NHPWLG1501108Mbps Super-G Wireless Network USB Dongle

108Mbps Super-G TM Wireless Network USB Dongle USER MANUAL Contents 1. Introduction...............................................................................................1 1.1 Product Feature................................................................................1 1.2 System Requirement........................................................................1 2. Getting Start...............................................................................................2 2.1 LED Indicators..................................................................................2 2.2 Install the 108Mbps Wireless Network USB Dongle.........................2 2.2.1 Utility Installation....................................................................2 2.2.2 Driver Installation...................................................................6 3. Configuration..............................................................................................10 3.1 Link Information...................................................................................10 3.2 Configuration.......................................................................................11 3.3 Advanced.............................................................................................12 3.4 Site Survey..........................................................................................14 3.5 About US.............................................................................................15 4. Glossary......................................................................................................16 1. Introduction 1.1 Product Feature ● Compliance with IEEE802.11g and 802.11b standards ● Highly efficient design mechanism to provide unbeatable performance ● Achieving data rate up to 54Mbps for 802.11g and 11Mps for 802.11b with wide range coverage ● Strong network security with WEP,WPA and WPA-PSK support ● Auto-switch between the two standards, IEEE 802.11b and 802.11g ● Driver/Utility support most commonly used operating systems including Windows 2000/XP. ● Pen size which is easy to carry provides users the most mobility and flexibility. ● Support USB 2.0 and USB 1.1 at the same time, especially for USB 2.0 the data rate reaches 480MBytes. 1.2 System Requirement ● Windows 2000 and XP operating systems ● PC with Pentium III 600MHz system or above is recommended ● Equipped with at least one PC USB socket or PC USB adapter, USB 1.1 at least. ● One CD-ROM drive 1 2. Getting Start 2.1 LED Indicators The Power LED will be ON when the unit is powered up. The Link LED will be Blinking indicates a WLAN connection. 2.2 Install the 108Mbps Wireless Network USB Dongle 2.2.1 Utility Installation 1. Before insert USB Dongle into the PC USB of your computer, please install the Utility Program first. Make sure that the 108Mbps Wireless Network USB Dongle is NOT inserted into the USB slot. NOTE: all the snapped images of installation mentioned in this manual are based on Windows XP. For other windows operating system, all the procedures are the same but the screens are not the exactly same. 2 2. Turn on the computer. Insert the CD into the CD-ROM Drive. Please select “USB Dongle” and then click the “Install”. 3. InstallShield Wizard will automatically start. Please click “Next” to continue. If user wants to change the installation folder, press “Brower” to change the directory or press “Next” to continue. 3 4 4. Click “Finish” to finish the installation. 5 5. Restart computer to make the settings effective. 2.2.2 Driver Installation 1. After restarting the computer, insert the USB dongle into USB port. Few seconds later, there will be a window popup as the following picture. 6 2. Click “Continue Anyway” to keep installation going. 3. Click “Finish” to finish the driver of USB installation. 7 4. After installing the driver of USB, there will be another pop-up window as the following picture to guide you to keep installing the driver of USB Dongle. 5. Click “Continue Anyway” to keep installation going. 8 6. Click “Finish” to finish the driver of USB Dongle installation. 7. To make sure if the installation is successful, you could check it through the device management. 8. Once the installation is successful, a utility program icon will show on your desktop. To lunch the utility, just double click the icon. 9 3. Configuration 3.1 Link Information The default page is as below after you launch the Utility program. Status: Shows the SSID associated, which can be used to identify the wireless network. SSID: Shows current SSID, which must be the same for the wireless client and AP in order for communication to be established. Frequency: Shows the current frequency used for wireless network. Wireless Mode: Shows the current wireless mode used for wireless communication. Encryption: Shows the current encryption mode used for wireless network. Tx Rate: Shows the current data rate used for transmitting. Channel: Shows the current channel for communication. Link Quality: Shows the link quality of the 108Mbps Wireless Network USB Dongle with the Access Point when operating under Infrastructure mode. Signal Strength: Shows the wireless signal strength of the connection between the 108Mbps Wireless Network USB Dongle with the Access Point. Data Rate: Shows the statistics of data transfer, and the calculation is based on the number of packets transmitted and received. 10 3.2 Configuration This is the page where you can change the basic settings of the Access Point with the minimum amount of effort to implement a secure wireless network environment. SSID: Service Set Identifier, which is a unique name shared among all clients and nodes in a wireless network. The SSID must be identical for each clients and nodes in the wireless network. Wireless Mode: There are two types available for selection ●Infrastructure – to establish wireless communication with LAN and other wireless clients through the use the Access Points. ●Ad-H…

Text truncated - open the document above for the full version.

From: [email protected] [mailto:[email protected]] Sent: Friday, September 30, 2005 1:31 AM To: steve.cheng Subject: 回信: TCB Review Comments for (A05-0930a- NHPWLG1501, 940624L04) Dear Steve About the Channel description in manual, our meaning is as below: When you get the product which domain is FCC that you could choose the channel in 1~11. When you get the product which domain is ETSI that you could choose the channel in 1~13. When you get the product which domain is MKK that you could choose the channel in 1~14. We don't provide the function for customers to choose different domain by themselves. Thanks for your assistance! Best Regards Wendy Liao Wendy Liao (廖意紋)/ ADT Corp. TEL: 03-318-3232 EXT 1625 FAX: 03-318-5050 Email: [email protected] 地址:桃園縣龜山鄉文化村華亞二路１９號 "steve.cheng" <steve.cheng@nacs emc.com> 收 件人 Wendy Liao <[email protected]> 2005/09/30 下午 副本抄 送 04:20 [email protected] 主旨 TCB Review Comments for (A05-0930a- NHPWLG1501, 940624L04) TCB Review Comments for (A05-0930a- NHPWLG1501, 940624L04) -EMC- Question #1: P11 of user manual has following statement, please confirm if regulatory domain selection is available to the end user. Steve Cheng / Technical Reviewer Curtis-Straus Certification

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

FCC ID Label Location

WLG-1501 Ver.A1 MADE IN TAIWAN MACXXXXXXXXXXXX FCC ID: NHPWLG1501 0560 "See Caution in Manual"

Page 3 Page 4 Page 5

FCC ID: NHPWLG1501 Report No.: RF931027L05B Technical Description This device is a 108Mbps Super-G TM Wireless Network USB Dongle which operates in the 2.4GHz frequency spectrum with throughput of up to 108Mbps which OFDM technique for turbo mode will be applied. If the signal to noise radio is too poor which could not support 54Mbps, the 11Mbps data rate with CCK technique will be applied. The transmitter of the EUT is powered by host equipment. The antenna is Chip antenna without antenna connector. For more detailed instruction, please take a look at the user’s manual.

D4: 2450MHz SYSTEM VALIDATION DIPOLE SN: 716

D3: 3G DOSIMETRIC E-FIELD PROBE

D4: DAE SN: 510

APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION D1: SAM PHANTOM

APPENDIX A: TEST CONFIGURATIONS AND TEST DATA A1: TEST CONFIGURATION Mode 1 Bottom Position The bottom of the EUT to the flat phantom distance 6 mm Mode 2 Tip Position The tip of the EUT to the flat phantom distance 0 mm Mode 3 Bottom Position The bottom of the EUT to the flat phantom distance 6 mm Mode 4 Tip Position The tip of the EUT to the flat phantom distance 0 mm EUT Photo Liquid Level Photo MSL 2450MHz D=155mm Date/Time: 10/29/04 17:28:30 Test Laboratory: Advance Data Technology WLG-1501 11b Bottom Mode 1 Ch 1 DUT: 108Mbps Super-GTM Wireless Network USB Dongle ; Type: WLG-1501 ; Test Channel Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 ; Liquid level : 155mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.3 Build 22 ; Postprocessing SW: SEMCAD, V1.8 Build 127 Low Channel/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.483 mW/g Low Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.15 V/m; Power Drift = -0.1 dB Peak SAR (extrapolated) = 0.692 W/kg SAR(1 g) = 0.428 mW/g; SAR(10 g) = 0.235 mW/g Maximum value of SAR (measured) = 0.475 mW/g Date/Time: 10/29/04 17:46:52 Test Laboratory: Advance Data Technology WLG-1501 11b Bottom Mode 1 Ch 6 DUT: 108Mbps Super-GTM Wireless Network USB Dongle ; Type: WLG-1501 ; Test Channel Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2437 MHz; σ = 2 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 ; Liquid level : 155mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.3 Build 22 ; Postprocessing SW: SEMCAD, V1.8 Build 127 Middle Channel/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.450 mW/g Middle Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 5.39 V/m; Power Drift = -0.2 dB Peak SAR (extrapolated) = 0.679 W/kg SAR(1 g) = 0.400 mW/g; SAR(10 g) = 0.218 mW/g Maximum value of SAR (measured) = 0.452 mW/g Date/Time: 10/29/04 17:00:43 Test Laboratory: Advance Data Technology WLG-1501 11b Bottom Mode 1 Ch 11 DUT: 108Mbps Super-GTM Wireless Network USB Dongle ; Type: WLG-1501 ; Test Channel Frequency: 2462 MHz Communication System: 802.11b ; Frequency: 2462 MHz ; Duty Cycle: 1:1 ; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2462 MHz; σ = 2.04 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 ; Liquid level : 155mm Phantom section: Flat Section ; Separation distance : 6 mm (The bottom side of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510 ; Calibrated: 2004/8/17 - Phantom: SAM 12 ; Type: SAM V4.0 ; Serial: TP 1202 - Measurement SW: DASY4, V4.3 Build 22 ; Postprocessing SW: SEMCAD, V1.8 Build 127 High Channel/Area Scan (5x8x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.417 mW/g High Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 6.57 V/m; Power Drift = 0.2 dB Peak SAR (extrapolated) = 0.778 W/kg SAR(1 g) = 0.463 mW/g; SAR(10 g) = 0.256 mW/g Maximum value of SAR (measured) = 0.501 mW/g Date/Time: 10/29/04 19:11:22 Test Laboratory: Advance Data Technology WLG-1501 11b Tip Mode 2 Ch 1 DUT: 108Mbps Super-GTM Wireless Network USB Dongle ; Type: WLG-1501 ; Test Channel Frequency: 2412 MHz Communication System: 802.11b ; Frequency: 2412 MHz; Duty Cycle: 1:1; Modulation type: CCK Medium: MSL2450 Medium parameters used: f = 2412 MHz; σ = 1.96 mho/m; ε r = 52.8; ρ = 1000 kg/m 3 ; Liquid level : 155 mm Phantom section: Flat Section ; Separation distance : 0 mm (The tip of the EUT to the Phantom) Antenna type : Internal Antenna ; Air temp. : 22.0 degrees ; Liquid temp. : 21.0 degrees DASY4 Configuration: - Probe: ET3DV6 - SN1687 ; ConvF(4.23, 4.23, 4.23) ; Calibrated: 2004/8/26 - Sensor-Surface: 4mm (Mechanical Surface Detection) - Electronics: DAE3 Sn510; Calibrated: 2004/8/17 - Phantom: SAM 12; Type: SAM V4.0; Serial: TP 1202 - Measurement SW: DASY4, V4.3 Build 22; Postprocessing SW: SEMCAD, V1.8 Build 127 Low Channel/Area Scan (7x7x1): Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.136 mW/g Low Channel/Zoon Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 8.74 V/m; Power Drift = -0.2 dB Peak SAR (extrapolated) = 0.234 W/kg SAR(1 g) = 0.110 mW/g; SAR(10 g) = 0.051 mW/g Maximum value of SAR (measured) = 0.127 mW/g Date/Time: 10/29/04 19:30:21 Test Laboratory: Advance Data Technology WLG-1501 11b Tip Mode 2 Ch 6 DUT: 108Mbps Super-GTM Wireless Network USB Dongle ; Type: WLG-1501 ; Test Channel Frequency: 2437 MHz Communication System: 802.11b ; Frequency: 2437 MHz; Duty Cycle: 1:1; Modulation type: CCK Medium: MSL2450 Medium parameters used: …

Text truncated - open the document above for the full version.

B - 1 APPENDIX B: ADT SAR MEASUREMENT SYSTEM C - 1 APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION

FCC ID: NHPWLG1501 Report No.: RF931027L05B1Report Format Version 2.0.3 Reference No.: 940624L04 FCC TEST REPORT REPORT NO.: RF931027L05B MODEL NO.: WLG-1501 (refer to page 6 for other Models) RECEIVED: NA TESTED: Oct. 15 ~ Dec. 21, 2004 ISSUED: Sep. 02, 2005 APPLICANT: CAMEO COMMUNICATIONS, INC. ADDRESS: 5F, No. 42, Sec. 6, Mincyuan E. Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: 47 14 th Lin, Chiapau Tsun, Linko, Taipei, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Kueishan, Taoyuan, Taiwan, R.O.C. This test report consists of 73 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: NHPWLG1501 Report No.: RF931027L05B2Report Format Version 2.0.3 Reference No.: 940624L04 Table of Contents 1CERTIFICATION.........................................................................................................4 2SUMMARY OF TEST RESULTS.................................................................................5 2.1MEASUREMENT UNCERTAINTY..............................................................................5 3GENERAL INFORMATION.........................................................................................6 3.1GENERAL DESCRIPTION OF EUT...........................................................................6 3.2DESCRIPTION OF TEST MODES.............................................................................7 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST.........................................................7 3.2.2 TEST MODE APPLICABILITY:....................................................................................8 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS...........................................10 3.4DESCRIPTION OF SUPPORT UNITS.....................................................................10 4TEST TYPES AND RESULTS...................................................................................11 4.1CONDUCTED EMISSION MEASUREMENT............................................................11 4.1.1LIMITS OF CONDUCTED EMISSION MEASUREMENT..........................................11 4.1.2TEST INSTRUMENTS..............................................................................................11 4.1.3TEST PROCEDURES..............................................................................................12 4.1.4DEVIATION FROM TEST STANDARD.....................................................................12 4.1.5TEST SETUP...........................................................................................................13 4.1.6EUT OPERATING CONDITIONS.............................................................................13 4.1.7TEST RESULTS.......................................................................................................14 4.2RADIATED EMISSION MEASUREMENT.................................................................20 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT...............................................20 4.2.2TEST INSTRUMENTS..............................................................................................21 4.2.3TEST PROCEDURES..............................................................................................22 4.2.4DEVIATION FROM TEST STANDARD.....................................................................22 4.2.5TEST SETUP...........................................................................................................23 4.2.6EUT OPERATING CONDITIONS.............................................................................23 4.2.7TEST RESULTS.......................................................................................................24 4.36dB BANDWIDTH MEASUREMENT........................................................................33 4.3.1LIMITS OF 6dB BANDWIDTH MEASUREMENT......................................................33 4.3.2TEST INSTRUMENTS..............................................................................................33 4.3.3TEST PROCEDURE.................................................................................................34 4.3.4DEVIATION FROM TEST STANDARD.....................................................................34 4.3.5TEST SETUP...........................................................................................................34 4.3.6EUT OPERATING CONDITIONS.............................................................................34 4.3.7TEST RESULTS.......................................................................................................35 4.4MAXIMUM PEAK OUTPUT POWER........................................................................43 4.4.1LIMITS OF MAXIMUM PEAK OUTPUT POWER MEASUREMENT.........................43 4.4.2TEST INSTRUMENTS..............................................................................................43 4.4.3TEST PROCEDURES..............................................................................................44 4.4.4DEVIATION FROM TEST STANDARD.....................................................................44 4.4.5TEST SETUP...........................................................................................................44 4.4.6EUT OPERATING CONDITIONS.............................................................................44 4.4.7TEST RESULTS.......................................................................................................45 4.5POWER SPECTRAL DENSITY MEASUREMENT....................................................47 4.5.1LIMITS OF POWER SPECTRAL DENSITY MEASUREMENT.....................…

Text truncated - open the document above for the full version.

FCC ID: NHPWLG1501 Report No.: SA931027L05B1Report Format Version 2.0.2 Reference No.: 940624L04 SAR TEST REPORT REPORT NO.: SA931027L05B MODEL NO.: WLG-1501 (refer to page 4 for other Models) RECEIVED: NA TESTED: Oct. 29, 2004 ISSUED: Sep. 02, 2005 APPLICANT : CAMEO COMMUNICATIONS, INC. ADDRESS: 5F, No. 42, Sec. 6, Mincyuan E. Rd., Neihu District, Taipei City 114, Taiwan, R.O.C. ISSUED BY: Advance Data Technology Corporation LAB ADDRESS: No. 47, 14 th Ling, Chia Pau Tsuen, Lin Kou Hsiang 244, Taipei Hsien, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2 nd Rd., Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 32 pages in total except Appendix. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0528 ILAC MRA No. 2177-01 FCC ID: NHPWLG1501 Report No.: SA931027L05B2Report Format Version 2.0.2 Reference No.: 940624L04 Table of Contents 1.CERTIFICATION .........................................................................................................3 2.GENERAL INFORMATION..........................................................................................4 2.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .............................................5 2.2 GENERAL INOFRMATION OF THE SAR SYSTEM ...................................................5 2.3 GENERAL DESCRIPTION OF THE SPATIAL PEAK SAR EVALUATION ..................9 3.DESCRIPTION OF TEST MODES AND CONFIGURATIONS ..................................13 4.DESCRIPTION OF SUPPORT UNITS ......................................................................14 5.TEST RESULTS ........................................................................................................15 5.1 TEST PROCEDURES ...............................................................................................15 5.2 MEASURED SAR RESULT .......................................................................................16 5.3 SAR LIMITS...............................................................................................................18 5.4 RECIPES FOR TISSUE SIMULATING LIQUIDS ......................................................18 5.5 TEST EQUIPMENT FOR TISSUE PROPERTY ........................................................20 6.SYSTEM VALIDATION ..............................................................................................21 6.1 TEST EQUIPMENT ...................................................................................................21 6.2 TEST PROCEDURE .................................................................................................21 6.3 VALIDATION RESULT...............................................................................................24 6.4 SYSTEM VALIDATION UNCERTAINTIES ................................................................25 7.MEASUREMENT SAR PROCEDURE UNCERTAINTIES.........................................26 7.1 PROBE CALIBRATION UNCERTAINTY ...................................................................26 7.2 ISOTROPY UNCERTAINTY......................................................................................26 7.3 BOUNDARY EFFECT UNCERTAINTY .....................................................................27 7.4 PROBE LINEARITY UNCERTAINTY ........................................................................27 7.5 READOUT ELECTRONICS UNCERTAINTY ............................................................27 7.6 RESPONSE TIME UNCERTAINTY...........................................................................28 7.7 INTEGRATION TIME UNCERTAINTY ......................................................................29 7.8 PROBE POSITIONER MECHANICAL TOLERANCE................................................29 7.9 PROBE POSITIONING .............................................................................................30 7.10 PHANTOM UNCERTAINTY ......................................................................................30 7.11 DASY4 UNCERTAINTY BUDGET.............................................................................31 8.INFORMATION ON THE TESTING LABORATORIES ..............................................32 APPENDIX A: TEST CONFIGURATIONS AND TEST DATA APPENDIX B: ADT SAR MEASUREMENT SYSTEM APPENDIX C: PHOTOGRAPHS OF SYSTEM VALIDATION APPENDIX D: SYSTEM CERTIFICATE & CALIBRATION FCC ID: NHPWLG1501 Report No.: SA931027L05B3Report Format Version 2.0.2 Reference No.: 940624L04 1. CERTIFICATION PRODUCT : 108Mbps Super-G TM Wireless Network USB Dongle MODEL NO. : WLG-1501 (refer to page 4 for other Models) BRAND NAME : GLOBAL SUN (refer to page 4 for other Brands) APPLICANT : CAMEO COMMUNICATIONS, INC. TEST SAMPLE : Engineering Sample STANDARDS : FCC Part 2 (Section 2.1093), FCC OET Bulletin 65, Supplement C (01-01), RSS-102 The above equipment (model no.: WLG-1501) is identical to model no. WL UD 2454 17A, which has been tested by Advance Data Technology Corporation on Oct. 29, 2004, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY:, DATE: Sep. 02, 2005 Andrea Hsia TECHNICAL ACCEPTANCE:, DATE: Sep. 02, 2005 Responsible for RF Stenely Hsu APPROVED BY:, DATE: Sep. 02, 2005 Cody Chang, Deputy Manager FCC ID: NHPWLG1501 Report No.: SA931027L05B4Report Format Version 2.0.2 Reference No.: 940624L04 2. GENERAL INFORMATION PRODUCT 108Mbps Super-G TM Wireless Network USB Dongle MODEL NO. WLG-1501 POWER SUPPLY 5.0Vdc from host equipment CLASSIFICATION Portable de…

Text truncated - open the document above for the full version.

FCC ID: NHPWLG1501 Report No.: RF931027L05B71Report Format Version 2.0.3 Reference No.: 940624L04 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST FCC ID: NHPWLG1501 Report No.: RF931027L05B72Report Format Version 2.0.3 Reference No.: 940624L04 RADIATED EMISSION TEST
