NE3PCS009High Power 1900 MHz Edge CU

FCC ID:NE3PCS009 NE3PCS009_BS41_ ECUPHPV3.doc Page 2/63 30.09.02 TABLE OF CONTENTS 1 EQUIPMENT UNDER TEST (EUT) 4 2 MEASUREMENTS 5 2.1 General description 5 2.2 Summary of the measurements 5 2.2.1 EUT configuration and operating conditions 5 2.2.2 Selected carrier test frequencies 6 2.2.3 Modulation characteristics 6 2.2.4 Measurement test configuration 6 2.2.5 Calibration of the measurement equipment 7 2.3 Test No. 1: RF power output (§ 2.1046) 8 2.3.1 Purpose 8 2.3.2 EUT operation condition 8 2.3.3 Test configuration 8 2.3.4 Measurement procedure 8 2.3.5 Measurement results 8 2.4 Test No. 2: Modulation characteristics (§ 2.1047, § 2.201) 9 2.5 Test No. 3: Occupied bandwidth (§ 2.1049) 10 2.5.1 Purpose 10 2.5.2 EUT operation condition 10 2.5.3 Test configuration 10 2.5.4 Measurement procedure and results 10 2.6 Test No. 4: Spurious emissions at antenna terminals (§ 2.1051, § 2.1057, § 24.238) 11 2.6.1 Purpose 11 2.6.2 Limits 11 2.6.3 EUT operation condition 11 2.6.4 Test configuration 11 2.6.5 Measurement procedure and results 11 2.7 Test No. 5: Field strength of spurious radiation (§ 2.1053, § 2.1057, § 24.238) 15 2.7.1 Purpose 15 2.7.2 Limits 15 2.7.3 EUT operation condition 15 2.7.4 Test configuration 15 2.7.5 Measurement procedure 16 2.7.6 Measurement results & limits 16 2.8 Test No. 6: Frequency stability (§ 2.1055, § 24.235) 18 2.8.1 Purpose 18 2.8.2 Limits 18 2.8.3 EUT operation condition 18 2.8.4 Test configuration 18 2.8.5 Measurement procedure 19 2.8.6 Measurement results 19 2.9 Test No. 7: Slow frequency hopping 20 2.9.1 Introduction 20 2.9.2 Purpose 20 FCC ID:NE3PCS009 NE3PCS009_BS41_ ECUPHPV3.doc Page 3/63 30.09.02 2.9.3 EUT operation condition 20 2.9.4 Test configuration 20 2.9.5 Measurement procedure 20 2.9.6 Measurement results 21 3 MEASUREMENT DATA AND SPECTRAL PLOTS 22 3.1 Part list of the measurement test equipment 22 3.2 Spectral plots 23 FCC ID:NE3PCS009 NE3PCS009_BS41_ ECUPHPV3.doc Page 4/63 30.09.02 1 Equipment under test (EUT) The equipment under test (EUT) comprises the modules listed in the table below. For a functional description of the modules, please refer to the appropriate related parts and exhibit sections of this certification application. To comply with the FCC rules (§2.1051, §24.238), the lowest and highest authorized channel frequency in the PCS frequency band are disabled and cannot be activated by the user. Refer to section IV of the “Ceritification Application Overview” located in the cover letter section, for details on how the channels are disabled. The tests were conducted with the modules installed in a BS-41U. Worst-case measurement data is reported. The test system is shown in Fig. 1 on page 6. The EUT was equipped with its maximum number of TRX. Although only one transceiver (EUT) was tested for compliance, the other transceivers were investigated to ensure that the worst case test condition/transceiver was measured. A complete description of the transceiver’s calibration/tuning procedure is included in the Parts List and TuneUp exhibit section of this application. Module Name Siemens Part No. Serial No. DUAMCO2HPPV2 S30861-U2364-X-01/01 FMM/P5004035 ECUPHPV3 S30861-U2372-X-03/01 RX+/P8225688 ECUPHPV3 S30861-U2372-X-03/01 RX+/P8225689 FCC ID:NE3PCS009 NE3PCS009_BS41_ ECUPHPV3.doc Page 5/63 30.09.02 2 Measurements 2.1 General description 2.2 Summary of the measurements The measurements described in the following sections were conducted pursuant to 47 CFR § 2.947. All applicable paragraphs of the 47 CFR parts 2 and 24 of the most current version of the rules were considered. The measurements were performed at Siemens AG, Institute for Quality Engineering and Testing, Hofmannstr. 50, 81359 Munich, Germany. The following tests were performed according to the FCC rules in order to verify the compliance of the EUT with the FCC requirements: In accordance with the FCC Rule §15.3 (z) the equipment was tested with the limits that are valid for an unintentional radiator. 2.2.1 EUT configuration and operating conditions If not stated otherwise, the following standard setup procedure for the EUT under test was used: A Protocol Tester K1297 is used to control the EUT. The K1297 is connected to the EUT via the A bis Link. For detailed test system equipment configuration please refer to Fig. 1 on page 6. The transmitter modules were tuned up according to the procedure described in the TuneUp exhibit section of this application. During the measurements, one carrier channel was tested at a time. The carrier was set to the maximum power level with all timeslots activated to ensure the maximum emission amplitudes during all measurements. A pseudo random bit pattern was applied to the digital modulator. This ensures that the measurements of the emission characteristics of the transmitter are pursuant to § 2.1049. Test No. Measurement FCC Rule Page Number of this Report Results 1 RF power output § 2.1046 8 compliant 2 Modulation characteristics § 2.1047, § 2.201 9 compliant 3 Occupied bandwidth § 2.1049 10 compliant 4 Spurious emissions at antenna terminals § 2.1051, § 2.1057, § 24.238 11 compliant 5 Field strength of spurious radiation § 2.1053, § 2.1057, § 24.238 15 compliant 6 Frequency stability § 2.1055, § 24.235 18 compliant 7 Slow frequency hopping N/A 20 compliant FCC ID:NE3PCS009 NE3PCS009_BS41_ ECUPHPV3.doc Page 6/63 30.09.02 2.2.2 Selected carrier test frequencies The measurements were performed at 3 selected carrier test frequencies, according to the following table: 1 Carrier Test Frequency [MHz] Remark 1930.4 lowest possible carrier frequency 1960.0 frequency at the middle of the band 1989.6 highest possible carrier frequency 2.2.3 Modulation characteristics The EUT supports two types of modulation: GMSK and 8PSK. The modulation characteristic of the GMSK and the 8PSK modulation is defined in standard 3GPP TS 05.04. During all measurements described below, a pseudo random sequence was applied to the digital modulator to ensure that the emission c…

Text truncated - open the document above for the full version.
