NCI-M360-M500AI Safety System

i VIA Mobile360 M500 AI Safety System User Manual ii Overview Mobile360 M500 is a smart on-board The AI Safety System monitoring device specially designed for industrial vehicles, such as stackers, forklifts and other engineering equipment. It can detect the dangerous state of the work area in real time and provide warnings to improve the safety of the operation of engineering vehicles. An indispensable security system in the era of smart industry. The AI Safety System monitoring function mainly uses three independent monitors, combined with deep learning calculations to complete machine vision recognition. Two of the ultra-wide-angle monitors with supplemental light design are installed on the front and rear of the forklift. They can provide safety detection even in poorly lit environments and assist operators in seeing blind spots near the vehicle during work. In addition, a monitor equipped with infrared supplement light can detect the fatigue of the operator at the same time, and can correctly identify the status of the personnel under various light conditions. If equipped with basic vehicle accessories such as display screen, speed sensor, seat belt, etc., it can analyze the status inside and outside the vehicle and the operator, and can send out visual and sound alarm reminders in time. The screen display can help the operator see The visual blind angle reduces the occurrence of industrial safety accidents and improves the working safety of forklifts. M500 power supply adopts wide-voltage design, which can cover most of the different types of forklifts on the market. Because the working environment of this kind of engineering vehicles is often harsh, such as iii high temperature, high humidity and a large amount of dust, etc., the main body, connector Including peripheral equipment, IP67 protection specifications are used to ensure that the system can operate normally in harsh environments. iv Contents Overview .............................................................................................................. ii Contents .............................................................................................................. iv 1. Specifications .............................................................................................. 1 2. Accessories .................................................................................................. 1 3. Operating Temp ......................................................................................... 2 4. Appearance Description ........................................................................... 3 4.1 Front Panel ......................................................................................... 3 4.2 Back Panel .......................................................................................... 3 5. Installation Instructions ............................................................................ 4 5.1 Host Installation ............................................................................... 4 5.2 Installation Mobile APP ................................................................... 5 5.3 Power Instructions ........................................................................... 6 5.4 Camera Installation Instructions ................................................... 6 5.5 Speaker Installation Instructions .................................................. 7 5.6 Antenna Installation Instructions ................................................. 8 5.7 Bracket Installation Instructions ................................................... 8 5.8 LCD Dispiay Installation Instructions ........................................... 9 6．Start Using M500 ......................................................................................... 9 6.1 LED Indicator Status Description ................................................ 10 6.2 Warning Description ...................................................................... 10 6.3 Calibration Method Description .................................................. 11 6.3.1 Online Way ........................................................................... 11 6.3.2 Front And Rear Camera Security Zone Calibration ..... 13 6.3.2.1 Express Calibration ................................................. 13 v 6.3.2.2 Custom Calibration ................................................. 15 6.3.3 Driver Camera Calibration ................................................ 16 6.3.4 Seat Belt Settings ................................................................ 17 6.3.5 System Setting ..................................................................... 18 6.3.6 Album .................................................................................... 19 6.3.7 System Information ............................................................ 20 6.3.8 System Upgrade .................................................................. 21 6.4 LCD Display Description ............................................................... 21 6.4.1 LCD Display Note ................................................................ 22 6.5 Record Save Description ............................................................... 22 1 1. Specifications Item Description Memory 1GB memory Storage 512MB ROM Audio Power 2W / 4 OHM External speaker Wireless Communication WIFI 802.11a/b/g/n/ac GPS/Beidou BT 5.0 Power DC9-36V Operating System Embedded Linux Dimensions 178mm x 164mm x 52.8mm 2. Accessories Item Description Front Camera (Aviation connector) Lens 6G ,F2.3, D:190° V:110.8° H:180°, WALH Fill light White LED AHD@720P Waterproof Rating IP67 Rear Camera (Aviation connector) Lens 6G ,F2.3, D:190° V:110.8° H:180°, WALH Fill light White LED AHD@720P Waterproof Rating IP67 Inside Camera (Aviation connector) Lens 6G ,F2.3, D:68° V:33° H:59° Fill light IR LED AHD@720P Waterproof Rating IP67 Speaker (Aviation connector) 2W/4 OHM Mono speaker 2 Power Cable (Aviation conne…

Text truncated - open the document above for the full version.

VIA Technologies Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021/04/02 Subject; Request for Confidentiality FCC ID: NCI-M360-M500 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description NII Software Security In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Mirror Hu Title: Engineer

VIA Technologies Inc. Letter of Authorization Company: VIA Technologies Inc. Address: 8F, 533,ZhongZheng Rd.,Xindian Dist. New Tapei City 231, Taiwan Product Name: AI safety system Model Number: Mobile 360 M500 FCC Identifier: NCI-M360-M500 We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Mirror Hu Date: 2021/04/02 Title: Engineer Signature of applicant:

RF Exposure FCC ID: NCI-M360-M500 Applicant: VIA TECHNOLOGIES, INC. Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: AI Safety System Refer Standard: FCC Part 2.1091: Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands) FCC MPE Limited: Limits for General Population/Uncontrolled Exposure Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (minutes) 0.3-1.34 614 1.63 *(100) 30 1.34-30 824/f 2.19/f *(180/f2) 30 30-300 27.5 0.073 0.2 30 300-1500 / / f/1500 30 1500-100,000 / / 1.0 30 Test Data Predication of MPE limit at a given distance Where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator, the power gain factor, is normally numeric gain. R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) Antenna Gain information 2.4G WLAN：2.49dBi 5G WLAN：2.37dBi BT/BLE: 2.49 dBi Worst-Case mode Conducted Output Power Results for2.4G WIFI 802.11b mode Channel Frequency (MHz) Output Power(dBm) Tune Up tolerance(dBm) 1 2412 16.28 17±1 6 2437 16.83 17±1 11 2462 16.78 17±1 Worst-Case mode Conducted Output Power Results for BT /BLE Bluetooth Band Mode Test Frequency Power(dBm) Tune-up tolerance(dBm) BT EDR GFSK 2402 5.07 5±1 GFSK 2441 4.90 5±1 GFSK 2480 4.45 5±1 BLE GFSK 2402 4.096 4±1 GFSK 2440 3.848 4±1 GFSK 2480 3.017 4±1 Worst-Case mode Conducted Power Test results of band U-NII-1/U-NII-3 802.11a mode Frequency (MHz) Conducted Output Power (dBm) Tune Up tolerance(dBm) 5180 12.88 12±1 5220 12.26 12±1 5240 11.93 12±1 5745 12.86 12±1 5785 12.48 12±1 5825 12.08 12±1 Calculation results (for 2.4G WIFI): Worst-case mode Frequency (MHz) Maximum tune up power(dBm) RF distance(cm) Result (mW/cm2) Limit (mW/cm2) 2412 18 20 0.024 1.0 2437 18 20 0.024 2462 18 20 0.024 Calculation results (for 5G WIFI): Worst-Case mode Frequency (MHz) Maximum tune up power(dBm) RF distance(cm) Result (mW/cm2) Limit (mW/cm2) 5180 13 20 0.007 1.0 5220 13 20 0.007 5240 13 20 0.007 5745 13 20 0.007 5785 13 20 0.007 5825 13 20 0.007 Calculation results (for BT/BLE): Worst-case mode Bluetooth Band Mode Test Frequency Power(dBm) Result (mW/cm2) Limit (mW/cm2) BT EDR GFSK 2402 6 0.0015 1.0 GFSK 2441 6 0.0015 GFSK 2480 6 0.0015 BLE GFSK 2402 5 0.001 GFSK 2440 5 0.001 GFSK 2480 5 0.001 Simultaneous Transmission Calculation (Worst-case mode) No. Transmitter Combinations Scenario Supported or not 1 2.4G WLAN+BT Yes 2 5G WLAN+BT Yes 3 2.4G WLAN+BT+5G WLAN Yes Antenna Mode/Channel Calculation results(mW/cm2) Limit (mW/cm2) Ratio WLAN 2.4G WIFI 0.024 1.0 0.024 WLAN 5G WIFI 0.007 1.0 0.007 BT BT 0.0015 1.0 0.0015 Max Simultaneous Transmission Calculation (Worst-case mode) No. Worst Mode MPE Ratio Results 1 2.4G WIFI+BT+5G WIFI 0.024+0.0015+0.007 0.0325<1.0(pass)
