NHPWTA268Intel Wireless Display TV Adaptor

12 3 456 WTA-268 Quick Install Guide TV Adaptor for Intel WiDi If any of the above items are missing, please contact your reseller. Package ContentsSystem RequirementsHardware Overview 1 Setup Button (Recessed) 4 S/PDIF Digital Audio PortOn/Off Button 2 HDMI Port 5 3 Composite Audio/Video Ports 6 Power Connector Power Adapter Outlet HDMI Cable Laptop HDMI Input TV Step 2Connect the supplied power adapter to the back of the WiDi TV adapter and the other end to a power outlet or surge protector. The WiDi TV adapter LED is red when it powers up. Then the LED turns yellow to indicate it is ready, but is not yet connected to your computer.Step 3Power on your TV and select the correct TV input source. Please refer to your TV documentation for instructions on how to change your input source. Step 4The Startup screen displays on your TV within 30 seconds. If this screen does not appear, make sure your TV is set to the correct video input and all the cables are firmly secured.Step 5Launch the Intel® Wireless Display software on your laptop. Some laptops may have a button or key, or launch from Windows. Click Start, type Intel® Wireless Display in the search field and then run the Intel® Wireless Display software.Step 6Use the Intel® Wireless Display software to scan and find the TV adapter for Intel® WiDi . The screen below shows that the Intel® Wireless Display software has found the wireless adapter.Step 7Doub le-click the TV adapter for Intel® WiDi TV adapter listed under Detected Adapters to connect to it. The LED on the TV adapter will start flashing green.If you are connecting the laptop to the WiDi TV adapter for the first time, it will display a 4-digit security code on the TV. E nter this 4-digit security code into the Intel® Wireless Display software. Step 8The TV screen will display your laptop screen and the LED on the WiDi TV adapter will turn solid green. Your device is now ready to use. Thank you for purchasing the WiDi TV Adapter. Follow the easy steps in this guide to properly set up your device. Please verify that all the package contents listed below are available. • Requires a laptop with Intel® Wireless Display powered by select Intel® Core™ processors• TV with a HDMI or AV Composite inputInstallationStep 1Connect the WiDi TV adapter to your TV. Use the HDMI connection for the best quality video. TV Adaptor for Intel WiDi EAD5 WTA-268 29072600WTA2680 FAQs This device may not be used for setting up outdoor radio links in France and in some areas the RF output power may be limited to 10 mW EIRP in the frequency range of 2454 – 2483.5 MHz. For detailed information the end-user should contact the national spectrum authority in France. Č esky [Czech] [Jméno výrobce] tímto prohlašuje, že tento [typ za ř ízení] je ve shod ě se základními požadavky a dalšími p ř íslušnými ustanoveními sm ě rnice 1999/5/ES. Dansk [Danish] Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr [udstyrets typebetegnelse] overholder de væsentlige krav og øvrige rel evante krav i direktiv 1999/5/EF. Deutsch [German] Hiermit erklärt [Name des Herstellers] , dass sich das Gerät [Gerätetyp] in Übereinstimmung mit den grundlegenden A nforderungen und den übrige n einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Eesti [Estonian] Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja nimetatud direktiivist tulenevatele teistele asjakoha stele sätetele. English Hereby, essential requirements and other relevant provisions of Directive 1999/5/EC. [name of manufacturer] , declares that this [type of equipment] is in compliance with the Español [Spanish] Por medio de la presente [nombre del fabricante] declara que el [clase de equipo] cumple con los requisitos esenciales y cualesquiera otras disposi ciones aplicables o exigibles de la Directiva 1999/5/CE. Ελληνική [Greek] ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment] ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ ΕΚ . Français [French] Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est conforme aux exigences essentielles et aux autres dispo sitions pertinentes de la directive 1999/5/CE. Italiano [Italian] Con la presente [nome del costruttore] dichiara che questo [tipo di apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Latviski [Latvian] Ar šo [name of manufacturer / izgatavot ā ja nosaukums] deklar ē , ka [type of equipment / iek ā rtas tips] atbilst Direkt ī vas 1999/5/EK b ū tiskaj ā m pras ī b ā m un citiem ar to saist ī tajiem noteikumiem. Lietuvi ų [Lithuanian] Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas. Nederlands [Dutch] Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in overeenstemming is met de essentiële eisen en de andere rele vante bepalingen van richtlijn 1999/5/EG. Malti [Maltese] Hawnhekk, [isem tal-manifattur] , jiddikjara li dan [il-mudel tal-prodott] jikkonforma mal- ħ ti ġ ijiet essenzjali u ma provvedimenti o ħ rajn relevanti li hemm fid Dirrettiva 1999/5/EC. - Magyar [Hungarian] Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak . Polski [Polish] Niniejszym [nazwa producenta] o ś wiadcza, ż e [nazwa wyrobu] jest zgodny z zasadniczymi wymogami oraz pozosta ł ymi stosownymi postanowieniami Dyrektywy 1999/5/EC. Português [Portuguese] [Nome do fabricante] declara que este [tipo de equipamento] está conforme com os requisitos essenciais e outras disposiç ões da Directiva 1999/5/CE. Slovensko [Slovenian] [Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami in ostalimi relevantnimi dolo č ili direktive 1999/5/ES. Slove…

Text truncated - open the document above for the full version.

Page 1 CONSTRUCTION PHOTOS OF EUT Page 2

59.00 39.00 Made in China Input: 12V 1.25A Polarity: FCC ID : NHPWTA268 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operations. Power Receptor ON/OFFS/PDIFSetup Button HDMIAnalog Audio Composit Video WiDi TV Adaptor WTA-268

Label Location

Page 3 Page 4 Page 5 Page 6 Page 7 Page 8 Page 9 Page 10 Page 11 Page 12 Page 13 Page 14

FCC ID: NHPWTA268 Report No.: RF110414C06 Operational Description This device is an Intel Wireless Display TV Adaptor, which operates in both 2.4GHz and 5GHz bands; the maximum data rate could be up to 300Mbps which OFDM technique. If the signal to noise radio is too poor which could not support 300Mbps, the 11Mbps data rate with DSSS technique will be applied. The transmitter of the EUT is powered by 12Vdc from AC adapter. The antenna is Printed antenna without antenna connector. FCC 15.407(c) states: The device shall automatically discontinue transmission in case of either absence of information to transmit or operational failure. These provisions are not intended to preclude the transmission of control or signaling information or the use of repetitive codes used by certain digital technologies to complete frame or burst intervals. Applicants shall include in their application for equipment authorization a description of how this requirement is met” Data transmission is always initiated by software, which is then pass down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets (ACKs, CTS, PSPoll, etc...) are initiated by the MAC. There are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets are being transmitted. For more detailed instruction, please take a look at the user’s manual.

Report No.: SA110104C15B Report Format Version 4.0.0 Reference No.: 110414C06 1 RF EXPOSURE REPORT REPORT NO.: SA110104C15B MODEL NO.: WTA-268 FCC ID: NHPWTA268 ACCORDING: FCC Guidelines for Human Exposure IEEE C95.1 APPLICANT: CAMEO COMMUNICATIONS, INC. ADDRESS: No. 42, Sec. 6, Mincyuan E. Rd., Neihu District, Taipei City 114, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 6 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced, except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval, or endorsement by any government agency. The test results in the report only apply to the tested sample. Report No.: SA110104C15B Report Format Version 4.0.0 Reference No.: 110414C06 2 TABLE OF CONTENTS RELEASE CONTROL RECORD ............................................................................................. 3 1. CERTIFICATION .......................................................................................................... 4 2. RF EXPOSURE............................................................................................................ 5 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE)...................................... 5 2.2 MPE CALCULATION FORMULA ................................................................................. 5 2.3 CLASSIFICATION ........................................................................................................ 5 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER............................... 6 Report No.: SA110104C15B Report Format Version 4.0.0 Reference No.: 110414C06 3 RELEASE CONTROL RECORD ISSUE NO. REASON FOR CHANGE DATE ISSUED Original release NA Apr. 19, 2011 Report No.: SA110104C15B Report Format Version 4.0.0 Reference No.: 110414C06 4 1. CERTIFICATION PRODUCT: Intel Wireless Display TV Adaptor MODEL: WTA-268 BRAND: CAMEO APPLICANT: CAMEO COMMUNICATIONS, INC. TESTED: Dec. 29, 2010 ~ Jan. 18, 2011 TEST SAMPLE: ENGINEERING SAMPLE STANDARDS: FCC Guidelines for Human Exposure IEEE C95.1 The above equipment (Model: WTA-268) has been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE:Apr. 19, 2011 Ivy Lin / Specialist APPROVED BY : , DATE:Apr. 19, 2011 Gary Chang / Assistant Manager Report No.: SA110104C15B Report Format Version 4.0.0 Reference No.: 110414C06 5 2. RF EXPOSURE 2.1 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) FREQUENCY RANGE (MHz) ELECTRIC FIELD STRENGTH (V/m) MAGNETIC FIELD STRENGTH (A/m) POWER DENSITY (mW/cm 2 ) AVERAGE TIME (minutes) LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE 300-1500 ... ... F/1500 30 1500-100,000 ... ... 1.0 30 F = Frequency in MHz 2.2 MPE CALCULATION FORMULA Pd = (Pout*G) / (4*pi*r2) where Pd = power density in mW/cm2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm 2.3 CLASSIFICATION The antenna of this product, under normal use condition, is at least 20cm away from the body of the user. So, this device is classified as Mobile Device. Report No.: SA110104C15B Report Format Version 4.0.0 Reference No.: 110414C06 6 2.4 CALCULATION RESULT OF MAXIMUM CONDUCTED POWER FREQUENCY BAND (MHz) MAX POWER (dBm) ANTENNA GAIN (dBi) DISTANCE (cm) POWER DENSITY (mW/cm 2 ) LIMIT (mW/cm 2 ) 2412-2462 28.8 2 20 0.239 1 5180-5240 16.5 3 20 0.018 1 5745-5825 25.3 3 20 0.135 1

Report No.: RF110104C15B 1 Report Format Version 4.0.0 Reference No.: 110414C06 FCC TEST REPORT (15.247) REPORT NO.: RF110104C15B MODEL NO.: WTA-268 FCC ID: NHPWTA268 RECEIVED: Dec. 29, 2010 TESTED: Dec. 29, 2010 ~ Jan. 17, 2011 ISSUED: Apr. 19, 2011 APPLICANT: CAMEO COMMUNICATIONS, INC. ADDRESS: No. 42, Sec. 6, Mincyuan E. Rd., Neihu District, Taipei City 114, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 124 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110104C15B 2 Report Format Version 4.0.0 Reference No.: 110414C06 TABLE OF CONTENTS RELEASE CONTROL RECORD.............................................................................................. 5 1. CERTIFICATION........................................................................................................... 6 2. SUMMARY OF TEST RESULTS .................................................................................. 7 2.1 MEASUREMENT UNCERTAINTY................................................................................ 7 3. GENERAL INFORMATION ........................................................................................... 8 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 8 3.2 DESCRIPTION OF TEST MODES ............................................................................. 10 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST ........................................................ 11 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 12 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 17 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 17 4. TEST TYPES AND RESULTS (FOR 2.4GHz BAND) ................................................. 18 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 18 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 18 4.1.2 TEST INSTRUMENTS................................................................................................ 19 4.1.3 TEST PROCEDURES ................................................................................................ 20 4.1.4 DEVIATION FROM TEST STANDARD....................................................................... 20 4.1.5 TEST SETUP.............................................................................................................. 21 4.1.6 EUT OPERATING CONDITIONS ............................................................................... 21 4.1.7 TEST RESULTS ......................................................................................................... 22 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 36 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 36 4.2.2 TEST INSTRUMENTS................................................................................................ 36 4.2.3 TEST PROCEDURES ................................................................................................ 37 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 37 4.2.5 TEST SETUP.............................................................................................................. 38 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 38 4.2.7 TEST RESULTS ......................................................................................................... 39 4.3 6dB BANDWIDTH MEASUREMENT.......................................................................... 43 4.3.1 LIMITS OF 6dB BANDWIDTH MEASUREMENT ....................................................... 43 4.3.2 TEST INSTRUMENTS................................................................................................ 43 4.3.3 TEST PROCEDURE................................................................................................... 43 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 43 4.3.5 TEST SETUP.............................................................................................................. 44 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 44 4.3.7 TEST RESULTS ......................................................................................................... 45 Report No.: RF110104C15B 3 Report Format Version 4.0.0 Reference No.: 110414C06 4.4 MAXIMUM OUTPUT POWER .................................................................................... 49 4.4.1 LIMITS OF MAXIMUM OUTPUT POWER MEASUREMENT..................................... 49 4.4.2 INSTRUMENTS .......................................................................................................... 49 4.4.3 TEST PROCEDURES ................................................................................................ 49 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 50 4.4.5 TEST SETUP.............................................................................................................. 50…

Text truncated - open the document above for the full version.

Report No.: RF110104C15B-1 1 Report Format Version 4.0.0 Reference No.: 110414C06 FCC TEST REPORT (15.407) REPORT NO.: RF110104C15B-1 MODEL NO.: WTA-268 FCC ID: NHPWTA268 RECEIVED: Dec. 29, 2010 TESTED: Dec. 30, 2010 ~ Jan. 18, 2011 ISSUED: Apr. 19, 2011 APPLICANT: CAMEO COMMUNICATIONS, INC. ADDRESS: No. 42, Sec. 6, Mincyuan E. Rd., Neihu District, Taipei City 114, Taiwan ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Tsuen, Lin Kou Hsiang, Taipei Hsien 244, Taiwan, R.O.C. TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This test report consists of 72 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product, certification, approval or endorsement by TAF or any government agency. The test results in the report only apply to the tested sample. Report No.: RF110104C15B-1 2 Report Format Version 4.0.0 Reference No.: 110414C06 TABLE OF CONTENTS RELEASE CONTROL RECORD.............................................................................................. 4 1. CERTIFICATION........................................................................................................... 5 2. SUMMARY OF TEST RESULTS .................................................................................. 6 2.1 MEASUREMENT UNCERTAINTY................................................................................ 6 3. GENERAL INFORMATION ........................................................................................... 7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................. 7 3.2 DESCRIPTION OF TEST MODES ............................................................................... 9 3.2.1 CONFIGURATION OF SYSTEM UNDER TEST .......................................................... 9 3.2.2 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL ............................. 10 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS ............................................ 12 3.4 DESCRIPTION OF SUPPORT UNITS ....................................................................... 12 4. TEST TYPES AND RESULTS .................................................................................... 13 4.1 RADIATED EMISSION MEASUREMENT .................................................................. 13 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT................................................ 13 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 13 4.1.3 TEST INSTRUMENTS................................................................................................ 14 4.1.4 TEST PROCEDURES ................................................................................................ 15 4.1.5 DEVIATION FROM TEST STANDARD....................................................................... 15 4.1.6 TEST SETUP.............................................................................................................. 16 4.1.7 EUT OPERATING CONDITION.................................................................................. 16 4.1.8 TEST RESULTS ......................................................................................................... 17 4.2 CONDUCTED EMISSION MEASUREMENT ............................................................. 27 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT........................................... 27 4.2.2 TEST INSTRUMENTS................................................................................................ 27 4.2.3 TEST PROCEDURES ................................................................................................ 28 4.2.4 DEVIATION FROM TEST STANDARD....................................................................... 28 4.2.5 TEST SETUP.............................................................................................................. 29 4.2.6 EUT OPERATING CONDITIONS ............................................................................... 29 4.2.7 TEST RESULTS ......................................................................................................... 30 4.3 PEAK TRANSMIT POWER MEASUREMENT ........................................................... 34 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT ......................................... 34 4.3.2 TEST INSTRUMENTS................................................................................................ 34 4.3.3 TEST PROCEDURE................................................................................................... 35 4.3.4 DEVIATION FROM TEST STANDARD....................................................................... 35 4.3.5 TEST SETUP.............................................................................................................. 35 4.3.6 EUT OPERATING CONDITIONS ............................................................................... 35 4.3.7 TEST RESULTS ......................................................................................................... 36 Report No.: RF110104C15B-1 3 Report Format Version 4.0.0 Reference No.: 110414C06 4.4 PEAK POWER EXCURSION MEASUREMENT ........................................................ 40 4.4.1 LIMITS OF PEAK POWER EXCURSION MEASUREMENT...................................... 40 4.4.2 TEST INSTRUMENTS................................................................................................ 40 4.4.3 TEST PROCEDURE................................................................................................... 40 4.4.4 DEVIATION FROM TEST STANDARD....................................................................... 41 4.4.5 TEST SETUP..........................................…

Text truncated - open the document above for the full version.

1 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (TEST MODE A) 2 CONDUCTED EMISSION TEST (TEST MODE B) 3 RADIATED EMISSION TEST (TEST MODE A) 4 RADIATED EMISSION TEST (TEST MODE B)
