TABLE OF CONTENTS APPLICANT: SECURITY ASSOCIATES INTERNATIONAL D/B/A J. TECHNOLOGY FCC ID: NNK1TWTX TEST REPORT CONTAINING: PAGE 1.............TEST PROCEDURE PAGE 2.............CIRCUIT DESCRIPTION & TEST PROCEDURE PAGE 3.............RADIATION INTERFERENCE TEST DATA PAGE 4.............CALCULATION OF DUTY CYCLE PAGE 5.............OCCUPIED BANDWIDTH EXHIBIT ATTACHMENTS: EXHIBIT 1...........POWER OF ATTORNEY LETTER EXHIBIT 2...........LETTER CONFIRMING MODIFICATIONS EXHIBIT 3...........BLOCK DIAGRAM EXHIBIT 4...........SCHEMATIC EXHIBIT 5A-5C.......INSTRUCTION MANUAL EXHIBIT 6...........FCC ID LABEL SAMPLE EXHIBIT 7...........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 8...........DUTY CYCLE PLOT EXHIBIT 9...........OCCUPIED BANDWIDTH PLOT EXHIBIT 10..........FRONT VIEW EXTERNAL PHOTO EXHIBIT 11..........REAR VIEW EXTERNAL PHOTO EXHIBIT 12-13.......COMPONENT SIDE INTERNAL PHOTO EXHIBIT 14-15.......COPPER SIDE INTERNAL PHOTO APPLICANT: SECURITY ASSOCIATES INTERNATIONAL D/B/A J. TECHNOLOGY FCC ID: NNK1TWTX REPORT #: T:\CUS\S\SAI\329Z9\SAI329Z9.RPT PAGE: TABLE OF CONTENTS LIST APPLICANT: SECURITY ASSOCIATES INTERNATIONAL D/B/A J. TECHNOLOGY FCC ID: NNK1TWTX TEST EQUIPMENT LIST 1. Spectrum Analyzer: Hewlett Packard 8566B - Opt 462, w/ preselector 85685A, & Quasi-Peak Adapter HP 8565OA, & HP 8449B - OPT H02 Cal. 7/6/99 2. Signal Generator, Hewlett Packard 8640B, cal. 9/23/99 3. Signal Generator, HP 8614A Serial No.2015A07428 cal. 5/27/99 3. Eaton Biconnical Antenna Model 94455-1 20-200 MHz Serial No. 0997 Cal. 10/30/98 4. Electro-Metric Dipole Kit, 20-1000 MHz, Model TDA-30 10/31/98 5. Electro-Metric Horn 1-18 GHz, Model RGA-180, Cal. 4/27/99 6. Electro-Metric Antennas Model TDA-30/1-4,Cal. 10/15/98 7. Electro-Metric Line Impedance Stabilization Network Model No. EM-7821, Serial No. 101; 100KHz-30MHz 50uH. Cal.11/19/98 8. Electro-Metric Line Impedance Stabilization Network Model No. EM-7820, Serial No. 2682; 10KHz-30MHz 50uH. Cal. 11/19/98 9. Special low loss cable was used above 1 GHz 10. Tenney Temperature Chamber 11. AC Voltmeter, HP 400FL, Serial No 2213A14499. Cal. 9/21/99 12. Digital Multimeter, Fluke 8010A/12A, Serial No. 4810047. Cal 9/21/99 13. Digital Multimeter, Fluke 77, Serial No. 43850817. Cal 9/21/99 14. Oscilloscope, Tektronix 2230, Serial No. 300572. Cal 9/23/99 15. Frequency Counter, HP 5385A, Serial No. 3242A07460. Cal 10/6/99 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-1992 using a HEWLETT PACKARD spectrum analyzer with a prese- lector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz. The ambient temperature of the UUT was 98.3oF with a humidity of 40%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was estab- lished by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor sup- plied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m REPORT #: T:\CUS\S\SAI\329Z9\SAI329Z9.RPT PAGE #: 1 TEST PROCEDURES CONTD. ANSI STANDARD C63.4-1992 10.1.7 MEASUREMENT PROCEDURES: The UUT was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The UUT was placed in the center of the table. The table used for radiat- ed measurements is capable of continuous rotation. The spectrum was scanned from 30 MHz to 10th harmonic of the fundamental. Peak readings were taken in three (3) orthogonal planes and the high- est readings were converted to average readings based on the duration of "ON" time. Measurements were made by TIMCO ENGINEERING INC. at the registered open field test site located at 6051 N.W. 19th Lane, Gainesville, Fl 32605. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. RULES:2.1033(b)(4) CIRCUIT DESCRIPTION This is a low power security device transceiver. The TX oscillator is a crystal controlled circuit formed by crystal X4 and transistor Q8. In series with the crystal is the data modulation components consisting of D3, a varactor, and associated resistors and capacitors (R26, 27, 28, C50, 51, 52, and L17). The crystal oscillator is then 9X multiplied and buffered by the circuits around transistor Q7, Finally, the signal is peaked by the L11, TC3 network. After this final tuned circuit, the RF energy is rounted via C35 and the pin diodoe D1 to the antenna. The calculations are shown in the report and the duty cycle was 100%. The receiver was tested and complies with the FCC Rules and regulations Part 15.109. We issued a report and Declaration of Conformity for the Receiver. ANTENNA & GROUND: This unit uses the PCB inductor as the antenna. There is no provision for an external antenna. APPLICANT: SECURITY ASSOCIATES INTERNATIONAL D/B/A J. TECHNOLOGY FCC ID: NNK1TWTX REPORT #: T:\CUS\S\SAI\329Z9\SAI329Z9.RPT PAGE #: 2 APPLICANT: SECURITY ASSOCIATES INTERNATIONAL D/B/A J. TECHNOLOGY FCC ID: NNK1TWTX NAME OF TEST: RADIATION INTERFERENCE RULES PART NO.: 15.231 REQUIREMENTS: Fundamental Field Strength Field Strength of Frequency of Fundamental Harmonics and Spurious MHz dBuV Emissions (dBuV/m @ 3m) 40.66 to 40.70 67.04 47.04 70 to 130 61.94 41.94 130 to 174 61.94 to 71.48 41.94 to 51.48 174 to 260 71.48 51.48 260 to 470 71.48 to 81.94 51.48 to 61.94 470 and above 81.94 61.94 THE LIMIT FOR AVERAGE FIELD STRENGTH dBuV/m FOR THE FUNDAMENTAL FREQUENCY= 81.26 dBuV/m. NO FUNDAMENTAL IN ALLOWED IN …
