NKF-ARENAINDYRAID

Exhibit C User Manual Arena Indy 2200 19" Rackmount Ultra 160 SCSI to IDE Disk Array System User's Guide Version 2.20A Jan. 2002 ID-2200 19" Rackmount Ultra 160 SCSI to IDE Disk Array System User's Guide Version 2.20A Jan. 2002 Copyright Notice 2002 MaxTronic International Co., Ltd. All rights reserved. No part of this written material may be reproduced, stored in a retrieval system, used in any form or by any means, electronic or mechanical, photocopying, recording, or otherwise, without the written permission of MaxTronic International CO., LTD. c FCC (applies in the U.S. and Canada) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with this user's guide, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Warning and Certifications This device is in conformity with the EMC * Reorient or relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of FCC Rules. Operation is subjected to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Use only shielded cables to connect I/O devices to this equipment. You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void you authority to operate the equipment. Warning: Important ! Safety Instructions, Care and Handling 1. Before starting, take a few minutes to read this manual, read all of these instructions and save this manual for later reference. 2. Protect the Disk Array from extremely high or low temperatures. Let the Disk Array warm (or cool ) to room temperature before using it. 3. Protect the Disk Array from being bumped or dropped. Do not place this product on an unstable cart, stand, or table. It may fall, causing serious damage to the product. 4. Keep the Disk Array away from magnetic forces. 5. Do not use this product near water. 6. Keep the Disk Array away from dust, sand, or dirt. 7. Gaps and openings in the cabinet and the back are provided for ventilation. To ensure reliable operation and to protect it from overheating, the gaps and openings should never be blocked or covered by placing the product on a bed, sofa, rug, or other similar surface. 8. Do not place this product near or over a radiator or heat register. 9. Refer to rating plate for voltage and check that the appliance voltage corresponds to the supply voltage. 10. The appliance must be grounded. This product is equipped with a 3wire grounding-type power cord, this power cord will only fit into a groundingtype power outlet. 11. If an extension cord or a power center is used with this product, make sure that the total of all products plug into the wall outlet does not exceed the ampere rating. 12. Do not place the Disk Array where the cord will be walked on. 13. Never push any kind of object into this product through cabinet gaps and openings, they may touch dangerous voltage points cause a risk of fire or electric shock. 14. Unplug the power cord from the wall outlet before cleaning. Keep the Disk Array dry. Do not use liquid cleaners, aerosol cleaners, or a wet cloth. Use a damp cloth for cleaning. 15. Except as specifically explained in this User's Manual, please do not attempt to service this product by yourself. Opening or removing the covers may expose you to dangerous voltages. 16. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions : If this product has been exposed to water or any liquid. If the product has been dropped or the cabinet damaged. Operating Environment When selecting a suitable working location, please consider : Ventilation Temperature Dust and dirt Electromagnetic and Radio Frequency Interference. Security The selected location should provide at least six inches of open space around the Disk Array cabinet for proper air flow. Your Disk Array functions best at normal room temperature. Choose a location free from extreme heat or cold. Warning! The Disk Array's LCD Panel may be damaged by exposure to intense sunlight. Limit exposure to indirect or subdued sunlight only. Your Disk Array should be used in a clean environment that is free from airborne contaminants such as dust, dirt, and smoke. Excessive moisture or oil particles in the air can also hinder your system's performance. To reduce the possibility of data errors caused by electromagnetic interference, locate your Disk Array at least five feet away from electrical appliances and equipment that generates magnetic fields. About This Manual This manual serves as a useful guide you can refer to when you wish to install and operate your Disk Array. It includes the following information : Chapter 1 : " Introduction " Introduces you to your new Disk Array's features and general RAID concepts. Chapter 2 : " Getting Started " Describes general information about this Disk Array. Chapter 3 : " Configuration " Provides a Quick and Easy way to setup this Disk Array. Chapter 4 : " Advanced Information " Describ…

Text truncated - open the document above for the full version.

Exhibit D Block Diagram

Exhibit A LABEL Size of Label Long x Wide = 2.5 cm x 1.0 cm Position of Label This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC ID : NKF- ArenaIndy Model No.: ArenaInd y

Exhibit F Photograph of EUT

Applicant : MaxTronic International Co., Ltd. Equipment : RAID Model : ArenaIndy Contain Exhibit A Label Exhibit B Test Report Exhibit C User Manual Exhibit D Block Diagram Exhibit E Circuit Diagram Exhibit F Photograph of EUT Exhibit B Te s t R e p o r t FCC Test Report ----------------------------------------------------------------------------------------------------------2/20 Report Number: RE-A09-FC-667 Test Date: Oct. 25, 2001 RAID Best Laboratory Co., Ltd. Tel: 886-2-2646-2899 Fax: 886-2-2646-2870 Contain 1 General Information 1.1 EUT Description....................................................................................................................3 1.2 Test System Detail.................................................................................................................4 1.3 Tested Configuration.............................................................................................................6 1.4 EUT Exercise Software.........................................................................................................7 1.5 Test Performed.......................................................................................................................7 2 Conducted Emission Measurement 2.1 Test Equipment List...............................................................................................................8 2.2 Test Set-Up.............................................................................................................................8 2.3 Limit ......................................................................................................................................8 2.4 Test Procedure........................................................................................................................9 2.5 Test Specification...................................................................................................................9 2.6 Test Result..............................................................................................................................9 3 Radiated Emission Measurement 3.1 Test Equipment List...............................................................................................................10 3.2 Test Set-Up............................................................................................................................10 3.3 Limit......................................................................................................................................11 3.4 Test Procedure.......................................................................................................................11 3.5 Test Specification..................................................................................................................11 3.6 Test Result.............................................................................................................................11 4 Modification List 5 Appendix Appendix A: Summary of Test Result.........................................................................14 Appendix B: The Photograph of measurement............................................................18 FCC Test Report ----------------------------------------------------------------------------------------------------------3/20 Report Number: RE-A09-FC-667 Test Date: Oct. 25, 2001 RAID Best Laboratory Co., Ltd. Tel: 886-2-2646-2899 Fax: 886-2-2646-2870 1. General Information 1.1 EUT Description Applicant : MaxTronic International Co., Ltd. Address : 4F, No. 529, Chung Cheng Rd., Hsin Tien City, Taipei Hsien, Taiwan, R.O.C. Equipment : RAID FCC ID : NKF- ArenaIndy Model : ArenaIndy Device’s Class : Class B Device Operation Voltage : 120VAC, 60Hz Output Ports : Power Port : Connected with the AC power source via one power cable which length is 1.8 meters long, non-shielded, no ferrite bead. Host #1 Port : Connected with the SCSI card installed in the PC located in near-end, via one SCSI cable which length is 1.55 meters long, shielded, no ferrite bead. Host #2 Port : Directly connected with one terminator. Terminal Port: Connected with one RS-232 cable, 1.7 meters long, shielded, with ferrite bead, to the serial port of PC. HDD #1 Socket: Putted in one hard disk driver. FCC Test Report ----------------------------------------------------------------------------------------------------------4/20 Report Number: RE-A09-FC-667 Test Date: Oct. 25, 2001 RAID Best Laboratory Co., Ltd. Tel: 886-2-2646-2899 Fax: 886-2-2646-2870 1.2 Test System Detail PC : TECO Model No. : M18-D8K7-1 Serial No. : 991120-0118; 991120-0144 FCC ID : DoC Approval BSMI : 3872A092 Power Type : 100-240VAC, 50/60Hz, 1.5A, Switching Power Cord : 180cm long, non-shielded, no ferrite bead. Data Cable : 120cm long, shielded, with ferrite bead Monitor : Viewsonic Model No. : VCDT321496-1D Serial No. : HR94500066 FCC ID : DoC Approval BSMI : 3882A702 Power Type : 100-240VAC, 50/60Hz, 1.5A, Switching Power Cord : 180cm long, non-shielded, no ferrite bead. Data Cable : 120cm long, shielded, with ferrite bead Backshell : Metal Connected Port : VGA Port Keyboard : Logitec Model No. : SK-720 Serial No. : N/A FCC ID : GYUR49SK BSMI : 3872A806 Power Type : By PC Data Cable : 180cm long, shielded, no ferrite bead Backshell : Metal Connected Port : PS/2 Keyboard Port Mouse : Logitech Model No : M-S48a Serial No. : N/A FCC ID : JNZ201213 BSMI : 4882A001 Power Type : By PC Data Cable : 120cm long, non-shielded, no ferrite bead Backshell : Metal Connected Port : PS/2 Mouse Port Printer : Epson Model No. : P950 Serial No. : BW9Y113923 FCC ID : DoC Approval BSMI : 3872P001 Power Type : 120VAC, 60Hz, 0.4A Power Core : 165cm long, non-shielded, no ferrite bead Data Cable : 120cm long, shielded, no ferrite bead Backshell : Metal Connected Port : Parallel Port FCC Test Report ----------------------------------------------------------------------------------------------------------5/20 R…

Text truncated - open the document above for the full version.

FCC Test Report ----------------------------------------------------------------------------------------------------------19/20 Report Number: RE-A09-FC-667 Test Date: Oct. 25, 2001 RAID Best Laboratory Co., Ltd. Tel: 886-2-2646-2899 Fax: 886-2-2646-2870 The Photograph of Conducted Emission Test FCC Test Report ----------------------------------------------------------------------------------------------------------20/20 Report Number: RE-A09-FC-667 Test Date: Oct. 25, 2001 RAID Best Laboratory Co., Ltd. Tel: 886-2-2646-2899 Fax: 886-2-2646-2870 The Photograph of Radiated Emission Test
