NEOMBF4050MBF4050, (MBF4317-4319 115V Dual Band) Fibre Optic Repeater

AXELL MBF-40 AMERICAS REPEATERS PRODUCT DESCRIPTION AND USER’S MANUAL Axell MBF-40 Multi Band Repeater-Americas PRODUCT DESCRIPTION AND USER’S MANUAL Doc No. 00071UM Rev. 3.4 Single/Dual-Band Repeater Tri/Quad-Band Repeater Quad-Band with Fan Hood Repeater AXELL MBF-40 AMERICAS REPEATERS PRODUCT DESCRIPTION AND USER’S MANUAL II Doc. No. 00071UM Rev. 3.4 © Axell Wireless Ltd THIS DOCUMENT IS VALID FOR THE FOLLOWING MBF-40 MODELS: MBF-40 US Repeaters Dual Band MBF-3708-3719; MBF-3707-3917; MBF-3707-3719; MBF-3707-4317; MBF-4317-3919; MBF-4317-4319; Tri -Band MBF-3708-3917-3719; MBF-3707-3708-3917; MBF-3707-3708-3719; Quad-Band MBF-3707-3708-3917-3719; MIMO MBF-3917-3917M-3719 MBF-40 Canada Repeaters Single Band MBF-4307-AO; MBF-3707S-AO; Dual Band MBF-3708S-3709S-M; MBF-4317-4326-M; Quad-Band MBF-4308-4317-4319-4326-M- F; MBF-3707-3708-3917-3719 GB 115V MIMO MBF-4307-4307-M- AO AXELL MBF-40 AMERICAS REPEATERS PRODUCT DESCRIPTION AND USER’S MANUAL © Axell Wireless Ltd Doc. No. 00071UM Rev. 3.4 III Copyright © 2015 Axell Wireless Ltd All rights reserved. No part of this document may be copied, distributed, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language without the prior written permission of Axell Wireless Ltd. The manufacturer has made every effort to ensure that the instructions contained in this document are adequate and free of errors and omissions. The manufacturer will, if necessary, explain issues which may not be covered by this document. The manufacturer's liability for any errors in the document is limited to the correction of errors and the aforementioned advisory services. This document has been prepared to be used by professional and properly trained personnel, and the customer assumes full responsibility when using them. The manufacturer welcomes customer comments as part of the process of continual development and improvement of the documentation in the best way possible from the user's viewpoint. Please submit your comments to the nearest Axell Wireless sales representative. Contact Information Headquarters Axell Wireless Aerial House Asheridge Road Chesham Buckinghamshire HP5 2QD United Kingdom Tel: +44 1494 777000 Fax: +44 1494 777002 Commercial inquiries [email protected] Web site www.axellwireless.com Support issues [email protected] Technical Support Line, English speaking +44 1494 777 747 Contact information for Axell Wireless offices in other countries can be found on our web site, www.axellwireless.com AXELL MBF-40 AMERICAS REPEATERS PRODUCT DESCRIPTION AND USER’S MANUAL IV Doc. No. 00071UM Rev. 3.4 © Axell Wireless Ltd About This Manual This Product Manual provides the following information: • Description of the MBF-40 Americas Repeaters • Procedures for setup, configuration and checking the proper operation of the MBF-40 • Maintenance and troubleshooting procedures Intended Audience This Product Manual is intended for experienced technicians and engineers. It is assumed that the customers installing, operating, and maintaining Axell Wireless Remotes are familiar with the basic functionality of Remote repeaters. Notice Confidential - Authorized Customer Use This document may be used in its complete form only and is solely for the use of Axell Wireless employees and authorized Axell Wireless channels or customers. The material herein is proprietary to Axell Wireless. Any unauthorized reproduction, use or disclosure of any part thereof is strictly prohibited. All trademarks and registered trademarks are the property of their respective owners. Disclaimer of Liability Contents herein are current as of the date of publication. Axell Wireless reserves the right to change the contents without prior notice. The information furnished by Axell Wireless in this document is believed to be accurate and reliable. However, Axell Wireless assumes no responsibility for its use. In no event shall Axell Wireless be liable for any damage resulting from loss of data, loss of use, or loss of profits and Axell Wireless further disclaims any and all liability for indirect, incidental, special, consequential or other similes damages. This disclaimer of liability applies to all products, publications and services during and after the warranty period. Guarantees • All antennas must be installed with lightning protection. Damage to power modules, as a result of lightning are not covered by the warranty. • Antennas must be connected before switching on AC or DC power. Switching power on prior to the connection of antenna cables is regarded as faulty installation procedure and therefore not covered by the Axell Wireless warranty. Exclusive Remedies The remedies provided herein are the Buyer’s sole and exclusive remedies. Axell Wireless shall not be viable for any direct, incidental, or consequential damages, whether based on contract, tort, or any legal theory. AXELL MBF-40 AMERICAS REPEATERS PRODUCT DESCRIPTION AND USER’S MANUAL © Axell Wireless Ltd Doc. No. 00071UM Rev. 3.4 V Compliance with FCC FCC Part 20 Warning Statement WARNING: This is NOT a CONSUMER device. It is designed for installation by FCC LICENCEES and QUALIFIED INSTALLERS. You must have an FCC LICENCE or express consent of an FCC Licensee to operate this device. Unauthorized use may result in significant forfeiture penalties, including penalties in excess of $100,000 for each continuing violation. If not installed and used in accordance with the instructions, this equipment generates, uses and can radiate radio frequency energy. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to RF reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit d…

Text truncated - open the document above for the full version.

Product labelling for MBF40 Series Aerial HouseAsheridge RoadCheshamBuckinghamshireHP5 2QD United KingdomDate: Tuesday, 18 March 2014 Telephone: +44 (0) 1494 777000Facsimile: +44 (0) 1494 777002E-Mail: [email protected] Page 1 of 2 A4 MBF4001LB Issue: 1 Drawn by: JRD Not to Scale © Axell Wireless 2014 MBF40 Series Repeater Produ ct labels are generated us ing the Axell Serial Info rmation System (ASIS) Serial Numbers are assi gned according to Part Number and stored in an Electronic database Label templates are designe d and attached to each Part Number record in the database. Templates contain Frequency Band Inform ation and FCC Identifi cation. This information is locked to the Part Number by the database. Production Operators have re ad only access to the database. Part Number s, Label Templates and their contents are controlled by Axell Engineer ing and Configur ation management. To generate a new serial number login to ASIS (password required) and select Serial Numb ers tab. Select the New Button. Enter Operator ID, Part Number and Qt y of Labels to generate. Press OK button. Seri al Numbers will be generated and added to database. Select Print Button, enter Op erator ID, select Serial Nu mber Range and press Next. Label s to be printe d will appear on the screen which follows. Co nfirm the Part Number and Se rial range to be printed are correct. Press Print button or Cancel. Printed Labels will be output fr om the defined Printer for the Label template media. Attach the Product ID Label (yellow) to the right hand side of MBF40. Position label 5mm above the lower lid screw fixing, with bottom edge of label (Bar Code) against side step for alignment. 1)2)3)4)5)6)7) Attach the FCC LICENSE WARNIN G Label immediately adjacent to the Serial Number Label with matching te xt orientation as shown. NOTE: This step is only applic able to US Variants of MBF40 series. (If required the labe l will print automatically) FCC License Warning if required Serial Number Label

A RADIO TEST REPORT FOR AXELL WIRELESS LIMITED ON MBF - 4317 - 4319 DOCUMENT NO. TRA-017640-47-00-B TRaC Wireless Test Report : TRA-017640-47-00-B Applicant : Axell Wireless Limited Apparatus : MBF- 43170-4319 Specification(s) : CFR47, Part 24E, Part 27 Purpose of Test : Certification FCCID : NEOMBF4050 Authorised by : : Radio Product Manager Issue Date : 21 st January 2015 Authorised Copy Number : PDF Total number of pages: 119 TRaC Global Test Report: TRA-017640-47-00-B Contents Section 1: Introduction 4 1.1 General 4 1.2 Tests Requested By 5 1.3 Manufacturer 5 1.4 Apparatus Assessed 5 1.5 Test Result Summary 6 1.6 Equipment Test Conditions 7 1.7 Standard References 8 1.8 Notes Relating To Assesment 9 1.9 Deviations from Test Standards 9 Section 2: Measurement Uncertainty 10 2.1 Measurement Uncertainty Values 10 Section 3: Modifications 12 3.1 Modifications Performed During Assessment 12 Appendix A: Uplink Formal Emission Test Results 13 A1 RF Gain and Output Power 14 A2 Amplifier Intermodulation Spurious Emissions 15 A4 Spurious Emissions at Antenna Terminals Less than 1MHz 33 A5 Spurious Emissions at Antenna Terminals Greater than 1 MHz 34 A6 Radiated Electric Field Emissions 47 A7 Passband Gain & Bandwidth 55 Appendix B: Downlink Formal Emission Test Results 57 B1 RF Gain and Output Power 58 B2 Amplifier Intermodulation Spurious Emissions 59 B3 Amplifier Modulated Channel Test 67 B5 Spurious Emissions at Antenna Terminals Greater than 1MHz 87 B6 Radiated Electric Field Emissions 100 B7 Passband Gain & Bandwidth 108 Appendix C: Additional Test and Sample Details 110 Appendix D: Additional Information 116 Appendix E: Photographs and Figures 117 3 TRaC Global Test Report: TRA-017640-47-00-B Section 1: Introduction 1.1 General This report contains an assessment of an apparatus against Electromagnetic Compatibility Standards based upon tests carried out on samples submitted to the Laboratory. Test performed by: TRaC Global [ ] Unit E South Orbital Trading Park Hedon Road Hull, HU9 1NJ. United Kingdom. Telephone: +44 (0) 1482 801801 Fax: +44 (0) 1482 801806 TRaC Global [X] Unit 1 Pendle Place Skelmersdale West Lancashire, WN8 9PN United Kingdom Telephone: +44 (0) 1695 556666 Fax: +44 (0) 1695 577077 Email: [email protected] Web site: http://www.tracglobal.com Tests performed by: S Hodgkinson Report author: S Hodgkinson This report must not be reproduced except in full without prior written permission from TRaC Global. 4 TRaC Global Test Report: TRA-017640-47-00-B 1.2 Tests Requested By This testing in this report was requested by : Axell Wirelesss Limited Aerial House Asheridge Road Chesham Buckinghamshire HP5 1TU 1.3 Manufacturer Axell Wireless Limited Aerial House Asheridge Road Chesham Buckinghamshire HP5 1TU 1.4 Apparatus Assessed The following apparatus was assessed between 14 th April and 3 rd December 2014 Fibre Optic (F/O) Remote Unit The Multi-Band Fibre Optic system is composed of two building blocks: OMU (Optical Master unit) and MBF-40 series (Fibre Distributed Antenna System) Remote Unit. This is an indoor solution for single or multi operator use. Technical specifications Frequency Range Uplink Downlink CFR 47 Rule Part 1900 MHz (PCS) 1850 - 1910 MHz 1930 - 1990 MHz 24, Subpart E 1700 MHz (AW S) 1710 - 1755 MHz 2110 - 2155 MHz 27, Subpart A 5 TRaC Global Test Report: TRA-017640-47-00-B 1.5 Test Result Summary Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. The statements relating to compliance with the standards below apply ONLY as qualified in the notes and deviations stated in sections 1.6 to 1.7 of this test report. Full details of test results are contained within Appendix A. The following table summarises the results of the assessment. Test Type FCC Part 2 CFR 47 Part 24 Subpart E CFR 47 Part 27 Subpart A Appendix in Report RF Power Output 2.1046 24.232(a) 27.50 (a) A1 & B1 Intermodulation Spurious Emissions 2.1051 24.238(a) 27.53(c) & (g) A2 & B2 Occupied Bandwidth & Modulation 2.1049 KDB 935210 N/A N/A A3 & B3 Spurious Emissions at Antenna Terminals Less than 1 MHz 2.1051 24.238(a) 27.53(c) & (g) A4 & B4 Spurious Emissions at Antenna Terminals Greater than 1MHz 2.1051 24.238(a) 27.53(c) & (g) A5 & B5 Field Strength of Spurious Emissions 2.1053 24.238(a) 27.53(c),(f) & (g) A6 & B6 Passband Gain & 20dB bandwidth KDB 935210 N/A N/A A7 & B7 Frequency Stability 2.1055 24.135 27.54 N/A(note 1) Transient behaviour 2.1055 N/A N/A N/A(note 2) Audio Frequency Response (a) TIA EIA- 603.3.2.6 N/A N/A N/A Modulation Limiting TIA EIA- 603.3.2.6 N/A N/A N/A Signal Booster Labelling Requirements 20.21(f)(1)(ii) N/A N/A N/A Notes: 1 The EUT does not contain modulation circuitry; therefore the test was not performed. 2 The EUT is not a keyed carrier system; therefore the test was not performed. Abbreviations used in the above table: CFR : Code of Federal Regulations ANSI : American National Standards Institution REFE : Radiated Electric Field Emissions PLCE : Power Line Conducted Emissions A Uplink Results Appendix B Downlink Results Appendix 6 TRaC Global Test Report: TRA-017640-47-00-B 1.6 Equipment Test Conditions Product class: Uplink Class A [ ] Class B [X] Downlink Class A [ ] Class B [X] Product Use: Cellular / PCS Signal Booster Supply Voltages: Vnom 110Vac Note: Vnom voltages are as stated above unless otherwise shown on the test report page Equipment Category: Single channel [ ] Two channel [ ] Multi-channel [X] Channel spacing: Wideband Uplink Wideband Downlink Test Location TRaC Global Skelmersdale [X] Hull [ ] Other [ ] Please Specify 7 TRaC Global Test Report: TRA-017640-47-00-B 1.7 Standard References 47 CFR 2 Code of Federal Regulations, Title 47, Part 2, “Frequency allocations and Radio Telemetry Matters; General Rules and Regulations” 47 CFR 24 Code of Federal Regulations, Title 47, Part 24,” Personal Communications Services” 47 CFR 27 Code of Federal Regulations, Title 47, Part 27,” Miscell…
