NE3PCS008850 High Power EDGE Base Station

s FCC ID: NE3PCS008 July 3, 2002 Subject: PCS Certification Application Cover Letter Reference:FCC ID: NE3PCS008 To Whom It May Concern: This is an application for Certification for FCC ID: NE3PCS008, for the High Power Edge Carrier Unit (ECU) 850. Confidentiality Request: We are requesting confidentiality for the following Exhibit Types: Operational Description, Parts List / Tune-up Info, Schematics, Block Diagrams, User manuals and Internal photographs. This request is based on the following reasons: Siemens serves a market both new and technically very advanced. Hence competition among equipment providers is very high, with millions of dollars at stake. Siemens’ applications for certification contain technical information regarding technology it spent millions of dollars to develop. If classified as non-confidential, Siemens’ competitors would gain an unfair advantage at Siemens’ expense. User Manuals are not available to the general public in any form. User Manuals are sellable items, made available only to legitimate Siemens customers (mobile telephone operators who own FCC licenses for the appropriate frequency bands). It is Siemens’ policy to provide User Manuals to a third party only upon execution of a Mutual Non-Disclosure Agreement (“NDA”). Siemens base stations are normally installed in a restricted area, accessible only by Siemens or its customer. When not installed in a restricted area, such as a rooftop, Siemens base stations are always locked with temper-proof hardware and locks, again accessible only by Siemens and its customer. Accordingly, only authorized persons, who also previously signed an NDA, have access to the inside of a Siemens base station cabinet. By not classifying User Manuals and Internal Photographs as confidential, the FCC allows Siemens’ competitors (or anyone else) to access to Siemens’ confidential and proprietary information via the FCC’s web site. This would cause irreparable damage to Siemens and place Siemens at a competitive disadvantage. For these reasons, Siemens strongly requests confidentiality for the following Exhibit Types: Operational Description, Parts List/Tune-up Info, Schematics, Block Diagrams, User Manuals, and Internal Photographs. Please do not hesitate to contact me, if you have any questions. Sincerely, Rashmi J. Contractor Senior Product Line Manager e-mail: [email protected] Siemens Information and Communication Mobile LLC (561) 923-6454

Figure 1: Label Figure 2: Labelplacement Figure 3: Labelplacement Label

Test Plan and Test Results FCC ID: NE3PCS008 Name of Applicant Siemens Information and Communication Networks, Inc. 900 Broken Sound Parkway Boca Raton, FL 33487 BS-241U BTS Base Station FCC ID:NE3PCS008 Test report ECU850HP.docPage 2/4605/23/02 TABLE OF CONTENTS 1 EQUIPMENT UNDER TEST (EUT)4 2 MEASUREMENTS5 2.1General description5 2.2Summary of the measurements5 2.2.1EUT configuration and operating conditions5 2.2.2Selected carrier test frequencies6 2.2.3Modulation characteristics6 2.2.4Measurement test configuration7 2.2.5Calibration of the measurement equipment7 2.3Test No. 1: RF power output (§ 2.1046)8 2.3.1Purpose8 2.3.2EUT operation condition8 2.3.3Test configuration8 2.3.4Measurement procedure8 2.3.5Measurement results8 2.4Test No. 2: Modulation characteristics (§ 2.1047, § 2.201)9 2.5Test No. 3: Occupied bandwidth (§ 2.1049)10 2.5.1Purpose10 2.5.2EUT operation condition10 2.5.3Test configuration10 2.5.4Measurement procedure and results10 2.6Test No. 4: Spurious emissions at antenna terminals (§ 2.1051, § 2.1057, § 22.917) 11 2.6.1Purpose11 2.6.2Limits11 2.6.3EUT operation condition11 2.6.4Test configuration11 2.6.5Measurement procedure and results11 2.7Test No. 5: Field strength of spurious radiation (§ 2.1053, § 2.1057, § 22.917) 13 2.7.1Purpose13 2.7.2Limits13 2.7.3EUT operation condition13 2.7.4Test configuration13 2.7.5Measurement procedure14 2.7.6Measurement results & limits14 2.8Test No. 6: Frequency stability (§ 2.1055, § 22.355)16 2.8.1Purpose16 2.8.2Limits16 2.8.3EUT operation condition16 2.8.4Test configuration16 2.8.5Measurement procedure17 2.8.6Measurement results17 2.9Test No. 7: Slow frequency hopping18 2.9.1Introduction18 FCC ID:NE3PCS008 Test report ECU850HP.docPage 3/4605/23/02 2.9.2Purpose18 2.9.3EUT operation condition18 2.9.4Test configuration18 2.9.5Measurement procedure18 2.9.6Measurement results18 3 MEASUREMENT DATA AND SPECTRAL PLOTS20 3.1Part list of the measurement test equipment20 3.2Spectral plots21 FCC ID:NE3PCS008 Test report ECU850HP.docPage 4/4605/23/02 1 Equipment under test (EUT) The equipment under test (EUT) comprises the modules listed in the table below. For a functional description of the modules, please refer to the appropriate related parts and exhibit sections of this certification application. The tests were conducted with the modules installed in a BS-241U. Worst-case measurement data is reported. The tested system was equipped as per Fig. 1 on page 7 with its maximum number of 8 transceivers. Although only one transceiver (EUT) was tested for compliance, the other transceivers were investigated to ensure that the worst case test condition/transceiver was measured. A complete description of the transceiver’s calibration/tuning procedure is included in the Parts List and TuneUp exhibit section of this application. Module NameSiemens Part No.Serial No. DUAMCO2850V1S30861-U2296-X-01/01KSA/N8112025 ECU850HPV2S30861-U2333-X-B1/01RX+/P4263532 ECU850HPV2S30861-U2333-X-B1/01RX+/P4263535 FCC ID:NE3PCS008 Test report ECU850HP.docPage 5/4605/23/02 2 Measurements 2.1 General description 2.2 Summary of the measurements The measurements described in the following sections were conducted pursuant to 47 CFR § 2.947. All applicable paragraphs of the 47 CFR parts 2 and 22 of the most current version of the rules were considered. The measurements were performed at Siemens AG, Institute for Quality Engineering and Testing, Hofmannstr. 50, 81359 Munich, Germany. The following tests were performed according to the FCC rules in order to verify the compliance of the EUT with the FCC requirements: In accordance with the FCC Rule §15.3 (z) the equipment was tested with the limits that are valid for anunintentional radiator. 2.2.1 EUT configuration and operating conditions If not stated otherwise, the following standard setup procedure for the EUT under test was used: A Protocol Tester K1297 is used to control the EUT. The K1297 is connected to the EUT via the A bis Link. For detailed test system equipment configuration please refer to Fig. 1 on page 7. The transmitter modules were tuned up according to the procedure described in the TuneUp exhibit section of this application. During the measurements, one carrier channel was tested at a time. The carrier was set to the maximum power level with all timeslots activated to ensure the maximum emission amplitudes during all measurements. A pseudo random bit pattern was applied to the digital modulator. This ensures that the measurements of the emission characteristics of the transmitter are pursuant to § 2.1049. Test No. MeasurementFCC RulePage Number of this Report Results 1RF power output§ 2.10468compliant 2Modulation characteristics § 2.1047, § 2.2019compliant 3Occupied bandwidth§ 2.104910compliant 4Spurious emissions at antenna terminals § 2.1051, § 2.1057, § 22.917 11compliant 5Field strength of spurious radiation § 2.1053, § 2.1057, § 22.917 13compliant 6Frequency stability§ 2.1055, § 22.35516compliant 7Slow frequency hoppingN/A18compliant FCC ID:NE3PCS008 Test report ECU850HP.docPage 6/4605/23/02 2.2.2 Selected carrier test frequencies The measurements were performed at 3 selected carrier test frequencies, according to the following table: Carrier Test Frequency [MHz] Remark 869.2lowest possible carrier frequency 881.6frequency at the middle of the band 893.8highest possible carrier frequency 2.2.3 Modulation characteristics The EUT supports two types of modulation: GMSK and 8PSK. The modulation characteristic of the GMSK and the 8PSK modulation is defined in standard 3GPP TS 05.04. During all measurements described below, a pseudo random sequence was applied to the digital modulator to ensure that the emission characteristics of the transmitter are pursuant to § 2.1049. FCC ID:NE3PCS008 Test report ECU850HP.docPage 7/4605/23/02 2.2.4 Measurement test configuration If not stated otherwise, the following measurement configuration was used to perform all measurements (see figure below): EUT RFout control in PC (…

Text truncated - open the document above for the full version.

Test Setup Photos Figure 1: Photograph of the anechoic chamber with the EUT. Figure 2: Photograph of the anechoic chamber with the test configuration for substitution method.
