NHPWLB2000802.11b WLAN Access Point

Wireless LAN Access Point User Guide Regulatory notes and statements Wireless LAN, Health and Authorization for use Radio frequency electromagnetic energy is emitted from Wireless LAN devices. The energy levels of these emissions however are far much less than the electromagnetic energy emissions from wireless devices like for example mobile phones. Wireless LAN devices are safe for use frequency safety standards and recommendations. The use of Wireless LAN devices may be restricted in some situations or environments for example: ·On board of airplanes, or ·In an explosive environment, or ·In case the interference risk to other devices or services is perceived or identified as harmful In case the policy regarding the use of Wireless LAN devices in specific organizations or environments (e.g. airports, hospitals, chemical/oil/gas industrial plants, private buildings etc.) is not clear, please ask for authorization to use these devices prior to operating the equipment. Regulatory Information/disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment. The Manufacturer is not responsible for any radio or television interference caused by unauthorized modification of this device, of the substitution or attachment. Manufacturer and its authorized resellers or distributors will assume no liability for any damage or violation of government regulations arising from failing to comply with these guidelines. USA-FCC (Federal Communications Commission) statement This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause interference, and 2. This device must accept any interference, including interference that may cause undesired operation of this device. FCC Radio Frequency Exposure statement This Wireless LAN radio device has been evaluated under FCC Bulletin OET 64C and found compliant to the requirements as set forth in CFR 47 Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF Exposure from radio frequency devices. The radiated output power of this Wireless LAN device is far below the FCC radio frequency exposure limits. Nevertheless, this device shall be used in such a manner that the potential for human contact during normal operation is minimized. When nearby persons has to be kept to ensure RF exposure compliance, in order to comply with RF exposure limits established in the ANSI C95.1 standards, the distance between the antennas and the user should not be less than 20 cm. FCC Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy. If not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try and correct the interference by one or more of the following measures: 1. Reorient or relocate the receiving antenna. 2. Increase the distance between the equipment and the receiver. 3. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. 4. Consult the dealer or an experienced radio/TV technician for help. Export restrictions This product or software contains encryption code that may not be exported or transferred from the US of Canada without an approved US Department of Commerce export license. Safety Statements Federal Communications Commission Statement This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: ·This device may not cause harmful interference, and ·This device must accept any interference received, including interference that may cause undesired operation. Safety Information Your device contains a low power transmitter. When device is transmitted it sends out radio frequency (RF) signal. CAUTION: To maintain compliance with FCC’s RF exposure guidelines, this equipment should be installed and operated with minimum distance 20cm between the radiator and your body. Use on the supplied antenna. Unauthorized antenna, modification, or attachments could damage the transmitter and may violate FCC regulations. CE Mark Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. TABLE OF CONTENT About This Guide.................................................................................1 Purpose.............................................................................................1 Overview of this User’s Guide.........................................................1 Unpacking and Setup...........................................................................3 Unpacking........................................................................................3 Setup................................................................................................3 Hardware Instalation............................................................................5 Front View.......................................................................................5 Rear Panel........................................................................................6 Hardware connections...............................................................…

Text truncated - open the document above for the full version.

External Photos of 802.11b Wireless LAN Access Point 1/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of 802.11b Wireless LAN Access Point 2/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of 802.11b Wireless LAN Access Point 3/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of 802.11b Wireless LAN Access Point 4/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of 802.11b Wireless LAN Access Point 5/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 External Photos of 802.11b Wireless LAN Access Point 6/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440

LABEL Position:

90.12.30 9500WLB20000XVV WLB-2000/X Joseph MODEL : WLB-2000/X Q'TY: S/N: 20 PCS FROM () TO CARTON OF NO. / MADE IN xxxxxx ( ) () VV , /x /A /E /F /J /S Joseph ! "MADE IN TAIWAN" "MADE IN CHINA" 6.00 mm 34.00 mm 000000000000(X) MAC: MADE IN xxxxxx Ver: XX Serial No: MODEL NO: WLB-2000/X () This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. ! 0470 FCC ID: NHPWLB2000 Right side of white box Box label WLB-2000/X MADE IN xxxxxx ! 0470 FCC ID: NHPWLB2000 WLB-2000/X MADE IN XXXXXX ! 0470 FCC ID: NHPWLB2000

Internal Photos of 802.11b Wireless LAN Access Point 1/5 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of 802.11b Wireless LAN Access Point 2/5 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of 802.11b Wireless LAN Access Point 3/5 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of 802.11b Wireless LAN Access Point 4/5 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Internal Photos of 802.11b Wireless LAN Access Point 5/5 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440

Training Research Co., Ltd. No. 255, Nan-yang Street, Shijr City, Taipei Hsien 221, Taiwan Tel: 886-2-26935155 Fax: 886-2-26934440 e-mail: [email protected] 1 of 2 TRCSince1985 ® Measurement of MPE 1. Foreword In adopt with the Human Exposure IEEE C95.1, and according to the FCC 1.1310. The Maximum Permissible Exposure (MPE) is obligated to measure in order to prove the safety of radiation harmfulness to the human body. The Gain of the antenna used is measured in an Anechoic chamber. The maximum total power to the antenna is to be recorded. By adopting the Friis Transmission Formula and the power gain of the antenna, we can find the distance right away from the product, where the limit of the MPE is. 2. Description of EUT Granted FCC ID : NHPWLB2000 Product name : 802.11b Wireless LAN Access Point Model name : as Appendix A of Test Report Classification : Mobile Device (i) Under normal use condition, the antenna is at least 20cm away from the user; (ii) Warning statement for keeping 20cm separation distance and the prohibition of operating next to the person has been printed in the user’s manual Frequency Range : 2.412 GHz ~ 2.462GHz Supported Channel : 11 Channel Modulation Skill : DBPSK, DQPSK, CCK Power Type : Powered by the Switching Power Adaptor Manufacturer: DVEModel: DSA-0151A-05 A I/P: AC 100-120V, 50/60Hz, 40VAO/P: +5V DC, 2.4A Training Research Co., Ltd. No. 255, Nan-yang Street, Shijr City, Taipei Hsien 221, Taiwan Tel: 886-2-26935155 Fax: 886-2-26934440 e-mail: [email protected] 2 of 2 TRCSince1985 ® 3. Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Filed Strength (H) (A/m) Power Density (S) (mW/cm2) Averaging Time |E| 2 , |H| 2 or S (minutes) (A) Limits for Occupational/Controlled Exposure 0.3-3.0 614 1.63 100 6 3.0-30 1842/f 4.89/f 900/f 2 6 30-300 61.4 0.163 1.0 6 300-1500 -- -- f/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3-1.34 614 1.63 100 30 1.34-30 824/f 2.19/f 180/f 2 30 30-300 27.5 0.073 0.2 30 300-1500 -- -- f/1500 30 1500-100,000 -- -- 1.0 30 [The EUT is tested in transmit and receive modes and in the first, middle and the last channel separately. The following shows only our observation have the greatest emissions.] According to OET BULLETIN 56 Fourth Edition/August 1999, Equation for Predicting RF Fields: Friis Transmission Formula: 22 22 /10531.1 )20(4 514.1816.50 4 cmmW R PG S − ×= × == ππ Estimated safe separation: cm PG R474.2 4 514.1816.50 4 = × == ππ Remarks: "The safe estimated separation that the user must maintain from the antenna is at least 2.474 cm." Where: S = power density (in appropriate units, e.g. mW/cm 2 ) P = power input to the antenna (in appropriate units, e.g., mW) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (appropriate units, e.g., cm) The Numeric gain G of antenna with a gain specified in dB is determined by: G = Log -1 ( dB antenna gain / 10 ) G = Log -1 (1.80 / 10) = 1.514

Test Report ------------------------------------------------------------------------------- 1/50 Report No.: C5115149, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 MEASUREMENT REPORT of 802.11b Wireless LAN Access Point Applicant : CAMEO COMMUNICATIONS, INC. Product Name : 802.11b Wireless LAN Access Point Model Name : as Appendix A FCC ID : NHPWLB2000 Report No. : C5115149 Tested by : Training Research Co., Ltd. TEL : 886-2-26935155 FAX : 886-2-26934440 No. 255, Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Test Report ------------------------------------------------------------------------------- 2/50 Report No.: C5115149, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 CERTIFICATION We here by verify that: The test data, data evaluation, test procedures and equipment configurations shown in this report were made mainly in accordance with the procedures given in ANSI C63.4 (1992) as a reference. All test were conducted by Training Research Co., Ltd., 255 Nanyang Street, Shijr, Taipei Hsien 221, Taiwan, R.O.C. Also, we attest to the accuracy of each. We further submit that the energy emitted by the sample EUT tested as described in the report is in compliance with the technical requirements set forth in the FCC Rules Part 15 Subpart B (Declaration of Conformity) and C Section 15.247. Applicant : CAMEO COMMUNICATIONS, INC. Applicant address : 6F, No.22, Chung Shin Rd., Hsi-Chih, Taipei 221, Taiwan Product Name : 802.11b Wireless LAN Access Point Model Name : as Appendix A FCC ID : NHPWLB2000 Report No. : C5115149 Test Date : March 17, 2003 Prepared by: Approved by: Jack Tsai Frank Tsai Conditions of issue : (1) This test report shall not be reproduced except in full, without written approval of TRC. And the test result contained within this report only relate to the sample submitted for testing. (2) This report must not be used by the client to claim product endorsement by NVLAP or any agency of U.S. Government. ́ NVLAP LAB CODE: 200174-0 Test Report ------------------------------------------------------------------------------- 3/50 Report No.: C5115149, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Federal Communications Commission Declaration of Conformity (DoC) For the Following Equipment: Product name : 802.11b Wireless LAN Access Point Model name : as Appendix A Trade name : as Appendix A Is herewith confirmed and found to comply with the requirements of CFR 47 part15 Subpart B - Unintentional Radiators regulation. The results of electromagnetic mission evaluation are shown in the report number: C5115149 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation Manufacturer USA local representative Company name: CAMEO COMMUNICATIONS, INC. To be determined Computer address: 6F, No.22, Chung Shin Rd., Hsi-Chih, Taipei 221, Taiwan ZIP / Postal code 221 Contact person: Jason Chang Title: Wireless Comm RD Dept Manager Internet e-mail address: [email protected] Tel / Fax: 886-2-26499800 / 886-2-26499984 Test Report ------------------------------------------------------------------------------- 4/50 Report No.: C5115149, FCC Part 15 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Tables of Contents Declaration of Conformity (DoC) ............................................................................................ 3 I. GENERAL ......................................................................................................................... 6 1.1 Introduction .................................................................................................................. 6 1.2 Description of EUT ....................................................................................................... 6 1.3 Description of Support Equipment ................................................................................. 6 1.4 Test method .................................................................................................................. 8 1.5 Configuration of System Under Test .............................................................................. 9 1.6 Verify the Frequency and Channel ................................................................................ 11 1.7 Test Procedure ............................................................................................................ 12 1.8 Location of the Test Site ............................................................................................... 12 1.9 General Test Condition ................................................................................................. 12 II. Section 15.101(a) : Equipment Authorization of Unintentional Radiators....................... 13 III. Section 15.203 : Antenna Requirement............................................................................. 14 IV. Section 15.207 : Power Line Conducted Emissions for AC Powered Units ................... 15 4.1 Test Condition & Setup ................................................................................................ 15 4.2 List of Test Instruments ................................................................................................ 15 4.3 Test Result of Conducted Emissions ............................................................................. 16 Table 1 EUT Ant. Undetachable, Channel 01 ............................................................... 16 Table 2 EUT Ant. Undetachable, Channel 06 ............................................................... 17 Table 3 EUT Ant. Undetachable, Channel 11 ............................................................... 17 Table 4 EUT Ant. Detachable, Standby mode .....…

Text truncated - open the document above for the full version.

Test Setup Photos ------------------------------------------------------------------------ 1/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement for EUT Antenna Undetachable: Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 2/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Conducted Test Setup Placement for EUT Antenna Detachable: Front View of the Test Configuration Side View of the Test Configuration Test Setup Photos ------------------------------------------------------------------------ 3/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement for EUT Antenna Undetachable: Front View of Unintentional Rear View of Unintentional Test Setup Photos ------------------------------------------------------------------------ 4/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement for EUT Antenna Undetachable: Front View of Intentional Rear View of Intentional Test Setup Photos ------------------------------------------------------------------------ 5/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement for EUT Antenna Detachable: Front View of Unintentional Rear View of Unintentional Test Setup Photos ------------------------------------------------------------------------ 6/6 FCC ID: NHPWLB2000 Training Research Co., Ltd., TEL: 886-2-26935155, Fax: 886-2-26934440 Radiated Test Setup Placement for EUT Antenna Detachable: Front View of Intentional Rear View of Intentional
