NBZNRM-6831Cellular Data Packet Radio Module

September 3, 1999 To:Frank Coperich FCC Application Processing Branch Re:Novatel Wireless FCC ID: NBZNRM-6831 Correspondence Reference Number:8701 EA Number: EA94035 Response to e-mail request for technical information dated 07/13/1999. Frank, We will respond to your letter point by point. 1.) Thank you. The emission classification of FXW is acceptable. 2.) We have measured the 99.75% Power Bandwidth at several places in the band using the –26 dBc methodology. Under worst case conditions we have found it to be 30 KHz. Please change the necessary bandwidth to 30K0. 3.) Please find attached the test report from MPB Technologies Inc. dated August 28, 1999 for radiated spurious emissions. 4.) Please find attached the test report from MPB Technologies Inc. dated August 28, 1999 for radiated ERP data. 5.) The SAR report shows the correct conducted power reading as 480 mW as manufactured. The equipment available for the EMC report was an engineering test sample. 6.) The manual supplied was preliminary. No booster amplifiers or antennas other than what was tested will be marketed. The Applicant is aware that other antenna combinations will require retesting and submission to the Commission. 7.) Please ignore earlier MPE data and warning statements. 8.) Thank you for this information. Sincerely, William Graff Director of Engineering M. Flom Associates

NOVATEL WIRELESS FCC ID:NBZNRM-6831 CANADA: MODEL:NRM-6831 BOM:01016602 MADE IN CANADA THIS PRODUCT COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE CONDITION THAT THIS DEVICE DOES NOT CAUSE HARMFUL INTERFERENCE. THIS PRODUCT CONTAINS AN RSA™ RC4® SYMMETRIC STREAM CIPHER FOR DATA LINK CONFIDENTIALITY. IP HEADER COMPRESSION SOFTWARE DEVELOPED BY THE UNIVERSITY OF CALIFORNIA BERKELEY © 1989 MERLIN Type II Wireless IP Modem ™ Insert this side up.

FCC ID: NBZNRM-6831 MFA p9940002, d9940062 Date:April 23, 1999 Mailing:Novatel Wireless Technologies Ltd. 6715 - 8th St., N.E., Suite 200 Calgary, AB T2E 7H7 Canada Attention of:Mervin Coleman, Director for Advanced Technology (403) 295-4813; FAX: -4801 Equipment:NRM-6831 "Merlin" FCC ID:NBZNRM-6831 P.O. Number:NW52254 FCC Rules:1.1310 (MPE) Gentlemen: Enclosed please find your copy of the Supplemental Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. Please allow from 6-8 weeks to hear from the Commission, who may request additional data or information, and even a sample for pre-grant audit testing. Should you need any clarification, just fax or phone. Thank you again for this order - it has been a pleasure to be of service. Sincerely yours, Morton Flom, P. Eng. enclosure(s) MF/cvr FCC ID: NBZNRM-6831 MFA p9940002, d9940062 Date:April 23, 1999 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P.O. Box 358315 Pittsburgh, PA 15251-5315 Attention:Authorization & Evaluation Division Applicant:Novatel Wireless Technologies Ltd. Equipment:NRM-6831 "Merlin" FCC ID:NBZNRM-6831 FCC Rules:1.1310 (MPE)and 47 CFR 1.1307, Environmental Assessment Gentlemen: On behalf of the Applicant, enclosed please find the Supplemental Test Data Report, the whole for Environmental Assessment (MPE) of the referenced equipment as shown. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Morton Flom, P. Eng. enclosure(s) cc: Applicant MF/cvr FCC ID: NBZNRM-6831 MFA p9940002, d9940062 Sub-part 1.1307: SUPPLEMENTAL REPORT ENVIRONMENTAL ASSESSMENT General Population / Uncontrolled Exposure, Maximum Permissible Exposure and Specific Absorption Rate EQUIPMENT IDENTIFICATION Novatel Wireless Technologies Ltd. FCC ID: NBZNRM-6831 DATE OF REPORT April 23, 1999 SUPERVISED BY:Morton Flom, P. Eng. FCC ID: NBZNRM-6831 MFA p9940002, d9940062 TABLE OF CONTENTS RULEDESCRIPTIONPAGE .Test Report1 .Identification of the Equipment Under Test2 .Standard Test Conditions and Engineering Practices3 1.1310Environmental Assessment4 FCC ID: NBZNRM-6831 MFA p9940002, d9940062 PAGE NO.1 of 7. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a)TEST REPORT (SUPPLEMENTAL) b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number:d9940062 d) Client:Novatel Wireless Technologies Ltd. 6715 - 8th St., N.E., Suite 200 Calgary, AB T2E 7H7 Canada e) Identification:NRM-6831 "Merlin" FCC ID: NBZNRM-6831 Description:Cellular Data Packet Radio Module f) EUT Condition:Not required unless specified in individual tests. g) Report Date:April 23, 1999 EUT Received:April 6, 1999 h, j, k):As indicated in individual tests. i) Sampling method:No sampling procedure used. l) Uncertainty:In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results:The results presented in this report relate only to the item tested. o) Reproduction:This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: NBZNRM-6831 MFA p9940002, d9940062 PAGE NO.2 of 7. IDENTIFICATION OF THE EQUIPMENT UNDER TEST (EUT) NAME AND ADDRESS OF APPLICANT: Novatel Wireless Technologies Ltd. 6715 - 8th St., N.E., Suite 200 Calgary, AB T2E 7H7 Canada MANUFACTURER: Sanmina Canada ULC 675 - 9 th Street NE Calgary, AB Canada T2E 8R9 FCC ID:NBZNRM-6831 MODEL NO:NRM-6831 "Merlin" DESCRIPTION:Cellular Data Packet Radio Module TYPE OF EMISSION:40K0F2D FREQUENCY RANGE, MHz:824.04 to 848.97 POWER RATING, Watts:0.006 to 0.6 xSwitchableVariableN/A MODULATION:AMPS TDMA CDMA xGMSK ANTENNA:HELICAL xMONOPOLE OTHER FCC ID: NBZNRM-6831 MFA p9940002, d9940062 PAGE NO.3 of 7. STANDARD TEST CONDITIONS and ENGINEERING PRACTICES Except as noted herein, the following conditions and procedures were observed during the testing: In accordance with ANSI C63.4-1992, section 6.1.9, and unless otherwise indicated in the specific measurement results, the ambient temperature of the actual EUT was maintained within the range of 10° to 40°C (50° to 104 °F) unless the particular equipment requirements specify testing over a different temperature range. Also, unless otherwise indicated, the humidity levels were in the range of 10% to 90% relative humidity. Prior to testing, the EUT was tuned up in accordance with the manufacturer's alignment procedures. All external gain controls were maintained at the position of maximum and/or optimum gain throughout the testing. Measurement results, unless otherwise noted, are worst case measurements. FCC ID: NBZNRM-6831 MFA p9940002, d9940062 PAGE NO.4 of 7. Name of test:Environmental Assessment Specification:FCC:47 CFR 1.1310 Measurement Guide:ANSI/IEEE C95.1 1992 Test Equipment:Maximum Permissible Exposure (MPE) measurement system, consisting of: Narda 8717-1174R, Radiation meter Narda 8761D, E-field probe (300 kHz – 3 GHz) (Calibrated Nov-98) Measurement Procedure: 1. The following measurements were performed with a Narda probe using ANSI/IEEE C95.1 as a guide. 2. Prior to making any measurements, the measurements system was calibrated in accordance with the manufacturer’s procedures. 3. The EUT’s radiating element (antenna) was placed on a 1 m tall table for ease of testing. For equipment normally operated on a metal surface, a ground plane was used. 4. The remaining equipment necessary to operate the EUT was maintained at a distance from the measurement arrangement suitable to minimize interference with the measurements. 5. The minimum safe distance was calculated from the formula Power Density = EIRP / 4πR 2 (Peak Watts/m 2 ). The calculation is shown with the measurement data. 6. With the EUT operating at maximum power, a search was initiated for worst case emissions with the probe raised and lowered over a range of 0.2 to 2 meters in height and over a ho…

Text truncated - open the document above for the full version.

Certification Report on Specific Absorption Rate (SAR) Experimental Analysis Novatel Wireless Technologies Ltd. PCMCIA Card (Merlin) Date: 24 June, 1999 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories. Page 1 of 29© APREL Project #: NVWB-Merlin - 3247 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] CERTIFICATION REPORT Subject:Specific Absorption Rate (SAR) Experimental Analysis Product:PCMCIA Card Model:Merlin Client:Novatel Wireless Technologies Ltd. Address:Suite 200 6715 – 8 th Street N.E. Calgary, Alberta T2E 7H7 Project #:NVWB-MERLIN-3247 Prepared by:APREL Laboratories 51 Spectrum Way Nepean, Ontario K2R 1E6 Tested by___________________________ Date: __________________ Heike Wuenschmann, C.E.T. Submitted by____________________________ Date: _________________ Dr. Paul G. Cardinal Director, Laboratories Approved by_____________________________ Date: _________________ Dr. Jacek J. Wojcik, P. Eng. Page 2 of 29© APREL Project #: NVWB-Merlin - 3247 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] FCC ID:NBZNRM - 6831 Applicant:Novatel Wireless Technologies Ltd. Equipment:PCMCIA card Model:Merlin Standard:FCC 96 –326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency Radiation ENGINEERING SUMMARY This report contains the results of the engineering evaluation performed on a Compaq Laptop with a Merlin PCMCIA card. The measurements were carried out in accordance with FCC 96-326. The Merlin PCMCIA card was evaluated for its maximum power level of 480 mW (26.8 dBm). The Laptop with PCMCIA card was tested at high, middle, and low frequencies, with the maximum SAR coinciding with the peak performance RF output power of channel 991 (low, 824 MHz). Test data and graphs are presented in this report. This unit as tested, and as it will be marketed and used (with a warning in the manual to keep bystanders at least 7 mm or ¼′′ from the antenna), is found to be compliant with the FCC 96- 326 requirement, for an uncontrolled RF exposure environment. . Page 3 of 29© APREL Project #: NVWB-Merlin - 3247 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] TABLE OF CONTENTS 1.Introduction....................................................................................................................4 2.Applicable Documents...................................................................................................4 3.Equipment Under Test...................................................................................................4 4.Test Equipment..............................................................................................................5 5.Test Methodology..........................................................................................................5 6.Test Results....................................................................................................................6 6.1.Transmitter Characteristics.................................................................................6 6.2.SAR Measurements.............................................................................................7 7.Analysis..........................................................................................................................9 8.Conclusions..................................................................................................................10 Appendix A...........................................................................................................................11 Appendix B...........................................................................................................................17 Appendix C...........................................................................................................................25 Appendix D...........................................................................................................................26 Appendix E............................................................................................................................29 Page 4 of 29© APREL Project #: NVWB-Merlin - 3247 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] 1. INTRODUCTION Tests were conducted to determine the Specific Absorption Rate (SAR) of a sample of a Novatel Wireless Merlin PCMCIA card. These tests were conducted at APREL Laboratories’ facility located at 51 Spectrum Way, Nepean, Ontario, Canada. A view of the SAR measurement setup can be seen in Appendix A Figure 1. This report describes the results obtained. 2. APPLICABLE DOCUMENTS The following documents are applicable to the work performed: 1) FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio- Frequency Radiation 2) ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. 3) ANSI/IEEE 95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields – RF and Microwave. 4) OET Bulletin 65 (Edition 97-01) Supplement C (Edition 97-01), “Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields”. 3. EQUIPMENT UNDER TEST • Novatel Wireless Merlin PCMCIA card (00.60.D6.02.00.B3) • Compaq Laptop Model Armada 7730MT The PCMCIA card’s antenna is a ¼ wavelength rotateable antenna. The antenna specifications supplied by the manufacturer can be found in Appendix B. Page 5 of 29© APREL Project #: NVWB-Merlin - 3247 51 Spectrum WayTel. (613) 820-2730 Nepean, Ontario, K2R 1E6Fax (613) 820 4161 e-mail: [email protected] 4. TEST EQUIPMENT • Narda 8021B miniature E-field probe, s/n…

Text truncated - open the document above for the full version.

FCC ID: NBZNRM-6831 MFA p9940002, d9940068 Date:April 23, 1999 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P.O. Box 358315 Pittsburgh, PA 15251-5315 Attention:Authorization & Evaluation Division Applicant:Novatel Wireless Technologies Ltd. Equipment:NRM-6831 "Merlin" FCC ID:NBZNRM-6831 Model:NRM-6831 "Merlin" FORM 731 Confirmation Number: Gentlemen: As per instructions received, enclosed herewith please find completed Remittance Advice Form 159 for the referenced equipment, bearing original signature, and the application having been electronically filed. Sincerely yours, Morton Flom, P. Eng. enclosure(s) CERTIFIED MAIL, R.R.R. cc: Visa cc: File MF/cvr FCC ID: NBZNRM-6831 MFA p9940002, d9940068 Date:April 23, 1999 Federal Communications Commission EQUIPMENT APPROVAL SERVICES P.O. Box 358315 Pittsburgh, PA 15251-5315 Attention:Authorization & Evaluation Division Applicant:Novatel Wireless Technologies Ltd. Equipment:NRM-6831 "Merlin" FCC ID:NBZNRM-6831 FCC Rules:22H, 1.1310 (MPE), Confidentiality Gentlemen: On behalf of the Applicant, enclosed please find Application Form 731, Engineering Test Report and all pertinent documentation, the whole for approval of the referenced equipment as shown. Filing fees are attached. We trust the same is in order. Should you need any further information, kindly contact the writer who is authorized to act as agent. Sincerely yours, Morton Flom, P. Eng. enclosure(s) CERTIFIED MAIL, R.R.R. cc: Applicant MF/cvr FCC ID: NBZNRM-6831 MFA p9940002, d9940068 LIST OF EXHIBITS (FCC CERTIFICATION (CELLULAR TRANSMITTERS) - REVISED 9/28/98) APPLICANT:Novatel Wireless Technologies Ltd. FCC ID:NBZNRM-6831 BY APPLICANT: 1. LETTER OF AUTHORIZATION 2. IDENTIFICATION DRAWINGS, 2.1033(c)(11) LABEL LOCATION OF LABEL COMPLIANCE STATEMENT LOCATION OF COMPLIANCE STATEMENT 3. PHOTOGRAPHS, 2.1033(c)(12) 4. CONFIDENTIALITY REQUEST: 0.457 and 0.459 5. DOCUMENTATION: 2.1033(c) (3)INSTALLATION/OPERATING MANUAL (9)TUNE-UP/ALIGNMENT PROCEDURE (10)SCHEMATIC DIAGRAM (10)CIRCUIT DESCRIPTION 6. ATTESTATION: ESN: Section 22.919 7. ATTESTATION: OET: Section 22.933 BY M.F.A. INC. A.TESTIMONIAL & STATEMENT OF CERTIFICATION B.STATEMENT OF QUALIFICATIONS FCC ID: NBZNRM-6831 MFA p9940002, d9940068 Sub-part 2.1033(c): EQUIPMENT IDENTIFICATION FCC ID: NBZNRM-6831 NAMEPLATE DRAWING ATTACHED, EXHIBIT 1. LOCATION AS PER LABEL DRAWING(S) DATE OF REPORT April 23, 1999 SUPERVISED BY:Morton Flom, P. Eng. FCC ID: NBZNRM-6831 MFA p9940002, d9940068 THE APPLICANT HAS BEEN CAUTIONED AS TO THE FOLLOWING: 15.21INFORMATION TO USER. The users manual or instruction manual for an intentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 15.27(a)SPECIAL ACCESSORIES. Equipment marketed to a consumer must be capable of complying with the necessary regulations in the configuration in which the equipment is marketed. Where special accessories, such as shielded cables and/or special connectors are required to enable an unintentional or intentional radiator to comply with the emission limits in this part, the equipment must be marketed with, i.e. shipped and sold with, those special accessories. However, in lieu of shipping or packaging the special accessories with the unintentional or intentional radiator, the responsible party may employ other methods of ensuring that the special accessories are provided to the consumer, without additional charge. Information detailing any alternative method used to supply the special accessories for a grant of equipment authorization or retained in the verification records, as appropriate. The party responsible for the equipment, as detailed in § 2.909 of this chapter, shall ensure that these special accessories are provided with the equipment. The instruction manual for such devices shall include appropriate instructions on the first page of text concerned with the installation of the device that these special accessories must be used with the device. It is the responsibility of the user to use the needed special accessories supplied with the equipment. FCC ID: NBZNRM-6831 MFA p9940002, d9940068 TABLE OF CONTENTS RULEDESCRIPTIONPAGE .Test Report1 2.1033(c)General Information Required2 2.1033(c)(14)Rule Summary4 .General Information5 .Standard Test Conditions and Engineering Practices6 2.1046 Carrier Output Power (Conducted)7 2.1049(c)(1)Emission Masks (Occupied Bandwidth)9 2.1055(a)(1) Frequency Stability (Temperature Variation)23 2.1055(b)(1)Frequency Stability (Voltage Variation)26 FCC ID: NBZNRM-6831 MFA p9940002, d9940068 PAGE NO.1 of 26. Required information per ISO/IEC Guide 25-1990, paragraph 13.2: a)TEST REPORT b) Laboratory: (FCC: 31040/SIT) (Canada: IC 2044) M. Flom Associates, Inc. 3356 N. San Marcos Place, Suite 107 Chandler, AZ 85225 c) Report Number:d9940068 d) Client:Novatel Wireless Technologies Ltd. 6715 - 8th St., N.E., Suite 200 Calgary, AB T2E 7H7 Canada e) Identification:NRM-6831 "Merlin" FCC ID: NBZNRM-6831 Description:Cellular Data Packet Radio Module f) EUT Condition:Not required unless specified in individual tests. g) Report Date:April 23, 1999 EUT Received:April 6, 1999 h, j, k):As indicated in individual tests. i) Sampling method:No sampling procedure used. l) Uncertainty:In accordance with MFA internal quality manual. m) Supervised by: Morton Flom, P. Eng. n) Results:The results presented in this report relate only to the item tested. o) Reproduction:This report must not be reproduced, except in full, without written permission from this laboratory. FCC ID: NBZNRM-6831 MFA p9940002, d9940068 PAGE NO.2 of 26. LIST OF GENERAL INFORMATION REQUIRED FOR CERTIFICATION IN ACCORDANCE WITH FCC RULES AND REGULATIONS, VOLUME II, PART 2 AND TO 22H, 1.1310 (MPE), Confidentiality Sub-part 2.1033 (c)(1):NAME AND ADDRESS OF APPLICANT: Novatel Wireless Technologies Ltd. 6715 - 8th St., N.E., Suite 200 Calgary, AB T2E 7H7 C…

Text truncated - open the document above for the full version.

27 East Lake HillP.O. Box 3485 Airdrie, AlbertaAirdrie, Alberta T4B 2B7 T4B 2B7Phone: (403) 912-0037 Fax: (403) 912-0083 3 September, 1999 SUBJECT: FCC CONFIRMATION NUMBER EA94035 (PART 22 AND 15 TESTING) This letter is to verify that the following testing was performed; Product:Merlin Serial number:01.6D FCC ID number:NBZNRM-6831 Standard tested to:CFR 47 Part 22, 15 Date performed:August 27-28, 1999 Lab:MPB Technologies’ “Electronics Test Centre” (Airdrie) Technologist:Ian Guldberg & Jeffery Taylor The following is the ERP measurements Frequency (MHz) PolarityPower into Dipole (dBm) Azimuth (degrees) Height of Rx antenna (cm) 824.04Vertical22.6201161 836.5195Vertical23.3325157 848.97Vertical26.4207156 824.04Horizontal16.8187167 836.5195Horizontal18.247284 848.97Horizontal15.8346273 The following data was used for calculating the Part 22 limits Frequency (MHz) PolarityAzimuth (degrees) Height of Rx antenna (cm) Level Measured at Spectrum Analyzer C±45 kHz * limit 824.04Vertical201161-13.6 dBm84.6 836.5195Vertical325157-14.1 dBm83.4 848.97Vertical207156-13.4 dBm80.8 824.04Horizontal187167-16.6 dBm87.1 836.5195Horizontal47284-18.0 dBm84.2 848.97Horizontal346273-16.9 dBm87.6 *see attached sample calculation Sincerely Jeffery Taylor, T.T. EMI/EMC Test Technologist 27 East Lake HillP.O. Box 3485 Airdrie, AlbertaAirdrie, Alberta T4B 2B7 T4B 2B7Phone: (403) 912-0037 Fax: (403) 912-0083 Sample Calculation of Part 22 Emissions Limit (Vertical Polarization, 824.04MHz) Calculation of Carrier Field strength at measuring antenna: Carrier power measured at spectrum analyser = -13.6 dBm Cable loss from measuring antenna to spectrum analyser = 3.8 dB Carrier Power at measuring antenna port = -13.6 dBm + 3.8 dB = -9.8 dBm Carrier Voltage at measuring antenna port = -9.8 dBm + 107dBuV/mW = 97.2 dBuV (for 50 ohm load) Antenna factor at 824 MHz = 23 dB/m Carrier Field strength at measuring antenna = 97.2 dBuV + 23 dB/m = 120.2 dBuV/m Calculation of Attenuation requirement for Part 22: Measured ERP of Carrier = 22.6 dBm = 0.182 W Required attenuation below carrier per Part 22 specification = 43 + 10log(P) = 35.6 dB Emission Limit for Field Strength Measurements: (Carrier Field strength at measuring antenna) – (required attenuation) = 120.2 dBuV/m – 35.6 dB = 84.6 dBuV/m 97.0 -3.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 88.0030.0035.0040.0045.0050.0055.0060.0065.0070.0075.0080.0085.00 EMI AMB LIM 302A17Project #: NovatelCompany: MerlinProduct: August 27, 1999Date & Time: Radiated EmissionsRadiated Emissions Vertical PolarityVertical Polarity FCC PART 22FCC PART 22 12:29 PM 13 Plot Number: 01.6dSerial #: dBuV/m MHz 100.000 kHz RBW 300.000 kHzVBW: 50.00 msSweep Time: 0.00 dBAn Atten: 0.00 dB PR Atten: 77.00 dBuV/m Ref. Lev: 3 metersDistance: Title: Operational TxMode of Operation: Ian GuldbergTechnologist: Channel 991 (824.04 MHz TX)Comments: 23/4/1998 limit.dat2/9/1999 ofts3m.dat16/6/1999 04318v3.dat Associated Files 97.0 -3.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 200.0088.00100.00110.00120.00130.00140.00150.00160.00170.00180.00190.00 EMI AMB LIM 302A17Project #: NovatelCompany: MerlinProduct: August 27, 1999Date & Time: Radiated EmissionsRadiated Emissions Vertical PolarityVertical Polarity FCC PART 22FCC PART 22 12:25 PM 2 Plot Number: 01.6dSerial #: dBuV/m MHz 100.000 kHz RBW 300.000 kHzVBW: AutoSweep Time: 0.00 dBAn Atten: 0.00 dB PR Atten: 77.00 dBuV/m Ref. Lev: 3 metersDistance: Title: Operational TxMode of Operation: Ian GuldbergTechnologist: Channel 991 (824.04 MHz TX)Comments: 23/4/1998 limit.dat2/9/1999 ofts3m.dat16/6/1999 04318v3.dat Associated Files 137.0 -3.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 100.0 110.0 120.0 130.0 1000.00200.00300.00400.00500.00600.00700.00800.00900.00 EMI AMB LIM 302A17Project #: NovatelCompany: MerlinProduct: August 27, 1999Date & Time: Radiated EmissionsRadiated Emissions Vertical PolarityVertical Polarity FCC PART 22FCC PART 22 12:21 PM 3 Plot Number: 01.6dSerial #: dBuV/m MHz 100.000 kHz RBW 300.000 kHzVBW: AutoSweep Time: 0.00 dBAn Atten: 0.00 dB PR Atten: 77.00 dBuV/m Ref. Lev: 3 metersDistance: Title: Operational TxMode of Operation: Ian GuldbergTechnologist: Channel 991 (824.04 MHz TX)Comments: 23/4/1998 limit.dat2/9/1999 ofts3m.dat16/6/1999 04318v3.dat Associated Files 97.0 -3.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 2000.001000.001100.001200.001300.001400.001500.001600.001700.001800.001900.00 EMI AMB LIM 302A17Project #: NovatelCompany: MerlinProduct: August 27, 1999Date & Time: Radiated EmissionsRadiated Emissions Vertical PolarityVertical Polarity FCC PART 22FCC PART 22 12:17 PM 4 Plot Number: 01.6dSerial #: dBuV/m MHz 1.000 MHz RBW 300.000 kHzVBW: AutoSweep Time: 0.00 dBAn Atten: 0.00 dB PR Atten: 97.00 dBuV/m Ref. Lev: 3 metersDistance: Title: Operational TxMode of Operation: Ian GuldbergTechnologist: Channel 991 (824.04 MHz TX)Comments: 23/4/1998 limit.dat2/9/1999 ofts3m.dat16/6/1999 04318v3.dat Associated Files 97.0 -3.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 5000.002000.002250.002500.002750.003000.003250.003500.003750.004000.004250.004500.004750.00 EMI AMB LIM 302A17Project #: NovatelCompany: MerlinProduct: August 28, 1999Date & Time: Radiated EmissionsRadiated Emissions Vertical PolarityVertical Polarity FCC PART 22FCC PART 22 10:52 AM 5 Plot Number: 01.6dSerial #: dBuV/m MHz 1.000 MHz RBW 1.000 MHzVBW: AutoSweep Time: 20.00 dBAn Atten: 0.00 dB PR Atten: 97.00 dBuV/m Ref. Lev: 3 metersDistance: Title: Operational TxMode of Operation: Ian GuldbergTechnologist: Channel 991Comments: 9/5/1997 limit.dat2/9/1999 31/12/1903 ofts3m.dat16/6/1999 09588v3.dat Associated Files 97.0 -3.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 90.0 10000.005000.005500.006000.006500.007000.007500.008000.008500.009000.009500.00 EMI AMB LIM 302A17Project #: NovatelCompany: MerlinProduct: August 28, 1999Date & Time: Radiated EmissionsRadiated Emissions Vertical PolarityVertical Polarity FCC PART 22FCC PART 22 10:56 AM 6 Plot Number: 01.6dSerial #: dBuV/m MH…

Text truncated - open the document above for the full version.
