality Federal Communications Commission Authorization and Evaluation Division Date: Mar.15,2013 Confidentiality Request regarding application for certification of FCC ID: N9STY-T6 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: 1.Schematic 2.Theory of Operation 3.Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, We do not want these documents to be accessible to the general public. Sincerely, (签名人英文名): Dennis Wang (签名人职称):manager TOYO ELECTRIC MFG. CO., LTD. Tel: 00886-2-27026037 Fax: 00886-2-27026037 E-mail:[email protected]

External Photos

Label: Model: TY-T6 Date Code: 0513 120V AC 60Hz , 3.5 A, 420 Watts Module Use Frequency Range: 2400-2483.5MHz TOYO Electric Mfg. Co., Ltd FCC ID: N9STY-T6 Contains FCC ID: W2STLG10UA03 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this device must accept any interference received, including interference that may cause undesired operation.

Internal Photos

FCC TEST REPORT 47 CFR FCC Part 15 Subpart C 15.249 Report Reference No......................: FCC ID..............................................: TRE13010034 R/C:88666 N9STY-T6 Compiled by ( position+printed name+signature)..: File administrators Eric Zhang Supervised by ( position+printed name+signature)..: Test Engineer Tim Zhang Approved by ( position+printed name+signature)..: Manager Wenliang Li Date of issue.....................................: Mar 15, 2013 Testing Laboratory Name..............: Shenzhen Huatongwei International Inspection Co., Ltd Address.............................................: Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Applicant’s name............................: TOYO ELECTRIC MFG. Co., LTD Address.............................................: 9TH,FL 30 SEC 3 RENAI RD DAAN DISTRICT, TAIPEI 106 TAIWAN Manufacturer’s name.....................: T&Y ELECTRIC(SHENZHEN)Co., LTD Address.............................................: ANLIANG INDUSTRIAL ZONE, HENGGANG, LONGGANG DISTRICT,GD,CHINA Test specification: Standard..........................................: 47 CFR FCC Part 15 Subpart C & 15.249 ANSI C63.10: 2009 TRF Originator ..................................: Shenzhen Huatongwei International Inspection CO., Ltd Master TRF.......................................: Dated 2006-06 Shenzhen Huatongwei International Inspection Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Huatongwei International Inspection Co., Ltd is acknowledged as copyright owner and source of the material. Shenzhen Huatongwei International Inspection Co., Ltd takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment Under Test.................. : MAIN CONTROLLER Trade Mark .......................................: / Model/Type reference.......................: TY-T6 Listed Models ..................................: / Modulation ........................................: GFSK Result................................................: Complied Report No.: TRE13010034 Page 2 of 24 Issued: 2013-03-15 FCC ID: N9STY-T6 Shenzhen Huatongwei International Inspection Co., Ltd T E S T R E P O R T Test Report No. : TRE13010034 Mar 15, 2013 ______________________________________________________________________________________________ Date of issue Equipment under Test : MAIN CONTROLLER Model /Type : TY-T6 Listed Models : / Applicant : TOYO ELECTRIC MFG. Co., LTD Address : 9TH,FL 30 SEC 3 RENAI RD DAAN DISTRICT, TAIPEI 106 TAIWAN Manufacturer : T&Y ELECTRIC(SHENZHEN)Co., LTD Address : ANLIANG INDUSTRIAL ZONE, HENGGANG, LONGGANG DISTRICT,GD,CHINA Test Result according to the standards on page 4: Positive The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: TRE13010034 Page 3 of 24 Issued: 2013-03-15 FCC ID: N9STY-T6 Shenzhen Huatongwei International Inspection Co., Ltd Contents 1. TEST STANDARDS .................................................................. 4 2. SUMMARY............................................................................. 5 2.1. General Remarks 5 2.2. Equipment Under Test 5 2.3. Short description of the Equipment under Test (EUT) 5 2.4. EUT operation mode 5 2.5. Related Submittal(s) / Grant (s) 5 2.6. Modifications 5 3. TEST ENVIRONMENT............................................................... 6 3.1. Address of the test laboratory 6 3.2. Test Facility 6 3.3. Statement of the measurement uncertainty 7 3.4. Summary of standards and result 7 3.5. Environmental conditions 7 3.6. Equipments Used during the Test 8 4. TEST CONDITIONS AND RESULTS ............................................. 9 4.1. ANTENNA REQUIREMENT 9 4.2. Conducted Emissions Test 10 4.3. Radiated Emission Test 13 4.4. Out of band emissions 18 4.5. 20dB Bandwidth Measurement 19 5. TEST SETUP PHOTOS OF THE EUT .......................................... 20 6. EXTERNAL AND INTERNAL PHOTOS OF THE EUT ....................... 22 Report No.: TRE13010034 Page 4 of 24 Issued: 2013-03-15 FCC ID: N9STY-T6 Shenzhen Huatongwei International Inspection Co., Ltd 1. TEST STANDARDS The tests were performed according to following standards: 47 CFR FCC Rules Part 15.249: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, 5725-5850 MHz and 24.0 - 24.25 GHz. ANSI C63.10: 2009 – American National Standard for Teating Unlicensed Wireless Devices Report No.: TRE13010034 Page 5 of 24 Issued: 2013-03-15 FCC ID: N9STY-T6 Shenzhen Huatongwei International Inspection Co., Ltd 2. SUMMARY 2.1. General Remarks Date of receipt of test sample : Jan 08, 2013 Testing commenced on : Jan 10, 2013 Testing concluded on : Mar 15, 2013 2.2. Equipment Under Test Power supply system utilised Power supply voltage : ● 120V / 60 Hz ○ 115V / 60Hz ○ 12 V DC ○ 24 V DC ○ Other (specified in blank below) AC 120V/60Hz 2.3. Short description of the Equipment under Test (EUT) 2422MHz MAIN CONTROLLER (M/N: TY-T6) For more details, refer to the user’s manual of the EUT. Serial number: Prototype 2.4. EUT operation mode The EUT has been tested under typical operating condition. 2.5. Related Submittal(s) / Grant (s) This submittal(s) (test report) is intended for FCC ID: N9STY-T6 filing to comply with Section 15.249 of the FCC Part 15, Subpart C Rules. 2.6. Modifications No modifications were implemented to meet testing criteria. Report No.: TRE13010034 Page 6 of 24 Issued: 2013-03-15 FCC ID: N9STY-T6 Shenzhen Huatongwei International Inspection Co., Ltd 3. TEST ENVIRONMENT 3.1. Address of the test laboratory Shenzhen Huatongwei International Inspection Co., Ltd Keji Nan No.12 Road, Hi-tech Park, Shenzhen, China Phone: 86-755-26715686 Fax: 86-7…

Text truncated - open the document above for the full version.

test photos
