NBZNRM6834MINSTREL S Wireless CDPD modem

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 9 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 User’s Manual www.novatelwireless.com Toll Free: 1-888-888-9231 As shown below, your Minstrel S TM can be ready to download web pages and send and receive email in just a few steps. For more detailed information on setting up your Minstrel S, read the Getting Started section of the Minstrel S User Guide . Insert the Minstrel S into the Springboard TM expansion slot of your Visor TM . Remove the slot protector and insert the Minstrel S into the slot until the connectors are secure. The Modem Manager software, which controls the modem’s connection to the Wireless IP network, will automatically launch. Start the Setup Wizard utility to begin configuration of the Minstrel S. Once the Minstrel screen appears, tap the Menu icon and select Setup Wizard from the Minstrel menu. Follow the directions on the screen to configure the Minstrel S. As directed, select the Wireless IP network provider you wish to use and contact the provider to set up an account. When prompted, enter the IP and DNS addresses and test the network registration. Install email and web browsing applications on your Visor. Install any email and web browsing applications you would like to use on your Visor following the directions provided by the software manufacturer. Charge the Minstrel S battery. The Minstrel S is shipped with a partially charged battery and, therefore, it is necessary to charge the battery before the modem is used. The battery status LED on the front of the Minstrel S flashes green when the battery is being charged and is solid green when the battery is fully charged. Connect to the Wireless IP network. Once your Minstrel S has been configured, you can connect to the Wireless IP network simply by inserting your Minstrel S into the Visor’s expansion slot. The Modem Manager software will automatically launch and register the modem to the network. Congratulations! Now that your Minstrel S has registered to the Wireless IP network, you can send and receive data across the Internet using your Visor and just about any email or web browsing application you choose. Quick Start Guide As shown below, your Minstrel S TM can be ready to download web pages and send and receive email in just a few steps. For more detailed information on setting up your Minstrel S, read the Getting Started section of the Minstrel S User Guide . Insert the Minstrel S into the Springboard TM expansion slot of your Visor TM . Remove the slot protector and insert the Minstrel S into the slot until the connectors are secure. The Modem Manager software, which controls the modem’s connection to the Wireless IP network, will automatically launch. Start the Setup Wizard utility to begin configuration of the Minstrel S. Once the Minstrel screen appears, tap the Menu icon and select Setup Wizard from the Minstrel menu. Follow the directions on the screen to configure the Minstrel S. As directed, select the Wireless IP network provider you wish to use and contact the provider to set up an account. When prompted, enter the IP and DNS addresses and test the network registration. Install email and web browsing applications on your Visor. Install any email and web browsing applications you would like to use on your Visor following the directions provided by the software manufacturer. Charge the Minstrel S battery. The Minstrel S is shipped with a partially charged battery and, therefore, it is necessary to charge the battery before the modem is used. The battery status LED on the front of the Minstrel S flashes green when the battery is being charged and is solid green when the battery is fully charged. Connect to the Wireless IP network. Once your Minstrel S has been configured, you can connect to the Wireless IP network simply by inserting your Minstrel S into the Visor’s expansion slot. The Modem Manager software will automatically launch and register the modem to the network. Congratulations! Now that your Minstrel S has registered to the Wireless IP network, you can send and receive data across the Internet using your Visor and just about any email or web browsing application you choose. Quick Start Guide www.novatelwireless.com Toll Free: 1-888-888-9231 QSG-90023060 Version B Versio n B QSG-90023060 1 Minstrel S TM User GuideVersion B 90023058 2 Minstrel S TM User GuideVersion B 90023058 The information contained in this document is subject to change without notice and should not be construed as a commitment by Novatel Wireless Inc. unless such commitment is expressly given in a covering document. The information herein is the exclusive property of Novatel Wireless Inc. No part of this publication may be reproduced or transmitted in any form or by any means including electronic storage, repro- duction, execution, or transmission without the prior written consent of Novatel Wireless Inc. © 2000 Novatel Wireless, Inc. All rights reserved. 3 Minstrel S TM User GuideVersion B 90023058 Getting Started....................................................................................................................................... 4 Welcome.................................................................................................................................... 5 Requirements ............................................................................................................................ 6 Overview of the Minstrel S Modem............................................................................................ 7 Overview of the Minstrel S Software ....................................................................................... 10 Charging the Battery................................................................................................................ 11 Installing the Minstrel S Software .....................................…

Text truncated - open the document above for the full version.

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 1 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 Authorization letter Letter requesting Confidentiality Letter from Novatel describing the device’s major component

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 11 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 Declaration of Conformity Letter

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Table of Contents Wireless CDPD Modem Minstrel S FCC ID: NBZNRM6834 Novatel Wireless Technologies Ltd. C C O O V V E E R R L L E E T T T T E E R R Exhibit 1: Authorization Letter and, Request for confidentiality Letter from Novatel describing the device’s major component Exhibit 2:Engineering Report (ERP & Spurious) Exhibit 3: Technical Descriptions and Tune-up Procedure (Confidential) Exhibit 4: FCC ID Label and location Exhibit 5:Photographs of the Equipment Internal and External Exhibit 6: Block Diagram, Mechanical/Assembly Drawings, & Antenna Specifications(Confidential) Exhibit 7: Schematic Diagram (Confidential) Exhibit 8:Parts List (Confidential) Exhibit 9:User’s Manual Exhibit 10:SAR Report (Includes Test Set-up Photographs) Exhibit 11: Declaration of Conformity Letter

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 5 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 Photographs of the Equipment Internal External

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 4 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 FCC ID Label PART NUMBER REVISION NUMBER DESCRIPTION DATE CREATED PMS COLORS DO NOT SCALE/EDIT ARTWORK AW-XXXXXXXXX 1 This is the graphic that will pad print directly to the backside of the shell. It must be printed exactly where it appears here. 08/08/00 White (represented by red) BOTTOM SHELL MINSTREL S BLACK= DO NOT PRINT RED REPRESENTS WHITE MINSTREL S Wireless Springboard Modem FCC ID: NBZNRM6834 CANADA: XXXXXXXXXX

Assessment of Compliance for Measurement of Effective Radiated Power (ERP) in accordance with the FCC Rules & Regulations Part 2.1046 Wireless CDPD Modem Minstrel S Novatel Wireless Technologies Ltd. 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] August 2000 NVWB-MINSTREL S -3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories August 2000 Page 2 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 FCC ID: NBZNRM6834 Applicant:Novatel Wireless Technologies Ltd. Equipment:Wireless CDPD Modem Model:Minstrel S Standard:FCC Rules and Regulations Part 2.1046 ENGINEERING SUMMARY This report contains the results of the effective radiated power (ERP) measurement performed on a NOVATEL WIRELESS Minstrel S wireless CDPD modem. The measurements were carried out in accordance with the FCC Rules and Regulations Part 2.1046. The product was evaluated for ERP when it was set at the maximum power level. The Minstrel S wireless CDPD modem is an attachment for the Handspring Visor PDA. Minstrel S was tested for ERP at high, middle, and low frequencies with the maximum ERP obtained at channel No.: 991 with the frequency being 824.04 MHz. The test data is presented in this report under the section: Test Results. The measured ERP is 0.191 W. (The results presented in this report relate only to the sample tested) August 2000 Page 3 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 Summary of the Results Test DescriptionPage No. Test Set-up Figure No. Results Summary RF Power Output as Radiated Ref. Paragraph 2.104681Passed August 2000 Page 4 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 INTRODUCTION General This report describes the results of the effective radiated power (ERP) measurement conducted on a Novatel Wireless Minstrel S wireless CDPD modem herein referred to as DUI (Device under Investigation) Test Facility The tests were performed for Novatel by APREL Laboratories at APREL’s EMI facility located in Nepean, Ontario, Canada. The laboratory operates an (3m and 10m) Open Area Test Site (OATS). The measurement facility is calibrated in accordance with ANSI C63.4-1992. A description of the measurement facility in accordance with the radiated and AC line conducted test site criteria per ANSI C63.4-1992 is on file with the Federal Communications Commission and is in compliance with the requirements of Section 2.948 of the Commissions rules and regulations. APREL’s registration number is: 90416 APREL is accredited by Standard Council of Canada, under PALCAN program (ISO Guide 25). APREL is also accredited by Industry Canada (formerly DOC) and recognised by the Federal Communications Commissions (FCC). Standard The evaluation and analysis were conducted in accordance with FCC Rules and Regulations Parts 2.1046 and the appropriate limits. Test Equipment The test equipment used during the evaluation is listed in Appendix A with calibration due dates. Environmental Conditions Measurements were conducted in open area test site. - Temperature:15 °C ± 2 - Relative Humidity:30 - 50 % August 2000 Page 5 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 - Air Pressure:101 kPa ± 3 FCC SUBMISSION INFORMATION FCC ID: NBZNRM6834 Equipment:Wireless CDPD Modem Model:Minstrel S For:Certification Applicant:Novatel Wireless Technologies Ltd. Suite 200 6715-8 th Street, N.E. Calgary, Alberta Canada, T2E 7H7 Manufacturer: Novatel Wireless Technologies Ltd. Suite 200 6715-8 th Street, N.E. Calgary, Alberta Canada, T2E 7H7 Evaluated by:APREL Laboratories 51 Spectrum Way Nepean, Ontario Canada K2R 1E6 August 2000 Page 6 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 MANUFACTURER’S DATA FCC ID No: NBZNRM6834 Equipment Type:Wireless CDPD Modem Model:Minstrel S Reference:FCC Rules and Regulations Parts 2 and Part 22 Manufacturer:Novatel Wireless Technologies Ltd. Power Source:DC Battery Development Stage of Unit:Production GENERAL SPECIFICATIONS 1.Frequency Range:824 to 849 MHz (Transmitter) Output Power:0.191 W ERP 3. Frequency Tolerance:2.5 ppm 4.Type of Modulation:GMSK 5.Emission Designators(See 47 CFR § 2.201 and §2.202) 28K8FXW 6. Antenna Impedance:50 Ohms August 2000 Page 7 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 N N o o v v a a t t e e l l W W i i r r e e l l e e s s s s TEST RESULTS FOR Effective Radiated Power (ERP) Of Novatel Wireless Minstrel S CDPD modem August 2000 Page 8 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 Test:RF Power Output as Radiated (ERP) Ref.:FCC Part 2 paragraph 2.1046 Criteria:N/A Set-up:See Figure No. 1. Equipment:See Appendix A. Methodology:RF Power Measurement by Radiated Method (ERP): Test site: The radiated RF power measurement was taken at APREL Laboratory’s open area test site (OATS). This open area test …

Text truncated - open the document above for the full version.

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 2 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 Engineering Reports (With Test Set-up Photographs) (Two Reports ERP & Spurious) Assessment of Compliance for Measurement of Field Strength of Spurious Radiation in Accordance with the FCC Rules & Regulations Part 2.1053 Wireless CDPD Modem Minstrel S Novatel Wireless Technologies Ltd. 51 Spectrum Way Nepean ON K2R 1E6 Tel: (613) 820-2730 Fax: (613) 820-4161 email: [email protected] August 2000 NVWB-MINSTREL S -3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories August 2000 Page 2 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 FCC ID:NBZNRM6834 Applicant:Novatel Wireless Technologies Ltd. Equipment:Wireless CDPD Modem Model:Minstrel S Standard:FCC Rules and Regulations Part 2.1046 ENGINEERING SUMMARY This report contains the results of Field Strength of Spurious Radiation measurement performed on a Novatel Wireless Minstrel S wireless CDPD modem. The measurements were carried out in accordance with the FCC Rules and Regulations Part 2.1053. The product was evaluated for spurious when it was set at the maximum power level. The Minstrel S wireless CDPD modem is an attachment for the Handspring Visor PDA. (The results presented in this report relate only to the sample tested) August 2000 Page 3 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 Summary of the Results Test DescriptionPage No. Test Set-up Figure No. Results Summary Field Strength of Spurious Radiation Ref. Paragraph 2.105381Passed August 2000 Page 4 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 INTRODUCTION General This report describes the results of the Field Strength of Spurious Radiation measurement conducted on a Novatel Wireless Minstrel S wireless CDPD modem herein referred to as DUI (Device Under Investigation). Test Facility The tests were performed for Novatel Wireless by APREL Laboratories at APREL’s EMI facility located in Nepean, Ontario, Canada. The laboratory operates an (3m and 10m) Open Area Test Site (OATS). The measurement facility is calibrated in accordance with ANSI C63.4-1992. A description of the measurement facility in accordance with the radiated and AC line conducted test site criteria per ANSI C63.4-1992 is on file with the Federal Communications Commission and is in compliance with the requirements of Section 2.948 of the Commissions rules and regulations. APREL’s registration number is 90416 APREL is accredited by Standard Council of Canada, under PALCAN program (ISO Guide 25). APREL is also accredited by Industry Canada (formerly DOC) and recognised by the Federal Communications Commissions (FCC). Standard The evaluation and analysis were conducted in accordance with FCC Rules and Regulations Parts 2.1053 and the appropriate limits. Test Equipment The test equipment used during the evaluation is listed in Appendix A with calibration due dates. Environmental Conditions Measurements were conducted in open area test site. - Temperature:20 °C ± 2 - Relative Humidity:30 - 50 % August 2000 Page 5 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 - Air Pressure:101 kPa ± 3 FCC SUBMISSION INFORMATION FCC ID:NBZNRM6834 Equipment:Wireless CDPD Modem Model:Minstrel S For:Certification Applicant:Novatel Wireless Technologies Ltd. Suite 200 6715-8 th Street, N.E. Calgary, Alberta Canada, T2E 7H7 Manufacturer: Novatel Wireless Technologies Ltd. Suite 200 6715-8 th Street, N.E. Calgary, Alberta Canada, T2E 7H7 Evaluated by:APREL Laboratories 51 Spectrum Way Nepean, Ontario Canada K2R 1E6 August 2000 Page 6 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 MANUFACTURER’S DATA FCC ID No:NBZNRM6834 Equipment Type:Wireless CDPD Modem Model:Minstrel S Reference:FCC Rules and Regulations Parts 2 and Part 22 Manufacturer:Novatel Wireless Technologies Ltd. Power Source:DC Battery Development Stage of Unit:Production GENERAL SPECIFICATIONS 1.Frequency Range:824 to 849 MHz (Transmitter) 2.Output Power:0.191 W ERP 3. Frequency Tolerance:2.5 ppm 4.Type of Modulation:GMSK 5.Emission Designators(See 47 CFR § 2.201 and §2.202) 28K8FXW 6. Antenna Impedance:50 Ohms August 2000 Page 7 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 N N o o v v a a t t e e l l W W i i r r e e l l e e s s s s . . TEST RESULTS FOR Field Strength of Spurious Radiation Of Novatel Wireless Minstrel S CDPD Modem August 2000 Page 8 APREL Project No NVWB-MINSTREL S-3509 This report shall not be reproduced, except in full, without the express written approval of APREL Laboratories Consulting * Research * Training * Certification Testing Since 1981 Test:Field Strength of Spurious Radiation Ref:FCC Parts 2.1046 and 22.917 (e) Criteria:Emission : The permitted maximum level of spurious emission is 43 + 10 log (P) dB below the unmodulated carrier power of the transmitter (P). This was calculated to be 84.6 d…

Text truncated - open the document above for the full version.

August 2000 APREL Project No.: NVWB-MINSTREL S Consulting * Research * Training * Certification Testing Since 1981 Exhibit 12 Minstrel S Novatel Wireless Technologies Ltd. FCC ID: NBZNRM6834 With a Novatel NRM6832 CDPD Transmitter (FCC ID: NBZNRM6832 Test Data) Test data/Report for 2.1049(c)(1) and 2.1047 : Modulation Emission Mask/s (Occupied Bandwidth ) 2.1051(2.991): Spurious Emissions at Antenna Terminal 2.1055(2.995): Frequency Stability
