MBF, Multi Band Repeater PRODUCT DESCRIPTION AND USER’S MANUAL © Axell Wireless Ltd A 200 93 00, rev E 1 (105) MBF, Multi Band Repeater Product Description and User’s Manual This revision of the MBF manual is valid for single, dual and tri band repeaters covering the frequency bands LTE 700, 850, 900, 1800, 1900, 2200 and AWS Firmware release version
Common Commands and Attributes v 1.3.2
MBF Commands and Attributes v 1.0.0 Copyright © 2010 Axell Wireless Ltd All rights reserved. No part of this document may be copied, distributed, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language without the prior written permission of Axell Wireless Ltd. The manufacturer has made every effort to ensure that the instructions contained in this document are adequate and free of errors and omissions. The manufacturer will, if necessary, explain issues which may not be covered by this document. The manufacturer's liability for any errors in the document is limited to the correction of errors and the aforementioned advisory services. This document has been prepared to be used by professional and properly trained personnel, and the customer assumes full responsibility when using them. The manufacturer welcomes customer comments as part of the process of continual development and improvement of the documentation in the best way possible from the user's viewpoint. Please submit your comments to the nearest Axell Wireless sales representative. MBF, Multi Band Repeater PRODUCT DESCRIPTION AND USER'S MANUAL © Axell Wireless Ltd A 200 93 00, rev E 2 (105) Table of Contents Safety Instructions and Warnings ................................................................................................. 4 References .................................................................................................................................... 7 Contact Information ..................................................................................................................... 8 Definitions, Abbreviations and Acronyms ................................................................................... 9 1.1 Basic Repeater Features .................................................................................................... 12 1.2 Repeater Types .................................................................................................................. 12 1.3 Repeater Applications ....................................................................................................... 16 2.1 Repeater Firmware ............................................................................................................ 19 2.2 The RMC, Repeater Maintenance Console ....................................................................... 19 2.3 The AEM, Axell Element Manager ................................................................................... 19 3.1 Overview ........................................................................................................................... 20 3.2 Repeater Models ................................................................................................................ 21 3.3 Characteristics ................................................................................................................... 22 3.4 Casing ................................................................................................................................ 22 3.5 Connections ....................................................................................................................... 24 3.6 Building Blocks ................................................................................................................. 24 3.7 Signal Diagrams ................................................................................................................ 30 3.8 OMU-Repeater System ..................................................................................................... 32 3.9 Access to the System ......................................................................................................... 33 3.10 SW for Configuration and Control .................................................................................... 34 4.1 Software Features - Overview ........................................................................................... 35 4.2 Network Nodes .................................................................................................................. 36 4.3 Fibre Loss Compensation .................................................................................................. 38 4.4 Alarm System .................................................................................................................... 39 4.5 Repeater Heartbeat ............................................................................................................ 52 4.6 RF Parameters ................................................................................................................... 57 4.7 Hardware Identification ..................................................................................................... 59 4.8 Tag and ID ......................................................................................................................... 60 4.9 User Access ....................................................................................................................... 61 4.10 Integration into AEM ........................................................................................................ 62 4.11 Upgrading Firmware ......................................................................................................... 62 5.1 Commissioning Advice ..................................................................................................... 64 5.2 Install the Repeater ....................................................…

Text truncated - open the document above for the full version.

MBF, Multi Band Repeater PRODUCT DESCRIPTION AND USER'S MANUAL © Axell Wireless Ltd A 200 93 00, rev E 31 (105) MCPA UMTS 2 x Duplex Filter RF O Optical In/Out Downlink Uplink RF in/out Fiber Optic Converter Radio Module UMTS Radio Module GSM MCPA GSM Downlink Uplink ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ ~ Dual band repeater for E-GSM and UMTS In the downlink the signal from the OMU enters the fibre optic converter in the repeater that translates the optical signal to RF. The signal is fed to the Radio Modules. The signals are amplified in the Radio Modules and further in the separate MCPAs. It is then fed to the combined duplex filter and out on the server port to the antenna. In the uplink the signal is amplified in the Radio Modules and translated to an optical signal and fed back to the OMU. A tri band repeater works in a corresponding way.

Process Instruction NO: A2010-PI ISSUE: 1 PRINT THIS DOCUMENT IN COLOUR PAGE: 4 OF 14 Attach the internal case label to the left hand inside wall of the side of the case. Attach the port designation label to the front edge of the case adjacent to the connector ports. 030 Select the CBL PSU 924: J755014 & fit into case

MBF, Multi Band Repeater PRODUCT DESCRIPTION AND USER’S MANUAL © Axell Wireless Ltd A 200 93 00, rev E 1 (105) MBF, Multi Band Repeater Product Description and User’s Manual This revision of the MBF manual is valid for single, dual and tri band repeaters covering the frequency bands LTE 700, 850, 900, 1800, 1900, 2200 and AWS Firmware release version
Common Commands and Attributes v 1.3.2
MBF Commands and Attributes v 1.0.0 Copyright © 2010 Axell Wireless Ltd All rights reserved. No part of this document may be copied, distributed, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language without the prior written permission of Axell Wireless Ltd. The manufacturer has made every effort to ensure that the instructions contained in this document are adequate and free of errors and omissions. The manufacturer will, if necessary, explain issues which may not be covered by this document. The manufacturer's liability for any errors in the document is limited to the correction of errors and the aforementioned advisory services. This document has been prepared to be used by professional and properly trained personnel, and the customer assumes full responsibility when using them. The manufacturer welcomes customer comments as part of the process of continual development and improvement of the documentation in the best way possible from the user's viewpoint. Please submit your comments to the nearest Axell Wireless sales representative. MBF, Multi Band Repeater PRODUCT DESCRIPTION AND USER'S MANUAL © Axell Wireless Ltd A 200 93 00, rev E 2 (105) Table of Contents Safety Instructions and Warnings ................................................................................................. 4 References .................................................................................................................................... 7 Contact Information ..................................................................................................................... 8 Definitions, Abbreviations and Acronyms ................................................................................... 9 1.1 Basic Repeater Features .................................................................................................... 12 1.2 Repeater Types .................................................................................................................. 12 1.3 Repeater Applications ....................................................................................................... 16 2.1 Repeater Firmware ............................................................................................................ 19 2.2 The RMC, Repeater Maintenance Console ....................................................................... 19 2.3 The AEM, Axell Element Manager ................................................................................... 19 3.1 Overview ........................................................................................................................... 20 3.2 Repeater Models ................................................................................................................ 21 3.3 Characteristics ................................................................................................................... 22 3.4 Casing ................................................................................................................................ 22 3.5 Connections ....................................................................................................................... 24 3.6 Building Blocks ................................................................................................................. 24 3.7 Signal Diagrams ................................................................................................................ 30 3.8 OMU-Repeater System ..................................................................................................... 32 3.9 Access to the System ......................................................................................................... 33 3.10 SW for Configuration and Control .................................................................................... 34 4.1 Software Features - Overview ........................................................................................... 35 4.2 Network Nodes .................................................................................................................. 36 4.3 Fibre Loss Compensation .................................................................................................. 38 4.4 Alarm System .................................................................................................................... 39 4.5 Repeater Heartbeat ............................................................................................................ 52 4.6 RF Parameters ................................................................................................................... 57 4.7 Hardware Identification ..................................................................................................... 59 4.8 Tag and ID ......................................................................................................................... 60 4.9 User Access ....................................................................................................................... 61 4.10 Integration into AEM ........................................................................................................ 62 4.11 Upgrading Firmware ......................................................................................................... 62 5.1 Commissioning Advice ..................................................................................................... 64 5.2 Install the Repeater ....................................................…

Text truncated - open the document above for the full version.

REPORT ON THE CERTIFICATION TESTING OF A AXELL WIRELESS DUAL BAND REPEATER MBF-D-7-71 WITH RESPECT TO THE FCC RULES CFR 47, PART 27 PRIVATE LAND MOBILE REPEATER. TEST REPORT NO:TTR-001973WUS2 COPY NO:1 ISSUE NO:1 FCC ID:NEOA216SERIES REPORT ON THE CERTIFICATION TESTING OF A AXELL WIRELESS DUAL BAND REPEATER MBF-D-7-71 WITH RESPECT TO THE FCC RULES CFR 47, PART 27 PRIVATE LAND MOBILE REPEATER. TEST DATE: 15 th – 29 th November 2010 APPROVED BY:J CHARTERS RADIO PRODUCT MANAGER DATE:14 th February 2011 Distribution: Copy Nos:1.Axell Wireless 2.TCB: TRaC EMC & Safety 3.TRaC Telecoms & Radio THIS DOCUMENT MAY BE REPRODUCED ONLY IN ITS ENTIRETY AND WITHOUT CHANGE TTR-001973WUS2Page 3 of 139 CONTENTS PAGE CERTIFICATE OF CONFORMITY & COMPLIANCE4 APPLICANT’S SUMMARY5 EQUIPMENT TEST CONDITIONS6 TESTS REQUIRED6 TEST RESULTS7 - 129 ANNEX PHOTOGRAPHSA PHOTOGRAPH No. 1: Test setup PHOTOGRAPH No. 2: Overview APPLICANT’S SUBMISSION OF DOCUMENTATION LISTB EQUIPMENT CALIBRATIONC MEASUREMENT UNCERTAINTYD Notes: 1.Component failure during test YES NO [ ] [X] 2.If Yes, details of failure: 3.The facilities used for the testing of the product contain in this report are FCC Listed. CERTIFICATE OF CONFORMITY & COMPLIANCE TTR-001973WUS2 FCC IDENTITY:NEOA216SERIES PURPOSE OF TEST:Certification TEST SPECIFICATION:FCC RULES CFR 47, Part 27 TEST RESULT:Compliant to Specification EQUIPMENT UNDER TEST:MBF-D-7-71 EQUIPMENT TYPE:Private Land Mobile Repeater MAXIMUM GAIN: 600MHz Band Uplink 700MHz Band Uplink 1700MHz Band Uplink 700MHz Band Downlink 2110MHz Band Downlink 38.20 dB 31.70 dB 30.20 dB 40.70 dB 33.20 dB MAXIMUM INPUT: 600MHz Band Uplink 700MHz Band Uplink 1700MHz Band Uplink 700MHz Band Downlink 2110MHz Band Downlink -65.40 dB -60.40 dB -61.50 dB -0.50 dB +5.30 dB MAXIMUM OUTPUT CONDUCTED: 600MHz Band Uplink 700MHz Band Uplink 1700MHz BandUplink 700MHz Band Downlink 2110MHz Band Downlink -27.20 dB -28.70 dB -31.30 dB +40.20 dB +38.50 dB MAXIMUM NUMBER OF CHANNELS:Not Applicable CHANNEL BANDWIDTH:Not Applicable, Wideband POWER SOURCE(s):+110Vac TEST DATE(s):15 th – 29 th November 2010 APPLICANT:Axell Wireless ADDRESS:Aerial House Asheridge Road Chesham Buckinghamshire HP5 1TU APPROVED BY:J CHARTERS RADIO PRODUCT MANAGER TTR-001973WUS2Page 5 of 139 APPLICANT’S SUMMARY EQUIPMENT UNDER TEST (EUT):MBF-D-7-71 EQUIPMENT TYPE:Private Land Mobile Repeater PURPOSE OF TEST:Certification TEST SPECIFICATION(s):FCC RULES CFR 47, Part 27 TEST RESULT:COMPLIANTYes No [X] [ ] APPLICANT’S CATEGORY:MANUFACTURER IMPORTER DISTRIBUTOR TEST HOUSE AGENT [X] [ ] [ ] [ ] [ ] APPLICANT’S CONTACT PERSON(s):Mr J Divall E-mail address:[email protected] APPLICANT:Axell Wireless ADDRESS:Aerial House Asheridge Road Chesham Buckinghamshire HP5 1TU United Kingdom TEL:+44 (0)1494 777000 FAX:+44 (0)1494 778456 MANUFACTURER:Axell Wireless EUT(s) COUNTRY OF ORIGIN:United Kingdom TEST LABORATORY:TRaC Telecoms & Radio, Skelmersdale UKAS ACCREDITATION No:0971 TEST DATE(s):15 th – 29 th November 2010 TEST REPORT No:TTR-001973WUS2 TTR-001973WUS2Page 6 of 139 EQUIPMENT TEST / EXAMINATIONS REQUIRED 1.TEST/EXAMINATIONRULE PARTAPPLICABILITYRESULT RF Power Output27.50YesComplies Audio Frequency ResponseTIA EIA-603.3.2.6N/AN/A Audio Low-Pass Filter ResponseTIA EIA-603.3.2.6N/AN/A Modulation LimitingTIA EIA-603.3.2.6N/AN/A Occupied Bandwidth27.53YesComplies Spurious Emissions at Antenna Terminals27.53YesComplies Field Strength of Spurious Emissions27.53YesComplies Frequency Stability27.54N/A(note 1)N/A Transient behaviourN/AN/A(note 2)N/A Notes: 1 The EUT does not contain modulation circuitry; therefore the test was not performed. 2 The EUT is not a keyed carrier system; therefore the test was not performed. Uplink Class A [ ] Class B [X]2.Product class: Downlink Class A [ ] Class B [X] 3.Product Use:Private Land Mobile Repeater 4.Emission Designator(s):F3E, F9W, GXW, G7W, DXW, F1D 5.Temperatures:Ambient (Tnom)20 o C 6.Supply Voltages:Vnom+110Vac Note: Vnom voltages are as stated above unless otherwise shown on the test report page Single channel[X] Two channel[ ] 7.Equipment Category: Multi-channel[ ] 8.Channel Bandwidth:Narrowband[ ] Wideband[ ] 9.Test LocationTRaC Telecoms & Radio Skelmersdale[X] Hull[ ] 10.Modifications made during test program No modifications were performed. System description: The MBF-D-7-71is bi directional repeater covering threebands in the uplink direction and two bands in the downlink direction. The uplink bands are wideband and cover the frequency ranges698 MHz – 716 MHz, 776 MHz – 787MHz and 1710 MHz – 1755 MHz. The downlinkbands are wideband and cover the frequency ranges 728MHz – 757 MHz and 2110 MHz – 2155 MHz TTR-001973WUS2Page 7 of 139 COMPLIANCE TESTS AMPLIFIER GAIN – CONDUCTED – PART 2.1046 – UPLINK Ambient temperature=20 o CRadio Laboratory Relative humidity=58% Supply voltage=+110Vac Channel number=See test results 600 MHz Band Frequency MHz Signal Generator input level dBm Input Cable Loss dB Level at Spectrum Analyser dBm Output Cable & Attenuator loss dB Gain dB Conducted Output Power dBm Gain after 10dB input level increase dB 698.000-63.600.3-27.270.336.9-27.027.0 707.000-65.100.3-27.460.338.2-27.228.3 716.000-63.700.3-27.650.336.7-27.426.7 Notes:1.The signal generator input was increased by 10dBs and the level of the output signal remeasured. 700MHz Band Frequency MHz Signal Generator input level dBm Input Cable Loss dB Level at Spectrum Analyser dBm Output Cable & Attenuator loss dB Gain dB Conducted Output Power dBm Gain after 10dB input level increase dB 776.000-58.900.3-28.850.330.7-28.620.77 742.500-59.900.3-28.880.331.6-28.621.70 787.000-60.100.3-28.970.331.7-28.721.83 Notes:1.The signal generator input was increased by 10dBs and the level of the output signal remeasured. 1700MHz Band Frequency MHz Signal Generator input level dBm Input Cable Loss dB Level at Spectrum Analyser dBm Output Cable & Attenuator loss dB Gain dB Conducted Output Power dBm Gain after 10dB input level increase dB 1710.000-59…
