Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Facsimile:+81 596 39 0232 This laboratory is registered by the NIST/NVLAP, U.S.A. The tests reported herein have been performed in accordance with its terms of registration. EMISSION TEST REPORT Test Report No. : 19C0029-02 TOHOKU ALPS CO., LTD. Model:880******* FCC Part 15 Subpart B IC RSS-210 (Issue No. 2) 1. This test report shall not be reproduced except in full, without the written approval of A-Pex International Co., Ltd. 2. This test report does not constitute an endorsement by NIST/NVLAP or U.S. Government. 3. This equipment is in compliance with above regulation. We hereby certify that the data are contain a true representation of the emission profile. 4. The results in this report apply only to the sample tested. 5. This test report clearly shows that Keyless Entry Unit (Receiver) , 880******* (88035FE020) is in compliance with FCC Part 15 Subpart B Class B and IC RSS-210 (Issue No. 2), specification. 6. IC RSS-210 (Issue No. 2) is based upon FCC Part 15. Date of test: March 23, 2000 Is sue d da te : March 27, 2000 Te ste d by: Approved by: Naoki SakamotoKazutoyo Nakanishi Engineer, EMC Dept. Group Leader of EMC section Form Version No. 1 Te s t re po rt FCC ID : NHVVG1U113 Our reference : 19C0029-02 Page : 2 of 15 Issued date : 2000-03-27 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 Table of Contents Page 1 GENERAL INFORMATION3 1.1 Product Description4 1.2 Tested System Details4 1.3 Tested Methodology5 1.4 Test Facility5 2 SYSTEM TEST CONFIGURATION6 2. 1 Operation Environment 6 2.2 Justification6 2. 3 EUT Exercise Software6 2.4 Test Procedure7 Figure 2.1 Configuration of Tested System8 3 RADIATED MEASUREMENT PHOTOS10 Figure 3.1 Radiated Measurement Photos10 3.1 Measurement Uncertainty11 4 RADIATED EMISSION DATA12 4.1 Field Strength Calculation13 5 TEST EQUIPMENT USED14 APPENDIX15 A:Test Data A1 - A2 Te s t re po rt FCC ID : NHVVG1U113 Our reference : 19C0029-02 Page : 3 of 15 Issued date : 2000-03-27 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1 GENERAL INFORMATION APPLICANT: TOHOKU ALPS CO., LTD. ADDRESS: 6-3-36, Nakazato, Furukawa-city, Miyagi-ken, 989-6181 Japan Tel: +81-229-23-5111 Fax: +81-229-22-3755 REGULATION(S): FCC Part 15 Subpart B MODEL NUMBER: 880******* (88035FE020) SERIAL NUMBER: - KIND OF EQUIPMENT: Keyless Entry Unit (Receiver) TESTED DATE: March 23, 2000 RECEIPT DATE OF SAMPLE : March 22, 2000 REPORT FILE NUMBER: 19C0029-02 TEST SITE: A-PEX Yokowa NO.2 Open Test Site Te s t re po rt FCC ID : NHVVG1U113 Our reference : 19C0029-02 Page : 4 of 15 Issued date : 2000-03-27 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1.1 Product Description Model: 880******* (referred to as the EUT in this report) is a Keyless Entry Unit(Receiver). This device has some series models to enter the characters as like the numerals or the alphabet in [*******]. Model No.: 88035FE020 was measured in behalf of all series models since these models have the same electric characteristics. The operatio n freq ue nc y is as following : Main Clock : 4.19MHz Sub Clock: 32.768kHz Operation voltage : DC 12V 1.2 Tested System Details The FCC IDs for all equipment, plus description of all cables used in the tested system are: ModelFCC IDDescriptionCable description Backshell Material (CANADA Certification No.) (1) ALPS ELECTRONICS NHVVG1U113Keyless Entr y Unit Uns hielded I/F Cable P.V.C. CO., LTD. (Receiver) M/N: 88035FE020 S/N: - (EUT) (2) ALPINEA269ZUA111Transmitter - - M/N: 88035AC230 (700101672) S/N: H91056558 (3) ALPS ELECTRONICS N/A Simulator Unshielded I/F Cable P.V.C. CO., LTD. M/N: - S/N: - (4) YUASA CorporationN/A Batter y Uns hielded DC Power Cable P.V.C. M/N: - S/N: - Te s t re po rt FCC ID : NHVVG1U113 Our reference : 19C0029-02 Page : 5 of 15 Issued date : 2000-03-27 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 1.3 Tested Methodology Both conducted and radiated testing were performed according to the procedures in FCC/ANSI C63.4(1992). Radiated testing was performed at a distance of 3 meters from the antenna to EUT. 1.4 Test Facility The open area test site and conducted measurement facility used to collect the radiated data is located at 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 Japan. This site has been fully described in a report dated May 27, 1997 submitted to FCC office, and Listed dated Aug. 18, 1997 (31040/SIT 1300F2). Te s t re po rt FCC ID : NHVVG1U113 Our reference : 19C0029-02 Page : 6 of 15 Issued date : 2000-03-27 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 2 SYSTEM TEST CONFIGURATION 2.1 Operation Environment Radiation Temperature : 23 Degree Humidity: 32% Power supply : DC 12V 2.2 Justification The system was configured in typical fashion (as a customer would normally use it) for testing. 2.3 EUT Exercise Software The EUT exercise program used during radiated and conducted testing was designed to exercise the various system components in a manner similar to typical use. The sequence is used: Operation: Receiving mode Te s t re po rt FCC ID : NHVVG1U113 Our reference : 19C0029-02 Page : 7 of 15 Issued date : 2000-03-27 Testing Laboratory A-pex International Co., Ltd. Telephone:+81 596 39 1485 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPANFacsimile:+81 596 39 0232 2.4 Test Procedure 2.4.1 Tabletop Equipment Radiated Emissions EUT was placed on a platform of nominal size, 1m by 1.5m, raised 80cm above the conducting ground plane. The rear of Eโฆ
Text truncated - open the document above for the full version.
108 Yokowa-cho ยท Ise-shi ยท Japan
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15B | 433.67 MHz - 434.17 MHz | - |

Remote Control for the Vehicle
Equipment Class
DSC - Part 15 Security/Remote Control Transmitter
Passive Entry System
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Passive Entry System
Equipment Class
DSR - Part 15 Remote Control/Security Device Transceiver
Passive Entry System
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
Passive Entry System
Equipment Class
DCD - Part 15 Low Power Transmitter Below 1705 kHz
