NP42424046-001T-96SR UHF Telemetry Transceiver/Modem

SYNTHESIZED UHF TELEMETRY UNIT PART NO. 242-3412-XX0 Second Printing August 1997 Supersedes 001-3412-001 December 1996 Part No. 001-3412-0028-97Printed in U.S.A. SYNTHESIZED UHF TELEMETRY UNIT PART NO. 242-3412-XYZ Copyright 1997 by the Johnson Data Telemetry Corporation. The Johnson Data Telemetry Corporation designs and manufactures radios and radio modems to serve a wide variety of data communication needs. The Johnson Data Telemetry Corporation produces equipment for the fixed data market including SCADA systems for utilities, petrochemical, waste and fresh water management markets and RF boards for OEM applications in the Radio Frequency Data Capture market. In addition, the Johnson Data Telemetry Corporation provides wireless commu- nication solutions to the mobile data market serving public safety, utilities and industrial users. DATA TELEMETRY PRODUCT WARRANTY The manufacturer's warranty statement for this product is available from your product supplier or from the Johnson Data Telemetry Corporation, 299 Johnson Avenue, PO Box 1733, Waseca, MN 56093-0833. Phone (507) 835-8819. WARNING This device complies with Part 15 of the FCC rules and Industry Canada RSS-119, issue 5. Operation is subject to the condi- tion that this device does not cause harmful interference. In addition, changes or modification to this equipment not expressly approved by the Johnson Data Telemetry Corporation could void the user's authority to operate this equipment (FCC rules, 47CFR Part 15.19). DO NOT allow the antenna to come close to or touch, the eyes, face, or any exposed body parts while the radio is transmitting. DO NOT operate the radio near electrical blasting caps or in an explosive atmosphere. DO NOT operate the radio unless all the radio frequency connectors are secure and any open connectors are properly termi- nated. DO NOT allow children to operate transmitter equipped radio equipment. SAFETY INFORMATION Proper operation of this radio will result in user exposure below the Occupational Safety and Health Act and Federal Commu- nication Commission limits. The information in this document is subject to change without notice. ™ Johnson Data Telemetry is a trademark of the Johnson Data Telemetry Corporation. ™ RNET is a trademark of Motorola Inc. 1 TABLE OF CONTENTS 1GENERAL INFORMATION 1.1SCOPE OF MANUAL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 1.2EQUIPMENT DESCRIPTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 DL-3412 WITH LOADER BOARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1 DL-3412 WITH RNET™ MODEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 DL3412 WITH DL3296 MODEM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 DM-3412 SYNTHESIZER PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.3TRANSCEIVER IDENTIFICATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.4ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2 1.5PART NUMBER BREAKDOWN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.6FACTORY CUSTOMER SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.7PRODUCT WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.8REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3 1.9FACTORY RETURNS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4 2INSTALLATION 2.1PRE-INSTALLATION CHECKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 2.2INTERFACING WITH DATA EQUIPMENT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 DM3412 (RF Board) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1 3PROGRAMMING 3.1INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 3.2SYNTHESIZER DATA PROTOCOL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1 D-WORD CALCULATION (24-BITS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 C-WORD CALCULATION (24-BITS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2 B-WORD CALCULATION (24-BITS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3 A0-WORD CALCULATION (24-BITS). . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

T-96H Radio Modem Technical Manual version 0.01 PRELIMINARY The entire contents of this manual and the Radio Service Software described in this manual are copyright 1998 by DATARADIO Inc. Copyright DATARADIO Inc. August 1998 part no.: 120 10504-001 i Table of Contents 1.PRODUCT OVERVIEW................................................................................................................................... 1 1.1 I NTENDED A UDIENCE ....................................................................................................................................... 1 1.2 I NTRODUCTION ................................................................................................................................................. 1 1.3 G ENERAL D ESCRIPTION .................................................................................................................................... 1 1.4 P HYSICAL D ESCRIPTION .................................................................................................................................... 1 1.5 C ONFIGURATION ............................................................................................................................................... 1 1.6 C ATALOG N UMBERS ......................................................................................................................................... 2 1.7 F ACTORY T ECHNICAL S UPPORT ........................................................................................................................ 2 1.8 P RODUCT W ARRANTY ...................................................................................................................................... 2 1.9 R EPLACEMENT P ARTS ....................................................................................................................................... 2 1.9.1Factory Repair ........................................................................................................................................ 2 1.10D IAGNOSTICS AND R EMOTE C OMMANDS ..................................................................................................... 3 1.10.1Addressing .......................................................................................................................................... 3 1.10.2Online Diagnostics ............................................................................................................................. 3 1.10.3Offline Diagnostics ............................................................................................................................. 4 1.10.4Remote Commands ............................................................................................................................. 4 1.11N ETWORK C ONFIGURATION .......................................................................................................................... 4 1.11.1Basic Network ..................................................................................................................................... 4 1.11.2Network Using T-Base ........................................................................................................................ 5 1.11.3Network Using T-Base Repeater......................................................................................................... 5 1.11.4Network Using T-96H for Online Diagnostics.................................................................................... 6 2.FEATURES AND OPERATION ...................................................................................................................... 7 1.1 O VERVIEW ........................................................................................................................................................ 7 2.1 I NTENDED A UDIENCE ....................................................................................................................................... 7 2.2 F RONT P ANEL ................................................................................................................................................... 7 2.2.1LED Indicators........................................................................................................................................ 7 2.3 DTE P ORT I NTERFACE ..................................................................................................................................... 7 2.3.1RS-232 Inteface Signal Levels................................................................................................................. 7 2.3.2Interface Port .......................................................................................................................................... 8 2.3.3Interface Signal Description ................................................................................................................... 8 2.4 C HANNEL S ELECTION ....................................................................................................................................... 9 2.5 O PERATION ....................................................................................................................................................... 9 2.5.1RTS/CTS Timing.................................................................................................................................... 10 2.5.2XTAL mode............................................................................................................................................ 10 2.5.3Extended Turnoff................................................................................................................................... 10 3.ADJUSTMENTS AND MAINTENANCE ..................................................................................................... 11 1.1 O VERVIEW .............................................................................................…

Text truncated - open the document above for the full version.

PHOTOGRAPHS: RULE PART NUMBER:2.983 (g)

FCC LABEL: RULE PART NUMBER:2.983 (f)

TABLE OF CONTENTS LIST APPLICANT: KP ELECTRONICS INC. FCC ID: H78ATS100 TEST REPORT CONTENTS: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTINUED PAGE 3......RF POWER OUTPUT PAGE 4......MODULATION CHARACTERISTICS PAGE 5......OCCUPIED BANDWIDTH PAGE 6......SPURIOUS EMISSIONS AT ANTENNA TERMINALS PAGE 7......FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 8......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 9......FREQUENCY STABILITY PAGE 10-11...TRANSIENT FREQUENCY STABILITY PAGE 12......CERTIFICATION OF TECHNICAL DATA PAGE 13......LIST OF TEST EQUIPMENT EXHIBITS CONTENTS: EXHIBIT 1.........POWER OF ATTORNEY LETTER EXHIBIT 2.........FCC ID LABEL SAMPLE EXHIBIT 3.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 4.........FRONT VIEW EXTERNAL PHOTOGRAPH EXHIBIT 5.........REAR VIEW EXTERNAL PHOTOGRAPH EXHIBIT 6.........COMPONENT SIDE INTERNAL PHOTOGRAPH EXHIBIT 7.........COPPER SIDE INTERNAL PHOTOGRAPH EXHIBIT 8.........BLOCK DIAGRAM EXHIBIT 9A-9D.....PARTS LIST EXHIBIT 10A.......SCHEMATIC - SYNTHESIZER EXHIBIT 10B.......SCHEMATIC - RF TRANSMITTER EXHIBIT 10C.......SCHEMATIC - ENCODER EXHIBIT 10D.......SCHEMATIC - POWER SUPPLY EXHIBIT 11A-11E...USER'S MANUAL EXHIBIT 12........AUDIO FREQUENCY RESPONSE GRAPH EXHIBIT 13........AUDIO INPUT VS DEVIATION GRAPH EXHIBIT 14........AUDIO LOW PASS FILTER GRAPH EXHIBIT 15........OCCUPIED BANDWIDTH CW PLOT EXHIBIT 16........OCCUPIED BANDWIDTH PLOT EXHIBIT 17A-17B...TRANSIENT FREQUENCY RESPONSE PLOTS APPLICANT: KP ELECTRONICS INC. FCC ID: H78ATS100 REPORT #: F:\CUS\K\KP\KP07U8.RPT PAGE: TABLE OF CONTENTS GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.983 (a,b,c) KP ELECTRONICS INC. will sell the MODEL NO. H78ATS100 VHF transmitter in quantity, for use under FCC RULES PART 22 & 90. 2.983 (d) TECHNICAL_DESCRIPTION (1) Type of Emission: 10K0F3E & 10K0F2D For 25KHz 10K0F3E & 10K0F2D For 12.5KHz For 25KHz Bn=2M+2DK M = 3000 D = 2.0KHz (Peak Deviation) K=1 Bn = 2(3.0K) + 2(2.0K)(1) = 6.0K + 4.0K = 10.0K ALLOWED AUTHORIZED BANDWIDTH = 20.00KHz. For 12.5KHz Bn=2M+2DK M = 3000 D = 2.0KHz (Peak Deviation) K=1 Bn = 2(3.0K) + 2(2.0K)(1) = 6.0K + 4.0K = 10.0K ALLOWED AUTHORIZED BANDWIDTH = 11.25KHz. 90.209(b)(5) (2) Frequency Range: 148-174 MHz (3) Power Range and Controls:There are NO user Power controls. (4) Maximum Output Power Rating: 2.0Watts, into a 50 ohm resistive load. (5) DC Voltages and Current into Final Amplifier: POWER INPUT FINAL AMPLIFIER ONLY Vce = 13.2 Volts Ice = 0.51 A. Pin = 6.70 Watts (6) Function of each electron tube or semiconductor device or other active circuit device: APPLICANT: KP ELECTRONICS INC. FCC ID: H78ATS100 REPORT NO.: F:\CUS\K\KP\KP07U8.RPT PAGE #: 1 2.983(d) (7) Complete Circuit Diagrams: The circuit diagram is included as PAGE Exhibit 10A-10D. The block diagram is included as PAGE Exhibit 8. (8) Instruction book. The instruction manual is in cluded as PAGES Exhibit 11A-11D. (9) Tune-up procedure. The tune-up procedure is given in PAGE P/O User Manuel. (10) Description of all circuitry and devices provided for determining and stabilizing frequency is included in the circuit description in the instruction manual. 2.983 (11) Description of any circuits or devices employed for suppression of spurious radiation, for limit- ing modulation, and for limiting power. In addition to the interstage filtering the multi- section low pass filter made up of L13, L14,L15, L16, C96, C89, C97, C90, & C94. Limiting Modulaton: The transmitter audio limiting circuitry is con- tained in the loop filter U6. Limiting Power: There is no provision for limiting power. (12) Digital modulation. This unit does NOT use digi- tal modulation, it uses 900 & 1500Hz in the AFSK transmission of data in addition to the voice. 2.983(e) The data required by 2.985 through 2.997 is sub APPLICANT: KP ELECTRONICS INC. FCC ID: H78ATS100 REPORT NO.: F:\CUS\K\KP\KP07U8.RPT PAGE #: 2 2.985(a) RF_power_output. RF power is measured by connecting a 50 ohm, re- sistive wattmeter to the RF output connector. With a nominal battery voltage of 13.6V, and the trans mitter properly adjusted the RF output measures: POWER HIGH INPUT POWER: (13.2V)(0.51A) = 6.73 Watts OUTPUT POWER: 2.0 Watts Efficiency: 29% /-----------\ /---------\ |Transmitter|---------------------|50 ohm | |under test | |Resistive| \-----------/ |Wattmeter| | \---------/ /-----------\ |Power | |Supply | \-----------/ APPLICANT: KP ELECTRONICS INC. FCC ID: H78ATS100 REPORT NO.: F:\CUS\K\KP\KP07U8.RPT PAGE #: 3 2.987(a) Voice Modulation_characteristics: AUDIO_FREQUENCY_RESPONSE (a) See Exhibit 12. 2.987(a) AUDIO_LOW_PASS_FILTER The audio low pass filter is included and the plot is Exhibit 14. Rules 90.210(b,d, & e) for mobile stations with a low pass filter. 2.987(b) Audio_input_versus_modulation A plot of the audio input versus deviation is shown in Exhibit 13. APPLICANT: KP ELECTRONICS INC. FCC ID: H78ATS100 REPORT NO.: F:\CUS\K\KP\KP07U8.RPT PAGE #: 4 2.989(c) Occupied_bandwidth: 90.210(b,) Data in the plots shows that on any frequency removed from the assigned frequency by more than 50%, but not more than 100%: At least 25dB. On any frequency removed from the assigned frequency by more than 100%, but not more than 250%: At least 35dB. On any frequency removed from the assigned frequency by more than 250%, of the authorized bandwidth: At least 43+log(P)dB. 90.210( d) 12.5KHz channel bandwidth equipment. For transmit- ters de signed to operate with a 12.5KHz channel bandwidth, any emission must be attenuated below the power (P) of the highest emission contained within the authorized bandwidth as follows; (1) On any frequency from the center of the authorized bandwidth f0 to 5.625kHz removed from fP0: Zero dB. (2) On any frequency removed from the center of the authorized bandwidth by a displacement frequency(fd-2.88kHz)dB. (3) On any frequency removed from the center of the authorized bandwidth by a displacement frequency(fd in kHz Log(P) or 70dB, whichever is …

Text truncated - open the document above for the full version.

TRANSISTOR, DIODE, AND IC FUNCTIONS RULE PART NUMBER:2.983 (d)6) DL-3412 TRANSCEIVER Re fe re nce De s.JDT Part #Funct ionJEDEC or Ve ndor Type CR561523-1504-110Antenna switchMMBV3401 CR562523-1504-001Antenna switchMMBV3401 CR591523-1504-016Directional couplerMMBD701LT1 CR592523-1504-016Directional couplerMMBD701LT1 CR701523-1504-023RectifierBAV99LT1 CR851523-5005-022VaractorBB535E7908 CR852523-5005-020VaractorBB515 CR853523-5005-020Deviation level biasBB515 CR854523-5005-022VaractorBB535E7908 CR855523-5005-022VaractorBB535E7908 CR856523-5005-022VaractorBB535E7908 CR901523-5005-022VaractorBB535E7908 Q101576-0013-046Tx enableMUN5213T1 Q102576-0013-032Tx enableMUN5114T1 Q121576-0013-046Rx enableMUN5213T1 Q122576-0013-046Rx enableMUN5213T1 Q123576-0013-032Rx enableMUN2114T1 Q124576-0006-027Soft key up controlPZT2222AT1 Q131576-0013-0465 volt shutdow nMUN5213T1 Q171576-0013-046Pin shiftMUN5213T1 Q172576-0013-032Pin shiftMUN2114T1 Q501576-0003-640RF bufferMSA-2111 Q511576-0003-636RF driverNE85633 Q531576-0006-027Power controlPZT2222AT1 Q701576-0003-634AmplifierMMBT918LT1 Q801576-0013-701Constant voltage sourceMDS1819A-RT1 Q841576-0013-046Pin ShiftMUN5231T1 Q842576-0013-032Pins shiftMUN5114T1 Q850576-0003-651VCONE85619 Q851576-0003-651Cascode ampNE85619 Q852576-0003-651Cascode ampNE85619 Q853576-0003-651AmplifierNE85619 Q901576-0013-701Capacitance multiplierMDS1819A-RT1 U111A544-2020-020Soft key up controlLMC660AIM U111B544-2020-020Soft key up controlLMC660AIM U111C544-2020-020Power controlLMC660AIM U111D544-2020-020Soft key up controlLMC660AIM U131544-2603-093Voltage regulatorTK11900MTL U141544-2603-093Voltage regulatorTK11900MTL U581A544-2019-017V-fwd ampMC33172DT U581B544-2019-017V-rev ampMC33172DT U811544-3954-027SynthesizerSA7025DK-T U521544-4001-063RF power moduleM57721M TRANSISTOR, DIODE, AND IC FUNCTIONS (conti nued) RULE PART NUMBER:2.983 (d)6) HNET MODEM Reference designatorFunctionType CZ1Transient Voltage Suppressor 5.6v, 0805VC080505A150 CZ2Transient Voltage Suppressor 5.6v, 0805VC080505A150 CZ3Transient Voltage Suppressor 14v, 0805VC080514A300 CZ6Transient Voltage Suppressor 14v, 0805VC080514A300 CZ7Transient Voltage Suppressor 14v, 0805VC080514A300 CZ8Transient Voltage Suppressor 14v, 0805VC080514A300 CZ9Transient Voltage Suppressor 14v, 0805VC080514A300 CZ10Transient Voltage Suppressor 14v, 0805VC080514A300 CZ11Transient Voltage Suppressor 14v, 0805VC080514A300 CZ12Transient Voltage Suppressor 14v, 0805VC080514A300 CZ4Transient Voltage Suppressor 5.6v, 0805VC080505A150 CZ5Transient Voltage Suppressor 5.6v, 0805VC080505A150 D1reverse power supply protection1N4001 D2reference settingBAV99LT1 D3TTL input protectionBAV99LT1 D4TTL input protectionBAV99LT1 D5TTL input protectionBAV99LT1 D6negative peak detectorMBD301LT1 D7positive peak detectorMBD301LT1 D8DIODE,ZENER 4.7vBZX84C4V7LT1 DS1Led, Narrow Beam, YellowHLMP-6400-010 DS2Led, Narrow Beam, RedHLMP-6000-010 DS3LED, Narrow Beam, GreenHLMP-6500-010 Q1LED SwitchMMBT3904LT1 Q2LED SwitchMMBT3904LT1 Q3LED SwitchMMBT3904LT1 Q4phase peak shape formatterMMBT3904LT1 Q5phase peak shape formatterMMBT3904LT1 U1RS-232 Driver/Receiver 5vMC145407DW U2Data Set (sync/async) InterfaceMC145428DW U4Undervoltage Sensing CircuitMC33064D U5Microprocessor ,QFP-8068HC711K4FU U6CPLD 64 Macrocell, Digital ModemPZ5064-I12A44 U7Dual , Op AmpLMC6484AIM U8Quad, Op AmpTLC2274I U9Digital PotentiometerAD8402AR50 U10Quad, Op AmpTLC2274I U11Analog Multiplexers/DemultiplexersMC74HC4053D U12Filter, Linear Phase Low PassLTC1069-7 U13Regulator, Micropower VoltageLP2951CD U14Regulator, Micropower VoltageLP2951CD TRANSMITTER TUNE UP PROCEDURE RULE PART NUMBER:2.983 (d)(9) TRANSMITTER TUNE UP PROCEDURE 1. Connect the transceiver to be aligned to a DC power source. A DC current meter capable of measuring at least 2.5 Amps should be connect in line with the DC source. Connect the output of the transceiver through a watt meter and into a 50 ohm dummy load. 2. Load the synthesizer with the center channel frequency. 3. Key the transmitter and make certain that the supply voltage at the RF board is 13.3 VDC. (Do not transmit for extended periods of time. ) 4. Adjust C535 clockwise for 5.0 Watts of output power. 5. Check the power levels on the low and the high frequencies for 5.0 Watts +/- 1 Watt.

CR901 2.1-18.7pF BB535 Q202 NE85633 68pF C206 51 R537 470 R124 68pF C122 PZT2222AT1 Q124 4 1 2 3 5.6k R126 0.01 C123 68pF C124 1 C125 3.6k R125 68pF C813 Q201 MSB1218A 0.01 C210 0.01 C703 0.01 C709 0.01 C706 68pF C707 1M R706 1 C708 0.01 C701 MH104MH105MH103MH102MH101 U111-D MC33174D 14 12 13 68pF C121 10k R123 0.0082 C116 150k R117 U111-B MC33174D 7 5 6 R116 150k 0.01 C115 10k R115 0.1 C114 43K R112 22k R111 68pF C113 EP111 0.01 C111 68pF C112 10k R113 10k R114 U111-A MC33174D 1 3 2 MC33174D U111-E 11 GND 4 PWR Q123 MUN5114T1 100k R127 Q122 MUN5213T1 Q121 MUN5213T1 Q102 MUN5114T1 1k R102 68pF C106 1 C105 0.01 C104 68pF C103 1 C102 68pF C101 Q101 MUN5213T1 68pFC142 1 C141 68pF C146 1 C145 0.01 C144 15k R142 100k R141 0.01 C143 U141 2 CONTROL 5 GND 4 VOUT 1 BYPASS 3 FEEDBACK 6 VIN 15K R134 51K R133 51 R132 68pF C133 1 C132 68pF C136 1 C135 0.01 C134 0.01 C137 U131 2 CONTROL 5 GND 4 VOUT 1 BYPASS 3 FEEDBACK 6 VIN 100k R131 68pF C131 Q131 MUN5213T1 0.01 C702 MBAV99 CR701 100 R701 22k R703 15k R704 Q701 MMBT918 1.5K R702 750 R705 0.01 C704 18 R892 18 R894 18 R893 10k R847 VCO_3474 A801 10 SYNTH_OUT 16 CLV 18 GND_18 17 GND_17 1 OPEN_A 4 GND_4 3 GND_3 5 5.5V 14 5.5P_S 12 PIN_SHIFT 8 GND_8 7 GND_7 6 GND_6 11 MOD_ADJUST 19 GND_19 9 RF_OUT 2 5V_NEG 13 MOD_INPUT 15 OPEN_B 68pF C827 1 C826 220K R827 10k R826 100K R825 68pF C850 0.01 C849 1.5k R843 68pF C848 0.01 C847 Q842 MUN5114T1 68pF C846 0.01 C845 68pF C903 0.01 C902 Q901 MSD1819A 4.7 C901 4.7k R901 Q902 MSD1819A 10K R903 2.2K R902 68pF C844 0.01 C843 10k R841 100 R842 Q841 MUN5213T1 68pF C842 0.01 C841 C172 68pF C171 1 MUN5114T1 Q172 Q171 MUN5213T1 R171 10k MUN5213T1 Q173 R823 100K C837 JIC C836 0.0047 R833 18k C833 0.0047C832 0.1 C831 100pF R832 12k R831 10 C825 0.001 R829 27k R822 4.7k C822 68pF C816 3.9pF L811 39nH C815 3.3pF C812 0.01 C811 0.01 C803 0.01 544-3954-027 U811 SA7025DK 12 GND12 19 TEST 4 GND4 10 AUXIN 7 VCC7 6 _RFIN 18 LOCK 13 PHI 14 PHP 17 RF 11 PHA 1 CLOCK 2 DATA 8 REF_IN 9 RA 15 VCC15 5 RFIN 3 STROBE 20 VCC20 16 RN C806 0.01 R821 100k C821 1 R817 4.7k R816 4.7k R815 4.7k R814 4.7k R813 4.7k R812 4.7k R811 4.7k C805 68pF C804 0.01 R802 20 MSD1819A Q801 R804 10k R803 4.7k R801 10k Y801 17.5MHz 18 GND18 19 GND19 15 GND15 17 GND17 20 GND20 14 VCC 7 GND7 1 VC_MOD_IN 16 GND16 8 RF_OUT C802 68pF C801 0.01 0.01 C279 33pF C564 100 R561 MMBV3401 35V CR562 1.5pF C563 8nH L561 68pF C562 J501 1 47k R565 1pF C561 68pF C544 0.01 C543 10pF C542 22pF C541 1uH L555 MMBV3401 35V CR561 13pF C556 18.5nH L554 11pF C555 35.5nH L553 7.5pF C554 35.5nH L552 10pF C553 18.5nH L551 8.2pF C552 68pF C551 MH534MH533MH532MH531 MMBD701LT1 50V CR592 51 R591 51 R593 JIC C596 JIC C595 0.01 C594 1k R594 0.01 C592 1k R592 27pF C593 27pF C591 MMBD701LT1 50V CR591 R585 JIC 10k R586 JIC C584 10 R584 MC33172D U581-B 7 5 6 JIC R582 10k R583 JIC C583 10 R581 U581-A MC33172D 1 3 2 MC14053B U913-A 14Z 13Y1 11 S 12Y0 MC14053B U913-C 4Z 3Y1 9 S 5Y0 MC14053B U913-B 15Z 1Y1 10 S 2Y0 MC14053B U913-D 6 _E 16 VDD 7 VEE 8 VSS U912 14 Q4 13 Q5 11 Q7 10 _QS 9 QS 4 Q0 5 Q1 6 Q2 7 Q3 3 CLK 1 STR 15 OE 8 GND 2 SER 12 Q6 16 VCC 100K R535 MC33172D U581-C 4 GND 8 PWR 10k R574 68pF C581 10k R573 100K R534 JIC C582 0.01 C536 20K R536 U111-C MC33174D 8 10 9 470 R533 68pFC535 EP501 3.9pF C512 18nH L511 1.8k R512 470pF C515 560 R514 Q511 NE85633 100 R515 68pF C519 68pF C517 1uH L512 C516 68pF 10 R513 68pF C514 0.01 C513 1.8pF C518 18nH L513 M57721 U521 2 VCC1 3 VBB 1 RF_IN 5 RF_OUT 4 VCC2 68pF C571 1 C570 4.7k R511 68pF C511 1 C572 68pF C573 1 C574 68pF C575 EP533 EP534 EP532 68pF C531 120 R122 120 R121 68pF C533 68pF C534 68pF C532 PZT2222AT1 Q531 4 1 2 3 68pF C524 0.01 C523 EP531 1 C522 68pF C521 68pF C502 470 R504R505 470 68pF C504 C503 68pF 22pF C505 10pF C506 0.01 C507C508 68pF L501 1uH Q501 MSA2111 42 31 68pF C501 150 R503 39 R502 150 R501 68pF C163 68pF C162 68pF C161 68pF C160 68pF C159 68pF C158 68pF C157 68pF C156 68pF C155 68pF C154 68pF C153 68pF C152 68pF C151 J201 DIAG14 J201 RX_OUT13 J201 RSSI12 J201 DIAG_EN11 J201 CLOCK10 J201 DATA9 J201 SYNTH_ENABLE 8 J201 LOCK_DETECT 7 J201 MOD_IN6 5V_SHUTDOWN J201 5 J201 RX_EN4 J201 TX_EN3 J201 13.6_V2 GROUND1 68pF C301 8.2pF C302 15nH L301 5.6pF C306 JIC C309 68pF C305 2.2K R305 18nH L302 68pF C307 270 R306 Q301 NE85633 1k R304 68pF C304 3.6k R303 10k R302 330 R301 1 C303 6.8pF C406 0.10uH L402 0.1 C409 1uH L403 0.01 C408 82pF C407 82pF C405 0.01 C404 1.2k R404 0.01 C403 0.10uH L401 Q401 MMBT918 0.01 C402 10k R403 39k R402 10 R401 0.01 C401 R266 10 330 R275 R263 68K C261 68pF R262 27K R265 10K C262 0.1 R264 33K LMC7101 U261 4 5 GND 2 PWR3 1 100 R261 C267 0.01 C266 68pF C264 47 C265 0.01 C268 0.01 680uH L253 R255 39k C277 10pF 0.01 C276 0.01 C275 0.01 C273 450 kHz Z252 20 kHz COM OUT IN 3.3k R271 2.4K R272 0.01 C272 0.01 C271 450 kHz Z251 20 kHz COM OUT IN U241 SA676DK 2 RF_IN- 14 LIMITER_IN 9 RSSI_FB 4 OSCB 3 OSCE 13 LIMITER_DEC2 17 IF_AMP_DEC1 18 IF_AMP_IN 19 IF_AMP_DEC2 20 MIXER_OUT 5 RSSI_OUT 7 AUDIO_FB 8 AUDIO_OUT 10 QUAD_IN 16 IF_AMP_OUT 12 LIMITER_DEC1 1 RF_IN+ 11 LIMITER_OUT 6 VCC6 15 GND15 0.01 C234 0.01 C232 0.01 C235 680 R235 1K R232 Q231 MMBT918 10k R234 30K R233 330 R231 68pF C231 0.82uH L221 10pF C233 39pF C223 1uH L222 52.95MHz Z222 2 13 3.3pF C222C221 1.5-5pF 52.95MHz Z221 2 13 68pF C203 0.01 C204 3.9pF C214 0.01 C212 1.8k R212 1uH L211 10 R211 0.01 C211 Q211 G DS 330 R213 0.01 C213 MOT-1-4 U211 1LO 562 4 IF 3RF JIC R208 68pF C215 JIC R206 459MHz Z202 811126516 17 1591718143101342 GND 0.01 C202 68pF C201 22pF C208 5.6pF C209 3.9pFC207 180 R205 10nH L202 MMBD6050 70V CR231 3k R202 10k R203 100 R201 8.2k R204 12nH L201 459MHz Z201 811126516 17 1591718143101342 GND 68pF C205 1K R917 0.01 C912 Q911 2N3904 47K R916 47K R915 10K R914 U911 13 LDAC 8 LOAD 12 DACA 7 CLK 10 DACC 11 DACB 14 VCC 2 REFA 1 GND 9 DACD 3 REFB 5 REFD 6 DATA 4 REFC 0.01 C911 10k R912 10k R911 6.3_V 9.6REG 9.6REG 9.6REG 9.6REG 17.5_MHZ 17.5_MHZ 13.6_SW 13.6_SW 9.0TX 9.0TX 9.0TX 9.0TX SYNTH_ENABLE SYNTH_ENABLE LOCK_DETECT LOCK_DETECT MOD_IN MOD_IN 5V_SHUTDOWN …

Text truncated - open the document above for the full version.

A Rev R9 47K R8 47K R11 100K R7 47K R12 100K R14 47K R22 220 R1647K R1947K R23 1K C14 22pF C15 22pF SW1A LD04H0SK 18 C10104 C21 104 C20 104 SW1D LD04H0SK 45 C5 104 SW1C LD04H0SK 36 SW1B LD04H0SK 27 C7 104 C16 104 R20 47K C6 104 C18 104 C17 104 D2 BAV99LT1 1 3 U3 AD22100AR V+ 1 VO 2 GND 4 R6 10K R3 1K R5 10K DS3 GREEN 21 Q3 MMBT3904 3 1 2 R18 10M Y1 9.8304MHZ 1 4 R13 470K R10 100K Q2 MMBT3904 3 1 2 DS1 YELLOW 21 R1 1K R2 1K R4 10K Q1 MMBT3904 3 1 2 DS2 RED 21 R21 10K R15 47K U1 145407 DO1 16 DO2 14 DO3 12 DI1 15 DI2 13 DI3 11 RX1 5 RX2 7 RX3 9 TX1 6 TX2 8 TX3 10 VCC 19 VDD 17 VSS 4 GND 2 C1+ 20 C1- 18 C2+ 1 C2- 3 C19 106 + C12 106 + C9 106 + C4 106 + C8 106 + C3 106 + U2 145428 TXS 1 TXD 2 RXD 11 RXS 12 DC 15 DIE 14 DOE 17 DCO 18 DCI 13 RST 19 DL 3 SB 9 CM 16 BR3 8 BR2 7 BR1 6 BC 5 BRCK 4 U5 68HC711K4FU 332-90807-100 XT 74 EX 73 RESET 75 IRQ 61 XIRQ 30 MODB 76 PA0 11 PA1 10 PA2 9 PE0 49 PE1 48 PE2 47 PE3 46 PE4 45 PE5 44 PE6 43 PE7 42 VRH 51 VRL 50 PA3 8 PA4 7 PA5 6 PA6 5 PA7 4 PB0 21 PB1 20 PB2 19 PB3 18 PB4 17 PB5 16 PB6 15 PB7 14 PC0 62 PC1 63 PC2 64 PC3 65 PC4 66 PC5 67 PC6 68 PC7 69 PD0 78 PD1 79 PD2 80 PD3 1 PD4 2 PD5 3 MODA 77 E 72 PG6 34 PG7 33 VSS 70 VSS 13 VSS 32 AVSS 52 AVDD 41 VDD 31 VDD 12 VDD 71 PG5 35 PG4 36 PG3 37 PG2 38 PG1 39 PG0 40 PH7 29 PH6 28 PH5 27 PH4 26 PH3 25 PH2 24 PH1 23 PH0 22 PF0 60 PF1 59 PF2 58 PF3 57 PF4 56 PF5 55 PF6 54 PF7 53 D3 BAV99LT1 1 2 3 D4 BAV99LT1 1 2 3 D5 BAV99LT1 1 2 3 C11 104 TP1 TP2 TP3 R17 4.7K U4 MC33064D IN 2 RST 1 GND 4 R57 1K R60 18K U6 PZ5064 332-90804-000 IN_1 11 IN_2 13 IN_3 16 A 18 B 19 C 28 F 25 INV 26 TX_/RX 27 TXD 7 TONE_EN 31 TST_TONE 29 G 32 CK_IN 43 RX…
